Würth SP1 User manual

CL01_3007102005, Rev: 0.60, State: 28. 12. 2022
Adolf Würth GmbH & Co. KG, 74650 Künzelsau
##keep##
For intensive foam cleaning of surfaces and
parts.
Non-runny, rm foam.
• Great cleaning power.
• Loosens stubborn dirt reliably and quickly.
Highly effective.
• Efcient use thanks to visible application of the cleaning
agent.
• Optimum foam yield.
Environmentally-friendly.
Minimal waste water contamination thanks to conservative
use of the cleaning agent.
Easy to use.
Ready for use in a short amount of time.
Two diffusers.
Can be used over small or large areas.
Foam Gun SP1
Details/Application
Cars, trucks, buses, construction machines, land and forestry, vehicle preparation, building facade cleaning, equipment mainte-
nance and much more.
Instructions
##keep##
• Remove loose dirt from the surface to be treated.
• Fill the supply tank of the SP1 Foam Gun with cleaning agent according to the mixing specications from the manufacturer.
• Screw on the appropriate diffuser, depending on the application.
• Connect the compressed air.
• Rotate the green lever to the vertical position to open access to the cleaning agent.
• Cover the object in foam, allow the cleaner to work in (but not dry) and then clean thoroughly with water.
Notice
• Do not use cleaning agents that contain acids, bases and/or are easily ammable.
• We recommend using BMF Cleaner or Absobon Engine Wash. A constant air pressure of 6 – 8 bar is required for optimum
output utilization.

CL01_3007102005, Rev: 0.60, State: 28. 12. 2022
Adolf Würth GmbH & Co. KG, 74650 Künzelsau
IMPORTANT!
After using the SP1 Foam Gun, ll the tank with water and rinse out the gun to remove cleaning agent residue from the unit. Then
turn the green lever to the horizontal position and pull the trigger to remove the remaining water from the unit head.
