Videx 3000 Series User manual

TECHNICAL SUPPORT
Tel: [phone]
Fax: [phone]
Email: [e-mail]
Web: www.videxuk.com
SERIES
3000
DOOR OPEN
PRIVACY ON
DOOR OPEN
PRIVACY ON
3176
3000 Series Audiophone
QUICK GUIDE
QG_3176_V.1.0_03/17
Door Open button/
concierge call button
Handset speaker
Handset
microphone
Audiophone
Handset
Handset cord
Front cover
retaining
screw
3 level (low,
medium and high)
call tone volume
adjustment
OVERVIEW
Privacy button
Door Open LED
Privacy ON LED
ART. 3176
3000 Series full base "2 wire BUS" digital audiophone which incorprates an
electronic call tone with an adjustable 3 level volume control. It also includes
a "door open" push button with a " door open" LED and privacy button with
privacy ON illumination LED.
For use on the VX2200 digital audio and video systems.
Call tone adjustment: 3 level (low, medium and high) call tone switch.
Privacy button: 1 privacy button (timed).
Privacy adjustments: 1 internal 3 way dip-switch to set the privacy time.
Privacy indication: 1 privacy illumination LED (red).
Door open indication: 1 door open illumination LED (green).
All manuals and user guides at all-guides.com
all-guides.com

ANSWERING A CALL
TO OPEN THE DOOR
To answer an incoming call
pick up the handset.
With the handset lifted a
conversation with the caller
can begin.
To end the call replace the
handset back on the cradle.
During a call
During a
conversation
CALL TONE VOLUME ADJUSTMENT
In every situation
12 3
OPERATING THE PRIVACY BUTTON TECHNICAL ADVICE
For further technical advice and assistance on the
installation of this product please contact Videx technical on
tel: [phone].
For any sales advice and assistance please contact Videx
sales on tel: [phone].
To download a copy of this quick guide visit the Videx
website: www.videxuk.com
In standby
DOOR OPEN
PRIVACY ON
PRIVACY ON
To activate privacy (switch the phone
OFF) press the privacy button. The
privacy LED will switch ON. The phone
will automatically switch ON after the
privacy duration time has expired or to
manually switch the phone ON, press
the privacy button.
With the handset on the cradle
press the lock button once.
The phone will emit a beep, to
indicate a call has been placed to
the concierge.
MAKING A CALL TO THE CONCIERGE
In standby
Wait for the callback from the
concierge. After a brief delay the
phone will ring. When the phone
rings pick up the handset to
answer the call.
A conversation can begin between
the phone and concierge. When
the conversation is nished replace
the handset back on the cradle.
12 3
Move the volume switch to the lower
position to set the call tone volume
to low, to the middle position to set
the call tone volume to medium and
to the upper position to set the call
tone volume to high.
During a conversation, with the
handset lifted, press the lock button
to operate the lock. The door
open LED will illuminate. To end the
call replace the handset back on the
cradle.
12
