UFO MicroLED 1000P Specification sheet

PRODUCT USER GUIDE
M croLED 1000P L ght Source
PLEASE READ THIS USER GUIDE BEFORE INSTALLING, OPERATING
OR PERFORMING MAINTENANCE ON THE LIGHT SOURCE UNIT
E357731
Rev: C2

INTRODUCTION
MICROLED 1000P USER GUIDE
2
Thank you for purchasing this UFO light source/lu inaire.
To ensure that the light source is set up opti ally and gives a long service life, please read this
user guide before installing, operating or perfor ing any aintenance on the unit.
Please keep this User Guide for future reference. This User Guide is laid out in three sections
Installation -details on how to connect your lu inaire
O eration - details how to progra e and set up your lu inaire
Maintenance - aintenance log, troubleshooting guide, technical specification
MODELS COVERED BY THIS USER GUIDE
UFO MIC1000P
IMPORTANT
This product ust be installed in accordance with the applicable installation code, by a person
fa iliar with the construction and operation of the product, and the hazards involved.
These light sources are not ains di able.
The LED array in this light source is not replaceable. When it reaches end of life the whole unit
ust be replaced.
Ty e Y Attachment: If the external flexible cable or cord of this lu inaire or associated
PSU/driver is da aged, it shall be exclusively replaced by the anufacturer or his service agent
or a si ilar qualified person to avoid a hazard.
Location: Do not locate this light source closer than 200 fro any fla able surface.
Clearance / Ventilation: It is i perative that a gap of 200 is le around the unit. This is to
allow air to circulate and prevent overheating. The location ust have free ventilation and ust
not have an a bient te perature higher than that specified for the lu inaire.
Mounting: This lu inaire co es with an integral ounting plate for securing the unit to a
vertical or horizontal surface. Refer to the instruction sheet supplied with the plate.
Warning: Never look directly at the lu inaire through the fibre port of the light source.
Warning: The lu inaire should be positioned so that prolonged staring into the
lu inaire at a distance closer than 2.7 etres is not expected.

MOUNTING
This lu inaire is powered by a 12V Power Supply Unit or 12V Constant Voltage Driver. Re ove
the PSU/driver fro its box.
Power supplies are available to suit UK, European and USA power outlets. The UK odel is
shown below.
POWER SUPPLY REQUIREMENTS
Plug the jack plug into the socket in the back of the light source, and the unit is now ready for
connection.
INSTALLATION
3
UFO LIGHTING
This lu inaire supplied with a separate ounting plate. If using the ounting plate refer to the
fitting instructions supplied with it.

There are 2 connections required - the fibre port and the ains supply. The fibre port should be
connected first. Connect and secure the fibre optic connector into the front of the unit and
secure using the M5 locking screw.
Plug the ains plug into the electrical supply socket. Switch on the power, the LED indicator
will illu inate, and the light source will start up auto atically. If no light is produced consult
the troubleshooting section of this anual.
Note that these light sources are not ains di able.
CONNECTION
The light source has 2 colour cycles, each with 3 different speed settings, the colours are
detailed in the table below:
OPERATION
Cycle Colour 1 Colour 2 Colour 3 Colour 4 Colour 5 Colour 6 Colour 7
1 W ite Red Orange Jade Green Cyan Blue
2 Red Orange Jade Green Cyan Blue W ite
The light source is controlled using the 2 push buttons on the rear of the unit.
The upper button stops and starts the colour cycle.
The lower button is used to select the cycle speed as follows:
Push the lower button repeatedly until the colour white is displayed. The light source is now in
Cycle 1 Speed A as detailed in the table below. Each push reduces the speed. On the third push,
the colour red will be displayed. The light source is now in Cycle 2 Speed A.
At any ti e the cycle can be stopped on a colour and started again using the upper push
button.
Cycle Speed A - Fastest Speed B - Slower Speed C - Slowest
1 (W ite Start) Pus once Pus once Pus once
2 (Red Start) Pus once Pus once Pus once
OPERATION
MICROLED 1000P USER GUIDE
4

Note: please co plete relevant troubleshooting procedures before returning the unit to us for
further investigation.
Problem Possible Cause(s) Remedy
Unit is dead -
LED power
indicator is not
illuminated
Mains supply off C eck supply and reinstate
Loose mains plugs C eck plugs
PSU failed Replace PSU
Unit is dead - no
lig t output but
LED power
indicator is sll
illuminated
LED array failure Replace Lig t Source
Poor lig t
output on fibre
Unit needs cleaning
Carefully clean LED Lens
wit dry clot
Clean fibre common end
Fibre port connector not
plugged in correctly
Ensure plugged in correctly
and secured wit locking
screw
Staonary on
one colour
Upper buon as been
pressed Press upper buon once
LED driver as failed Replace Lig t Source
Colour cycle
cannot be
stopped
LED driver as failed Replace Lig t Source
TROUBLESHOOTING
5
UFO LIGHTING

MAINTENANCE LOG
Date Maintenance Undertaken
Note: a record of all aintenance MUST be kept in the table above, indicating what
aintenance was undertaken and when. This MUST be dated for warranty purposes.
MAINTENANCE
MICROLED 1000P USER GUIDE
6

TECHNICAL SPECIFICATION
7
UFO LIGHTING
Port connector size 30mm diameter
Fibre type Glass / PMMA
Material/Finis ABS (black, silver or w ite)
Dimensions (L x W x H) 132mm (5.2”) x 98mm (3.9”) x 67mm (2.6”)
Weig t 0.3kg
Operang Environment Indoor use - IP20
Min Ambient Temp. -10°C
Max Ambient Temp. +45°C
LED Array Type RGBW
LED Array Power 2-5W
LED Array Model Cree XLamp MC-E
LED Array Life (L70, B10) > 50,000 ours @ 25°C
Wavelengt and
Luminous Flux
Red: 625nm / 45lm
Green: 530nm / 93lm
Blue: 460nm / 12lm
W ite: 3500K / 120lm
Colour C ange
Funconality Pus buon manual colour c ange
Supply Voltage 90-264Vac
Mains Running Current 0.03A @ 240Vac
Mains Voltage VA rang 8VA
External PSU Type Power Pax, 12V, 2A, 24W



