Wren FI.PK.FIT.002 Assembly instructions

FITTING GUIDE
L CORNER BASE
CABINET
For Internal Use:FI.PK.FIT.002_50-WKIN0008_BASE2_LCNR_Rev5
Page 1
View from rear of cabinet
Sample cabinet shown
(3)
Ff
Ff
Screws for attaching to walls and countertop are not provided as these vary depending on materials,
thickness and construction. Ensure appropriate xings for wall and countertop construction are used.
Please refer to the specialist countertop supplier if these are required for solid surface countertops.
(H) x8 1 ¼” Screws (B) x82 ” Screws
(V) x1 XL Space-Plug(K) x3 L Bracket - Large
(Ff) x10 Fixing Plate
B
View from underside
(1)
(2)
Ff
Ff Ff
Ff
Step 1.
Attach Fixing Plates (Ff) onto cabinets in 3 positions (1), (2), (3) as
shown using 4 x ” screws (B) per plate. Be careful not to interfere
with leg positions.
Step 2.
Secure each of the legs into place with 2 x ” screws (B). Ensure legs
are rotated as shown so that part of them is supporting the end panel.
Step 3.
Secure cabinet to the wall using Space-Plugs (U).
Use a stud nder to locate the studs on the wall, drill pilot holes through the back brace
of the cabinet into the wall at the stud locations. Unwind the Space-Plugs (U) until they
contact both surfaces, insert and tighten an appropriately sized screw through the back
of the cabinet and the Space-Plugs (U) into the wall. (Use appropriate xing for wall
construction where a stud is not available)
The 2 regular Space-Plugs (U) are to be used on the back of the larger cabinet and the XL
Space-Plug (V) at the rear of the smaller cabinet in the assembly.
FI.PK.FIT.002 - BASE 2
(U) x2 Space-Plug

For Internal Use:FI.PK.FIT.002_50-WKIN0008_BASE2_LCNR_Rev5 Page 2
FITTING GUIDE
L CORNER BASE
CABINET
Ff
Ff
B
B
Step 4.
Use 2 x Fixing Plates (Ff) with 4 x ” screws (B)
to attach the corner post to the door frontal.
Step 5.
The remaining two xing plates (Ff) are to
be used to attach the loose shelf sections
together.
Step 6.
Screw into any adjacent cabinets using 1 ¼” screws (H) provided to
secure the cabinet. Screw just to the rear of the hinge plate and to the
rear of the cabinet at the top and bottom. Place cover caps on the screw
heads to conceal them.
XL Space-Plug
Regular Space-
Plugs
View from rear of cabinet
Sample cabinet shown
Ff
Ff
Ff
Sample cabinet shown
H
Sample Hinge shown
