UFO IONIC Specification sheet

PRODUCT USER GUIDE
Ionic Track Lighting System
PLEASE READ THIS USER GUIDE BEFORE INSTALLING, OPERATING
OR PERFORMING MAINTENANCE ON THE LIGHTING SYSTEM
Rev: C2
360312

INTRODUCTION
IONIC USER GUIDE
2
Thank you for purchasing this UFO Ionic lighting system.
Please read these instructions fully before performing any installation, operation or
maintenance on the system and before connecting your Ionic lighting system to the electrical
mains. Please keep this manual for future reference.
The UFO Ionic is a fully configurable magnetic track lighting system which has been specifically
designed for ease-of-use and many installation environments.
IMPORTANT - The UFO Ionic extrusions and tracks are ordered cut to length from UFO and
cannot be cut or modified on site. Any attempt to cut or modify the extrusions and tracks will
invalidate warranty for the complete UFO Ionic installation.
Ionic spotlights are available in a choice of 2700k, 3000K, and 4000K colour temperatures. These
spot lights are dimmable locally using the dimmer controls on the fittings or globally using a
UFO supplied dimmer/driver system.
Ionic spotlights operate on a constant voltage low voltage supply. Constant current and
constant voltage LEDs cannot be intermixed on the same driver. Please refer to the specific
section within this manual for connection guidance.
WARNING – The Ionic system operates on 12V DC only. Connecting these fittings to a driver with
excessive voltage output will result in catastrophic damage to the LED devices within the
fittings. Always check the output voltage of the driver to ensure correct output voltage prior to
powering up the system.
The Ionic system is suitable for indoor/dry areas only and must not be installed in damp or wet
conditions.
IMPORTANT
THIS PRODUCT MUST BE INSTALLED IN ACCORDANCE WITH THE APPLICABLE INSTALLATION
CODE BY A PERSON FAMILIAR WITH THE CONSTRUCTION AND OPERATION OF THE PRODUCT,
ITS COMPONENT PARTS AND THE HAZARDS INVOLVED.
EXTERNAL WIRES
To allow for full articulation of the Ionic
snoot, there are 2 low voltage wires
connecting it to the fitting body. Please
ensure these wires are not twisted around
the neck of the snoot. Applying too much
force to these wires could cause
irreparable damage to the fitting.

COMPONENTS
3
UFO LIGHTING
SPOTLIGHT FITTINGS OVERVIEW
There are 3 dierent spotlight fittings available in the Ionic range.
IONIC SX FITTING IONIC MX FITTING IONIC LX FITTING
IONIC SX IONIC MX IONIC LX
LED Type Osram Oslon Square
LED Life (L70,B10) >54,000 hours
Power Consumpon 1.5W 2.5W 3.0W
Colour Temp. 2700K / 3000K / 4000K
CRI >95
Lumen Output 64lm 132lm 178lm
Luminous Efficacy 35lm/W 49lm/W 52lm/W
Available Opcs
16° / 23° / 36°
45° x 20°
20° x 50°
61° / 80°
13.5° / 19° / 28°
Using an adaptor we can also
fit the SX range.
A focusable snoot is also
available
13.5° / 19° / 28°
Rotaon 360°
Tilt 77° 70° 65°
Securing Method Magnec
Material Aluminium
Weight 29g 64g 134g
Operang Env. Indoor / Dry
Finishes Anodised black or silver. Custom finish on request
Each fing is equipped with a local dimming control shown as a circle in above diagrams.

COMPONENTS
IONIC USER GUIDE
4
TRACK OVERVIEW
Ionic track is manufactured from aluminium. Supplied as standard in either anodised black or
aluminium. Extrusion can be supplied in lengths up to 2800mm. In standard systems the ends
of the track are terminated by a power in connector at one end and an end cap at the other.
IONIC TRACK IS 9MM TALL
IONIC TRACK IS 20MM WIDE
LOCAL DIMMING CONTROLS
Independent local dimming is available on all systems irrespective of driver/interface option
specified. Dimming of each individual fitting is controlled by a recessed potentiometer on the
body of each fitting.
Use a 2mm flat bladed
screwdriver to control
dimming level

COMPONENTS
5
UFO LIGHTING
CONTROL OVERVIEW
We can supply the Ionic system in global dimming and non-dimming versions. Note that all
ionic spotlight fittings are locally dimmable via a potentiometer on the fitting body. This works
independently of driver type and is available whichever global option is specified.
GLOBAL DIMMER /DRIVER
INTERFACE
SPLITTER BOX
Provides global dimming to all fittings installed on between 1 & 4 tracks.
No global dimming. Suitable for use with 1 track.
No global dimming. Two versions available, 4-way and 6-way.
Dimming control knob
Red Power Indicator
Green output voltage/global
dimming status indicator
Dimensions:
4 way splitter box:
125mm x 50mm x 25mm
6 way splitter box:
145mm x 66mm x 40mm
(dimensions include mounting
flange)
Dimensions:
97mm x 40mm x 20mm
(dimensions include mounting
flange)
Dimensions:
195mm x 90mm x 34mm
Red Power Indicator
Red Power Indicator

INSTALLATION
IONIC USER GUIDE
6
CONNECTION - FOR GLOBAL DIMMING SYSTEM (1 TO 4TRACKS)
CONNECTION - FOR NON DIMMING SYSTEM (1 TRACK)

INSTALLATION
7
UFO LIGHTING
CONNECTION - FOR NON DIMMING SYSTEM (2 - 6 TRACKS)
There are 3 steps required to connect up an Ionic system. These are broadly the same
irrespective of whether you have a dimming or non dimming system.
THE SPOTLIGHT FITTINGS
First, the spotlight fittings should be fitted to the track. The fittings are held in place by magnetic
attraction and they are polarity agnostic so can be fitted either way round. Ensure that the local
dimming control located on each fitting is turned fully clockwise. We recommend using a 2mm
flat bladed screwdriver for this.
THE 12VPOWER INPUT
The 12V power connector from the power supply unit should then be connected to the global
dimming driver, the splitter or the interface depending on the system specified.
THE MAINS POWER CONNECTION
Finally the IEC cable can be connected to the power supply unit and then plugged into the
mains supply.
All the spotlights should now illuminate at full brightness. If this is not the case, consult the
troubleshooting section further on in this user guide.

INSTALLATION
IONIC USER GUIDE
8
ELECTRICAL INFORMATION
Ionic spotlight fittings can be added, removed and moved between tracks as long as the overall
power capacity of the connected power supply unit is not exceeded.
The following tables show the most common configurations of Ionic PSUs / and manual
dimmer and highlight the maximum number of fittings that should be connected for each.
WARNING
Connecting too many Ionic spotlight fittings to a driver, interface or splitter causing excessive
load, or using an underrated 12V PSU, will result in the system shutting down and may cause
damage to the driver circuit.
Always check the maximum output power of the fittings and ensure that based on the
maximum load of the PSU, a suitable number of fittings are connected (see above), and a
correctly rated PSU for the fittings load is selected, prior to powering up the system.
IONIC with Interface and PSU
IONIC SX IONIC MX IONIC LX
Power Consumpon 1.5W 2.5W 3.0W
Max Fings (40W PSU) 25 15 12
Max Fings (60W PSU) 35 21 17
Note that the maximum number of fittings may need to be reduced if very long cable lengths
are specified - this is due to voltage drop over the cables length.
IONIC with Manual Dimming Driver
IONIC SX IONIC MX IONIC LX
Power Consumpon 1.5W 2.5W 3.0W
Max Fings 12 8 7

INSTALLATION
9
UFO LIGHTING
MOUNTING OPTIONS OVERVIEW
There are 4 surface mounting options for Ionic track - C-clips, corner mounting feet, straight
magnetic brackets and 45° magnetic brackets. If a recessed mount is required, a channel can be
cut to allow the track to be fitted.
MOUNTING WITH C-CLIPS
Ionic C-clips are suitable for mounting straight lengths of track to a solid surface. We
recommend a C-clip is placed approximately every 500mm along the track length as well as at
either end.
MOUNTING WITH CORNER FEET
Corner mounting feet are primarily used for mounting vertical lengths of track in the corners of
a glass display case. For very short track lengths, one foot on the base is suitable, however most
installations require a foot at both the top and bottom of the track.
1
2
3
1
2
3

INSTALLATION
IONIC USER GUIDE
10
MOUNTING WITH MAGNETIC CLIPS
There are 2 dierent type of magnetic clips available - straight and 45°. Both are suitable for
mounting lengths of track onto a solid magnetic/metallic surface. We recommend a clip is
placed approximately every 500mm along the track length as well as at either end.
1
2
3
1
2
3

ACCESSORIES
11
UFO LIGHTING
ACCESSORIES OVERVIEW
We have a range of accessories for all 3 of the spotlight types. Fitting is as shown below and
removal is the reverse process.
Note that the instructions are shown for the SX spotlight however the MX and LX accessories are
installed using the same procedure.
Accessory Cap
fitted on top of
the snoot.
Secured by the
o’ring.
Ionic SX Fitting with
Can be push
fitted to
standard or
extended snoot.
If required, use slight
screw on motion to
help with push-fit.
Accessory Cap
fitted with
either
honeycomb or
diffuser lens.
DIFFUSER, HONEYCOMB &COLOUR FILTER (SX, MX &LX MODELS)
Colour filter sits
on top of lens
(unscrew snoot
and fit)

ACCESSORIES
IONIC USER GUIDE
12
EXTENDED AND DIRECTIONAL SNOOTS (SX, MX &LX MODELS)
Extended Snoot
Fitted by
unscrewing the
standard snoot
and replacing
with this one.
Angled Snoot
push-fits on top
of the standard
or extended
snoot.
Angled Snoot
Fitted in place
and secured by
the o’ring.
If required, use slight
screw on motion to
help with push-fit.
FOCUSABLE SNOOT (MX MODELS ONLY)
Focusable Snoot
Fitted by
unscrewing the
standard snoot
and replacing
with this one.

TROUBLESHOOTING
13
UFO LIGHTING
MAINTENANCE LOG
Date Maintenance Undertaken
Note: A record of all maintenance MUST be kept in the table above, indicating what maintenance
was undertaken and when. This MUST be dated for warranty purposes.

TROUBLESHOOTING
IONIC USER GUIDE
14
System is dead.
Power LED on interface / splitter / driver is not lit
and no light output from Ionic light fittings
Mains supply o or
disconnected from PSU Check supply and reinstate
Loose / damaged connector(s)
or faulty cable
Check all connectors and cables
from mains to track for damage
or other faults.
PSU failed – check output with
DVM Replace PSU
Track(s) being shorted out by
bad connection or debris on
track itself
Power down system and check
for short circuits using DVM.
Ensure tracks are clear of debris
One track dead – not powering light fittings – all
other tracks okay (Be sure to try known working
light fittings on aected track)
Loose or faulty connection or
faulty cable from interface /
splitter / driver to aected track
Check connections and
reconnect/repair as required.
Replace connection cable if
damaged
Faulty track Replace aected track
Light fittings on tracks flash on/o steadily PSU capacity has been
exceeded
Remove some light fittings or, if
40W PSU is being used,
upgrading to 60W PSU will
provide extra capacity.
See Connections page for
further details.

NOTES
15
UFO LIGHTING



DESIGN SPECIFY BUILD INSTALL
United Kingdom •United States •Germany •Europe •UAE
UFO Licht GmbH
Andreasstraße 20
93059 Regensburg \Deutschland
[phone]
www.ufo-licht.de
Universal Fiber Optics USA LLC
1749 Northgate Blvd
Sarasota \ FL34234 \USA
941-343-8115
www.fiberopticlighting.com
Universal Fibre Optics Ltd
Home Place \Coldstream
TD12 4DT \UK
[phone]
www.ufo.lighting
