User Manual V2.6 Date: 12/6/2012
Installation of the Interface and Call point
The Interface is housed in a back flanged IP65 Rated Enclosure and can be located and fixed
without having to open the cover or requiring any internal fixings within the enclosure making it
a secure and waterproof Installation giving maximum protection for the control equipment inside.
The Call Point is a two piece fixing with the shield located and fixed and the main Intercom fascia
locked into place and secured via the security fixing on the under frame of the casing and again
providing a very secure vandal resistant and waterproof housing.
The New GSM Intercom WT-9002 has been designed as a system to communicate via a fixed call
Point to either a land line or Mobile using the GSM Network without the requirement of any
cabling from the gate entry to the point of contact and also eliminating the problems that occur
with long range wireless systems as this system has no range barriers as long as an acceptable
GSM-Network is available at the site location.
This system also allows the person called to operate two separate relays using the key pads on
either the Land Line or Mobile Phone regardless of the location or distance apart and these may
represent a gate and a door or entrance lights etc
Other features include a Battery Backup to alert you when the mains power fails at the gate and
the system can also sound an audible alarm in the event the power fails to further alert the
property owner.
Introduction
The system comes with a complete GSM Interface in an IP 65 Enclosure and a Stainless Steel
external Call-Point requiring only a 6 wires connection between the Interface and the Call Point.
The system also has the facility to store up to 1000 authorized users who can access the system
via Mobile phone or Landline and these numbers can be programmed via text messaging or using
the software package provided with the system.
It is also possible to change or override the parameters of both the output relays remotely via
SMS and receive confirmations of these commands and add and remove authorized users without
having to be present on site or again use the software package provided with the system.
GSM Intercom Remote Control and Alarm System
Product Model: WT9002
–
V2.0 2012

2|Page
User Manual V2.6 Date: 12/6/2012
It is advised the distance from the Interface to the Call Point des not exceed 3 meters and it is
also advised to install at least an 8 core in the event you may want to use a backlight version of
the call point or change at a later stage to a Keypad or Camera version available later this year.
Installation and wiring
Once you have located and installed both the Interface and the Call point you will have the 8
cores coming from the Call Point and will require a power source to the unit and the connecting
cables from the Interface to the gate control board to connect into the gate input pulse
connections to activate the gates via the Intercom Interface and again it is advised to run
another 8 core connecting cables in the event you may want to use the secondary relay or the
manual input triggers for the two output relays at a later stage.
Power Supply
The Power supply required needs to be a 12 Volt DC capable of providing 1 amp currant to
enable the battery back-up to remain consistently charged, the system will operate with a 12 Volt
supply but may restrict the charging capability of the battery back up system and therefore the
system may not be able to send power down alerts in the event of a mains power failure.
SIM Card
The system will accept any Universal Network SIM Card and it is essential that you remove any
Pin Code requests from the SIM Card which can be done by placing the SIM Card in an unlocked
Mobile Phone and using the features on most Mobile Phones to disable the Pin Code request as if
the Pin Request is enabled the system will not log on to the network and the unit will refuse to
be programmed and will not function.
In addition it is essential you also disable the Voice Mail function which can be in same case done
again by placing the SIM Card in an unlocked Mobile Phone and contacting your service provider
to remove this function and insure the SIM Card does not accept or store any incoming voice
messages, which can sometimes cause the system to freeze up and stop functioning.
Mobile Phone Credit
It is also essential that the SIM Card is retained with enough credit at all times so as to be able to
make outgoing calls at all times otherwise the system will not operate in the Intercom mode and
obviously make the required outgoing calls even though the access control system will continue
to operate by calling the unit as there is no connection charge for using this function a the
system will continue to accept and implement the commands requested, but will not return the
confirmation SMS Messages until the SIM Card is returned to a credit status
Booting up the System
Once you have inserted the SIM Card in the Holder on the control Board and wired up the system
as per the enclosed diagram, you can now Boot up the system by turning on the unit by using
the Low Voltage Switch on the control board.
The board has two LED Indicator Lights Green as Network and Red as Power on Indicator and
both will initially come on together and the Green LED indicator will oscillate infrequently until it
locates the network and flashes every 4 seconds constantly and the system has successfully
logged on to the network and ready to be programmed for use.

3|Page
User Manual V2.6 Date: 12/6/2012
Hardware Description:
Wiring Diagram:

4|Page
User Manual V2.6 Date: 12/6/2012
To Install the SIM Card you will need to lift up the card carrier and slot in the SIM Card and locate it in place
making sure it is fitting the correct way around with the slot edge matching and face down.
The system would have been supplied with the Battery Back battery connection disconnected for safety
reasons and you will now need to plug this back in and can also plug in the 12 Volt Power supply and switch
the system on using the On/Off Switch.
The visual LCD screen will now show you a network < Search… Wait > message and an < OK >
momentary indication that is has located the required network and the screen will indicate a visual signal
strength, the battery status and if power is applied to the system along with the model number of the system
being the < WT-9002 >.
The Green Network indicator Led located on the LCD board should then also be oscillating every
approximately every 4 seconds continually to confirm the system has registered successfully with the network.
Registering the Administration Numbers to program the system
The system will allow up to 3 administrators to program the unit and these numbers are also the telephone
numbers that the system will call in the order they were programmed in and these are also the telephone
numbers that receive the SMS Text alerts again in the order they were programmed in and default sets the
first telephone number programmed only to receive the text alerts and the other two are set using the
*RERN# as explained later
The system is factory preset as default to allow anybody to be able to program the first Administration
number into the system and after this has been done this is the only initial number that can add the
additional administration numbers and parameters of the system.
Once the second and third administration has been added the original administrator can then be deleted by
one of the other two administrators and this would apply when an engineer would be setting up a customers
site and testing and commissioning the system using his own number, which would be replaced with the
customers number once fully commissioned to the satisfaction of the engineer.
To program the first administer number you would send the following SMS Message to the Unit assuming the
number is 0124806804
Message sent *TEL1#0124806804
The visual screen will light up when this message has been received and if is in the correct format you will
see a momentary indication that confirms it is correct and you will the < OK > and the system will return a
confirmation SMS Message as
Message Received TEL1=0124806804
This is now the first number the system will call when the Intercom call point is activated via the bell push
and the first number that will receive any SMS text alerts and it is possible to toggle these SMS Messaging
alerts OFF and ON using the *RERN# as referred to later.
To program the remaining two administration numbers you would use the same format as with the first
administrator i.e. *TEL2# and *TEL3#
In some situations you may wish to have the system call your home number twice in the event the first call is
not reached in time because of the locations of the Land Line Telephones and thus it is possible to enter the
Installin
g
the SIM Card and Bootin
g
up the system

5|Page
User Manual V2.6 Date: 12/6/2012
same number in both admin 1 and admin 2 slot or even admin 3 can all be the same number of which the
system will call.
The system in this event will call number one and if it is not answered within the time scale set the system
will call the second number and then the third number before abandoning the attempt and logging off.
To check the administrator numbers in the list you would send the following command to unit.
Message Sent *ADM?#
The visual screen will light up when this message has been received and if is in the correct format you will
see a momentary indication that confirms it is correct and you will the < OK > and the system will return a
confirmation SMS Message as
Message received
TEL1
0124806804
TEL2
11111111111
TEL3
11111111111
END
Setting up the Caller ID System to activate security settings
The system will allow the 3 administrators automatic access to the system (Gates) via their Mobile Phone by
just calling the system which activates the output relay one as per the factory default of one second and to
set this function to the active mode you would sent the following SMS Messages to the system.
Message Sent *TEL?#1
The visual screen will light up when this message has been received and if is in the correct format you will
see a momentary indication that confirms it is correct and you will the < OK > and the system will return a
confirmation SMS Message as
Message received TEL-ON
Now if you call the system the Visual Display will show your telephone number and confirm you are an
ADMIN status and activate the relay one as per the default setting of one second.
Now the 3 Administrators can access the system direct via Mobile Phone as well as control the system when
called via the Intercom system.
Setting up the Guest list to be able to access the system
It is possible to allow up to 1000 user numbers to be stored that have access to the system via their Mobile
Phone or Land Line and these numbers can be entered or deleted remotely via SMS Messaging or using the
Soft Ware package provided.
For domestic applications where only a few numbers are to be added it is possibly easier and more
convenient to store them via SMS Messaging.

6|Page
User Manual V2.6 Date: 12/6/2012
To enable the function mode to be able to store the Guest List Numbers you would send the following SMS
Message to the system.
Message sent *ANY?#1
The visual screen will light up when this message has been received and if is in the correct format you will
see a momentary indication that confirms it is correct and you will the < OK > and the system will return a
confirmation SMS Message as
Message received ANY-ON
The system is now ready to accept numbers programmed in as guests who can be entered with no restriction
to the amount of digits in the number and the simple format of programming automatically stores the
number in the correct listing a programming slot
You can enter any number by just adding the number to the following SMS command assuming the number
is 0124806804
Message sent *BOOK#0124806804
The visual screen will light up when this message has been received and if is in the correct format you will
see a momentary indication that confirms it is correct and you will the < OK > and the system will return a
confirmation SMS Message as
Message received BOOK<<4 this number is now store in list 4 and now access the system via their Mobile
Phone by calling the system phone number and the visual display will show the number as a guest when
calling into the system and activate relay one for one second.
Deleting any of the numbers in the Guest List.
To delete any numbers in the Guest list you would simply send the following SMS Command followed by the
telephone number assuming the number is 0124806804
Sent Message *DEL>#0124806804
The visual screen will light up when this message has been received and if is in the correct format you will
see the number 0124806804 displayed a confirmation “END” and the system will return a confirmation
SMS Message as
Message received Delete-OK and the number 0124806804 has now been deleted from the Guest List
and cannot access the system any more.
Delete all phone numbers in the Guest List.
To delete all phone numbers in the Guest list you would simply send the following SMS Command
Sent Message *DELB#
Message received Delete-Book and all the phone numbers have been deleted from the Guest List.

7|Page
User Manual V2.6 Date: 12/6/2012
Setting up the Intercom parameters
The system allows you to adjust certain parameters such as ring time, speaker and Microphone settings etc.
of which may be required to customize certain installations due to site conditions.
Adjusting Call time
To adjust the period of time of the outgoing call from the Call Point it is possible to set the ringing call time
from a period of 20 seconds up to a maximum of 99 seconds before the system moves on to calling the next
telephone number
To set the call time to 25 seconds you would send the following SMS Message to the system
Messages sent *TETI#25
The visual screen will light up when this message has been received and if is in the correct format you will
see a momentary indication that confirms it is correct and you will see the < OK > and the system will return
a confirmation SMS Message as
Message received TETI=<25> and the outgoing call will last 25 seconds before moving on to the next
call and if all three numbers do not respond the system will hang up and disconnect from the network.
Factory default is set at 20 seconds
Adjusting the Talk time
It is possible to set the talk time period of a connected call the system will hold for 1 minute up to a
maximum of 30 minutes before the system disconnect the call automatically.
To limit the talk time to only 5 minutes before the system disconnect the call you would send the following
SMS Message to the system
Messages sent *RITI#5
The visual screen will light up when this message has been received and if is in the correct format you will
see a momentary indication that confirms it is correct and you will see the < OK > and the system will return
a confirmation SMS Message as
Message received RITI=<5> and the connected call will last 5 minutes before it disconnected from the
network.
Adjusting Speaker Volume
It is possible to adjust the Output Speaker Volume via SMS Message from a 0 setting up to 6 (Default value:
5) and to set the speaker volume to level 5 you would send the following SMS Message to the system.
Messages sent *SOUD#6
The visual screen will light up when this message has been received and if is in the correct format you will
see a momentary indication that confirms it is correct and you will the < OK > and the system will return a
confirmation SMS Message as
Message received SOUND<6> and the speaker level has been set to level 6

8|Page
User Manual V2.6 Date: 12/6/2012
Adjusting Speaker Volume
It is possible to adjust the Microphone Volume via SMS Message from a 0 setting up to 9 (Default value: 2)
and to set the Microphone volume setting to level 4 you would send the following SMS Message to the
system.
Message sent *MICO#4
The visual screen will light up when this message has been received and if is in the correct format you will
see a momentary indication that confirms it is correct and you will the < OK > and the system will return a
confirmation SMS Message as
Message received MICO:4 and the Microphone setting is now at level 4
Output Relay Operations
The system has two output relays both factory set as default to latch for one second when operated via the
Intercom mode when being activated via the handset of the person called.
On receiving a call the person called can control both relay one and two using the following keys on their
handset whilst the call is active.
Press * will activate relay one whilst the call is active!
Press # will activate relay two whilst the call is active!
Once the person called has been advised the Gates or door has been activated and allowed access they can
just hang up the call to disconnect the call.
Just hang up the call will terminate the call and disconnect the system from the network.
Changing the Default Relay settings
It is possible to change the Default Relay settings for both relay one and relay two to suit the customers
application and this change of settings is the same settings for when the system is called via caller ID to
activate relay one and the setting when the customer activates relay two via their handset whilst an incoming
call is active using the Intercom.
To change the default setting of relay one to 10 seconds from one second you would send the
following SMS Message to the system
Message sent *EXT1#00010 and the command can be used up to a maximum of 65535 seconds with 5
digits from 00001 to 65535
The visual screen will light up when this message has been received and if is in the correct format you will
see a momentary indication that confirms it is correct and you will the < OK > and the system will return a
confirmation SMS Message as
Message received EXT1=00010 and relay one will latch for 10 seconds when called via caller ID or
latched via the customers handset when called using the *prompt
To change the default setting of relay Two to 360 seconds from one second you would send the
following SMS Message t the system

9|Page
User Manual V2.6 Date: 12/6/2012
Message Sent *EXT2#00360
The visual screen will light up when this message has been received and if is in the correct format you will
see a momentary indication that confirms it is correct and you will the < OK > and the system will return a
confirmation SMS Message as
Message received EXT2=00360 relay two will latch for 360 seconds when latched via the customer’s
handset when called using the #prompt
Temporary latching the relays
It is possible to temporary latch both relays independently without affecting the default settings for a period
of from one second up to a maximum of 65535 and receive SMS Text alerts when the Relays have been
activated and also when they have returned to normal status in the Off mode, subject to the administrators
SMS alert being activated via the *RERN# command.
To Temporary latch relay one for say one hour 3600 seconds you would send the following SMS
Message to the system.
Message sent *RLY1#03600
The visual screen will light up when this message has been received and if is in the correct format you will
see a momentary indication that confirms it is correct and you will the < OK > and the system will show a
counter setting which will visually count down from the 03600 for Relay 1 and return a confirmation SMS
Message as
Message received RLY1=03600 and relay one is active for one hour or 3600 seconds
When the relay has completed the 3600 second cycle you will received a confirmation SMS Message as.
Message received RELY1-OFF and relay one is back to normal status as OFF
To Temporary latch relay two for say one minute or 60 seconds you would send the following
SMS Message to the system.
Message sent *RLY2#00060
The visual screen will light up when this message has been received and if is in the correct format you will
see a momentary indication that confirms it is correct and you will the < OK > and the system will show a
counter setting which will visually count down from the 00060 for Relay 2 and return a confirmation SMS
Message as
Message received RELAY2=00060 and relay one is active for one minute or 60 seconds
When the relay has completed the 60 second cycle you will received a confirmation SMS Message as.
Message received RELY2-OFF and relay two is back to normal status as OFF

10|Page
User Manual V2.6 Date: 12/6/2012
Permanently Latching both Relays
It is possible also to permanently Latch both Relays either on or off independently without affecting the
default settings of either relay
To permanently latch Relay one on you would send the following SMS Message to the system.
Message Sent *FRL1#1
The visual screen will light up when this message has been received and if it is in the correct format you will
see a momentary indication that confirms it is correct and you will the < OK > and will return a confirmation
SMS Message as.
FRL1<ON> and Relay one is permanently latched on
To permanently latch Relay one back off you would send the following SMS Message to the
system.
Message Sent *FRL1#0
The visual screen will light up when this message has been received and if it is in the correct format you will
see a momentary indication that confirms it is correct and you will the < OK > and will return a confirmation
SMS Message as.
FRL1<OFF> and Relay one is permanently latched back off
The same format is used for Relay two using the *FRL2#1 or *FRL2#0 commands.
Setting the SMS Messaging Matrix
The three administrators can all receive SMS text alerts with the factory default set for administrator one only
to receive these SMS text alerts.
These alerts can be toggled either on or off remotely to suit and is done simply with the *RERN# command
as per the following
To set all three administrators to receive the SMS Text alerts you would send the following SMS Message to
the system.
Message sent *RERN#111
The visual screen will light up when this message has been received and if it is in the correct format you will
see a momentary indication that confirms it is correct and you will the < OK > and will return a confirmation
SMS Message as.
RERN<111> and al three administrators will receive SMS text alerts.
To toggle the SMS text alerts on or off you just use the format of *RERN# and use the 0for off and the 1
for the on command
Therefore to toggle so only Admin 2 and 3 receive SMS text alerts the SMS Message sent would be as
*RERN#011 and the return message would be RERN:<011> and only admin 2 and 3 receive the SMS text
alerts

11|Page
User Manual V2.6 Date: 12/6/2012
To check the SMS messaging matrix setting you would send the following SMS Message to the system.
Message sent *RER?#
Setting the Alarm Inputs
The system has 2 alarm inputs that will send SMS text alerts, activating the output relay or sound the siren
output when it triggered and these possible actions can be enabled or disabled independently.
The alarm inputs must be enabled in order to work. To enable the function of alarm input 1 you would send
the following SMS message to the system.
Message sent *CTR1#1
The visual screen will light up when this message has been received and if it is in the correct format you will
see a momentary indication that confirms it is correct and you will see the < OK > and will return a
confirmation SMS Message as
INCTR1=ON and Alarm Input one is enabled
To disable the function of alarm input 1 you would send the following SMS message to the system.
Message sent *CTR1#0
The visual screen will light up when this message has been received and if it is in the correct format you will
see a momentary indication that confirms it is correct and you will see the < OK > and will return a
confirmation SMS Message as
INCTR1=OFF and Alarm Input one is disabled
The same format is used for Alarm Input two using the *CTR2#1 or *CTR2#0 commands.
To check the settings of both alarm input you would send the following SMS message to the system.
Message sent *CTR?#
Setting the Possible Actions for Alarm Input
The alarm inputs can be programmed to send SMS text alerts, activating the output relay or sound the siren
output by enabling the possible actions when the alarm input has triggered.
To enable the possible actions for the alarm inputs you would send the following SMS message format to the
system.
SMS Command Format:
*CTC1#A,M1,M2,S
*CTC2#A,M1,M2,S

12|Page
User Manual V2.6 Date: 12/6/2012
Description:
A stands for the possible action (Selectable) 0 - 4
M1 stands for enable (1) / disable (0) sending of SMS alert *STR[N]#
M2 stands for enable (1) / disable (0) sending of SMS alert *STO[N]#
S stands for enable (1) / disable (0) sounding of audible siren
Selectable Possible Action (A):
Action 0:
-No Action
Action 1:
-Activates Output Relay 1 to stay on
Action 2:
-Activates Output Relay 2 to stay on
Action 3:
-Turn Off Output Relay 1
Action 4:
-Turn Off Output Relay 2
To program alarm input one to switch on output relay 1 and sends SMS text alerts only when
triggered you would send the following SMS Message to the system.
Message Sent *CTC1#1,1,0,0
The visual screen will light up when this message has been received and if it is in the correct format you will
see a momentary indication that confirms it is correct and you will see the < OK > and will return a
confirmation SMS Message as
CTC1=1,1,0,0 and the alarm input 1 has been programmed successfully
To program alarm input one to sends SMS text alerts and sound the siren output when triggered
you would send the following SMS Message to the system.
Message Sent *CTC2#0,1,0,1
The visual screen will light up when this message has been received and if it is in the correct format you will
see a momentary indication that confirms it is correct and you will see the < OK > and will return a
confirmation SMS Message as
CTC2=0,1,0,1 and the alarm input 2 has been programmed successfully

13|Page
User Manual V2.6 Date: 12/6/2012
Input Alarm Message Settings
It is possible to change the Input Alarm display message for both Alarm Input one and Alarm Input two to
suit the customer’s application and the message content can be set up to 50 alphanumeric characters. Only
letters and numbers are allowed, no special characters.
To change the display message for Alarm Input 1 to “Door Opened!” when the input 1 is triggered you
would send the following SMS message to the system.
Message sent *STR1#Door Opened!
The visual screen will light up when this message has been received and if it is in the correct format you will
see a momentary indication that confirms it is correct and you will see the < OK > and will return a
confirmation SMS Message as
STR1<Door Opened!> and the input 1 alarm message has been programmed successfully
To change the display message for Alarm Input 2 to “Gate2 Opened!” when the input 1 is triggered you
would send the following SMS message to the system.
Message sent *STR2#Gate2 Opened!
The visual screen will light up when this message has been received and if it is in the correct format you will
see a momentary indication that confirms it is correct and you will see the < OK > and will return a
confirmation SMS Message as
STR2<Gate2 Opened!> and the input 1 alarm message has been programmed successfully
Input Restoral Message Settings
It is possible to change the Input Restoral display message for both Alarm Input one and Alarm Input two to
suit the customer’s application and the message content can be set up to 50 alphanumeric characters. Only
letters and numbers are allowed, no special characters.
To change the display message for Alarm Input 1 to “Door Closed!” when the input 1 is restored you would
send the following SMS message to the system.
Message sent *STO1#Door Closed!
The visual screen will light up when this message has been received and if it is in the correct format you will
see a momentary indication that confirms it is correct and you will see the < OK > and will return a
confirmation SMS Message as
STO1<Door Closed!> and the input 1 restoral message has been programmed successfully
To change the display message for Alarm Input 2 to “Gate2 Closed!” when the input 1 is restored you
would send the following SMS message to the system.
Message sent *STO2#Gate2 Closed!
The visual screen will light up when this message has been received and if it is in the correct format you will
see a momentary indication that confirms it is correct and you will see the < OK > and will return a
confirmation SMS Message as

14|Page
User Manual V2.6 Date: 12/6/2012
STO2<Gate2 Closed!> and the input 1 restoral message has been programmed successfully
Input Trigger Delay Time Setting

The system will report the state of all inputs when any input changes state for longer than a
programmable trigger time. The trigger time of each alarm input is programmable and can be varied from
a minimum of 0.1 second to a maximum of 6553.5 seconds. Any change that does not remain stable for
the specified trigger time will be ignored. The factory default trigger time is 1 seconds.
To change the default setting of input one trigger delay time to 10 seconds you would send the
following SMS Message to the system
Message sent *DLY1#00100 and the command can be used up to a maximum of 65535 seconds with 5
digits from 00001 to 65535
The visual screen will light up when this message has been received and if is in the correct format you will
see a momentary indication that confirms it is correct and you will see the < OK > and the system will return
a confirmation SMS Message as
Message received DLY1=00100 and input one will alarm when it has triggered for 10 seconds.
Power down Alarm
The system has a built in function that will both send a SMS text alert and sound a siren output in the event
of a mains power failure at the gate and both these functions can be enabled or disabled independently.
To disable the Power down SMS text alerts for the power down function you would send the following SMS
message to the system.
Message sent *ALAC#0
The visual screen will light up when this message has been received and if it is in the correct format you will
see a momentary indication that confirms it is correct and you will see the < OK > and will return a
confirmation SMS Message as.
Message received ALAC-OFF and the power down SMS Messaging function has been disarmed
To enable this function again you would send the following SMS Messages to the system
Message Send *ALAC#1
The visual screen will light up when this message has been received and if it is in the correct format you will
see a momentary indication that confirms it is correct and you will see the < OK > and will return a
confirmation SMS Message as.
Message received ALAC-ON the power down SMS messaging function has been re-armed.

15|Page
User Manual V2.6 Date: 12/6/2012
Power down Siren Output
The system also has a Siren output which is activated also when the power supply is removed for more then
5 seconds and this function activates and sounds the connected siren.
The time period of the alarm can be programmed from 1 second up to a maximum of 18 hours or 65535
seconds and can also be armed or disarmed remotely
To set the alarm run time to say 900 seconds you would send the following SMS Messages to the
system.
Message Sent *ALTM#00900
The visual screen will light up when this message has been received and if it is in the correct format you will
see a momentary indication that confirms it is correct and you will see the < OK > and will return a
confirmation SMS Message as.
Message received *ALTM<00900 and the Siren will sound for 900 seconds every time the power is
removed for more then 5 seconds
To disarm this function you would send the following SMS Message to the system.
Messages sent *ALNF#0
The visual screen will light up when this message has been received and if it is in the correct format you will
see a momentary indication that confirms it is correct and you will see the < OK > and will return a
confirmation SMS Message as.
Message received ALNF-OFF and the Siren alarm function has been disabled
To enable the Siren Alarm Function you would send the following SMS Message to the system
Message sent *ALNF#1
The visual screen will light up when this message has been received and if it is in the correct format you will
see a momentary indication that confirms it is correct and you will see the < OK > and will return a
confirmation SMS Message as.
Message received ALNF-ON and the Siren alarm function has been rearmed.
Check the Alarm Settings
It is possible to also check the settings of the alarm by sending the following SMS Message to the system.
Message sent *ALA?#
The visual screen will light up when this message has been received and if it is in the correct format you will
see a momentary indication that confirms it is correct and you will see the < OK > and will return a
confirmation SMS Message as.

16|Page
User Manual V2.6 Date: 12/6/2012
Message received
ALM1:ON/OFF
ALM2:ON/OFF
ALAC:ON/OFF
ALTM:<00600> or similar
Check the Signal Strength
It is possible to also check the actual signal strength of the system at its present location by sending the
following SMS Message to the system.
Message sent *CSQ?#
The visual screen will light up when this message has been received and if it is in the correct format you will
see a momentary indication that confirms it is correct and you will see the < OK > and will return a
confirmation SMS Message as.
Message received CSQ <22> or similar
The signal scale of registration can be from as low as < 2 > - < 3> up to a maximum of < 31 > and for
optimum voice quality it is suggested you insure the signal strength at the location exceeds at least < 9 > or
< 10 > and it is possible to use an extension antennae to improve the signal strength if required.
Check the System Status
It is possible to also check the system status by sending the following SMS Message to the system.
Message sent *TEST#
The visual screen will light up when this message has been received and if it is in the correct format you will
see a momentary indication that confirms it is correct and you will see the < OK > and will return a
confirmation SMS Message as.
Message received TEST<OK> means the GSM network is ON and the system is working
Time Setting
To set the time, you can send the following SMS command to the unit. The time must enter in 24 Hour
format.
SMS Command Format:
*TSET#SS,MM,HH;
SS is a 2 digits value stand for seconds
MM is a 2 digits value stands for minutes
HH is a 2 digits value stand for hours
For example to set the time 8.00am, you would send *TSET#00,00,08; to the unit and the
unit will return the following SMS text message TSET=00,00,08;

17|Page
User Manual V2.6 Date: 12/6/2012
Learning Mode for Remote Controls
It is possible to add remote controls for the system to do so you must have additional identical remote
control with you. To program them to the system, you would send the following text command to the
unit
Messages sent *LERN#
The visual screen will light up when this message has been received and you may press any button on the
remote control if it is programmed and you will see the < OK > and will return a confirmation SMS Message
as.
Message received LEARN-OK and the remote control is programmed successfully
Otherwise Message received LEARN-FAIL
Changing the Password
It is possible to change the 6-digits password of the system. To do this you would send the following SMS
message to the system
Message sent *PAWO#654321
The visual screen will light up when this message has been received and if it is in the correct format you will
see a momentary indication that confirms it is correct and you will the < OK > and will return a confirmation
SMS Message as.
Message Received PAWO-OK and the system is now back in factory default and ready to reprogram.
Reset the System
Passwords are requires to access the system and for resetting the system back to factory default and this
may be required if the user wants to relocate the user or has managed to freeze up the system or lost access
to the control f the system.
Therefore as with most electronic systems the factory reset will re-formulate and program the system to
factory default and you can start again.
To do this you would send the following SMS Message to the system
Message sent *REST#123456
The visual screen will light up when this message has been received and if it is in the correct format you will
see a momentary indication that confirms it is correct and you will the < OK > and will return a confirmation
SMS Message as.
Message Received REST-OK and the system is now back in factory default and ready to reprogram.

18|Page
User Manual V2.6 Date: 12/6/2012
List of S.M.S Commands
*
*
*TEL1#
ReturnMessage
TEL1=<PhoneNumber>
ProgrammingFunction
<PhoneNumber1>
SMSCommand
*TEL3#
Add Administrator1
*TEL2#
*TEL?#
*ANY?#
Add Administrator2
Add Administrator3
<PhoneNumber2>
<PhoneNumber3>
TEL2=<PhoneNumber>
TEL3=<PhoneNumber>
AdminCallerIDaccessON TEL‐ON1
*TEL?#0
1
AddGuestListIDNumber
AdminCallerIDaccessOFF TEL‐OFF
GuestlistCallerIDaccessON ANY‐ON
*ANY?#0GuestlistCallerIDaccessOFF ANY‐OFF
*BOOK#
*DEL>#
*TETI#
*SOUD#
*EXT1#
*MICO#
GuestNumberBOOK<PhoneNumber>
GuestNumberDeleteGuestListIDNumber Delete‐OK
20‐59
0‐6
0‐9
<00000‐65535>
<00000‐65535>
SetMicro
p
honelevelfrom1‐9
Chan
g
edefaultRela
y
onetime
Chan
g
edefaultRela
y
twotime
SetS
p
eakerVollevelfrom1‐6
Setcall timeinSeconds TETI=<ValueinSecs>
SOUD<Value>
MICO: <Value>
EXT1=<Value>
EXT2=<Value>*EXT2#
EXT1andEXT2Canbeconfi
g
uredfrom00001<1sec>u
p
to<65535>65,535seconds
*RLY1#<00000‐65535>Tem
p
LatchRela
y
oneinSeconds RLY1=<Value>
*RLY2#<00000‐65535>Tem
p
LatchRela
y
twoinSeconds RLY2=<Value>
RLY1andRLY2Canbeconfi
g
uredfrom00001<1sec>u
p
to<65000>65,535seconds
*FRL1#
*FRL1#
*FRL2#
1Permanentl
y
LatchRela
y
oneON FRL1‐ON
0
1
Permanentl
y
LatchRela
y
oneOFF
*FRL2#
<000><111>
TheMatrixto
p
ro
g
ramthe3adminnumbersisastheorderofTEL1TEL2TEL3<Oisoffand1ison>
0
*RERN#Pro
g
ramAdminMessa
g
in
g
Matrix RERN<Matrix>
Permanentl
y
LatchRela
y
twoON
Permanentl
y
LatchRela
y
twoOFF
FRL1‐OFF
FRL2‐ON
FRL2‐OFF
*DELB#DeleteAllGuestListNumbers Del‐Book
*RITI#1‐30SettalktimeinMinutes RITI=<ValueinMins>
*CTR1#1EnableAlarmIn
p
ut oneINCTR1‐ON
*CTR1#0DisableAlarmIn
p
ut oneINCTR1‐OFF
*CTR2#1EnableAlarmIn
p
ut two INCTR2‐ON
*CTR2#0DisableAlarmIn
p
ut two INCTR2‐OFF
*CTR?#  Checkthesettin
g
sofbothalarmin
p
uts INCTR1:ONCTC1:2INCTR2:ON..
*CTC1#A,M1,M2,SSetthe
p
ossibleactionsforalarmin
p
ut1CTC1=1,1,0,0
*CTC2#A,M1,M2,SSetthe
p
ossibleactionsforalarmin
p
ut2CTC2=1,1,0,0

19|Page
User Manual V2.6 Date: 12/6/2012
*ALAC#
ALAC‐ON
0
1*ALAC#TurnPowerdownTextAlertsOf
f
*ALTM#
*ALNF#
<00000‐65535>
1
ALTM:<Value>SetAlarmSirenRuntime
0
TurnPowerdownTextAlertsOn ALAC‐OFF
TurnSirenAlarmFunctionOn ALNF‐ON
ALTMCanbeconfi
g
uredfrom00001<1sec>u
p
to <65535>65,535 Factor
y
defaultis10minutes<600secs>
*ALNF#TurnSirenAlarmFunctionOf
f
ALNF‐OFF
Please be aware the factory reset *REST#123456 will erase the complete memory and you
will need to program the system from the beginning again!
Hand Set Functions
These are the functions the person called from the Intercom can control via their handset using the following
p
rom
p
ts whilst the tele
p
hone call is live
*
#
Will activate Relay one when these prompts are used when a call is live
Will activate Relay two when these prompts are used when a call is live
*STR1#“Messa
g
eContent” Chan
g
ethetextfor alarmin
p
ut1tri
gg
er STR1<messa
g
econtent>
*STR2#“Messa
g
eContent” Chan
g
ethetextforalarmin
p
ut2tri
gg
er STR2<messa
g
econtent>
*STO1#“Messa
g
eContent” Chan
g
ethetextforalarmin
p
ut1restore STO1<messa
g
econtent>
*STO2#“Messa
g
eContent” Chan
g
ethetextforalarmin
p
ut2restore STO2<messa
g
econtent>
*DLY1#
*DLY2#
<00000‐65535>
<00000‐65535>
SettheIn
p
ut1tri
gg
erdela
y
time
SettheIn
p
ut2tri
gg
erdela
y
time
DLY1=<Value>
DLY2=<Value>
DLY1andDLY2Canbeconfi
g
uredfrom00001<0.1sec> u
p
to<6553.5>65,535seconds
*ALA?#  ChecktheAlarmSettin
g
sALM1:ONALM2:ONALAC:ON…
*CS
Q
?#  ChecktheSi
g
nalStren
g
th CS
Q
<0>toCS
Q
<31>
*TEST#  ChecktheS
y
stemStatus TEST<OK>
*TSET#SS
,
MM
,
HH
;
TimeSettin
g
TSET=<Value>
*LERN#  Learnin
g
ModeforRemoteControl LEARN‐OK
/
LEARN‐FAIL
*REST#123456
*PAWO#123456Chan
g
ePassword
ResettoFactor
y
Default
PAWO‐OK
REST‐OK

20|Page
User Manual V2.6 Date: 12/6/2012
Specifications
Dual Band (900/1800Mhz) or Quad Band Module (850/900/1800/1900Mhz)
Power Supply: 15 Volts DC 1 Amp supply
Operating Temperature - 25 to 55°C
Humidity Less than 95% RH
Lightning Protector: 3-5W
2 Output relays normally open 120VAC/24VDC 1 amp.
Can call up to 3 numbers outbound.
Battery back-up for up to 8 hours.
Caller ID for up to 1000 users.
Connections for manual operation of both output relays.
Programmable via SMS or software.
LCD for site programming and diagnostic status of system.
Facility to switch off modem and retain hard wired Intercom if applicable.
Comes in IP 65 enclosure with external flange mounting.
C.E Approval
Warranty Terms
Witura Corporation Sdn. Bhd. shall warrant all WT-9002 GSM Access Control Systems against defective parts and workmanship
for 1 year. Witura Corporation Sdn. Bhd. shall, at its discretion, repair or replace the defective equipment upon the return of
such equipment to any Witura branch. This warranty applies ONLY to defects in components and workman-ship and NOT to
damage due to causes beyond the control of Witura, such as incorrect voltage, lightning damage, mechanical shock, water
damage, fire damage, or damage arising out of abuse and improper application of the equipment.
Note: Wherever possible, return only the PCB to Witura Service Centres.
DO NOT return the enclosure.
The WT-9002 IP65 is a product of
Witura Corporation Sdn Bhd
And is
manufactured in Malaysia
Copyright Witura Corporation Sdn. Bhd. 2012 all rights reserved
