U-Line H-3023 User manual

0514 IH -3023PAGE 1 OF 2
H-3023, H-3024
H-3025, H-3026
H-3027
WALL-MOUNT
WIRE SHELVING
Step Ladder
(Optional)
TOOLS NEEDED
Phillips
Screwdriver
Cordless Drill
(3/16" Drill Bit)
Tape Measure
PARTS
Shelf Bracket x 4
Bolt x 4
Mounting Bracket x 4
Shelf x 2
Center Mounting Bracket x 2
Shelf Support x 4 Anchor x 12
Post x 2
Screw x 12
1. Mounting brackets should be spaced 1½" shorter
than the width of the shelf. Do this by measuring
from the center of one mounting bracket to the
center of the other. Drill top mounting brackets to
the wall using (2) anchors and (2) screws for each
mounting bracket. (See Figure 1)
2. Align center mounting brackets about 17 inches
directly below the top mounting bracket, so it will be
at the midpoint of the posts. Mount center mounting
brackets using (2) anchors and (2) screws for each
center mounting bracket. (See Figure 2)
INSTRUCTIONS
Figure 1
Figure 2
Mounting
Bracket
17"
Center Mounting
Bracket

0514 IH -3023PAGE 2 OF 2
3. Slide top shelf brackets onto posts. Fasten shelf
supports at the desired height of top shelf on both
posts. Push shelf brackets down upon the shelf
supports. (See Figure 3)
4. Slide the bottom of posts through the center
mounting bracket. Then, fasten top of posts
to top mounting brackets using bolts.
(See Figure 4)
5. Slide bottom shelf brackets onto posts. Then fasten
shelf supports at the desired height of the bottom
shelf. Push shelf brackets down upon the shelf
supports. (See Figure 5)
6. Drill bottom mounting brackets to the wall using (2)
anchors and (2) screws for each mounting bracket.
Use bolts to fasten posts to bottom mounting bracket.
(See Figure 6)
7. Place shelves on top of shelf brackets. (See Figure 7)
Figure 6
Figure 7
Figure 3
Figure 4
Figure 5
INSTRUCTIONS CONTINUED
