PAGE 1 OF 2 0615 IH-1479
πH-1479
CONVERTIBLE JR
ALUMINUM HAND TRUCK
WITH SOLID RUBBER WHEELS
1-800-295-5510
uline.com
TOOLS NEEDED
10mm Wrench 13mm Wrench
Pliers Hammer
PARTS
REF. QTY. DESCRIPTION
12 Handle with Bracket
2 4 6mm Hex Washer Head Bolt
3 4 6mm Locknut
4 1 Extended Handle
5 1 Frame
6 2 Cotter Pin
7 2 Washer
8 2 Spacer
9 1 Axle
10 2Round Pin
11 2Frame Reinforcement
12 48mm Locknut
13 2Axle Support
14 4 8mm Bolt
15 2Wheel
16 1Nose Plate
4
3
2
21
6
10
16 15
6
14
13
12
11
7
14
8
9
13
15
11
75
8

PAGE 2 OF 2 0615 IH-1479
Round
Pin Axle
Hex
Washer
Head
Bolts
Locknuts
Handle With
Bracket
NOTE: Do not use air or power tools.
ATTACH HANDLE
1. Align holes in handles with brackets and extended
handle. Insert four hex washer head bolts through
handles with brackets and extended handle and
secure with locknuts. (See Figure 1)
ATTACH NOSE PLATE AND AXLE SUPPORTS
1. Position frame reinforcements against bottom frame
rail. (See Figure 2a) Slide nose plate into channel
on frame reinforcement, keeping bolt holes aligned.
(See Figure 2)
2. Align axle support with outside rail of frame.
(See Figure 2)
3. Insert four 8mm bolts through the axle supports,
frame, frame reinforcements and nose plate. Secure
with locknuts but DO NOT tighten. (See Figure 2)
ATTACH AXLE AND WHEELS
1. Lay hand truck down on front so axle supports face
upwards. (See Figure 3)
2. Insert axle through holes in axle supports. Align holes
in axle with grooves on inside of the axle supports.
Use a hammer to tap in the round pins. (See Figure 3a)
3. Slide a spacer onto each end of the axle. Slide a
wheel onto each end of the axle. Slide a washer
onto each end of the axle. (See Figure 4)
4. Insert a cotter pin through the holes in each end
of the axle. Bend cotter pins using pliers to secure
wheels. Wheels should spin freely. (See Figure 4)
5. Tighten all locknuts.
ASSEMBLY
Figure 3
Figure 4
Frame
Frame
Reinforcements
πCHICAGO • ATLANTA • DALLAS • LOS ANGELES • MINNEAPOLIS • NYC/PHILA • SEATTLE • MEXICO • CANADA
1-800-295-5510
uline.com
Figure 2
Figure 1
Figure 2a
Figure 3a
