Wren CHEST 2 Assembly instructions

For Internal Use: FI.PK.BED.222.013_WBIN00030_Chest2_FittingGuide_Rev1 Page 1
CHEST UNIT
Chest Unit Fitting Guide
CHEST 2 - FI.PK.BED.222.013
(K) x2
30mm
Screw
2 x L Bracket
LGE
(L) x8
15mm
Screw
(N) x4
Door Buer
Step1.
Remove the drawers from the chests and put to one side.
Install the bottom chest using the tting pack provided. Ensure the chest is positioned correctly, level and
secure.
Step2.
Use 2 x 15mm screws (L) to secure each of the L bracket LGE to the top, rear of the bottom chest on either
side.
Step3.
Carefully lift the top chest and position it on top of the bottom chest, ensure the front and sides are
aligned with each other.

For Internal Use: FI.PK.BED.222.013_WBIN00030_Chest2_FittingGuide_Rev1 Page 2
CHEST UNIT
Chest Unit Fitting Guide
CHEST 2 - FI.PK.BED.222.013
Screws and fixings for attaching to walls are not provided as these vary
depending on materials, thickness and construction. Ensure appropriate
fixings for wall construction are used.
Step4.
Secure the two chests together by screwing up through the rail of the bottom chest into the xed shelf of
the top chest using 2 x 30mm screws (K) and by screwing up through each of the L brackets using 2 x 15mm
screws (L) per L bracket.
Step5.
Drill pilot holes through the top units back rail into the wall. Screw through the rail and into the wall to secure
the unit.
These screws and wall xings are not provided.
