Electric Scooter 4 Lite User Manual

Safety Reminder
Read this manual carefully before use, and retain it for future reference.
Always steer clear of obstacles.
Watch out for Safety Risk
Avoid hitting your head on door frames,
elevators, and other overhead obstacles.
Do not press the accelerator when you are
walking alongside the scooter.
Unless otherwise authorized by the local laws,
it is forbidden and illegal to ride on public roads,
motorways, and expressways.
Do not abruptly change the steering direction at
high speed.

Do not Try Dangerous Actions
Do not use mobile phone or wear earphones when
operating the scooter.
Do not hang bags or other heavy stuff on the
handlebar. Do not ride on one foot.
Do not accelerate when going downhill, and brake
in time to slow down. When on a steep slope, you
need to step off the scooter and push.
Do not ride in the rain. Do not ride through puddles
or any other (water) obstacles. Do not ride with anyone else, including children.
Do not keep your feet on the rear
mudguard. Do not let go of the handlebar while riding.

Product Overview
1
12
13
14
15
16
17
18
19
20
21
22
2
3
4
5
6
7
8
9
10
11
Do not try riding up or down stairs, nor try jumping
over obstacles. Do not touch the mechanical brake.

4Brake Lever 56
10 Wheel Motor 11 Charging Port 12 Accelerator
Quick Release Lever
18
1716
Deck
Rear Mudguard
13 14 15
Scooter Bell
Control Panel & Power Button
789Front Fork
Quick Release Lever Lock
1 2 3
Handlebar Headlight
Buckle & Bell Lever
Tail Light & Rear Reflector
Front Reflector
Stem
Hook
Battery Compartment
19 20 21
Mechanical Brake Side Reflector
22 Kickstand
31
24
26 28
27
25
23
30
29
Control Panel & Power Button
23 Speedometer: It displays the current speed when the scooter is working. When the scooter has an issue, it displays an error
code. When the scooter is charging, it displays the current battery level.
24
25
26
27
Bluetooth: When the icon lights up, it indicates the scooter has been successfully connected to the mobile device.
Temperature Warning: If the battery temperature is too high or too low, the thermometer icon will be on.
This will result in reduced acceleration and possibly charging issues. Use or charge the scooter after its
battery temperature returns to the normal operating range.
Error Notification: When the wrench icon displays red, it indicates that the scooter has an error.
Power Button: Press the button to turn the scooter on, and hold the button for 2 to 3 seconds to turn the scooter off.
When the scooter is on, press the button to turn on/off the headlight and tail light, and press twice to cycle through
the modes.
Note: The scooter will turn off automatically when it enters standby mode for more than 10 minutes. The standby
mode means that the scooter is not being charged or not locked when it is on and not running.
28 Battery Level: The battery power is indicated by 5 bars, each representing approximately 20% of a full battery.
29 Inflation: When the inflation icon is on, it means that it is time to maintain the tires. Check the tire pressure and inflate the
tires immediately to avoid tire damage caused by inadequate tire pressure. The recommended tire pressure is 50 psi.
Note: After performing maintenance, follow the instructions in the app to disable the inflation reminder.
Lock: When the icon lights up, it indicates that the scooter is locked. You can lock/unlock the scooter via the Mi Home/Xiaomi
Home app.
30
Modes: is for walking mode, and its maximum speed is 6 km/h; the taillight will blink red when this mode is enabled. D is
for standard mode. S is for sport mode, and it has high speed in this mode; it is recommended to use this mode after
mastering the riding skills.
31

Package Contents
Electric Scooter
Electric Scooter 4 Lite User Manual
Manual de usuario de Xiaomi Electric Scooter 4 Lite
Руководство пользователя для Электросамоката Xiaomi Electric Scooter 4 Lite
Xiaomi Elektrische Step 4 Lite Gebruikershandleiding
Посібник користувача для Електричного самоката Xiaomi Electric Scooter 4 Lite
Manual do utilizador de Trotinete elétrica Xiaomi 4 Lite
Xiaomi ﻦﻣ Lite 4 ﻲﺋﺎﺑﺮﻬﻛ ﺮﺗﻮﻜﺳ مﺪﺨﺘﺴﻣ ﻞﻴﻟد
Electric Scooter 4 Lite Important Information
·
001
Información importante sobre el Xiaomi Electric Scooter 4 Lite
·
017
Важная информация об Электросамокате Xiaomi Electric Scooter 4 Lite
·
033
·
050
Belangrijke informatie Xiaomi Elektrische Step 4 Lite
·
065
Важлива інформація щодо Електричного самоката Xiaomi Electric Scooter 4 Lite
·
081
Informações importantes sobre a Trotinete elétrica Xiaomi 4 Lite
·
097
Xiaomi ﻦﻣ Lite 4ﻲﺋﺎﺑﺮﻬﻛ ﺮﺗﻮﻜﺳ ﻦﻋ ﺔﻤﻬﻣ تﺎﻣﻮﻠﻌﻣ
Electric Scooter 4 Lite Specifications·
01
Especificaciones de Xiaomi Electric Scooter 4 Lite ·
02
Tехнические характеристики Электросамоката
Xiaomi Electric Scooter 4 Lite·
03
·
04
Xiaomi Elektrische Step 4 Lite Specificaties
·
05
Специфікація для Електричного самоката
Xiaomi Electric Scooter 4 Lite ·
06
Especificações da Trotinete elétrica Xiaomi 4 Lite ·
07
Xiaomi ﻦﻣ Lite 4 ﻲﺋﺎﺑﺮﻬﻜﻟا ﺮﺗﻮﻜﺴﻟا تﺎﻔﺻاﻮﻣ
Allen Key Screw × 5 (1 is spare) Battery Charger
Important Information Specifications
User Manual
Extension Nozzle

Assembly and Set-up
1
2
3
1
Headlight Facing Forward
2Install the handlebar onto the stem, and make sure to install the handlebar in the correct direction.
Put down the kickstand, and hold up the stem until it is completely in an upright position. Then push the quick release
lever inward to the end.
Follow the number order as illustrated to pre-tighten the four screws with the included Allen key. Make sure the handlebar
is correctly installed and then tighten the screws thoroughly.
3
1
2
3
4
Charge Your Scooter
1
3
2
4
Lift up the rubber flap.
Put back the rubber flap.
Connect the battery charger to the charging port.
Disconnect the battery charger from the
charging port when charging is completed.

The scooter is fully charged when the LED on the battery charger changes from red to green.
˜30% + = ˇ 30
When the scooter is turned off for about a month with the battery level of the scooter being lower than 30%, the scooter will enter
sleep mode. In this case, the scooter cannot be turned on. To exit the sleep mode, charge the scooter for about three seconds to
activate the battery.
1Before being activated, the scooter will keep beeping when turned on and is limited to 10 km/h. When the scooter is used for
the first time, it must be activated via the Mi Home/Xiaomi Home app.
Connecting with the Mi Home
2Scan the QR code on the label attached to the control panel, on the right side of the deck, or on the back cover of the user
manual to download the Mi Home/Xiaomi Home app.
Note: The QR code is unique to your scooter, please keep it safe.

4Tap "+" on the top right corner and open "Scan" to scan the QR code on the
label attached to the control panel, on the right side of the deck, or on the back
cover of the user manual again. Then follow the instructions in the app to add
the scooter.
3Open the Mi Home/Xiaomi Home app.
Complete
Exit/Sign out
5
Cancel
Activate
6
Watch the riding guide video. Do not exit the video before finishing it.
Otherwise, the activation will fail.
Tap "Activate" to activate the scooter. Once the scooter is activated,
the beeping will stop and the speed restriction will be lifted.
Notes:
· The app is referred to as Xiaomi Home app in Europe (except for Russia). The name of the app displayed on your device
should be taken as the default.
·The version of the app might have been updated, please follow the instructions based on the current app version.

Reset Bluetooth
Make sure the scooter is turned on. Press the accelerator and simultaneously press the power button 5 times to reset. When the
scooter beeps, it has been reset successfully.
Restore Factory Settings
Make sure the scooter is turned on. Squeeze the brake lever, and simultaneously press and hold the accelerator and the power button
for 7 seconds. When you hear a beep, the scooter has been restored to factory settings. This operation will completely delete the data
stored in the scooter, please proceed with caution.
Note: The scooter cannot be restored to factory settings during riding or when locked.
Before Riding
How to Ride
1
Wear a helmet, elbow pads and knee pads before riding.
Note: Check the tire pressure before riding. The recommended tire pressure is 50 psi.
V≥5 km/h
Starting & Accelerating
When the scooter starts to coast, put both feet on the deck and gently press the
accelerator. The accelerator can be used once the scooter is going over 5 km/h.
Step on the deck with one foot, and slowly kicks off the other on the
ground.
2

0Release the accelerator to slow down, and you can enable the energy
recovery function to help reduce the speed. Squeeze the brake firmly to
make an emergency stop.
Tilt your body to the steering direction as you turn, and slowly turn the
handlebar.
3 Steering
4Decelerating & Braking & Parking
When the scooter slows down or stops, put one foot on the ground to get
off the scooter. Put down the kickstand when parking the scooter.
To avoid others using the scooter without your permission, you can lock the scooter when it is parked.

Slide to Lock Tap to Unlock
Lock & Unlock Your Scooter
18 km
Estimated remaining
mileage
88
S
Current baery
level (%)
Riding mode
Xiaomi Electric Scooter 4 Lite
12.5
km/h
Average speed
22
km
Current mileage
View more riding records
Cruise control
Slide to lock the scooter
18 km
Estimated remaining
mileage
88
S
Current baery
level (%)
Riding mode
Xiaomi Electric Scooter 4 Lite
12.5
km/h
Average speed
22
km
Current mileage
View more riding records
Unlock
Cruise control
·When the scooter is locked, the motor is locked and all the icons on the control panel will automatically go out except the
Bluetooth icon and the lock icon. If the scooter goes beyond the Bluetooth connection range, the Bluetooth will be
disconnected and its icon will go out.
·After the scooter is locked in the app, the motor will be locked and the power button will not function. If the scooter is moved
forcibly, its front wheel cannot move normally, and it will have a rolling resistance accompanied by the buzzer alarm and a
vibrating alert on the phone. This function cannot prevent the scooter from being stolen, please keep your scooter safe. The
scooter will automatically turn off after 24 hours of being locked, and it will remain locked when turned on again. To unlock the
scooter, tap "Unlock" in the app. Locking the scooter will consume the scooter's power, please use this function wisely.
Note: The phone will vibrate only if the page of the scooter in the Mi Home/Xiaomi Home app is open.
1
2
1
Fold/Unfold & Carry
Quick Release Lever Lock
Quick Release Lever
Make sure the scooter is turned off and not being charged before folding. Hold the stem, lift the quick release lever lock, and
pull the quick release lever outward.

2
3
Buckle
3Align the buckle with the hook and secure them
together.
Hook
4Hold the stem with either one hand or both hands
to carry. 5When unfolding the scooter, pull the buckle upwards to release it from the hook.
Release
Fold the stem.
Adjust the Mechanical Brake
Tool: 14 mm T-handle socket wrench (the tool needs to be prepared by the user).
Before adjustment, make sure the scooter is powered off and not charging. When the brake is too tight, use the tool to turn the nut on
the screw rod counterclockwise, so as to slightly shorten the brake cable's exposed bottom part. When the brake is too loose, use the
tool to turn the nut on the screw rod clockwise, so as to slightly lengthen the brake cable's exposed bottom part.

2
Inflate the Tire
Valve Cap
Remove the tire valve cap, and connect the pump
and the valve securely together.
1Connect the pump to the extension nozzle.
4
3 Inflate the tire. Remove the extension nozzle, and install the valve cape.
Check the tire pressure every month, and inflate the tires if the pressure is too low. The recommended tire pressure is 50 psi.
Do Not Remove
Original instructions
Made in China
Illustrations of product, accessories, and user interface in the user manual are for reference purposes only. Actual product and functions may vary due
to product enhancements.
For further information, please go to www.mi.com
For detailed e-manual, please go to www.mi.com/global/service/userguide
This QR code is unique to your scooter and can also be found on the labels attached to the control panel and to the right side of the deck. It is used to
connect the scooter with the Mi Home/Xiaomi Home app and contains important information about activating your scooter. Please keep this code
safe.
