SIM Setup
Description
1 Nano SIM Slot
1 micro SAM or 2nd micro SIM Slot
User action
To Install SIM cards please turn off your device, remove the battery cover then
remove the primary battery from the battery compartment but keep the battery
connected.
Insert a SIM card (with contacts face down) by carefully sliding it into the slot until
the card is fully inserted.
Make sure the card orientation is matching with the icon engraved in the housing.
Place the primary battery then place battery cover.
Note: if the device was powered on during insertion. Please reboot the device after
inserting a SIM
User Guide
SIM Setup Carbon Mobile 5 with printer
EN
User Guide
Carbon Mobile 5 with printer
4
EN

Charging the Battery
Description
To charge the battery.
User action
After unpacking your Verifone Carbon Mobile 5 device, charge the unit for eight
hours or until fully charged.
Manual Start Up
Description
To start up or power on the terminal.
User action
Hold the start/power button for about 3 seconds until the device displays the start-
up screen.
Manual Shutdown
Description
To shut down or power off the terminal.
User action
Hold the start/power button for about 1 second until the message is displayed on
the screen. Touch the "Power Off" selection to turn off.
User Guide
Carbon Mobile 5 with printer
5
User Guide
Terminal Charge and Power Up Carbon Mobile 5 with printer
EN
EN

Language selection
Description
Shows the list of supported languages with locales.
User action
Language and Country can be selected here, where they will be applied to
system and all apps which supports the selected language.
Optional Info
It shows a summary about the device, which can be used to validate
software stack before starting the activation process:
Model name
Serial number
Device manufacturer
Battery level
VHQ Customer ID
Certificate Sponsor ID
Android version
Build version
Engage ADK and VOS versions
Information about installed warranty keys
Current connection status
SIM card status
Part number
URL of VHQ server
Heartbeat frequency
Current IP address.
