Wren TOWER UNIT User manual

For Internal Use: FI.WR.INS.093_WKIN00220_TOWER_Feature_Aperture_Assembly_Rev1.indd
Built-in 2070 x 600
Built-in 2250 x 600 Tall
TOWER UNIT
600 Feature Units
Open Shelf
Wine Rack
Plate Rack
Assembly Guide

TOWER UNIT
600 Feature Units
Open Shelf
Wine Rack
Plate Rack
Assembly Guide
For Internal Use: FI.WR.INS.093_WKIN00220_TOWER_Feature_Aperture_Assembly_Rev1.indd For Internal Use: FI.WR.INS.093_WKIN00220_TOWER_Feature_Aperture_Assembly_Rev1.indd Page 1
BEFORE YOU START
INSTALLATION
SHOULD BE
PERFORMED BY A
COMPETENT
PERSON ONLY.
THIS PRODUCT COULD
BE DANGEROUS
IF INCORRECTLY
INSTALLED
Top Unit (C)
x1
Size example ONLY
Mid Unit (B)
x1
Size example ONLY
Base Unit (A)
x1
Size example ONLY
REQUIRED TOOLS
NOT to be used
with CAM DOWEL
& CAM LOCK
Hanging Bracket
x2 Inc Screws
Hanging Bracket Plate
x2 (Screws NOT included)
Hinge Mounting Plate
x2 Inc Screws
Feature Unit Fitting Pack may vary in accordance to
Specic Customer Kitchen Plan
Base Unit Fitting Pack contents may vary in
accordance to Specic Customer Kitchen Plan
Corner
Gusset
x2
Hanging Bracket
Cover Cap
x2
Prior to installation, xtures including doors, drawers and loose
shelves should be removed to ensure a safe installation. Use
Wren provided DoorSafe for temporary storage.
(L) x8
15mm
Screw
(L) x16
15mm
Screw
(S) x4
20mm
Screw
(K) x4
30mm
Screw
(K) x4
30mm
Screw
(M) x4
Cover
Caps
(ZZ) x8
Metal Shelf
Pegs
(ZZ) x8
Metal Shelf
Pegs
DoorSafe
Supplied
with:
Supplied
with:
Supplied
with:
x1
Space Plug
(N) x1
Door
Buer
(K) x7
30mm
Screw
(L) x28
15mm
Screw
(M) x4
Cover
Cap
(F) x12
Wooden Dowel
(G) x8
Cam Dowel
(Expanding)
(H) x8
Cam Lock
x5
Legs

TOWER UNIT
600 Feature Units
Open Shelf
Wine Rack
Plate Rack
Assembly Guide
For Internal Use: FI.WR.INS.093_WKIN00220_TOWER_Feature_Aperture_Assembly_Rev1.indd Page 2
Step 1.
Secure each of the legs into place onto base unit (A) with
2 x 15mm screws (L) per leg.
Step 3.
Push leg rmly down into leg base.
Adjust legs to 155mm before turning carcass
upright. Once in situ level accordingly.
Step 2.
Lightly hit centre peg of leg
base with hammer until ush.
Leg position diagram
Front
Front
Base Unit A
Ensure legs are rotated as shown, ensuring
support of adjoined panels at both sides.
Front legs should have at edge to the front.
L
L

TOWER UNIT
600 Feature Units
Open Shelf
Wine Rack
Plate Rack
Assembly Guide
For Internal Use: FI.WR.INS.093_WKIN00220_TOWER_Feature_Aperture_Assembly_Rev1.indd For Internal Use: FI.WR.INS.093_WKIN00220_TOWER_Feature_Aperture_Assembly_Rev1.indd Page 3
B
A
Step 4.
Position Feature Unit (B) onto
secured Base (A) with an 18mm
overhang, as shown.
Step 5.
Using 2x 30mm Screws (K) screw up through the
front rail of base unit (A) to secure both units
Base (A) & Feature unit (B) together. Screws
should be equally spaced, as shown.
18mm
K
K
Screw into any side units using the 30mm screws (K) provided to secure
to the unit. Screw just to the rear of the hinge mounting plate at the top
and bottom of both sides of the unit, place a cover cap (M) on the head
to conceal it.
Secure base unit (A) to wall using space plugs (G). Drill 2 pilot holes
through the back brace into the wall and insert wall plugs. Then unwind
space plug until it contacts both surfaces. Finally, tighten the screws.
Screws for attaching to walls are not provided as these vary
depending on your wall material and construction.
Ensure appropriate xings for
wall construction are used.
K
Front
Mid Unit
B
Base Unit
A
View from back of unit

TOWER UNIT
600 Feature Units
Open Shelf
Wine Rack
Plate Rack
Assembly Guide
For Internal Use: FI.WR.INS.093_WKIN00220_TOWER_Feature_Aperture_Assembly_Rev1.indd Page 4
Step a
Insert Hanging
Bracket into pre-drilled holes
Step 6.
Hanging Brackets steps a,b & c to be carried out on both
sides of Top Unit (C) as shown.
Step c
Secure with provided
2 x 20mm screws (S) per bracket
Step b
Rotate locking
lever 180 degrees
S
S
Detail A Detail A Detail A
Step 7.
Secure Corner
Gussets to the
bottom left and right
hand side of the wall
unit using 4 x 15mm
screws (L) per plate.
L
L
L
L
Detail B
B
A
Step 8.
Drill a small pilot hole through the centre of the Corner Gussets.
Use this hole at the end of the process to screw through and
into the wall. Cover the screw heads using the
cover caps (M) provided.
Screws for xing to walls are not provided as these vary
depending on your wall material and construction. Ensure
appropriate xings for wall constructions are used.
Pilot
hole
M
Detail B
View through
back panel
Top Unit C
Care to be taken. Hanging procedure
is neccesary for a safe installation.

TOWER UNIT
600 Feature Units
Open Shelf
Wine Rack
Plate Rack
Assembly Guide
For Internal Use: FI.WR.INS.093_WKIN00220_TOWER_Feature_Aperture_Assembly_Rev1.indd For Internal Use: FI.WR.INS.093_WKIN00220_TOWER_Feature_Aperture_Assembly_Rev1.indd Page 5
Step 9.
Measure appropriately and attach the 2 x hanging bracket plates onto the
wall screwing through the provided holes into your wall.
Screws for xing to walls are not provided as these vary depending
on your wall material and construction. Ensure appropriate xings for
wall construction are used.
Step 10.
Hang the cabinet using
the brackets to hook
onto the plate as shown.
Hanging Bracket
Plate
Step 11.
Using points a, b & c adjust the Cabinet to suit.
Step a.
Rotate the screw clockwise
to move the cabinet up.
Anti-clockwise for down.
Step b.
Adjust the depth
using centre
screw.
Step c.
Screw the red screw until it
touches the plate to lock
in position.
Hanging
Bracket
viewed though
Back Panel
b
C c
a
a
b
K
Step 12.
Screw into any side units using the
provided 2x 30mm screws (K) to
secure the unit. Screw just to the
rear of the hinge plate then place a
cover cap on the head to conceal it.

TOWER UNIT
600 Feature Units
Open Shelf
Wine Rack
Plate Rack
Assembly Guide
For Internal Use: FI.WR.INS.093_WKIN00220_TOWER_Feature_Aperture_Assembly_Rev1.indd Page 6
Base Unit
A
Mid Unit
B
Top Unit
C
Step 13.
Using 2x 30mm Screws (K) screw up through the top of Feature
Unit (B) to secure it in place with Top Unit (C) as shown.
Screws should be equally spaced, as shown.
K
K
Ensure that screw is positioned
beneath Top Unit (C).
18mm
Top Unit
C
Mid Unit
B
Front

TOWER UNIT
600 Feature Units
Open Shelf
Wine Rack
Plate Rack
Assembly Guide
For Internal Use: FI.WR.INS.093_WKIN00220_TOWER_Feature_Aperture_Assembly_Rev1.indd For Internal Use: FI.WR.INS.093_WKIN00220_TOWER_Feature_Aperture_Assembly_Rev1.indd Page 7
To adjust hinge using a screw
driver, tighten or loosen as
required at points 1& 2.
Point 1 - left - right
Point 2- side - side
1
2
DOOR
FRONTAL
ADJUSTMENT
To release door,
pull catch as shown,
to release hinge from
the hinge plate.
View on Inside of carcass
The soft-close should be adjusted
to suit the size of the door.
Larger doors require the soft-close
strength adjusting higher than
smaller doors, to account for the
dierence in weight. The soft-
close should also be adjusted
to personal preference of door
closure speed. Increasing the
strength reduces the speed of the
door closure & vice versa.
Door Adjustment
Doors supplied in accordance to Customer Specic Kitchen Plan.
To strengthen (+) soft-close,
Turn the lever clockwise,
as required.
To weaken (-) soft-close,
Turn the lever anti-clockwise,
as required.
Factory standard position.
The top and
bottom hinges
MUST be
adjusted to
the SAME
STRENGTH.
View from rear
View from rear
View from rear
View on side of drawer side

TOWER UNIT
600 Feature Units
Open Shelf
Wine Rack
Plate Rack
Assembly Guide
For Internal Use: FI.WR.INS.093_WKIN00220_TOWER_Feature_Aperture_Assembly_Rev1.indd Page 8
Drawer Adjustment
Drawers supplied in accordance to Customer Specic Kitchen Plan.
Drawer Frontal Adjustment
View on side of drawer side
View on side of drawer side
1
32a
2b
Screw point 1as shown to
adjust drawer frontal
right & left.
Screw point 1as shown to
adjust drawer frontal
right & left.
Screw point 2a
as shown to adjust
drawer frontal up & down.
Screw point 2a
as shown to adjust
drawer frontal up & down.
Tighten 2b
once in position.
Tighten 2b
once in position.
Releasing xing clip.
Screw point 3whilst
applying downward
pressure as shown to
release.
Releasing xing clip.
Screw point 3whilst
applying downward
pressure as shown to
release.
Drawer Frontal Adjustment
1
3
2a
2b
