Wren ROBE UNIT Instructions for use

ROBE UNIT
Sliding Robe Construction Guide
For Internal Use: WBIN00024_Sliding_Robe_Construction_Guide_Rev3 Page 1
2 Door configuration shown
for illustration purposes. Other
configurations available.

ROBE UNIT
Sliding Robe Construction Guide
For Internal Use: WBIN00024_Sliding_Robe_Construction_Guide_Rev3 Page 2
BEFORE YOU START
INSTALLATION SHOULD BE PERFORMED BY A COMPETENT PERSON ONLY.
THIS PRODUCT COULD BE DANGEROUS IF INCORRECTLY INSTALLED
8mm
Hex Key

ROBE UNIT
Sliding Robe Construction Guide
For Internal Use: WBIN00024_Sliding_Robe_Construction_Guide_Rev3 Page 3
Top Roller (Inside)
1 x LH / 1 x RH
Up dampers
2 x Per Door
Bottom Roller (Inside)
1 x LH / 1 x RH
Per Door
Damper Stoppers
2 x Per Door
Top Track
(Quantity depends
on Customer Specific
Bedroom Plan)
Top Track Damper
Stoppers
2 x Per Door
15mm Screws
(20 Per Door supplied
with mechanisms)
4.0 x 30mm Screws
(x 16)
Top Roller (Outside)
1 x LH / 1 x RH
Bottom Roller (Outside)
1 x LH / 1 x RH
Per Door
Bottom Track
(Quantity depends
on Customer Specific
Bedroom Plan)
Drilling Position
Template
(x 1)

ROBE UNIT
Sliding Robe Construction Guide
For Internal Use: WBIN00024_Sliding_Robe_Construction_Guide_Rev3 Page 4
Step 2.
Using the drilling template mark positions ‘A’ on the bottom inside face of the internal door. Min distance
from the edge of door = 125mm
Step 3.
Using 4 x 15mm screws attach ‘Bottom Roller’ (Inside) to the door.
AA
A A
Min. Distance = 125mm
Step 1.
Complete the Robe Construction and secure to the wall following the ‘Robe Unit Assembly Guide’
provided with the robe units. Install the plinth provided following standard procedure.

ROBE UNIT
Sliding Robe Construction Guide
For Internal Use: WBIN00024_Sliding_Robe_Construction_Guide_Rev3 Page 5
Step 4.
Repeat steps 2 + 3 for other side of the door.
Step 5.
Using drilling template, mark positions ‘B’ on the inside face on the top of the door. Min distance from the
edge of the door = 50mm.
Step 6.
Using 6 x 15mm screws attach the ‘Top Roller’ (Inside) to the door.
B
B B B B B
B
Min. Distance
= 50mm

ROBE UNIT
Sliding Robe Construction Guide
For Internal Use: WBIN00024_Sliding_Robe_Construction_Guide_Rev3 Page 6
Step 7.
Loosen external screw and position ‘up damper’ in place. Once positioned, re-tighten the external screw.
1.
1.
2.
2.

ROBE UNIT
Sliding Robe Construction Guide
For Internal Use: WBIN00024_Sliding_Robe_Construction_Guide_Rev3 Page 7
Step 8.
Slide activation stop to ‘un-activated’ position.
Step 9.
Press anti-jumping device lever to unlocked position.
Step 10.
Repeat steps 5 - 9 for other side of the door.

ROBE UNIT
Sliding Robe Construction Guide
For Internal Use: WBIN00024_Sliding_Robe_Construction_Guide_Rev3 Page 8
Step 11.
Using the drilling template, mark positions ‘A’ on the bottom of the external door. Min distance from edge
of door = 125mm.
AA
A A
Step 12.
Using 4 x 15mm screws attach bottom roller to the door. (Outside roller conguration.)
Min. Distance = 125mm

ROBE UNIT
Sliding Robe Construction Guide
For Internal Use: WBIN00024_Sliding_Robe_Construction_Guide_Rev3 Page 9
Step 13.
Using drilling template, mark positions ‘B’ on inside face on the top of the door. Min distance from the
edge of the door = 50mm.
Step 14.
Using 6 x 15mm screws attach the top roller (Outside) to the door.
B
B B B B B
B
Min. Distance
= 50mm

ROBE UNIT
Sliding Robe Construction Guide
For Internal Use: WBIN00024_Sliding_Robe_Construction_Guide_Rev3 Page 10
Step 15.
Loosen external screw and position ‘up damper’ in place. Once positioned re-tighten the external screw.
1.
1.
2.
2.

ROBE UNIT
Sliding Robe Construction Guide
For Internal Use: WBIN00024_Sliding_Robe_Construction_Guide_Rev3 Page 11
Step 16.
Slide activation stop to ‘un-activated’ position.
Step 17.
Press anti-jumping device lever to unlocked position.
Step 18.
Repeat steps 11 - 17 for other side of the door.

ROBE UNIT
Sliding Robe Construction Guide
For Internal Use: WBIN00024_Sliding_Robe_Construction_Guide_Rev3 Page 12
Step 19.
Cut top and bottom tracks to length. (See customer specic bedroom plan for details.)
Step 20.
Position front and back ‘Top Track Damper Stoppers’ in both ends of the top track. Do not tighten until
step 32.
TOP TRACK

ROBE UNIT
Sliding Robe Construction Guide
For Internal Use: WBIN00024_Sliding_Robe_Construction_Guide_Rev3 Page 13
Step 21.
Position front and back ‘Damper Stopper’ in both ends of the bottom track. Do not tighten until step 32.
Step 22.
Place the top track on top of the unit and push it back so that the retaining stop is tightly pressed to the
front of the top xed shelf.
BOTTOM TRACK

ROBE UNIT
Sliding Robe Construction Guide
For Internal Use: WBIN00024_Sliding_Robe_Construction_Guide_Rev3 Page 14
Step 23.
Mark the underside on the top xed shelf 25mm from the front.
Step 24.
Predrill the marked line every 400mm with a 3.5mm drill bit and using (4.0 x 30mm countersunk) screws
attach the top track to the top of the xed shelf.
25mm
400mm

ROBE UNIT
Sliding Robe Construction Guide
For Internal Use: WBIN00024_Sliding_Robe_Construction_Guide_Rev3 Page 15
Step 25.
Position the drilling template at the end of the base xed shelf in contact with the end panel. Using
position ‘C’ drill a 5mm hole. Repeat for both sides of each unit in the run.
Step 26.
Position the bottom track below the bottom xed shelf. Make sure that the retaining stop on the bottom
track is pushed tightly to the front of the xed shelf.
Step 27.
Using (4.0 x 30mm countersunk) screws attach the bottom track to the bottom of the bottom xed shelf.
C

ROBE UNIT
Sliding Robe Construction Guide
For Internal Use: WBIN00024_Sliding_Robe_Construction_Guide_Rev3 Page 16
Step 28.
Lift inside door assembly on to the top of the outside track.
Step 30.
Press levers on ‘Bottom Rollers’ to raise the wheels onto the bottom track (front).
Step 29.
Press ‘anti-jumping’ device on both top rollers to secure the door to the top track.

ROBE UNIT
Sliding Robe Construction Guide
For Internal Use: WBIN00024_Sliding_Robe_Construction_Guide_Rev3 Page 17
Step 31.
Using outside screws on the top rollers (marked with + / - symbols) adjust the height of the door as
required (+/- 3.5mm)
Step 33.
Repeat steps 28 - 32 for the outside door assembly.
Step 32.
Push the door to the end position. Tighten top and bottom ‘Damper Stoppers’ where they end once the
door is at the end position. Repeat for both sides of the door.
View from Top of unit.
View from Underside of unit.
