urmet domus Miro Instruction Manual

DS 1139-004 LBT 20347
Mod.
1139
CITOFONO VIVAVOCE IP
IP HAND-FREE DOOR PHONE
INTERPHONE MAINS-LIBRES IP
INTERFONO MANOS LIBRES IP
SPRECHANLAGE MIT FREISPRECHSYSTEM IP
IP HANDSFREE DEURTELEFOON
Sch./Ref.1139/3
LIBRETTO UTENTE
USER HANDBOOK
NOTICE UTILISATEUR
MANUAL DEL USUARIO
BENUTZERHANDBUCH
GEBRUIKSHANDLEIDING

7
DS1139-004
ENGLISH
INDEX
1. DESCRIPTION OF COMPONENTS............................................................................................................ 7
1.1. INDICATOR LEDS ............................................................................................................................. 8
1.2. BUTTON FUNCTIONS ...................................................................................................................... 8
2. FEATURES ................................................................................................................................................. 8
2.1. CALL RECEPTION ............................................................................................................................ 8
2.2. ANSWERING THE CALL ................................................................................................................... 9
2.3. DOOR OPENER DURING CALL........................................................................................................ 9
2.4. FLOOR CALL..................................................................................................................................... 9
2.5. CALLING THE SWITCHBOARD ........................................................................................................ 9
2.6. INTERCOM CALL ............................................................................................................................. 9
2.7. CALL TONE SELECTION .................................................................................................................. 9
2.8. ADJUSTING THE CALL VOLUME................................................................................................... 10
2.9. PANIC ALARM ................................................................................................................................ 10
2.10. AUTOMATIC DOOR OPENER......................................................................................................... 10
3. USER DATA RESET.................................................................................................................................. 11
4. REBOOTING THE DEVICE ....................................................................................................................... 11
The Ref. 1139/3 is an IP device dedicated exclusively to the IPerVoice system.
1. DESCRIPTION OF COMPONENTS
1
6
10
11
9
8
7
2
3
4
5
1. Microphone
2. Button see button function table
3. Button see button function table
4. Button to connect to Yokis devices
5. Button to connect to Yokis devices
6. Multicolour indicator LED
7. Call and conversation speaker
8. Button to switch on audio or end the current conversation
9. Green LED under the button
10. Door opener button
11. Green LED under the button

8DS1139-004
1.1. INDICATOR LEDS
The functions of the components listed in the paragraph above are shown in detail below.
6. Multicolour indicator LED
FUNCTIONS
Slowly blinking yellow: programming state on
Fast green blinking: confirm pressing of the buttons or
Slow red blinking: ringer mute
Slow green blinking: automatic door opener active
9. Green LED under the button
On steady: call in progress
On blinking: conversation ongoing
11. Green LED under the button
on blinking (max. 3 seconds): door opener confirmation after pressing button
1.2. BUTTON FUNCTIONS
State
Button
STAND-BY
WAITING
FOR
PICK-UP
(RECEIVING
CALL)
DURING
AUDIO
OPERATION
IN STAND-BY
AND ONLY
AFTER PRESSING
BUTTON
STATE OF
PROGRAMMING(1)
(ONLY WITH DOOR PHONE
IN STAND-BY)
Open
pedestrian
door
Open
pedestrian
door
Open
pedestrian
door
Open pedestrian
door
Connect / disconnect the automatic door
opening system
--- Audio
activation
End of current
conversation ---
Call volume adjustment for door and floor
level calls (the possible volume adjustments
are, in this order, LOW, HIGH, MUTE)
Special
function(2)
Special
function(2)
Special
function(2)
Call to switchboard
or intercom(2)
Call source selection (from main calling
station, from secondary calling station, to
floor, intercom, from switchboard)
Garage
door opener
or special
function(2)
Garage
door opener
or special
function(2)
Garage
door opener
or special
function(2)
Call to switchboard
or intercom(2) Call tone selection
(1) To enter and exit programming state, hold button pressed for longer than 5 seconds. Three fast
beeps will be heard and the yellow LED will blink slowly to indicate that programming mode is selected.
Programming mode will shut down in all cases after the 10 minute timeout (two long beeps will be
heard).
(2) If configured in front-end beforehand.
2. FEATURES
2.1. CALL RECEPTION
The user’s apartment station will ring with the programmed tone when a call is received according to the
source of the call:
main calling station
secondary calling station
floor call
intercom call
•
•
•
•

9
DS1139-004
switchboard.
Green LED under button then lights up.
2.2. ANSWERING THE CALL
Pressing the button, the green LED under the button will start blinking; a conversation with the caller is
established at this point. By pressing again the button , the communication is closed.
2.3. DOOR OPENER DURING CALL
With the door phone in stand-by condition(3) or during call reception(3) (received from the calling station) or
in audio mode (with the calling station), the pedestrian gate or the garage gate can be opened by pressing
buttons or respectively.
(3) According to how the door opener is programmed: free or secret.
2.4. FLOOR CALL
If a floor call is received, the door phone will play the ring tone chosen by the user.
The function is only available if a button was connected to the “FC” terminals.
2.5. CALLING THE SWITCHBOARD
The user can call the switchboard, if this function has been configured in IPerVoice server, using one of the
two programmable calling buttons ( and ) present on the door phone.
To perform the call, follow this procedure: with the door phone in “STAND-BY” condition briefly press button
, and then press the calling button associated to the “Call to switchboard” function. Communication will
be established if the switchboard picks up before the timeout. Otherwise, the door phone will be turned off
and will ring as normal when the switchboard calls back. After replying, the green LED under the button will
start blinking; a conversation is established at this point.
2.6. INTERCOM CALL
The function is activated by programming a call button on the door phone in the IPerVoice server. Proceed
as follows to make the call: press button and then press the required call button ( or ); then wait for the
called apartment to reply. Upon the reply, the green LED under the button will start blinking; a conversation
with the called party is established at this point.
2.7. CALL TONE SELECTION
Five call tones are available for selection on apartment stations of the IPerVoice system, one for each calling
source.
The tones can be programmed by following the simple sequence below.
1. enter programming mode by holding button pressed for longer than 5 seconds; the yellow LED will
blink slowly to indicate that programming mode has been selected and the door phone will beep 3
times;
2. press button again for the number of times corresponding to the number of the call source for which
you want to change the call tone according to the following table:
Number of presses of the button Call source
1 From main calling station
2 From secondary calling station
3 Floor call
4 Intercom call
5 From switchboard
•

10 DS1139-004
After one second, the multicolour LED (6) will blink red for the number of times the button was
pressed in sign of confirmation and then will start blinking with yellow light again.
3. press the button to scroll the 5 available ring tones; the multicolour LED (6) blinks red to confirm the
selection;
4. after having made the selection, the user can:
select a different call source for which to change the call tone, by repeating the operation from step 2,
close programming mode by holding button pressed for longer than 5 seconds; in all cases, after
10 minutes the device exits programming state and the changed parameters are saved (two long
beeps are heard).
2.8. ADJUSTING THE CALL VOLUME
Proceed as follows to adjust the call volume (from calling station and to floor):
1. enter programming mode by holding button pressed for longer than 5 seconds; the yellow LED will
blink slowly to indicate that programming mode has been selected and the door phone will beep 3
times;
2. pressing the button will generate a confirmation beep at the new set call volume (the volume changes
according to the sequence LOW, HIGH, MUTE);
3. close programming mode by holding button pressed for longer than 5 seconds; in all cases, after 10
minutes the device exits programming state and the changed parameters are saved (two long beeps are
heard).
2.9. PANIC ALARM
The “Panic Alarm” signal can only be activated if a button was connected to the “PANIC” terminals.
When the button is pressed, the door phone emits the floor call (even if the door phone was in
mute mode).
IMPORTANT The following requirements are needed for the panic alarm function:
the system has a switchboard
the system was configured appropriately (for more information see the IPerVoice handbook on the
www.urmet.com website);
the switchboard is manned;
the switchboard operator is instructed on what to do if a panic alarm is received.
2.10. AUTOMATIC DOOR OPENER
To activate the automatic door opener service:
1. enter programming mode by holding button pressed for longer than 5 seconds; the yellow LED will
blink slowly to indicate that programming mode has been selected and the door phone will beep 3
times;
2. press the button :
• if the function was active, the multicolour LED (6) blinks(4) with green light;
• if the function was deactivated, the multicolour LED (6) is off;
3. close programming mode by holding button pressed for longer than 5 seconds; in all cases, after 10
minutes the device exits programming state and the changed parameters are saved (two long beeps are
heard).
(4) Only after having exited programming mode.
–
–
•
•
•
•

11
DS1139-004
3. USER DATA RESET
To restore default parameters of the device after entering programming mode, hold button pressed for
longer than 5 seconds, hold buttons and pressed for longer than 5 seconds. The device will
generate 2 long beeps and reboot.
The user data reset operation is irreversible.
4. REBOOTING THE DEVICE
Rebooting is used to reboot the device. The operation cannot be undone.
To reboot, the door phone must be in stand-by mode. Hold the button pressed for at least 7 seconds.

DS 1139-004 LBT 20347
Area tecnica
servizio clienti +39 011.23.39.810
http://www.urmet.com
e-mail: [email protected]
MADE IN CHINA
URMET S.p.A.
10154 TORINO (ITALY)
VIA BOLOGNA 188/C
Telef. +39 011.24.00.000 (RIC. AUT.)
Fax [phone] - 323

DS 1139-003 LBT 20317
Mod.
1139
CITOFONO VIVAVOCE IP
IP HAND-FREE DOOR PHONE
INTERPHONE MAINS-LIBRES IP
INTERFONO MANOS LIBRES IP
SPRECHANLAGE MIT FREISPRECHSYSTEM IP
IP HANDSFREE DEURTELEFOON
Sch./Ref.1139/3
LIBRETTO DI INSTALLAZIONE
INSTALLATION HANDBOOK
NOTICE D’INSTALLATION
MANUAL DE INSTALACIÓN
INSTALLATIONSANLEITUNG
INSTALLATIEHANDLEIDING

6DS1139-003
ENGLISH
The Ref. 1139/3 is an IP device dedicated exclusively to the IPerVoice system.
For trouble-free operation, the device requires a LAN/POE-type connection.
DESCRIPTION OF COMPONENTS
1
2
1. IPerVoice LAN connector with POE power supply (DOORPHONE POE PORT)
2. 12-way connector for connecting the door phone to optional devices for obtaining the following
functions:
• panic alarm
• call repetition
• floor call
• Yokis device activation.
WIRE DESCRIPTION FOR SYSTEM CONNECTIONS
Colour Name Description
Yellow PANIC Panic alarm
Green X1 Button
Blue GT Button common and
White Y1 Button
Grey - Not used
Colour Name Description
Grey - Not used
Brown S- Call repetition
Orange S+
Purple FC Floor call

7
DS1139-003
WIRING INSTRUCTIONS
RJ45 Ethernet Cable
The IPerVoice system has been designed to work with the EIA/TIA 568B standard.
Plug the cable into one of the RJ45 connectors with the Urmet logo.
Insert the wire in its guide, according to the provided colour code (Standard T568B).
8
1
Wire
No. Cable colour
1 White-Orange
2 Orange
3 White-Green
4 Blue
Wire
No. Cable colour
5 White-Blue
6 Green
7 White-Brown
8 Brown
Grey sheath
Cut the cables so that they protrude from the guide by about 5 mm, insert the guide in its plug and crimp
with the specially provided tool.
Plug
8
1
~ 5 mm
8
1
Make sure that the grey sheath stays inside the plug.
This type of connection will NOT guarantee double insulation.
INSTALLATION
WITH FLUSH-MOUNTED CASING MOD. 503
Install flush-mounting box at the height indicated in the drawing below.
Fix the bracket to the mounting box.
Box Mod. 503
Metal bracket
1,55 m
n° 2 M3,5 x 19 mm
included
Connect.
Fix the door phone to the bracket.
1
2
•
•
•

8DS1139-003
WITH FLUSH-MOUNTED CASING Ø 60 MM
Install flush-mounting box at the height indicated.
Remove the plastic base from the door phone unit and fix the base to the wall as shown in the drawing here
below.
1,55 m
n° 1 2,9 x 13 mm
countersunk screw
Box Ø 60 mm
n° 1 screw and screw
anchor included
Connect.
Fix the door phone to its plastic base.
1
DISTANCES, SECTIONS CABLES AND TECH SPECS
Type of connection Max distance Min - max cross section
Call to floor level 30 m 0,5 - 1 mm2
Panic Alarm 30 m 0,5 - 1 mm2
Call repeating 30 m 0,5 - 1 mm2
Yokis devices 10 m 0,5 - 1 mm2
LAN 100 m CAT5e (#)
(#) To ensure longest-range door phone operation, the cable must be a class 5e device and the twisted
pairs’ cross section must be AWG24.
The maximum resistance of the individual wires must not exceed 10ohm/100m.
The cable must be up to the following standards:
- EIA/TIA 568-B.2 or EIA/TIA 568-C.2
- EN50288 3-1
- IEC 61156-5
The connection between the door phone and POE switch must be ensured by a single cable without any
extra patch cords.
POE input voltage: ......................................................................................................................... 48-54 V
Max consumption @ 48 V:....................................................................................................................125 mA
Operating Temperature: ...................................................................................................................-5 ÷ 45°C
Maximum current X1/GT or Y1/GT contacts: .........................................................................50 mA - 12 Vdc

9
DS1139-003
Connection of a E2BPP module to the door phone for the centralisation of lights and rollers
SD541-4004
MVR500ER
OFNLBP
Roller
MVR500ER
OFNLBP
ANTENNA
GT
X1
Y1
R1 R1
R1
R1
R1 R1
Roller
Max 10 m
After suitably programming the Yokis devices, it will be possible:
to activate the centralised closing of the rollers with a button (for example: );
a second button (for example: ) will activate the turning off of the lights.
For more information on YOKIS products, please visit www.yokis.com
–
–

DS 1139-003 LBT 20317
Area tecnica
servizio clienti +39 011.23.39.810
http://www.urmet.com
e-mail: [email protected]
MADE IN CHINA
URMET S.p.A.
10154 TORINO (ITALY)
VIA BOLOGNA 188/C
Telef. +39 011.24.00.000 (RIC. AUT.)
Fax [phone] - 323
