Van Der Stahl MS-451 PV User manual

Printed SEP 2019
3rd Edition 3.11E
MICROCOMPUTER-CONTROLLED SEALER FOR STERILIZABLE BAGS
0493200A
MEDICAL POUCH SEALER
MS-451 PV
OPERATING INSTRUCTIONS
www.vanderstahl.com

MS-451PV Operating Instruction 3.11E
22
Thank you for purchasing the MS-451PV sealer.
Please read all of the safety and operating instructions before operating this machine. Periodic maintenance
and proper operation are necessary to ensure safety when using this impulse sealer. Keep this manual on
hand when operating the sealer.
MS-451PV controls the heating temperature by taking direct reading from the heating element through the
thin temperature sensor. Compared with the heating time control type, this makes the stable sealing condition
even after the prolonged use, reduces the unnecessary heating so that it saves the energy and the lives of
routine maintenance parts are extended.
As a result of research to further improve the MS-451PV series, some details in the operating instructions
may differ from your actual machine. For operating problems or product information, please contact your
local dealer.
Foreword

MS-451PV Operating Instruction 3.11E
33










Before using, always verify the voltage specification of your particular unit and operate it at the
correct voltages. Please note the following.
1 The voltage specification of your unit is listed on the label which displays the serial
number.
This label can be found on the machine body.
2 Please confirm the plug configuration on your specific unit.
The explanations and illustrations in this operator's manual utilize the plug configurations most
common in Japan.
The following marks are used in this manual to easily identify the conditions of risks, damages,
or some tips for the optimal use of your unit.
Caution   

Warning   

Danger   

Attention  

TIPS  

This manual is designed to cover machines of various voltages and
plug configurations
About the warning labels
Warning Voltages and plug configurations differ according to various worldwide specifications.
Always verify those of your particular unit before beginning operation. Connecting the
power cord to an outlet of a different specification is extremely hazardous.

MS-451PV Operating Instruction 3.11E
44
1 Specifications ……………………………………………………………………………………………… 6
2 Proper Operating Boundaries for MS-451PV …………………………………………………………… 7
3 Package Contents …………………………………………………………………………………………… 7
4 Replacement Parts ………………………………………………………………………………………… 8
5 Warning-Caution Label Location and Content ………………………………………………………… 8
6 Operating Precautions …………………………………………………………………………………… 10
7 Major Parts and Function………………………………………………………………………………… 14
8 Proper Use of the Sealer ………………………………………………………………………………… 16
9 Initial Settings of the Control Unit (Factory Setting) ………………………………………………… 20
10 How to Set the Control Unit …………………………………………………………………………… 21
10-1 [MENU 1] Set the sealing condition ……………………………………………………………………………………………… 21
10-2 [MENU 2] How to register the Administrator ID ………………………………………………………………………………… 23
10-2-1 Activate/deactivate the Administrator ID ………………………………………………………………………………… 23
10-2-2 Set the Administrator password …………………………………………………………………………………………… 24
10-3 [MENU 2] How to register the Operator ID ……………………………………………………………………………………… 25
10-3-1 Activate/deactivate the Operator IDs ……………………………………………………………………………………… 25
10-3-2 Register the Operator’s name ……………………………………………………………………………………………… 26
10-3-3 Set the Operator password ………………………………………………………………………………………………… 26
10-4[MENU 3] Set the Inspection Mode ……………………………………………………………………………………………… 27
10-4-1 How to set the Inspection Mode 1 ………………………………………………………………………………………… 29
10-4-2 How to set the Inspection Mode 2 ………………………………………………………………………………………… 29
10-4-3 How to set the Inspection Mode 3 ………………………………………………………………………………………… 30
10-4-4 How to set the Inspection Mode 4 ………………………………………………………………………………………… 31
10-5 [MENU 4] Seal counter ……………………………………………………………………………………………………………… 33
10-6 [MENU 5] Set the thin-film grip distance ………………………………………………………………………………………… 33
10-7 [MENU 6] Select the unit …………………………………………………………………………………………………………… 34
10-8 [MENU 7] Select the peel mode …………………………………………………………………………………………………… 34
10-9 [MENU 8] Set the minimum seal pressure ……………………………………………………………………………………… 35
10-10 [MENU 9] Change the temperature unit ………………………………………………………………………………………… 36
10-11 [MENU 10] Change the date setting……………………………………………………………………………………………… 36
10-12 [MENU 11] Set the time …………………………………………………………………………………………………………… 37
10-13 [MENU 12] Adjust the time………………………………………………………………………………………………………… 38
10-14 [MENU 13] Initialize RAM ………………………………………………………………………………………………………… 38
10-15 [MENU 14] Monitor the temperature in real time ……………………………………………………………………………… 39
10-16 [MENU 15] Monitor the pressure to the sealing pressure load-cell…………………………………………………………… 40
10-17 [MENU 16] Monitor the pressure to the PTT load-cell ………………………………………………………………………… 41
10-18 [MENU 17] Monitor the seal pressure to the seal levers ……………………………………………………………………… 42
10-19 [MENU 18] Register the lot number ……………………………………………………………………………………………… 42
10-20 [MENU 19] Set the continuous operation mode ………………………………………………………………………………… 43
10-21 [MENU 20] Daily Inspection Mode ……………………………………………………………………………………………… 43
10-22 [MENU 21] Data view ……………………………………………………………………………………………………………… 44
Table of Contents

MS-451PV Operating Instruction 3.11E
55
11 Details of the Inspection Modes ……………………………………………………………………… 46
11-1 When the Inspection Mode starts - Inspection Mode 1 and 2 - ………………………………………………………………… 46
11-2 How to start Inspection Mode - Inspection Mode 3 - …………………………………………………………………………… 51
11-3 When the Inspection Mode starts - Inspection Mode 4 -………………………………………………………………………… 52
12 Daily Inspection for PTT-50 …………………………………………………………………………… 55
13 Replacing the Routine Maintenance Parts ………………………………………………………… 58
13-1 Preparation before replacing parts ………………………………………………………………………………………………… 59
13-2 Replacing the zone (center-dry) tape ……………………………………………………………………………………………… 61
13-3 Replacing the heating element …………………………………………………………………………………………………… 62
13-4
Replacing glass tape and Sarcon sheet …………………………………………………………………………………………………………… 63
13-5 Replacing the pressure rubber …………………………………………………………………………………………………… 64
13-6 Replacing silicone rubber (white) ………………………………………………………………………………………………… 64
13-7 How to replace the microswitch …………………………………………………………………………………………………… 65
13-8 Replacing the temperature sensor ………………………………………………………………………………………………… 66
13-9 Replacing battery …………………………………………………………………………………………………………………… 68
13-10 Replacing fuse ……………………………………………………………………………………………………………………… 69
13-11 Replacing shock absorber ……………………………………………………………………………………………………… 69
14 Adjusting Each Parts …………………………………………………………………………………… 70
14-1 Adjusting the sealing pressure …………………………………………………………………………………………………… 70
14-2 Adjusting sensitivity volume on VIU photo sensor ……………………………………………………………………………… 71
15 Optional Items …………………………………………………………………………………………… 72
15-1 Sealing area safety cover…………………………………………………………………………………………………………… 72
15-2 Touch-switch protection cover……………………………………………………………………………………………………… 73
15-3 Film-cutting template with cutting mat …………………………………………………………………………………………… 74
16 About the Load-Cell Calibration ……………………………………………………………………… 75
17 Transferring Sealing Data to PC ……………………………………………………………………… 75
18 Electric Diagram ………………………………………………………………………………………… 76
19 Common Problems and Solutions …………………………………………………………………… 77
20 Error Messages during Operation …………………………………………………………………… 79
20-1 Sealing condition related errors …………………………………………………………………………………………………… 79
20-2 Peel tensile tester related errors …………………………………………………………………………………………………… 80
20-3 System related errors ……………………………………………………………………………………………………………… 81
21 To discard ………………………………………………………………………………………………… 82
Exploded View / Parts List……………………………………………………………………………… 83

MS-451PV Operating Instruction 3.11E
66
Sealer
PTT-50
VIU
Safety Measures
Power DC 24V
Power consumption 6W
Peel strength (max) 50N (precision: full scale ± 0.4%)
Peel speed 300 mm/min (± 2mm/min)
Drive method DC motor
Max travel distance 55 mm MAX
Units (peel strength) Select among N or lbf (default setting : N)
Power
AC 110V 50/60HZ
6XSSO\YROWDJHVKRXOGEHZLWKLQWKHÀXFWXDWLRQUDQJHRIIURP
the rated voltage.
Power consumption 1400W / Stand by 30W
Power cord SOXJZLWKHDUWKPFRUG8/6SHFLÀFDWLRQ
Machine dimensions W 630 × D 340× H 300 mm (without a table)
Machine weight 36 kg
Effective seal length 450 mm (-0 to +10 mm)
Sealing width
10 mm (± 0.1 mm)
*This is the tolerance of the heating element width. It does not
necessarily correspond with the sealing width.
Materials Sterilized pouches
Operating method By touch switch
Sealing method Impulse/ upper single-side heating type
Seal condition
Heating Temperature: 140 ~ 400 ºF / 60 ~ 204 ºC
(in 1 ºF/ºC increment)
Heating Time: 0.0 ~ 3.0 seconds
(in 0.1s increment)
Cooling Temperature: 140 ºF / 60 ºC ~ up to set heating
temperature (in 1 ºF increment)
Units (seal pressure) Select among MPa, Kgf/cm2, psi (default setting : MPa)
Seal pressure (max) 2500N (precision: full scale ± 2.5%)
Operating temperature range +41 ~ 104 ºF (+5 ~ 40 ºC )
Operating humidity range 30 - 80%RH
Data output From USB cable
Power DC 24V
LED 5 White color LED 3 pieces
Lens 0DJQLÀFDWLRQDERXWWLPHV
Anti over-heating circuit device Power switch automatically turns off when the heating continues over
8 seconds.
Pressure lever safety measure When the hands are caught between the seal levers, the pressure
lever returns to the initial position within 0.4 seconds.
Abnormality detection sensor The power will be automatically shut off when the body cover (bottom
part) is removed from the machine.
Motor overload [PTT-50] The motor stops when the applied load is more than rated torque
value.
1 Specifications

MS-451PV Operating Instruction 3.11E
77
Accessories for Sealer Accessories for PTT-50 (Peel Tensile Tester)
These illustrations are not reduced equally.
1. Machine ---- 1 unit
2. Accessories
3. Spare parts
Please check the following after opening the package:
Ŷ Is the machine model the same as you have ordered?
Ŷ Has any damage occurred during shipment?
Ŷ Please make sure that all of the accessories described below are included.
I-heating element
・・・・・・・・・・・ 5 pcs.
Semi -transparent tape (3m roll)
・・・・ 1 roll
Zone (center-dry) tape
・・・・・・・・ 1 roll
Sarcon sheet W 13mm × L 470mm・・ 1 pc.
Glass tape 38mm(5m roll)・・・・・・ 1 roll
1 The impulse sealer is a machine which sends strong electric current quickly to the thin ribbon heater,
which presses against the film and instantly heat seals the package.
Though this machine yields superior quality sealing, it is not compatible with films thicker than that
indicated in the diagram below, sponge-like sheets, and materials which are not able to withstand high
heat.
2 Film thickness limits for MS-451PV is described below. The machine cannot seal bags which are thicker
than that indicated. The machine may malfunction if you try to exceed the limits of machine.
Heating method )LOPWKLFNQHVVWRWDOWKLFNQHVVRISLOHG¿OP
Upper single side Less than 0.5 mm
3 Package Contents
2 Proper Operating Boundaries for MS-451PV
Phillips screwdriver...1 pc.
Table...1 pc.
Touch switch...1pc. Thin-film grips...1 pc.
Proximity switch GLS-M1...1 pc
Film cutting template...1 pc
Specimen setting gauge ... 2 pcs.
Tension spring for daily
inspection ... 1 pc.
Tension spring jig set for daily
inspection ... 1 pc.
For 25mmFor 10mm
Grip fixing pin ... 1 pc.

MS-451PV Operating Instruction 3.11E
88
UNPLUG BEFOR
PERFORMING
MAINTENANCE.
Caution
Caution
W2135
UNPLUG BEFORE
PREFORMING
MAINTENANCE.
Machine side
Routine maintenance parts, which will need to be replaced after extensive use, are sold individually as detailed
below. Replacement parts can be purchased through Van der Stahl Scientific.
Parts Number Parts Name Sales Unit
560304 / 560305 I-heating element 10 or 5 pcs. / set
39441 =RQHFHQWHUGU\WDSH 1 roll [W40mm x 5m]
39432 Glass tape 1 roll [W38mm x 10m]
560023 6LOLFRQHUXEEHUZKLWH 2pcs/set [W16mm x L460mm]
27005 / 39630 Sarcon sheet 2pcs/set [W3mm x L470mm] or
1 roll [W13mm x 5m]
560010B Temperature sensor 1 pc.
560018 Microswitch 1 pc.
492800 Shock absorber 1 pc. [with nut]
Warning -Caution labels are placed in locations where there is a danger of injury to a person or damage to the
machine. Label location details are illustrated below.
Please check them before beginning operation.
Labels not rapidly apparent are indicated by dotted lines.
Explanation of the warning icons:
W1263
Caution: electrical shock hazard - do not touch
W1264
Caution: HOT - do not touch during operation
W1266
Caution: crush hazard -keep hands clear
4 Replacement Parts
5 Warning-Caution Label Location and Content

MS-451PV Operating Instruction 3.11E
99
W1260
W1263
W1263
W1262
W1260
W1262
W1263
W1263
W1262
W1262
W1260
W1260
Bottom of the control unit
On the pressure lever On the PTT
On the body frame
Sealer cover front
If Warning-caution labels peel off or are lost, please purchase the proper labels
and place them in the appropriate location.

MS-451PV Operating Instruction 3.11E
1010
Warning In an emergency, unplug the power cord immediately
MS-451PV incorporates a number of safety devices and is carefully
designed to prevent fires or other malfunctions.
However, should all of safety devices fail simultaneously, there is a
possibility of center-dry tape catching fire due to a failure of the heating
circuit's tripping mechanism that results in the heating element
overheating. Should smoke or fire appear from the center-dry tape,
immediately turn OFF the power.
Warning When replacing parts, unplug the power plug
Maintenance of the machine is important. Parts should be replaced in
accordance with the operating instructions. There is a risk of danger if
the parts are not replaced properly. Before replacing parts, unplug the
machine from the power source.
Warning Do not use for packaging liquids
Do not splash water on MS-451PV or use machine for packaging
liquids since machine is not waterproof.
There is a danger of electrocution or malfunction of the machine.
Warning Do not insert any metal objects into the sealing area
Please do not place any metal objects into the sealing area during
operation. This could cause electrocution.
Warning Do not modify the machine
Modification of MS-451PV or the use of unspecified parts may not
only lead to damage of the machine, but there is also a risk of danger to
the operator. Please do not temper with the machine. Accidents or
damage caused by modifications by the customer is the sole
responsibility of the customer.
Warning Confirm proper electric power source
Make sure power source has the specified voltage and electric power as
explained in the operating instructions. Do not use an extension cord, as
the machine may malfunction or may result in fire. Machine will
malfunction if connected to anything other than the specified voltage.
Insert the electric power plug fully into the wall outlet.
Warning Do not use parts other than those specified
When replacing parts, always use only specified parts sold through
Van der Stahl Scientific.We are not responsible for malfunctions
caused by the use of unspecified parts.
6 Operating Precautions
For Safety Operation

MS-451PV Operating Instruction 3.11E
1111
Caution Do not use in the following places
Do not operate machine in the following places since there is a danger
of malfunction
1 Dusty locations.
2 Locations not within normal temperatures.
3 Locations with highly humidity.
Caution Do not place hands in the sealing area
1 With prolonged use, the sealing area will retain heat and
become hot.
2 Do not place your fingers in the sealing area. There is a danger
of burns.
3 If fingers or foreign objects are caught in the lever and heating
doesn’t start within 0.5 seconds, the pressure is released and
lever returns to the first position.
Be careful not to be caught at both ends of the sealing lever .
The pressure is stronger especially at the both ends than the
center part of sealing lever. Heating process could possibly start
even while the fingers are caught.
Caution Use machine properly
Read this operating instructions carefully and correctly operate sealer.
Accidents or damage caused by the misuse of the machine, or against
the operating instructions are the sole responsibility of the customer.
Caution Place the machine at a proper location
Place the MS-451PV on a flat, horizontal surface and secure an
appropriate workbench. Also avoid near the heat source or the noise
generator. Please make sure to connect the earth wire without fail.
Heating temperature should be set at a minimum
Set the heating temperature at minimum of required to perform sealing.
If the temperature is raised excessively, the parts such as zone (center-
dry) tape and glass tape could possibly be damaged and result in
breaking the heating element. Excessive heating temperature also
decreases the work efficiency and wastes electricity.
For Smooth Operation

MS-451PV Operating Instruction 3.11E
1212
Set the cooling temperature depending on the film
Cooling process is important when using an impulse sealer. After the
film is heated, the film must cool with the frame and pressure lever in
the closed position. Setting the cooling temperature excessively low
will decrease the work productivity. Set the cooling temperature that is
suitable for each film.
When the center-dry tape, silicone rubber becomes damaged
The zone (center-dry) tape, silicone rubber will start to wear with use.
Once they are damaged, it will be difficult to achieve smooth and
strong seals. Thoroughly read how to replace the parts and be careful
when doing so.
When temperature sensor is malfunctioning
Since the temperature sensor directly measures and controls the
temperature of heating element, disconnection of the sensor part to the
heating element could stop the entire machine operation.
Please make sure to set the temperature sensor properly especially after
replacing the parts around heating area.
Dust in the sealing area
Dust will prevent attainment of a smooth seal. It could also cause
damage to heating element and / or other routine maintenance parts.
Before using the machine, clean the sealing area.
MS-451PV is an impulse sealer
Do not become alarmed if the sealing area does not become hot after
the power switch is turned to the ON position. It is not because of the
machine malfunction.
MS-451PV uses an impulse method so the heating element will not
become hot just by plugging in the unit or turning the power switch to
the ON position. The heater will only become hot for an instant when
the heating process is in operation. However, after extended periods of
use, the sealing area may become hot.
Run test trials first before beginning operation
Achieving a superior seal with an impulse sealer is determined by
heating / cooling / pressure strength. Depending on the type of film and
the contents of the bag, heating / cooling / pressure strength conditions
may differ drastically. Find the optimum sealing conditions by
conducting seal test before proceeding.
Other Safeguards

MS-451PV Operating Instruction 3.11E
1313

MS-451PV Operating Instruction 3.11E
1414
7 Major Parts and Function
Control unit
Setting sealing conditions etc..
See “10 How to Set the
&RQWURO8QLW´ĺSDJH21
for the details.
Visual inspection unit (VIU)
Used for inspecting the
sealing.
Touch switch
Depress the touch switch in
order to operate.
Emergency stop switch
A red emergency stop
switch is a safety device
which allows the operator
to stop the machine in
emergency. The power is
shut off and the lever
returns to the initial
position.
Remove the body cover
while performing
maintenance.
Body cover
Power cord
Power switch
Table
Push to turn ON the power.
Peel tensile tester
Used for inspecting
the peel tensile at
inspection mode.
Inserted to the VIU unit
when operating inspection
mode.
VIU lens
Open the cover when
operating inspection mode.
Frame cover

MS-451PV Operating Instruction 3.11E
1515
Control Unit Detail
Control Unit
Display monitor
Enter key
Menu key
Press when setting
the conditions etc.
1 Set conditions etc. are displayed.
2 Error message is displayed.
Used when changing
set conditions.
Number key
Used for inputting the seal
conditions, dates, IDs, and
registering passwords.
Letters and numbers can
be input when registering
IDs.
Arrow key
UP/DOWN arrows are used for moving the
cursor and changing items.
Right/Left arrows are used for moving the
cursor.
Heating lamp
Turns ON while heating.
Cooling lamp
Turns OFF while cooling.
Error lamp
Turns ON when the
error is detected.
Seal mode lamp
VIU inspection lamp
Turns ON while sealing
is performed.
Turns ON while VIU
inspection is performed.
PTT lamp
Turns ON while PTT
inspection is performed.
INSPECT key
Used when you want to use
inspection mode.
PASS/FAIL key
Used when inputting the result of
VIU inspection.
PEEL TEST RESET/START key
Used when starting PTT inspection
or re-doing inspection.

MS-451PV Operating Instruction 3.11E
1616
Place the machine on a flat, horizontal surface and secure an
appropriate workbench.
The thin-film grip on the measurement-side is not
attached at the time of factory shipment. Insert the pin
to fix the grip as in the illustration on the right.
If the table is not necessary, you do not need to perform
this process.
1Slightly loosen the 6 x 10 white plastic screw at
the sealer front.
2Insert the L-shaped table corner into the gap
between the unit frame and the white plastic
screw.
3Tighten the white plastic screw at the proper
work position (height) to secure the table.
Insert the touch switch to the socket located on the right
side of the machine.
Use only as described in this manual.
There is a risk of danger and malfunctions may result if the machine is used not in accordance with this manual.
8 Proper Use of the Sealer
8-1 Secure the work place
8-2 Attach the PTT thin-film grip
8-3 Mount the table
8-4 Install the touch switch
Thin-film grips on
the measurement-side
Fix with a pin.
White plastic nut M6 x 10
Warning Installing the machine on an unstable or
inclined surface may cause the overturn of
the sealer.

MS-451PV Operating Instruction 3.11E
1717
When the password is required:

  




The power cord is located on the left side of the
machine, when facing toward it. Make sure the
electrical outlet has adequate current carrying capacity
as described at ³6SHFLILFDWLRQV´ĺSDJH6).
Insert the electric power plug fully into the wall outlet.
The power switch is located on the left side of frame
when facing toward the machine. Turn ON the power
switch. The screen will turn ON.
1The right display will be shown on the screen.
2Press the numeric keys to input a six-digit
password.
3The corresponding ID to the inputted
password will be shown on the screen. Push
any key to start the sealer.
8-5 Plugging in the electrical power cord
8-6 Power switch ON
Turning ON the power switch
Warning There is a danger of fire if the electrical
power source does not meet proper
specifications.
TIPS  ,IWKH$GPLQLVWUDWRUDQGRU2SHUDWRU,'V
is activated, the machine may ask you to
input the password. Input the password
you have registered. For the details, refer
to ³+RZWR6HWWKH&RQWURO8QLW´ĺ
page 21.
TIPS Only numbers may be used for
registering as a password.

MS-451PV Operating Instruction 3.11E
1818

 


After setting all the conditions at the control unit, hold
the bag by both hands and stretch it tight. Set the bag
between seal levers and put the touch switch.
While sealing, the right display will be shown on the
screen.
The upper line shows the parameters set by the user.
The bottom line shows the actual heating/cooling
temperature as well as the seal pressure.
Also the seal counter is shown on the right upper side of
the screen in four digits.
Set the sealing condition such as heating temperature/
heating time/ cooling temperature and operation pattern
etc. with the control unit.
With the operation mode, the display will show the
current date and time as in the right illustration.
8-8 Perform sealing
8-7 Set the sealing conditions with
control unit
Touch switch
Counter
Seal pressure
Set heating
temperature
Set cooling
temperature
Actual heating
temperature
Actual cooling
temperature
Attention Refer to “10-1 [MENU 1] Set the sealing
FRQGLWLRQ´ĺSDJH21for the details.
TIPS If the Inspection Mode is activated, the
inspection mode may start running when
turning ON the power switch. Please follow
the procedure referring to “11 Details of
WKH,QVSHFWLRQ0RGHV´ĺSDJH46.
For how to set the inspection mode, refer
to “10-4 [MENU 3] Set the Inspection
0RGH´ĺSDJH27.
TIPS For how to set the date, refer to “10-11
>0(18@&KDQJHWKHGDWHVHWWLQJ´ĺ
page 36.
For how to set the time, refer to “10-12
>0(18@6HWWKHWLPH´ĺSDJH37.

MS-451PV Operating Instruction 3.11E
1919
Please run test trials first before beginning operation.
Find the most suitable conditions (heating temperature
etc.) as you do test sealing.
After the heating and cooling cycle has finished, the
pressure lever returns to the initial position, and the
sealing is complete. If a sealing is not clean enough,
adjust the heating time or sealing pressure.
After finishing operation, always turn OFF the power
switch.
The set value is retained by the control unit; therefore,
there is no need to put the value every time after turning
OFF the power switch.
Unplug the power outlet in the case of not using the
machine for a while.
After use, please clean up the parts. Inspect parts such
as center-dry tape and heater to make sure that they are
not damaged. If the parts appear to be damaged,
replace them referring to operating instructions.
8-9 Test sealing
8-10 Finish sealing
8-11 Power switch OFF
8-12 Inspection after operation
Turning off the power switch
Caution After operating the machine for a while,
sealing area becomes hot and the danger
of burning increases. Do not put fingers
into the sealing area where a strong
pressure is applied. When the foreign
object is put between the pressure levers
or the microswitch does not turn on within
0.35 sec., the lever releases the pressure
automatically. However there is a
possibility that the heating process could
start while the foreign object is caught in
the sealing area since the strong pressure
is applied especially to the both sides of
the sealing lever.

MS-451PV Operating Instruction 3.11E
2020

























 








MENU 1 TEMP. Setting The initial setting for the sealing temperature is set at 140°F for heating, 0.0s for the time and
)IRUFRROLQJIRUDOO¿YHRSHUDWLRQSDWWHUQV
MENU 2 OPERATOR
SETTING
No password is set for the administrator or operators at the initial setting. For details on setting the
password, refer to ³>0(18@+RZWRUHJLVWHUWKH$GPLQLVWUDWRU,'´ĺSDJH23and “10-3
>0(18@+RZWRUHJLVWHUWKH2SHUDWRU,'´ĺSDJH25.
MENU 3 INSPECTION
MODE
The initial setting for the inspection mode is set at Inspection Mode 1. For details on setting the
inspection mode, refer to ³>0(18@6HWWKH,QVSHFWLRQ0RGH´ĺSDJH27.
MENU 4 SEAL COUNT When shipped from the factory, the counter that keeps track of the number of seals is set at 0. For
a detailed explanation, refer to ³>0(18@6HDOFRXQWHU´ĺSDJH33.
MENU 5 PEEL ORG Setting the grip distance for tensile testing
7KHGLVWDQFHEHWZHHQWKLQ¿OPJULSVRQWKHWHQVLOHWHVWHULVVHWDWPPLQFKHVZKHQVKLSSHG
from the factory. For details and how to change the setting, refer to “10-6 [MENU 5] Set the thin-
ILOPJULSGLVWDQFH´ĺSDJH33.
MENU 7 PEEL MODE Setting the tensile strength measurement standard
The tensile strength is set at 0 N when shipped from factory. For details and how to change the
setting, refer to ³>0(18@6HOHFWWKHSHHOPRGH´ĺSDJH34.
MENU 8 SEAL FORCE
MIN
Setting the minimum sealing pressure
The minimum sealing pressure is set at 0.10 Mpa when shipped from the factory. For details and
how to change the setting, refer to ³>0(18@6HWWKHPLQLPXPVHDOSUHVVXUH´ĺSDJH
35.
MENU 9 TEMPERATURE Setting the unit for temperature setting
7KHWHPSHUDWXUHXQLWLVVHWDW))DKUHQKHLWZKHQVKLSSHGIURPWKHIDFWRU\)RULQIRUPDWLRQRQ
how to change the setting, refer to ³>0(18@&KDQJHWKHWHPSHUDWXUHXQLW´ĺSDJH36.
The sealer is shipped from the factory with the following default settings. For details on how to change the
settings, please refer to “10 How to Set the Control Unit.”
9 Initial Settings of the Control Unit (Factory Setting)
