WOOSIM WSP-SM40 User manual

http://www.woosim.com
MODEL WSP-SM40
(2inch Mobile Printer)
Rev. 1.2
All specifications are subjected to change without notice

WSP-SM40 Rev. 1.2
http://www.woosim.com
2
 Copyright
WSP-SM40 2inch Mobile printer operator’s manual.
Copyright ⓒ2017 by Woosim Systems Inc.
All rights reserved.
The information contained in this manual is the property of Woosim Systems Inc.
And may not be reproduced in whole or in part without the prior written permission of Woosim
Systems Inc.
 Trademark
a registered trademark of Woosim Systems Inc.
All other trademark are the properties of their respective companies.
 Caution
Some semiconductor devices are easily damaged by static electricity. You should turn the printer
“OFF”, before you connect or removed the cable on the rear side, in order to guard the printer
against the static electricity.
If the printer is damaged by the static electricity, you should turn the printer “OFF”
 Notice
The contents of this manual are subject to change without notice.

WSP-SM40 Rev. 1.2
http://www.woosim.com
3
 Introduction
The WSP-SM40 is the ideal solution for Mobile banking system , Retail,
point of sales, Credit card Transaction, other traveling and mobile computing etc.
The general features of WSP-SM40 printer are as follows:
Pocket size (80.9×113.5×47.1mm)
Light weight(247g) for true mobility
Very silent printing thru direct thermal printing method
High speed (85mm/sec, MAX)
High resolution(203dpi : 8dots/mm).
UART(RS-232C or TTL), Bluetooth Ver3.0 interface
Support Graphic LCD(128×32dots) with Blue LED Backlight
Support Magnetic Stripe Reader & Smart Card Module
Support text and graphic printing
Intutive LED’s indicate Power(on/off), Error and Battery status
Easier paper roll loading by CLAMSHELL design
One touch paper cover
Printer door open & Paper-out sensor
Easier maintenance with self-diagnostic.
In field programming –Update Firmware, Download Fonts and Logos
Microsoft Windows/Windows CE, Linux, Android, iOS compatible
Flow control : Software (XON/XOFF)
※Hardware flow control not supported in printer.
Free fall: 1.5 meter onto concrete
Agency Approvals

WSP-SM40 Rev. 1.2
http://www.woosim.com
4
 Operating Precautions
Please follow the precautions below to enjoy and maintain the full performance of the printer.
Using the Printer
● Be careful not to drop or bump the printer on a hard surface.
● Do not install the printer in direct sunlight or such areas.
Suitable environment for the use of the printer is as follows:
◆ Operating temperature :-10°C to 50°C
◆ Relative humidity : 30% to 80%
● Do not install the printer near devices that generate strong electromagnetic fields
such as a copy machine.
● Do not open the platen cover during printing .
● Do not remove or reinstall the communication cable during printing or transmission.
● Do not touch the connectors of the communication during printing.
● Switch the POWER OFF when not in use.
● Do not use alcohol or other solvent.
●The AC adapter, the battery charger and the battery pack may become warm when in use.
This is normal and is not a malfunction.
● When the battery pack is used at low temperature, the length of time the printer can be used
may be shortened.
Thermal Paper Handling
● Store the thermal paper in a cool, dry and dark place.
● Do not rub the paper with hard object.
● Do not leave the paper with hard object.
● Do not allow plastic film, erasers, or adhesive tape to touch the paper for long periods.
● Do not stack the thermal paper with diazo copies immediately after copying or wet-type copies.
● Do not use chemical glue.
●Always use the clean thermal paper.

WSP-SM40 Rev. 1.2
http://www.woosim.com
5
CONTENTS
1. Outline. ................................................................................................................................................................ 6
1.1. Model classifications................................................................................................................................. 6
1.2 Product Part Number System................................................................................................................... 6
1.3. Specifications. ............................................................................................................................................ 7
2. Setting up the printer....................................................................................................................................... 9
2.1. Printer & Accessories................................................................................................................................ 9
2.2. Printer Features ........................................................................................................................................10
2.3. Dimensions................................................................................................................................................11
2.4. Replacing paper roll.................................................................................................................................12
2.5. Power supply ............................................................................................................................................13
2.5.1. Specified power supply.................................................................................................................13
2.5.2. Installing the battery .....................................................................................................................13
2.5.3. Recharging the battery pack........................................................................................................14
2.6. Set operation mode.................................................................................................................................15
3. Interface ..............................................................................................................................................................19
3.1. UART(RS-232C or TTL).............................................................................................................................19
3.2. Bluetooth...................................................................................................................................................20
3.3. Magnetic stripe card Reading & IC Card insert ...................................................................................20
4. Smart Card Module..........................................................................................................................................21
4.1. General Spec.............................................................................................................................................21
4.2. Inserting the SAM card ...........................................................................................................................21
4.3. Communication Protocol Sequence.......................................................................................................22
4.3.1. Regular Operation .........................................................................................................................22
4.3.2. Irregular Operation (Communication Error)................................................................................22
5. Using the printer...............................................................................................................................................23
5.1. Control panel. ...........................................................................................................................................23
5.2. The self test ..............................................................................................................................................24
6. Consumable Parts.............................................................................................................................................25
6.1. Recommended paper...............................................................................................................................25
6.2. Printing position. ......................................................................................................................................25
7. Revision History ................................................................................................................................................26

WSP-SM40 Rev. 1.2
http://www.woosim.com
6
1
1. . O Ou ut tl li in ne e. .
1
1. .1 1. . M Mo od de el l c cl la as ss si if fi ic ca at ti io on ns s. .
1
1. .2 2 P Pr ro od du uc ct t P Pa ar rt t N Nu um mb be er r S Sy ys st te em m
WSP-SM40 ( ) ( )
Model
Interface
A1 : UART/Bluetooth
Power
None : DC 8.4V
Model name / Interface Spec.
Example) 1. Porti-S40 Serial/Bluetooth Part No. ⇒S40/A1
2. Porti-SC30 Bluetooth Only Part No. ⇒SC30/Z1
Note) The above table is the interface format which is supported.
But some of the interfaces are not supported according to the product
and please contact us, if you have any questions regarding the interface.
S40
SC30
W25
.
.
.
Wired
Wireless
A
RS-232C
1
Bluetooth
B
TTL
2
IrDA
C
USB
3
Wireless LAN
D
RS-485
0
None
E
Parallel
Z
None

WSP-SM40 Rev. 1.2
http://www.woosim.com
7
1
1. .3 3. . S Sp pe ec ci if fi ic ca at ti io on ns s. .
Item
Specifications
Print method
Direct thermal line printing
Characters per line
42cpl (MAX)
Character size
Eng: 9*24dots, 12*24dots Kor: 16*24dots, [24*24dots]
Optional Characters
Simplified/Traditional Chinese, Arabic, Cyrillic, Russian,
Tukish, Greek, Japanese, Persian, Latin9 and Others upon request.
Resolution
203dpi, 8dots/mm
Print width
2-inch (48mm, 384dots)
Print speed
85mm / sec (MAX)
Dimension
80.9×113.5×47.1mm
Weight (w/o paper)
247g
Interface
UART(RS-232C or TTL), Bluetooth Ver3.0
Paper roll
Thermal roll paper (57mm wide, 40ø)
Barcodes
1-dimension : UPC-A, UPC-E, EAN-8, EAN-13, CODE-39, CODE-93,
CODE-128, ITF, CODABAR
2-dimension : PDF417, Micro PDF417, Truncated PDF417, QR-CODE,
DATA Matrix, Maxicode
Etc :GS1 databar
Driver
Microsoft Windows, Linux
H/W Spec
MCU : RX-32bit, RAM : 128M bit, FLASH : 64M bit
Receive buffer size
1M bytes
Sensor
Support Paper, Label
MSR
ISO 7810 / 7811 / 7812 1&2 or 2&3 Track Reading
Smart Card Module
ISO 7816 Compliant (EMV level 1/2 Certified) /
T=0, T=1 support / 2 SAM (Security Application Module)
LCD
128×32 Dots FSTN (Blue LED Backlight)
Battery
Rechargeable 7.4V DC, 1100mAh (Li-ion)
Battery duration
1 hour continuous printing
Battery charger
Input (100~250V AC, 50~60Hz)
Output(8.4VDC/0.8A), 4hours full charge time
( Continue…)

WSP-SM40 Rev. 1.2
http://www.woosim.com
8
Item
Specifications
Environment
conditions
Temperature
-10°C ~ 50°C (operating)
-10°C ~ 70°C (storage)
Humidity
30% - 80% (operating)
10% - 90% (storage)
MCBF(Mean Cycle
Between Failure)
Mechanical
37,000,000 lines
Head
Approximately 50 Km
< Table 1 >

WSP-SM40 Rev. 1.2
http://www.woosim.com
9
2
2. . S Se et tt ti in ng g u up p t th he e p pr ri in nt te er r. .
2
2. .1 1. . P Pr ri in nt te er r & & A Ac cc ce es ss so or ri ie es s
Your printer box should include these items. If any items are damaged or missing, please
contact your dealer for assistance.
WSP-SM40
Battery Pack
▼ OPTIONAL
Communication cable
External Battery Cradle
Car Charger
Thermal roll paper
Battery charger adaptor
2 SAM

WSP-SM40 Rev. 1.2
http://www.woosim.com
10
2
2. .2 2. . P Pr ri in nt te er r F Fe ea at tu ur re es s
▶Part Name
