Wren PEBBLE FI.PK.BED.222.005 Assembly instructions

For Internal Use: FI.PK.BED.222.005_WBIN00006_590_TopBox_FittingGuide_Rev1 Page 1
WALL UNIT
Top Box Unit Fitting Guide
Height: 288 - 450
Width: 400 -1000
FI.PK.BED.222.005 - PEBBLE
Screws and fixings for attaching to walls are not provided as these vary
depending on materials, thickness and construction. Ensure appropriate
fixings for wall construction are used.
Step1.
Ensure the robe unit is level, positioned correctly and fully secured before
installing top box. Position the top box on top of the robe unit.
Level the top box with the robe so the sides and front of both units are aligned
and ush.
(K) x8
30mm Screw
(N) x2
Door Buer
x8
Stick On
Cover Cap

For Internal Use: FI.PK.BED.222.005_WBIN00006_590_TopBox_FittingGuide_Rev1 Page 2
WALL UNIT
Top Box Unit Fitting Guide
Height: 288 - 450
Width: 400 -1000
FI.PK.BED.222.005 - PEBBLE
Step2.
Screw down through the top box bottom xed shelf into the robe top xed
shelf using 4 x 30mm screws (K). Position 2 screws at the front and 2 screws at
the rear of the unit.
Step3.
Drill pilot holes through back panel and rail into the wall.
Secure the top box to the wall by screwing through the
pilot holes into the wall. Place stick on cover caps on the
heads to conceal them.
These screws and wall xings are not provided.
Step4.
Screw into any adjacent units using 30mm screws (K) provided to secure the
unit. Screw just to the rear of the hinge plate at the top and bottom on both
sides. Place stick on cover caps on the heads to conceal them.
