Wren FI.PK.BED.222.001 Assembly instructions

For Internal Use: FI.PK.BED.222.001_WBIN00005_Chest_FittingGuide_Rev1 Page 1
CHEST UNIT
Chest Unit Fitting Guide - FI.PK.BED.222.001
Height: 595 - 1172
Width: 400 -1000
Screws and fixings for attaching to walls are not provided as these vary
depending on materials, thickness and construction. Ensure appropriate
fixings for wall construction are used.
(K) x10
30mm
Screw
2 x L Bracket
LGE
(L) x18
15mm
Screw
(N) x6
Door Buer
400 - 500 Widths: 4 Legs
600 - 1000 Widths: 5 Legs
Step1.
Remove the drawers from the unit and put to one side, lift the chest and place
it on its side. Secure each of the legs in place with 2 x 15mm screws (L) per leg.
Ensure legs are rotated as shown so the tab is supporting the end panel.
Attach bottom section of legs and set all legs to the same height.

For Internal Use: FI.PK.BED.222.001_WBIN00005_Chest_FittingGuide_Rev1 Page 2
CHEST UNIT
Chest Unit Fitting Guide - FI.PK.BED.222.001
Height: 595 - 1172
Width: 400 -1000
Step2.
Position the unit and level using an 8mm hex key from inside the unit.
Step4.
Screw into any side units using the 30mm screws (K)
provided, through a spare runner hole to secure to the
unit.
Step5.
Use 2 x 15mm screws (L) to secure each of the L bracket
LGE to the top, rear of the unit on either side.
Step6.
Screw up through the front rail into the worktop using
2 x 30mm screws (K) provided to secure it in place.
Step7.
Screw up through the L brackets LGE and into the
worktop using 2 x 15mm screws (L) per L bracket LGE.
Step3.
Drill pilot holes through the back rail into the wall.
Screw through the rail and into the wall to secure the unit.
These screws and wall xings are not provided.
