WB Mfg Quad XL User manual

wibenchmfg.com 507 E. Grant St. Thorp, WI 54771 • P - 800.242.2303
Specifications are subject to change. Product
images are for illustrative purposes only and may
differ from the actual product.
1
Quad XL
Assembly Instructions
Before you begin, please make sure all parts and proper quantities are included. (See Part Identifier Key) Any parts damaged during shipment must be reported
within 24 hours of receipt. To report information regarding damages or if you have any questions, please call 800.242.2303.
Tools Required
• 4mm Allen
wrench OR
• 4mm Hex bit
• Drill extension
• Phillips drill bit
• Screw gun
• #2 square bit
V062212 Version subject to change
Step 1:
• Place the longer base cabinet upside down on a
protected flat surface with it’s caster base facing
up. (Upon installer’s discretion, remove doors and
shelving before turning cabinets over to lessen the
weight of the cabinets.)
Step 2:
• Align caster with the threaded inserts. (See image to
the right; threaded inserts are marked in red as an
example for assembly instruction ONLY.)
• Use the ⁄-20x25mm joint connector bolts to attach
casters to the base cabinet.
• Repeat for remaining casters. (Make sure you have
two locking and two non-locking casters on this
cabinet.)
Step 3:
• Repeat Steps 1-2 for the two smaller base cabinets.
Step 4:
• With someone’s help, position the cabinets right side
up. Make sure to have the all locking casters’ levers
pushed down to secure cabinet in place.
Step 5:
• Align the pre-drilled holes in cabinet (B) with the
threaded inserts in cabinet (A).
• With cabinets aligned together, connect them with the
⁄-20x30mm joint connector bolt w/ loc tite going
through cabinet (B). Use a 4mm Allen wrench or 4mm
hex bit and a screw gun to tighten.
• Use 4 bolts total to connect cabinet (A) to cabinet (B).
• Repeat Step 5 with the second base cabinet.
Step 5
Steps 1-2
A
B

wibenchmfg.com 507 E. Grant St. Thorp, WI 54771 • P - 800.242.2303
Specifications are subject to change. Product
images are for illustrative purposes only and may
differ from the actual product.
2
Quad XL
Assembly Instructions
Step 6:
• Place top on base cabinets. Align pre-drilled holes
on the base cabinets with threaded inserts in the top.
(There will be two pre-drilled holes in cabinet (A) and
one pre-drilled hole in each of the smaller cabinets.)
• Using a ⁄-20x30mm joint connector bolt, (going
through one of the base cabinets) insert the bolt
through the pre-drilled hole up into the threaded insert
of the top. Use a 4mm Allen wrench or 4mm Hex bit
and a screw gun to fasten the bolt into place.
• Repeat Step 6 for the other base cabinets.
• If shelving and doors were removed, place shelving in
first and then attach the doors.
Step 7:
• Wire pulls are factory installed on the inside of door/s
to prevent damage in transit. (If you have a base
cabinet with double doors, use the clear tab to open
the doors.)
• Unscrew each wire pull handle using a Phillips drill bit
and a screw gun.
Step 8:
• Reattach with wire pull on the outside of the cabinet.
• Repeat for other wire pull.
Step 8
A
Step 6
Step 7*

wibenchmfg.com 507 E. Grant St. Thorp, WI 54771 • P - 800.242.2303
Specifications are subject to change. Product
images are for illustrative purposes only and may
differ from the actual product.
3
Part # Description Qty.
0400236 ⁄x30mm joint connector bolt w/ loctite
(Used to attach 2 smaller base cabinets to the larger base cabinet)
8
(4 per side)
040681 #10⁄” square-drive flat head screw for wood
(Used to attach caster base to the 3 base cabinets)
12
(4 for each base cabinet)
Cast1
0400484 3” heavy duty plate casters w/ out brake 6
(2 for each base cabinet)
Cast1
0400485 3” heavy duty plate casters w/ brake 6
(2 for each base cabinet)
Cast1
04066947 ⁄x25mm joint connector bolt (black)
(Used to apply casters)
48
(16 for each base cabinet)
0400236 ⁄x30mm joint connector bolt (black)
(Used to attach base cabinet to top)
4
(2 for base cabinet w/ doors)
(1 for each base cabinet wo/ doors
Part Identifier Key
Quad XL
Assembly Instructions
