VEVOR 2822C Operation instructions

Technical Support and E-Warranty Certificate www.vevor.com/support
PLANER
USER MANUAL
We continue to be committed to provide you tools with competitive price.
"Save Half", "Half Price" or any other similar expressions used by us only represents an
estimate of savings you might benefit from buying certain tools with us compared to the major
top brands and doses not necessarily mean to cover all categories of tools offered by us. You
are kindly reminded to verify carefully when you are placing an order with us if you are
actually saving half in comparison with the top major brands.

- 1 -
MODEL: 2822C
Have product questions? Need technical support? Please feel free to
contact us:
[e-mail]
NEED HELP? CONTACT US!
This is the original instruction, please read all manual instructions
carefully before operating. VEVOR reserves a clear interpretation of our
user manual. The appearance of the product shall be subject to the
product you received. Please forgive us that we won't inform you again if
there are any technology or software updates on our product.
PLANER

- 2 -
Symbol
Symbol Description
Warning - To reduce the risk of injury, user must read instructions
manual carefully.
This symbol, placed before a safety comment, indicates a kind of
precaution, warning, or danger. Ignoring this warning may lead to an
accident. To reduce the risk of injury, fire, or electrocution, please
always follow the recommendation shown below.
This product is of protection class II. That means it is equipped with
enhanced or double insulation.
Warning- Be sure to wear ear protectors when using this product.
Warning- Be sure to wear eye protectors when using this product.
Warning- Be sure to wear dust masks when using this product.
1.GENERAL POWER TOOL SAFETY WARNINGS
Read all safety warnings and all instructions. Failure to follow the
warnings and instructions may result in electric shock, fire and/or serious
injury.
Save all warnings and instructions for future reference. The term
“power tool” in the warnings refers to your mains-operated (corded) power
tool or battery-operated (cordless) power tool.
Work area safety

- 3 -
◆Keep work area clean and well-lit. Cluttered or dark areas invite
accidents.
◆Do not operate power tools in explosive atmospheres, such as in
the presence of flammable liquids, gases or dust. Power tools create
sparks that may ignite dust or fumes.
◆Keep children and bystanders away while operating a power tool.
Distractions can cause you to lose control.
Electrical safety
◆Power tool plugs must match the outlet. Never modify the plug in any
way. Do not use any adapter plugs with earthed (grounded) power tools.
Unmodified plugs and matching outlets will reduce risk of electric shock.
◆Avoid body contact with earthed or grounded surfaces, such as
pipes, radiators, ranges and refrigerators.There is an increased risk of
electric shock if your body is earthed or grounded.
◆Do not expose power tools to rain or wet conditions. Water entering
a power tool will increase the risk of electric shock.
◆Do not abuse the cord. Never use the cord for carrying, pulling or
unplugging the power tool. Keep cord away from heat, oil, sharp
edges and moving parts.
Damaged or entangled cords increase the risk of electric shock.
◆When operating a power tool outdoors, use an extension cord
suitable for outdoor use. Use of a cord suitable for outdoor use reduces
the risk of electric shock.
◆If operating a power tool in a damp location is unavoidable , use a
residual current device (RCD) protected supply. Use of an RCD
reduces the risk of electric shock.
Personal safety
◆Stay alert, watch what you are doing and use common sense when
operating a power tool. Do not use a power tool while you are tired or

- 4 -
under the influence of drugs, alcohol or medication. A moment of
inattention while operating power tools may result in serious personal
injury.
◆Use personal protective equipment. Always wear eye protection.
Protective equipment such as dust masks, non-skid safety shoes, hard
hats, or hearing protection used for appropriate conditions will reduce
personal injuries.
◆Prevent unintentional starting. Ensure the switch is in the off-position
before connecting to power source and/or battery pack, picking up or
carrying the tool.
Carrying power tools with your finger on the switch or energizing power
tools that have the switch on invites accidents.
◆Remove any adjusting key or wrench before turning the power tool
on.
A wrench or a key left attached to a rotating part of the power tool
may result in personal injury.
◆Do not overreach. Keep proper footing and balance at all times.
This enables better control of the power tool in unexpected situations.
◆Dress properly. Do not wear loose clothing or jewellery. Keep your
hair, clothing and gloves away from moving parts. Loose clothes,
jewellery or long hair can be caught in moving parts.
◆If devices are provided for the connection of dust extraction and
collection facilities, ensure these are connected and properly used.
Use of dust collection can reduce dust-related hazards.
Power tool use and care
◆Do not force the power tool. Use the correct power tool for your
application. The correct power tool will do the job better and safer at the
rate for which it was designed.
◆Do not use the power tool if the switch does not turn on and off. Any
power tool that cannot be controlled with the switch is dangerous and must
be repaired.
◆Disconnect the plug from the power source and/or the battery pack

- 5 -
from the power tool before making any adjustments, changing
accessories, or storing power tools. Such preventive safety measures
reduce the risk of starting the power tool accidentally.
◆Store idle power tools out of the reach of children and do not allow
persons unfamiliar with the power tool or these instructions to
operate the power tool. Power tools are dangerous in the hands of
untrained users.
◆Maintain power tools. Check for misalignment or binding of
moving parts, breakage of parts and any other condition that may
affect the power tool’s operation. If damaged, have the power tool
repaired before use. Many accidents are caused by poorly maintained
power tools.
◆Keep cutting tools sharp and clean. Properly maintained cutting tools
with sharp cutting edges are less likely to bind and are easier to control.
◆Use the power tool, accessories, and tool bits, etc., in accordance
with these instructions, taking into account the working conditions
and the work to be performed. Use of the power tool for operations
different from those intended could result in a hazardous situation.
Service
◆Have your power tool serviced by a qualified repair person using
only identical replacement parts. This will ensure that the safety of the
power tool is maintained.
Planer Safety Rules
◆Wait for the cutter to stop before setting the tool down. An exposed
rotating cutter may engage the surface leading to possible loss of control
and serious injury.
◆Hold the power tool by insulated gripping surfaces only, because
the cutter may contact its own cord. Cutting a “live” wire may make
exposed metal parts of the power tool “live” and could give the operator an
electric shock.

- 6 -
◆Use clamps or another practical way to secure and support the
workpiece to a stable platform. Holding the work by your hand or against
the body leaves it unstable and may lead to loss of control.
◆Use suitable detectors to determine if utility lines are hidden in the
work area or call the local utility company for assistance. Contact with
electric lines can lead to fire and electric shock. Damaging a gas line can
lead to an explosion. Penetrating a water line causes property damage or
may cause an electric shock.
◆Do not reach into the chip ejector with your hands. They could be
injured by rotating parts.
◆Apply the machine to the workpiece only when switched on.
Otherwise, there is a danger of kickback when the cutting tool jams in the
workpiece.
◆When working, always hold the planer in such a manner that the
planer base plate faces flat on the workpiece. Otherwise the planer can
become wedged and lead to injuries.
◆Never plane over metal objects, nails or screws. The planer blade
and the blade shaft can become damaged and lead to increased
vibrations.
2. PRODUCT DESCRIPTION AND SPECIFICATIONS
Read all safety warnings and all instructions. Failure to follow
the warnings and instructions may result in electric shock, fire and/or
serious injury.
Intended Use
The machine is intended for planing of firmly supported wooden materials,
such as beams and boards. It is also suitable for beveling edges and
rebating.

- 7 -
Product Features
The numbering of the product features refers to the illustration of the
machine on the graphics page.
1. Parallel Guide
2. Lock Screw
3. Depth Adjustment Knob
4. Planing Depth Scale
5. Chip Ejector (Alternatively
Right/Left)
6. Lock-Off Button for On/Off
Switch
7. On/Off Switch
8. Park Rest
9. Belt Cover
10. Belt
* Accessories shown or described are not part of the standard
delivery scope of the product. A complete overview of accessories
can be found in our accessories program.

- 8 -
Standard accessories
PART NO.
DESCRIPTION
QTY
1
Planer Blade
2
2
Hex Wrench
1
3
Wrench
1
4
Parallel Guide
1
5
Dust Bag
1
6
Storage Bag
1
3. TECHNICAL DATA
MODEL NO
2822C
Rated
Voltage/Frequency
220V-240V, 50 Hz
120V, 60 Hz
Rated Input Power
710W
6A
No-Load Speed
16500 r/min
Planing Width.Max
80 mm
Planing Depth
0-2 mm
Weight
2.88 kg
Protection Class
/Ⅱ
4. ASSEMBLY
◆Before any work on the machine itself, pull the mains plug.
Changing the Tool
◆Be cautious when replacing the planer blades. Do not grasp the
planer blades by the cutting edges. Possible danger of injury due to the
sharp cutting edges of the planer blades. Use only original blades
The blade has 2 cutting edges and can be reversed. When both cutting

- 9 -
edges are dull, the planer blade must be replaced. The blade may not be
resharpened.
4.1 Disassembling the Planer Blade(s) (see figure A)
To reverse or replace the planer
blade 14, rotate the blade drum 11 until
it is parallel to the planer base plate 9.
Loosen the two fastening screws 13
with the Hex key 15 by approx. 1 – 2
turns.
If necessary, loosen the clamping
element 12 by giving it a light blow with
a suitable tool (e.g. a wooden wedge).
Push the planer blade 14 sidewards out of the blade drum 11 with a
piece of wood.
4.2 Assembling the Planer Blade(s) (see figure B)
The guide groove of the planer blade
always ensures continuous height
adjustment when replacing or reversing it.
If required, clean the blade seat in the
clamping element 12 and the planer blade
14.
When assembling the planer blade,
ensure that it is seated properly in the
blade holder of the clamping element 12
and aligned flush at the side edge of the rear planer base plate 9. Afterward,
tighten the 2 fastening screws 13 again with the Hex key 15.
Note: Before restarting, check if the fastening screws 13 are tightened well.
Rotate the blade drum 11 by hand and ensure that the planer blade does
not graze.
4.3 Dust/Chip Extraction

- 10 -
◆Dust from materials such as lead-containing coatings, some wood types,
minerals and metal can be harmful to one’s health. Touching or breathing
in the dust can cause allergic reactions and/or lead to respiratory infections
of the user or bystanders.
Certain dust, such as oak or beech dust, are considered carcinogenic,
especially in connection with wood-treatment additives (chromate, wood
preservative). Materials containing asbestos may only be worked by
specialists.
– As far as possible, use a dust extraction system suitable for the material.
– Provide good ventilation in the working place.
– It is recommended to wear a P2 filter-class respirator.
Observe the relevant regulations in your country for the materials to be
worked.
Clean the chip ejector 1regularly. Use a suitable tool (e.g., a piece of wood,
compressed air, etc.) to clean a clogged chip ejector.
◆Do not reach into the chip ejector with your hands.
They could be injured by rotating parts.
To ensure optimum extraction of dust/chips, always work with external dust
extraction or a chip/dust bag.
4.3.1 External Dust Extraction (See Figure C)
When you wish to perform the
clean planning operation, a
chip/dust bag (accessory) can
be used for smaller jobs. Insert
the sleeve of the chip/dust bag
firmly into the chip ejector 5. It
can be connected to the chip
ejection on both sides. Empty
the chip/dust bag at regular
intervals to maintain optimum dust collection. You also can connect a
vacuum cleaner to your tool.
4.3.2 Change of Chip Ejector Side

- 11 -
The chip ejector 5 can
be inserted into the right
or left side. If you want
to change it to the right
or left side, turn the chip
pipe as the figure shows,
pull it out, and change to
another side, insert it,
and lock it.
4.4 Replacing Belt
When you need to change the belt, use a
screwdriver to remove the screw in the belt
cover 9, remove the broken belt, assemble the
new one. Then tighten the screw, check the
belt cover at the correct place or not.
5.OPERATION
CAUTION:
Always be sure that the tool is switched off and unplugged before
adjusting o checking function on the tool.
5.1 Adjusting the Planing Depth
Depth of cut may be adjusted by
simply turning the knob as the figure
on the front of the tool so that the
pointer points to the desired depth of
cut.
The adjustment knob enables
continuously variable adjustment of

- 12 -
the planing depth from 0–2.0 mm using the planing depth scale (scale
graduation = 0.25 mm).
5.2 Park Rest
The park rest 8allows
the machine to be set
down directly after
operation, without danger
of damaging the working
surface or the planer
blade. While planing, the
park rest 8is tilted
upwards thus enabling
full contact of the rear part with the planer base plate
Note: The park rest 8may not be removed.
5.3 Starting Operation
◆Observe correct mains voltage! The voltage of the power source
must agree with the voltage specified on the nameplate of the
machine. Power tools marked with 230 V can also be operated with
220 V.
Switching On and Off
To start the machine, first push the lock-off button for the On/Off switch 6
and then press the On/Off switch 7and keep it pressed.
To switch off the machine, release the On/Off switch 7. To save energy,
only switch the power tool on when using it.
Note: For safety reasons, the On/Off switch 6cannot be locked; it must
remain pressed during the entire operation. To save energy, only switch the
power tool on when using it.
5.4 Working Advice
Planing

- 13 -
Set the required planing depth and place the front part of the planer base
plate against the workpiece.
◆Before any work on the machine itself, pull the mains plug .
◆Apply the machine to the workpiece only when switched on.
Otherwise there is danger of kickback when the cutting tool jams in the
workpiece.
Switch the machine on and guide the machine with even feed over the
surface to be planned.
To achieve high-grade surfaces, work only with low feed and apply
pressure on the centre of the planer base plate.
When machining hard materials (e.g., hardwood) as well as
when utilizing the maximum planer width, set only low planning depths and
reduce planer feed, as required.
Excessive feed reduces the surface quality and can lead to rapid clogging
of the chip ejector.
Only sharp blades achieve good cutting capacity and give the machine a
longer life.
The integrated park rest 8also allows for continued planning at any given
location on the workpiece after an interruption:
– With the park rest folded down, place the machine on the location of the
workpiece where the planning is to be continued.
– Switch on the machine.
– Apply the supporting pressure onto the front part of the planer base plate
and slowly push the machine forward

- 14 -
(). This tilts the park rest upward () so that the rear part of the planer
base plate faces the workpiece again. Guide the machine over the surface
to be planned () with even feed.
5.5 Beveling Edges
The V-grooves in the front planer base plate allow quick and easy beveling
of workpiece edges. Depending on required bevel width, use the
corresponding V-groove. For this, place the planer with the V-groove onto
the edge of the workpiece and guide it along the edge.
5.6 Planing with Parallel Guide
Insert the parallel guide 1 into the
machine ,and using the lock screw 2 fix
the parallel guide, and then push the
machine to work. Guide the planer
applying sideward supporting pressure.
Maintenance and Service
5.7 Maintenance and Cleaning
◆Before any work on the machine

- 15 -
itself, pull the mains plug.
◆For safe and proper working, always keep the machine and
ventilation slots clean.
Ensure easy operation of the park rest 8and clean it regularly.
If the replacement of the supply cord is necessary, this has to be done by
VEVOR or an authorized VEVOR service agent in order to avoid a safety
hazard.

- 16 -
6. DISPOSAL
The machine, accessories and packaging should be sorted for
environmental-friendly recycling.
Do not dispose of power tools as household waste!
Only for EC countries:
According to the European Directive 2012/19/EU for Waste Electrical and
Electronic Equipment and its implementation into national right, power
tools that are no longer usable must be collected separately and disposed
of in an environmentally correct manner.
Made In China

Technical Support and E-Warranty Certificate
www.vevor.com/support
