Viavi OLP-88 User manual

OLP-88/OLP-88P
SmartClass™ Fiber
True PON Tester
Operating manual
BN 2327/98.21
2019.06
English

Please direct all inquiries to your local Viavi sales company. The
addresses can be found at:
www.viavisolutions.com/en-us/contact-sales-expert
A description of additional instrument features can be found at:
www.viavisolutions.com/en-us/products/network-test-and-certification
Notice
Every effort was made to ensure that the information in this document
was accurate at the time of printing. However, information is subject to
change without notice, and Viavi reserves the right to provide an
addendum to this document with information not available at the time
that this document was created.
General Public License
This product includes Qt 4.8.3 software licensed under the GNU LGPL
v. 2.1, and barebox 2013.03.0 and linux 3.1.26 software licensed under
the GNU GPL v. 3. To request a copy of the source code for this software,
please write to:
Open Source Request • Viavi Legal Department •
430 N. McCarthy Blvd. • Milpitas, CA 95035 USA
Copyright
© Copyright 2019 Viavi Solutions Inc. All rights reserved.
Viavi and the Viavi logo are trademarks of Viavi Solutions Inc.
All other trademarks and registered trademarks are the properties of
their respective owners.
Viavi Solutions Deutschland GmbH
Arbachtalstraße 5, D-72800 Eningen u. A.
Order no.: BN 2327/98.21
Version: 2019.06
Previous version: 2019.03
Notes:
Changes may be made to specifications, descriptions and delivery
information.

OLP-88/OLP-88P 3
CONTENTS
CONTENTS
INTRODUCTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
OLP-88/OLP-88P TruePON Testers . . . . . . . . . . . . . . . . . . . . 5
Operating manual update. . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Symbols used in this operating manual . . . . . . . . . . . . . . . . 9
SAFETY INFORMATION . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Warning symbols on the unit . . . . . . . . . . . . . . . . . . . . . . . . 11
Proper usage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Laser safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Battery operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Ventilation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
PS4 Universal AC/DC Power Supply . . . . . . . . . . . . . . . . . . 13
GETTING STARTED . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Unpacking the instrument. . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Connecting optical cables . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
BASIC OPERATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Switching the instrument on/off . . . . . . . . . . . . . . . . . . . . . 25
Operator control panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Menus and display elements . . . . . . . . . . . . . . . . . . . . . . . . 26
Navigating in the menus . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Displaying application information . . . . . . . . . . . . . . . . . . . 29
Changing System Settings . . . . . . . . . . . . . . . . . . . . . . . . . . 30
WiFi menu (optional) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Bluetooth menu (optional) . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Installing a software option . . . . . . . . . . . . . . . . . . . . . . . . . 34
Updating the firmware. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Creating screenshots . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
MANAGING PROJECTS . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Creating a new project. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Editing a project . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Deleting a project . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Activating a project . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
TRUEPON OPERATION . . . . . . . . . . . . . . . . . . . . . . . . . 40
Preparing the TruePON measurement . . . . . . . . . . . . . . . . 40
General view of the TruePON application . . . . . . . . . . . . . 41
Detail views of the TruePON application . . . . . . . . . . . . . . 43
Edit the location/threshold settings . . . . . . . . . . . . . . . . . . 45
Enabling the pass/fail evaluation . . . . . . . . . . . . . . . . . . . . . 45

4 OLP-88/OLP-88P
CONTENTS
Changing the serial number format . . . . . . . . . . . . . . . . . . 45
Saving TruePON test results . . . . . . . . . . . . . . . . . . . . . . . . . 46
PROBE/PCM OPERATION . . . . . . . . . . . . . . . . . . . . . . . . 48
General information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
Patch Cord Microscope (PCM) . . . . . . . . . . . . . . . . . . . . . . . 48
FMAE series adapters for the PCM . . . . . . . . . . . . . . . . . . . 49
Features available with the P5000i Digital Probe . . . . . . . 49
QuickCapture™ key . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
File toolbar. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
Configuring the Digital Probe . . . . . . . . . . . . . . . . . . . . . . . 52
Saving Probe/PCM results . . . . . . . . . . . . . . . . . . . . . . . . . . 56
DATA MANAGEMENT . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
Saving results . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
Data management of TruePON tests . . . . . . . . . . . . . . . . . 58
Data management of Probe and PCM tests . . . . . . . . . . . 61
Exporting results to USB . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64
Making a report . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65
MAINTENANCE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .66
Cleaning the test port . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
Cleaning the instrument . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
REMOTE CONTROL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
ENVIRONMENTAL COMPLIANCE . . . . . . . . . . . . . . . . . . . . 68
SPECIFICATIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70
Functionality . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70
Technical specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70
General specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71
Patch cord microscope specifications. . . . . . . . . . . . . . . . . 71
PS4 Universal AC/DC Power Supply . . . . . . . . . . . . . . . . . . 72
ORDERING INFORMATION . . . . . . . . . . . . . . . . . . . . . . . . 73
OLP-88/OLP-88P stand alone unit . . . . . . . . . . . . . . . . . . . 73
Included items . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73
Hardware options. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73
Software options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73
Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73

OLP-88/OLP-88P 5
OLP-88/OLP-88P TRUEPON TESTERS
1 INTRODUCTION
1INTRODUCTION
OLP-88/OLP-88P TruePON Testers
This manual applies to the models BN 2327/36 and BN 2328/36.
The SmartClass™ Fiber OLP-88/OLP-88P/88P TruePON Tester is
the first compact handheld test instrument that combines
• a professional PON power meter for qualification, activation,
and troubleshooting passive optical networks,
• with automatic pass/fail analysis,
• fiber end face inspection,
• ONU/ONT serial number identification,
• and optional detection of rogue ONUs or ONTs.
The OLP-88/OLP-88P instruments blend a high-performance
-selective FTTx/PON power meter for B-PON, E-PON, G-PON
and automated fiber inspection and test capabilities.
Thanks to the automatic ODN budget class detection, it provides
an immediate pass/fail indication and enables to check if the
network and customer ONUs/ONTs meet expected
specifications at the 1310 nm, 1490 nm, and 1550 nm PON
power levels.
Fig. 1 Performing a measurement in a PON network

6 OLP-88/OLP-88P
1 INTRODUCTION
OLP-88/OLP-88P TRUEPON TESTERS
An integrated pass/fail analysis feature simplifies standard
conformity testing and provides unambiguous measurement
result presentation.
For all G-PON systems the ONU/ONT serial number is
automatically provided. G-PON systems carrying PON-ID1, the
OLP-88/OLP-88P/-88P performs insertion loss measurements
without referencing, auto setting of pass/fail thresholds based
on ODN budget class, and identification of OLT.
Battery operation from AA dry cells or from a rechargeable
Li-Ion Battery Pack ensure long operating time in the field and a
robust, shock-proof design makes the SmartClass™ Fiber
OLP-88/OLP-88P/88P instruments the perfect choice for FTTx/
PON testing, even under tough conditions.
Operation from an AC/DC power supply and remote control
capabilities via USB 2.0 and Ethernet make the SmartClass™
Fiber OLP-88/OLP-88P/88P instruments even a perfect solution
for fixed installations in central offices, in production
environments, and on the laboratory workbench.
Common features
All OLP-88/OLP-88P series PONmeters can connect to single
mode fibers (9/125 µm).
Tests on systems from different manufacturers with different
connector types are easy to handle due to the interchangeable
adapter system.
Connector type
The connection is made with a contact type connector. Make
sure that the connectors used are designated …/APC.
Selective power measurements
All OLP-88/OLP-88P instruments feature a ports to which PON
downstream and upstream links (from OLT, Optical Line
Termination and ONT, Optical Network Termination) can be
connected. The signals at wavelengths 1310 nm, 1490 nm, and
1550 nm are filtered and measured separately. These power
meter ports are calibrated at the respective center wavelength.
1 PON-ID is G-PON system specific information standardized by ITU-T G.984.3
Amendment 3

OLP-88/OLP-88P 7
OLP-88/OLP-88P TRUEPON TESTERS
1 INTRODUCTION
Through path
The through path links the ONT upstream (1310 nm) and OLT
downstream (1490 nm and 1550 nm) signals. Thanks to the low
insertion loss the OLP-88/OLP-88P can be inserted into the PON
network transparently.
Burst power measurements at 1310 nm
The OLP-88/OLP-88P can also be used to measure burst type
signals as found in PON uplink paths at 1310 nm. The average
burst power is displayed independently from the burst duty
cycle (active/idle). This power meter port is calibrated at the
respective center wavelength.
Differences between the Viavi instruments
OLP-37 OLP-87 OLP-88/
OLP-88P
Supported
services
B-PON, G-PON, E-PON X X X
XG-PON test capability – Special
version
–
CATV Video test capability X X X
RFoG test capability X X –
Upstream 1310nm test
capability (through mode)
–XX
Functions Broadband power meter – X –
ONU/ONT identification – – X
ODN budget class detection
and auto threshold setting
––X
In-service loss-test with auto
pass/fail analysis
––X
OLT identification – – X
Alien/rogue ONU/ONT
detection
––X
Fiber
inspection
–OptionOption

8 OLP-88/OLP-88P
1 INTRODUCTION
OPERATING MANUAL UPDATE
Operating manual update
Continuing enhancement and further development of the
SmartClass™ Fiber family may mean that this operating manual
does not cover all the latest functions of your instrument.
If the operating instructions about features provided by your
instrument are missing, please visit the Viavi web site to check if
additional information is available.
To download the latest user manual:
1. Visit the Viavi web site at http://updatemyunit.net.
2. Select your SmartClass™ Fiber model from the product line.
3. Open the download area and download the latest user
manual.

OLP-88/OLP-88P 9
SYMBOLS USED IN THIS OPERATING MANUAL
1 INTRODUCTION
Symbols used in this operating manual
Various elements are used in this operating manual to draw
attention to special meanings or important points in the text.
Symbols and terms used in warnings
The following warnings, symbols and terms are used in this
document in compliance with the American National Standard
ANSI Z535.6-2011:
NOTICE
Follow the instructions carefully to avoid damage or
destruction to the instrument.
CAUTION
Follow the instructions carefully to avoid a low or medium risk
of injury to persons.
WARNING
Follow the instructions carefully to avoid severe injury to
persons.
DANGER
Follow the instructions carefully to avoid death or severe
injury to persons.
High voltage
Follow the instructions carefully to avoid damage to the
instrument or severe injury to persons.
This safety instruction is given if the danger is due to high
voltage.
Laser
Follow the instructions carefully to avoid damage to the
instrument or severe injury to persons.
This safety instruction is given if the danger is due to laser
radiation. Information specifying the laser class is also given.

10 OLP-88/OLP-88P
1 INTRODUCTION
SYMBOLS USED IN THIS OPERATING MANUAL
Warning format
All warnings have the following format:
The following elements are used in this operating manual:
WARNING
Type and source of danger
Consequences of ignoring the warning.
JAction needed to avoid danger.
I Requirement
This requirement must be met first; e.g.
IThe system is switched on.
J
1.
2.
Instruction
Follow the instructions given (the numbers indicate the order
in which the instructions should be followed); e.g.
JSelect mode.
Italics Result
Indicates the result of following an instruction; e.g.
The page opens.
Boldface Pages, controls, and display elements
Screen pages, controls, and display elements are indicated in
boldface.
Text in
blue
Cross references
Cross references are indicated in blue type. When using the
PDF version, just click on the blue text to skip to the cross
reference.
[G]Instrument keys
Instrument keys are indicated within square brackets.
[More]Touchscreen buttons
Touchscreen buttons are indicated within square brackets.

OLP-88/OLP-88P 11
WARNING SYMBOLS ON THE UNIT
2 SAFETY INFORMATION
2SAFETY INFORMATION
Warning symbols on the unit
Proper usage
This instrument is intended for measurements on optical fiber
devices and systems.
JPlease make sure the instrument is not operated outside the
permitted ambient conditions.
JAlways make sure that the instrument is in proper working
order before switching it on.
Warning symbols indicating a potential hazard
JIn all cases where the unit is labeled with a warning symbol,
the operating manual must be consulted to learn more
about the nature of the potential hazard and any action that
must be taken.

12 OLP-88/OLP-88P
2 SAFETY INFORMATION
LASER SAFETY
Laser safety
WARNING
Dangerous laser radiation
Laser radiation can cause irreparable damage to eyes and
skin.
The maximum permitted power for the OLP-88/OLP-88P
means that the optical input signals can reach hazard level.
Bear this in mind when using the OLP-88/OLP-88P. In
particular, the instrument is equipped with a through channel
that transmits all the optical radiation from the input to the
output without attenuation, even when the OLP-88/OLP-88P is
switched off.
JPlease note that also in broadband mode light is emitted at
the unconnected port.
JAlways be aware of the hazard level of the instrument to be
connected.
JConnect all optical fibers before switching on the radiation
source.
JSwitch off the laser source before disconnecting the optical
fibers.
JNever look directly into the unconnected port of the
instrument, the output of a laser source, or an optical fiber
connected to a source or a system.
JAlways cover unused ports.
JBe aware that the emitted light is not visible.
JHeed the normal precautions for working with laser radiation
and consider local regulations.

OLP-88/OLP-88P 13
BATTERY OPERATION
2 SAFETY INFORMATION
Battery operation
Ventilation
PS4 Universal AC/DC Power Supply
Safety class
The PS4 Universal AC/DC Power Supply unit has a protective
isolation that conforms with IEC 60950.
WARNING
Explosion danger
Short-circuiting the batteries can result in overheating,
explosion, or ignition of the batteries and their surround-
ings.
JNever short-circuit the battery contacts by touching both
contacts simultaneously with an electrical conducting object.
JOnly use AA size dry batteries or rechargeable batteries.
JMake sure the batteries are inserted with the correct polarity.
NOTICE
Insufficient ventilation
Insufficient ventilation can damage the instrument or
adversely affect its function and safety.
JEnsure adequate ventilation when operating the instrument.

14 OLP-88/OLP-88P
2 SAFETY INFORMATION
PS4 UNIVERSAL AC/DC POWER SUPPLY
Environmental conditions
NOTICE
Ambient temperature too high/low
Temperatures outside the operating range of 0 to +40 °C
can damage the PS4 Universal AC/DC Power Supply or
adversely affect its function and safety.
JOnly operate the PS4 Universal AC/DC Power Supply
indoors.
The PS4 Universal AC/DC Power Supply must only be
operated at ambient temperatures between 0 and +40 °C.
NOTICE
Insufficient ventilation
Insufficient ventilation can damage the PS4 Universal AC/
DC Power Supply or adversely affect its function and safety.
JEnsure adequate ventilation when operating the PS4
Universal AC/DC Power Supply.
NOTICE
Condensation
Operation in the presence of condensation can damage the
PS4 Universal AC/DC Power Supply or adversely affect its
function and safety.
JDo not operate the PS4 Universal AC/DC Power Supply if
condensation has formed.
JIf condensation cannot be avoided, such as when the PS4
Universal AC/DC Power Supply is cold and is moved to a
warm room, wait until the PS4 Universal AC/DC Power
Supply Unit is dry before plugging it into the AC power line.

OLP-88/OLP-88P 15
UNPACKING THE INSTRUMENT
3 GETTING STARTED
3GETTING STARTED
Unpacking the instrument
Packing material
We suggest that you keep the original packing material. It is
designed for reuse (unless it is damaged during shipping). Using
the original packing material ensures that the instrument is
properly protected during shipping.
Checking the package contents
JUnpack the instrument and check the package contents. For
more information see “Included items” on page 73.
Checking for shipping damage
After you unpack the instrument, check to see if it was damaged
during shipping. This is particularly likely if the packaging is
visibly damaged. If there is damage, do not attempt to operate
the instrument. Doing so can cause further damage. In case of
damage, please contact your local Viavi sales company.
Addresses can be found at www.viavisolutions.com.
Recovery following storage/shipping
Condensation can occur if a instrument that is stored or shipped
at a low temperature is brought into a warm room. To prevent
damage, wait until no more condensation is visible on the
surface of the instrument before powering it up. Do not operate
the instrument until it has reached its specified temperature
range and wait until it has cooled down if the instrument was
stored at a high temperature (see “General specifications” on
page 71).

16 OLP-88/OLP-88P
3 GETTING STARTED
UNPACKING THE INSTRUMENT
Instrument overview
Fig. 2 Front view OLP-88 and OLP-88P
1Patch cord microscope (PCM) with FMAE adapter
2PCM controls: focus control, automated Pass/Fail analysis,
magnification control
3Optical test ports with interchangeable test adapters
4Test head cover (green for APC- and gray for PC connectors)
53.5 inch touchscreen
6Key pad (operator control panel)
7Battery compartment and stand (on rear of instrument)

OLP-88/OLP-88P 17
UNPACKING THE INSTRUMENT
3 GETTING STARTED
Connector panel
Fig. 3 Connector panel
Fig. 4 External power supply connector and communication inter-
faces
1 Optical test port 1: Downstream
Connection to OLT facing side of the PON
2 Optical test port 2: Upstream
Connection to ONU/ONT facing side of the PON
1 Ethernet port (RJ-45)
2 External power supply connector (12 V)
3 USB 2.0 host port (Type A)
4 USB 2.0 device port (Type Micro-B)

18 OLP-88/OLP-88P
3 GETTING STARTED
UNPACKING THE INSTRUMENT
Power supply
The following power sources can be used to operate the
OLP-88/OLP-88P:
• Eight 1.5 V dry batteries
(Mignon AA size, alkaline type recommended)
• Eight 1.2 V NiMH rechargeable batteries
(Mignon AA size, no internal charge)
• PS4 Universal AC/DC Power Supply
•RBP2 LiIon Battery Pack
NOTE: Best Measurement accuracy is achieved when the measurements
are performed in battery mode (w/o AC adapter).
Battery operation
WARNING
Dangers when handling batteries
Handling batteries may be dangerous. Please note the fol-
lowing safety instructions.
JPlease note the battery operation safety information in the
chapter “Battery operation” on page 13.
Replacing batteries
JDo not replace individual batteries. Always change all eight
batteries at the same time.
JAlways use eight batteries of the same type; i.e. do not mix
rechargeable and non-rechargeable batteries.

OLP-88/OLP-88P 19
UNPACKING THE INSTRUMENT
3 GETTING STARTED
Replacing batteries
Fig. 5 Replacing the batteries
The battery compartment is on the back of the instrument.
1. Press down the latch to release and to open the lid of the
battery compartment.
2. Insert new batteries in the tray or remove the used batteries
from the tray and replace all eight with fresh ones.
NOTE: Take care to insert the batteries correctly. The correct polarity is
indicated by a diagram inside the battery compartment.
– or –
Insert new or replace the RBP2 LiIon Battery Pack.
– or –
Switch from non-rechargeable batteries to rechargeable ones
by replacing the battery tray with a new battery pack (or vice
versa).
3. Close the battery compartment.
4. Press the [E] key to switch on.
Recharging the batteries
The rechargeable RBP2 LiIon Battery Pack is recharged when the
PS4 Universal AC/DC Power Supply is being used to power the
instrument. The instrument switches to trickle charging
automatically as soon as the RBP2 LiIon Battery Pack is fully
charged.
1 RBP2 LiIon Battery Pack
2Latch lock
3 AA battery tray

20 OLP-88/OLP-88P
3 GETTING STARTED
UNPACKING THE INSTRUMENT
NOTE: Rechargeable AA batteries will not be recharged in the
instrument. For AA-type rechargeable batteries please use an
external charger.
It is not possible to charge the rechargeable AA batteries or the
RBP2 LiIon Battery Pack via the USB interface.
The instrument is powered by the PS4 Universal AC/DC Power
Supply if the PS4 Universal AC/DC Power Supply and the USB
interface are both connected.
Deep discharge
A rechargeable battery that appears to be dead (unit will not
turn on even when connected to external power) may well be in
a deep discharge state. It can be fully charged with the following
charging cycle:
1. Plug in the power cord for 1–1.5 hours.
Battery should be partly charged now.
2. Switch the power on.
If the instrument starts: Let the battery fully charge.
– or –
If the instrument does not start:
Unplug power cord, plug it back in and repeat steps 1 and 2.
NOTE: If the battery is completely deep-discharged, this cycle might
need to be repeated up to 3 times.
General tips on using batteries
• Always handle batteries with care.
• Do not drop or damage the batteries or expose them to
excessively high temperatures.
• Do not store the batteries for more than one or two days at
very high temperatures (e.g. in a vehicle), either separately or
inserted in the instrument.
• Do not leave discharged batteries in the instrument for a long
time if it is not being used.
