Wren PEBBLE FI.PK.BED.222.002 Assembly instructions

For Internal Use: FI.PK.BED.222.002_WBIN00007_Wall_FittingGuide_Rev1 Page 1
WALL UNIT
Bridging / Top Box Unit Fitting Guide
Height: 288 - 450
Width: 400 - 1000
FI.PK.BED.222.002 - PEBBLE
(L) x8 15mm Screws
(S) x4 20mm Screws
(K) x8 30mm Screws 2x Corner Gusset Plate
2x Hanging Bracket Cover Cap
2x Wall Hanging Bracket
2x Wall Hanging Plate
8x Stick On Cover Cap
(N) x2 Door Buer
Screws and fixings for attaching to walls are not provided as these vary
depending on materials, thickness and construction. Ensure appropriate
fixings for wall construction are used.
Step1.
A. Insert wall hanging bracket into pre-drilled holes on the rear of the unit.
B. Rotate locking lever 180 degrees.
C. Secure with 2 x 20mm screws (S) per hanging wall bracket.
Step 3.
Drill a pilot hole through the centre of the wall gusset
plate. Use this hole at the end of the process to screw
through and into the wall.
Step 2.
Secure corner gusset plates to the bottom left and right
side on the back of the wall unit, using 4 x 15mm screws
(L) per plate.
View from back of unit. View from back of unit.

For Internal Use: FI.PK.BED.222.002_WBIN00007_Wall_FittingGuide_Rev1 Page 2
WALL UNIT
Bridging / Top Box Unit Fitting Guide
Height: 288 - 450
Width: 400 - 1000
FI.PK.BED.222.002 - PEBBLE
Step 8.
Cover wall hanging bracket screws on the inside of the unit with 2 x hanging
bracket cover caps provided .
Step 7.
Screw into any adjacent units using 30mm screws (K) provided to secure the
unit. Screw just to the rear of the hinge plate at the top and bottom on both
sides. Place stick on cover caps on the heads to conceal them.
Step 6.
Secure the unit to the wall by screwing through the pilot hole and gusset from
step 3 into the wall. Place cover stickers on the heads to conceal them.
View from inside unit.
Step5.
Point a.
Rotate the top screw clockwise to move the unit up.
Anti-clockwise for down.
Point b.
Adjust the depth using centre screw.
Point c.
Turn the bottom screw (red screw) until it touches the plate to lock in position.
Step 4.
A. Measure appropriately and attach the 2 x wall
hanging plates onto the wall screwing through the
provided holes into your wall.
B. Hang the unit using the wall hanging brackets to
hook onto the wall hanging plates.
