Xtreme 500VA Guide

S70 Line Interacve Tower UPS
500VA, 700VA, 1000VA, 1500VA, 2000VA Models
User & Installaon Manual
www.xpcc.com | © 2014 Xtreme Power Conversion Corporaon. All rights reserved. (Rev 8/13/14)

Xtreme Power Conversion Corporaon
S70 User’s Manual
Page 2
Uninterrupble Power Supply
Table of Contents
Package Contents.........................................................................................3
Product Introducon....................................................................................3
Product Overview.........................................................................................3
Line Interacve Technology...........................................................................3
Installaon & Inial Startup.........................................................................5
Troubleshoong...........................................................................................7
Specicaons...............................................................................................8
Obtaining Service.........................................................................................9
Xtreme Power Conversion Limited Warranty...............................................10
Xtreme Power Conversion Load Protecon Policy.......................................11

Xtreme Power Conversion Corporaon
S70 User’s Manual
Page 3
Uninterrupble Power Supply
Package Contents
You should be receiving the following items inside the package:
• UPS Unit
• User Manual
• Local Monitoring Soware CD
• USB cable
Product Introducon
Thank you for selecng this Uninterrupble Power Supply (UPS). It provides you with protecon for connected
equipment. Please read this manual before installing the S70 Series UPS models S70-500, S70-700, S70-1000,
S70-1500, and S70-2000 as it provides important informaon that should be followed during installaon and main-
tenance of the UPS and baeries, allowing you to correctly set up your system for the maximum safety and per-
formance. Included is informaon on customer support and service, if it is required. If you experience a problem
with the UPS, please refer to the Troubleshoong secon in this manual to correct the problem. If the problem is
not corrected, please collect informaon so that the Technical Support personnel can more eecvely assist you.
Product Overview
Many dierent kinds of sensive electrical equipment can be protected by an Uninterrupble Power Supply (UPS)
including computers, workstaons, process control systems, telecommunicaons systems, sales terminals, other
crical instrumentaon, etc. The purpose of the UPS is to protect these systems from poor quality ulity power,
complete loss of power, or other associated problems.
Electrical interference exists in many forms, causing problems in AC power, from lightning, power company ac-
cidents and radio transmission motors, air condioners, and vending machines. Protecon of sensive electrical
equipment is vital to protect against power outages, low or high voltage condions, slow voltage uctuaons,
frequency variaons, dierenal and common-mode noise, transients, etc.
To prevent power line problems from reaching crical systems causing damage to soware, hardware, and equip-
ment malfuncons, the UPS maintains constant voltage, isolang crical load output and cleaning the ulity AC
power.
Line Interacve Technology
A line interacve technology UPS provides basic power protecon and Automac Voltage Regulaon (AVR) to the
load when AC input power is available. When AC input power is unavailable, the line-interacve UPS will switch to
baeries to supply the load with power. In the event that the power failure lasts longer than the UPS backup me,
the UPS will shut down avoiding baery damage. When the input AC voltage returns, the UPS will automacally
return online to recharge the baeries.
• AC input ows into and through the AVR to the load.
• When AC input varies outside the acceptable specicaon, the AVR switches taps on the transformer to
beer regulate the output.
• If AC input power fails, the inverter turns on an supplies power from the baeries to the load.
• When AC input power returns, the UPS automacally begins supplying the load with power through the
AVR circuit.
• The charger circuit provides recharge for the baeries.

Xtreme Power Conversion Corporaon
S70 User’s Manual
Page 4
Uninterrupble Power Supply

Xtreme Power Conversion Corporaon
S70 User’s Manual
Page 5
Uninterrupble Power Supply
Installaon & Inial Startup
Note: Before installaon, inspect the unit and packaging to make sure that nothing inside has been damaged.
Placement & Storage
Install the UPS in a protected area that is free of excessive dust and has adequate air ow. Place the UPS away
from other units at least 7.8 in (20 cm) to avoid interference. DO NOT operate the UPS where the temperature and
humidity is outside the specied limits. (See Specicaons for details).
Connect UPS to Ulity and Charging
Before the inial use of the UPS, plug the UPS input cord into a wall outlet and turn the UPS on by depressing the
Power switch on the front of the UPS. For best results, the baeries in the UPS should be charged for at least 6
hours before use. The UPS charges its baery while it is connected to AC ulity power and powered on.
Connecng the Loads
Plug the loads to be supported by the UPS into the output receptacles on the rear of the UPS. Simply turn the
power switch on the UPS on and the devices connected to the UPS will be protected by the UPS unit.
Connect Modem / Phone for Surge Protecon
(S70 -1000, -1500, -2000 models only)
Connect a single modem/phone line into surge-protected “IN” outlet on the back of the UPS unit. Connect from
“OUT” outlet to the computer with phone line cable.
Connect Communicaon Cable
To allow for unaended UPS shutdown/start-up and status monitoring, connect one end of the communicaon
cable to the USB port and the other end to a USB port of a PC. With the monitoring soware installed, you will be
able to schedule UPS shutdown/start-up and to monitor the UPS status through the PC.
Turn UPS ON / OFF
To turn the UPS unit on, press the Power switch on the front of the UPS. To turn the UPS unit o, press the Power
switch on the front of the unit again.
Cold Start Funcon
When the UPS is o and there is not input ulity power available, it is sll possible to cold start the UPS unit to
power loads. Follow the instrucons for Turning UPS ON and be aware that you will see and hear the ON BATTERY
ALARM.
IMPORTANT SAFETY INSTRUCTIONS: (SAVE THESE INSTRUCTIONS)
CAUTION! (UPS having Internal Baeries): Risk of electrical shock – Hazardous live parts inside this unit are ener-
gized from the baery supply even when the input AC power is disconnected.
CAUTION! (No User serviceable Parts): Risk of electrical shock, do not remove cover. No user serviceable parts

Xtreme Power Conversion Corporaon
S70 User’s Manual
Page 6
Uninterrupble Power Supply
inside. Refer servicing to qualied service personnel.
CAUTION! (Non-isolated Baery supply): Risk of electric shock, baery circuit is not isolated from AC input, haz-
ardous voltage may exist between baery terminals and ground. Test before touching.
WARNING! Unit intended for installaon in a controlled environment.
CAUTION! Do not dispose of baeries in a re, the baery may explode.
CAUTION! Do not open or mulate the baery, released electrolyte is harmful to the skin and eyes.
CAUTION! A baery can present a risk of electric shock and high short circuit current. The following precauon
should be observed when working on baeries:
• Remove watches, rings or other metal objects.
• Use tools with insulated handles.
To reduce the risk of electric shock, disconnect the UPS from the main supply before installing a computer inter-
face signal cable. Reconnect the power cord only aer signaling interconnecons have been made.
Servicing of baeries should be performed or supervised by personnel with knowledge of baeries and the re-
quired precauons. Keep unauthorized personnel away from baeries.
The instrucons contained within this safety manual are deemed important and should be closely followed at all
mes during installaon and follow-up maintenance of the UPS and baeries.

Xtreme Power Conversion Corporaon
S70 User’s Manual
Page 7
Uninterrupble Power Supply
Troubleshoong
Condion Visual Indicator Alarm
No words display on front panel Low baery Charge the UPS at least 6 hours
Baery fault Replace the baery with the same
type of baery
The UPS is not turned on Press the Power Switch on the front
of the UPS
Alarm connuously sounds when
the AC input is normal
The UPS is overloaded Remove some of the load from the
output of the UPS
When power fails, backup me is
shorter than expected
The UPS is overloaded Remove some of the load from the
output of the UPS
Baery voltage is too low Charge the UPS at least 8 hours
Baery defect – possibly due to
high environmental temperature or
improper operaon of the baery
Replace the baery with the same
type of baery
Ulity power is available but the
UPS is in baery mode
Power cord is loose Reconnect the input power cord
properly

Xtreme Power Conversion Corporaon
S70 User’s Manual
Page 8
Uninterrupble Power Supply
Specicaons
MODEL NUMBER S70-500 S70-700 S70-1000 S70-1500 S70-2000
INPUT Capacity 500VA (300W) 700VA (420W) 1000VA (600W) 1500VA (900W) 2000VA (1200W)
Voltage 120VAC
Frequency 60Hz
OUTPUT Voltage 120VAC
Waveform Sine wave (normal), simulated sine wave (baery mode)
Frequency 60Hz ± 1Hz
Transfer me 4ms (typical)
BATTERY Baery type Sealed, maintenance-free lead acid
Baery quanty and size (1) 12V 7AH (1) 12V 9AH (2) 12V 7AH (2) 12V 9AH
Recharge 4–6 hours to 90% capacity
PHYSICAL UPS dimensions (W x D x H) 3.9 x 11.3 x 5.6 in 5.7 x 13.8 x 6.3 in 5.7 x 15.6 x 8.1 in
Shipping dimensions 5.5 x 13.1 x 8.7 in 7.5 x 17.4 x 10 in 9.1 x 19.3 x 11.3 in
UPS weight 9.5 lbs 10.8 lbs 17.6 lbs 24.5 lbs 25.4 lbs
Shipping weight 10.1 lbs 11.5 lbs 19.4 lbs 27.1 lbs 28.0 lbs
Line cord 5  5–15P
Receptacles (4) 5–15R (6) 5–15R (8) 5–15R
ENVIRONMENT Operang temperature 32–104°F (0–40°C)
Humidity 0–90%
Altude 11,500  above sea level
INDICATORS &
ALARMS
LCD display AC/baery mode, load/baery level, input/output voltage, overload fault, low baery
Data line protecon N/A RJ45
WARRANTY 3 years electronics and baery (2 years outside of USA)
COMMUNICATIONS INTERFACE USB
INCLUDED IN BOX Shutdown and monitoring soware, USB cable, user manual

Xtreme Power Conversion Corporaon
S70 User’s Manual
Page 9
Uninterrupble Power Supply
Obtaining Service
If the UPS requires Service:
1. Use the TROUBLESHOOTING secon in this manual to eliminate obvious causes.
2. Verify there are no circuit breakers tripped.
3. Call your dealer for assistance. If you cannot reach your dealer, or if they cannot resolve the problem, call Xtreme
Power Conversion Corp Technical Support at 800.582.4524. Technical support inquiries can also be made at
[email protected]. Please have the following informaon available BEFORE calling the Technical Support
Department:
• Your name and address.
• The serial number of the unit.
• Where and when the unit was purchased.
• All of the model informaon about your UPS.
• Any informaon on the failure, including LED’s that may or may not be illuminated.
• A descripon of the protected equipment, including model numbers if possible.
• A technician will ask you for the above informaon and, if possible, help solve your problem over
the phone. In the event that the unit requires factory service, the technician will issue you a Return
Material Authorizaon number (RMA).
If you are returning the UPS to Xtreme Power for service, please follow these procedures:
1. Pack the UPS in its original packaging. If the original packaging is no longer available, as the Technical
Support Technician about obtaining a replacement set of packaging material. It is important to pack the
UPS properly in order to avoid damage in transit. Never use Styrofoam beads for a packing material.
2. Include a leer with your name, address, dayme phone number, RMA number, a copy of your original
sales receipt, and a brief descripon of the problem.
3. Mark the RMA number on the outside of all packages. Xtreme Power cannot accept any package without
the RMA number marked on the outside of the boxes.
4. Return the UPS by insured, prepaid carrier to the address provided by the Technician.
5. Refer to the Warranty statements in this manual for addional details on what is covered.

Xtreme Power Conversion Corporaon
S70 User’s Manual
Page 10
Uninterrupble Power Supply
Xtreme Power Conversion Limited Warranty
Xtreme Power Conversion (XPC) Corporaon warrants Xtreme Power Conversion equipment, when properly
applied and operated within specied condions, against faulty materials or workmanship for a period of three
years for S70-Series products from the date of purchase. XPC Corporaon warrants internal baeries for a
period of three years from the date of purchase. For equipment sites within the United States and Canada, this
warranty covers repair or replacement, at the sole discreon of XPC Corporaon. The customer is responsible for
the costs of shipping the defecve product to XPC Corporaon. XPC Corporaon will pay for ground shipment of
the repaired or replacement product. This warranty applies only to the original purchaser.
If equipment provided by XPC Corporaon is found to be Dead-on-Arrival (DOA), XPC Corporaon will be re-
sponsible for the costs of shipping product to and returning equipment from the customer in a mely manner
as agreed to with the customer, once the customer has requested and received a Return Material Authorizaon
(RMA) number. DOA equipment is dened as equipment that does not properly funcon according to user docu-
mentaon when inially received and connected in conjuncon with proper procedures as shown in the user
documentaon or via support provided by XPC Corporaon personnel or authorized agents.
This warranty shall be void if (a) the equipment is repaired or modied by anyone other than XPC Corporaon
or a XPC Corporaon approved third party; (b) the equipment is damaged by the customer, is improperly used
or stored, is subjected to an adverse operang environment, or is operated outside the limits of its electrical
specicaons; or (c) the equipment has been used or stored in a manner contrary to the equipment’s operang
manual, intended use or other wrien instrucons. Any technical advice furnished by XPC Corporaon or a XPC
Corporaon authorized representave before or aer delivery with regard to the use or applicaon of Xtreme
Power Conversion equipment is furnished on the basis that it represents XPC Corporaons best judgment under
the situaon and circumstances, but it is used at the recipient’s sole risk.
EXCEPT AS STATED ABOVE, XPC Corporaon DISCLAIMS ALL WARRANTIES, EXPRESSED OR IMPLIED, INCLUDING
WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE.
EXCEPT AS STATED ABOVE, IN NO EVENT WILL XPC Corporaon BE LIABLE FOR DIRECT, INDIRECT, SPECIAL, INCI-
DENTAL, OR CONSEQUENTIAL DAMAGES ARISING OUT OF THE USE OF Xtreme Power Conversion EQUIPMENT,
including but not limited to, any costs, lost prots or revenue, loss of equipment, loss of use of equipment, loss
of soware, loss of data, cost of substutes, or claims by third pares. Purchaser’s sole and exclusive remedy for
breach of any warranty, expressed or implied, concerning Xtreme Power Conversion equipment, and the only
obligaon of XPC Corporaon under this warranty, shall be the repair or replacement of defecve equipment,
components, or parts; or, at XPC Corporaons sole discreon, refund of the purchase price or substuon of an
equivalent replacement product.

Xtreme Power Conversion Corporaon
S70 User’s Manual
Page 11
Uninterrupble Power Supply
Xtreme Power Conversion Load Protecon Policy
THIS POLICY IS NOT A WARRANTY. REFER TO THE XPC CORPORATION, INC. LIMITED WARRANTY FOR
INFORMATION CONCERNING THE WARRANTY FOR YOUR XPC PRODUCT. THE LIMITATIONS AND CONDITIONS
CONTAINED IN THIS POLICY DO NOT AFFECT THE TERMS OF THE XPC LIMITED WARRANTY.
Denions:
1. “Product” means a Standard 120, 208, or 240 Volt power protecon device that is used in the United
States and Canada. This policy does not include custom manufactured products.
2. “Power Disturbance” means an AC power line transient (telephone line or Local Area Network, if appli-
cable), spike or surge.
3. “Connected Equipment” properly connected electronic equipment
4. “Fair Market Value” of damaged Connected Equipment as determined by XPC shall be the lower of (a) the
average price the same or similar items are being sold for on eBay, (b) the price list of Orion Blue Book (or
if such price list is no longer published, a published or announced price list reasonably selected by XPC),
(c) the lowest price the same or similar items can be purchased for in the United States or (d) the total
amount of all payment(s) you have or are entled to receive from insurance, other warranes, extended
warranes, a legal liability claim or from other sources or persons for the damaged Connected Equipment.
5. “Purchaser” means the person or enty that originally purchased the Product from an authorized reseller
or distributor of XPC Products.
The Purchaser of this Product is protected, for the term of the XPC Limited Warranty, against certain losses caused
by a Power Disturbance for properly connected electronic equipment (referred to as the "Connected Equipment")
subject to certain terms and condions provided below.
This policy applies only to the original purchaser of the Product. If the Product is transferred or sold to another
person or enty, this policy is void.
Load Protecon Policy Dollar and Period Limits
For purchasers that meet the qualicaons and condions set forth in this policy, XPC will provide reimbursement
(cost of repair or fair market value as determined by XPC) during the period limits and up to the dollar limits stated
as follows:
PRODUCT DOLLAR LIMIT PERIOD OF COVERAGE
XVT 25,000 Term of XPC Limited Warranty
XST 25,000 Term of XPC Limited Warranty
S70 25,000 Term of XPC Limited Warranty
XPRT 6kVA & 10kVA 50,000 Term of XPC Limited Warranty
NXRT 50,000 Term of XPC Limited Warranty
P90, P90L, P90g, P90Lg 50,000 Term of XPC Limited Warranty
T90 50,000 Term of XPC Limited Warranty
TX90, TX90i 50,000 Term of XPC Limited Warranty
This Load Protecon Policy is not deemed "rst dollar" coverage. XPC’s obligaon is reduced by any amounts that
the Purchaser is entled to recover, from other sources regarding the Connected Equipment, including, but not
limited to, insurance, other warranty, extended warranty, or legal liability, regardless of whether or not the Pur-
chaser makes a claim for recovery.
Eligibility for Coverage Under the Load Protecon Policy
1. The Product must be registered on the XPC website, www.xpcc.com, within 10 days of purchase. All re-
quired informaon must be provided, and Purchaser should retain a copy for Purchaser’s records. When
registering on the website, Purchaser must list all connected equipment that is directly connected to the

Xtreme Power Conversion Corporaon
S70 User’s Manual
Page 12
Uninterrupble Power Supply
product. Only those devices registered in that manner will be covered.
2. All Connected Equipment must be UL or CSA approved.
3. The Product must be plugged into a properly wired and grounded outlet. Use of input surge devices, ex-
tension cords, adapters, ground wires, or electrical connecons not manufactured by XPC voids the XPC
Load Protecon Policy. No other surge protecon device may be connected to the output sockets of the
Product. The installaon must comply with all applicable electrical and safety codes set forth pursuant to
the NEC.
4. The Product must have undeniable physical evidence of a Power Disturbance that directly and proximately
caused the damage;
5. The Connected Equipment must have been damaged by a Power Disturbance on a properly installed,
grounded, and Naonal Electric Code, ("NEC"), code-compliant 120, 208, 240 Volt AC power line in the
United States or Canada, by a Power Disturbance on standard telephone land line or PBX telephone equip-
ment line that is properly installed and connected to an RJ11 port on the Product; or by a Power Distur-
bance on a standard Local Area Network connecon that is properly installed and connected to an RJ45
port on the Product and (d) is directly plugged into, and properly connected to, the Product in its original
condion which was properly operated when a Power Disturbance passed through the Product and (i)
exhausts the protecon capacity of the Product or (ii) damages the Product.
6. The Load Protecon Policy does not apply if the Product has been operated in a failure mode or not in
compliance with XPC operang instrucons in the Product user's manual, or if the Connected Equipment
has not been operated in compliance with the instrucons and manuals of its manufacturer/vendor.
7. This policy is null and void if, XPC determines, in its sole discreon, that the Product has been tampered
with or altered in any way.
What is Not Covered Under the Load Protecon Policy:
The following damage is not covered by this Policy:
1. Restoraon of lost data and reinstallaon of soware.
2. Damage from a cause other than AC power-line transients, except for damage due to telephone line, Local
Area Network, or CATV transients, which is covered only if the Product oers such protecon.
3. DAMAGE CAUSED BY FAILURE TO PROVIDE A SUITABLE INSTALLATION ENVIRONMENT FOR THE PRODUCT
(INCLUDING, BUT NOT LIMITED TO, LACK OF A PROPER SAFETY GROUND).
4. Damage caused by the use of the Product for purposes other than those for which it was designed.
5. Damage caused by accidents, or natural disasters, including but not limited to, re, ood, and wind.
6. Damage caused by abuse, misuse, alteraon, modicaon, or negligence.
7. Any labor costs or travel, room and board expenses associated with the repair and/or restoraon of lost or
damaged hardware, soware or data.
EXCEPT AS EXPRESSLY PROVIDED IN THIS POLICY, XPC SHALL NOT BE LIABLE FOR ANY DAMAGES WHATSOEVER,
INCLUDING, BUT NOT LIMITED TO, DIRECT, INDIRECT, SPECIAL, INCIDENTAL, CONSEQUENTIAL, OR MULTIPLE
DAMAGES ARISING OUT OF THE USE OF THE PRODUCT OR DAMAGE TO THE CONNECTED EQUIPMENT, REGARD-
LESS OF THE LEGAL THEORY ON WHICH SUCH CLAIM IS BASED, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH
DAMAGE. SUCH DAMAGES INCLUDE, BUT ARE NOT LIMITED TO, LOSS OF PROFITS, LOSS OF SAVINGS OR REV-
ENUE, LOSS OF USE OF THE PRODUCT OR THE CONNECTED EQUIPMENT OR ANY ASSOCIATED EQUIPMENT, LOSS
OF SOFTWARE, COST OF CAPITAL, COST OF ANY SUBSTITUTE EQUIPMENT, FACILITIES OR SERVICES, DOWNTIME,
THE CLAIMS OF THIRD PARTIES, INCLUDING CUSTOMERS, AND INJURY TO PROPERTY.
Subming a Load Protecon Policy Claim:
1. Any claim under the Load Protecon Policy must be made within 10 days of the date of alleged damage to the
Connected Equipment.
2. Call the XPC technical support department at 1-800- 582-4524 and obtain a Load Protecon Policy Returned
Material Authorizaon (RMA) number. Have informaon on all applicable insurance or other resources of re-
covery/payment that is available to the Purchaser and the name of the power ulity supplier for the locaon
of the Connected Equipment. XPC will forward to the Purchaser a Load Protecon Policy claims form, which

Xtreme Power Conversion Corporaon
S70 User’s Manual
Page 13
Uninterrupble Power Supply
must be completed and led with XPC within 30 days.
• Mark the Load Protecon Policy RMA number on the Product the Purchaser is returning.
• Pack the Product in its original packaging or similar packing materials if the original packaging has
been discarded. Enclose the completed Load Protecon Policy claim form and a copy of the Purchas-
er’s original sales receipt for the Product in the box.
• Mark the RMA number clearly on the outside of the box.
• Ship the Product (one-way shipping charges paid by the Purchaser) to:
XPC Corporaon
230 Yuma Street
Denver, CO 80223
An: LPP RMA#
3. XPC will evaluate the Product to determine its level of funconality, and will examine the Product for evidence
of damage from a Power Disturbance.
• If XPCs' evaluaon provides no evidence of damage from a Power Disturbance, XPC will send to the
Purchaser (i) a report summarizing the tests performed and (ii) a rejecon of claim noce.
• If the Product shows evidence of damage from a Power Disturbance, XPC will request that all Con-
nected Equipment for which a Load Protecon Policy claim has been submied, be sent for evaluaon
to either XPC or an authorized service center. If it is determined that the Connected Equipment has
been damaged by a Power Disturbance, XPC will, in its sole discreon, issue payment to the Purchaser
for either the cost of repair of the Connected Equipment or the Fair Market Value of the damaged
Connected Equipment, up to the dollar limits stated above. XPC reserves the right to require the
Purchaser to transfer tle and deliver the Connected Equipment to XPC if it chooses to reimburse the
Purchaser for the fair market value of the Connected Equipment. XPCs' maximum liability shall be
reduced to reect all such other payments or sources of recovery, whether applied for or not.
4. If XPC issues payment to the Purchaser to have the Connected Equipment repaired, the repair must be per-
formed at a service center that is authorized by the manufacturer of the Connected Equipment. XPC reserves
the right to contact the authorized service center directly to discuss repair costs and damage to the Connected
Equipment to determine if it was caused by a Power Disturbance and the right to request that the service
center forward the Connected Equipment or components of the Connected Equipment to XPC for inspecon
5. Unless modied in wring signed by an ocer of XPC and the Purchaser, the terms of this policy are the com-
plete and exclusive agreement between the pares, superseding all prior agreements, oral or wrien, and all
other communicaons between the pares relang to the subject maer of this agreement. No employee of
XPC or any other party is authorized to make any representaons beyond those made in this agreement con-
cerning the Load Protecon Policy.
XPC Corporaon
230 Yuma Street
Denver, CO 80223
1.800.582.4524
