Xtreme TX90 Guide

TX90 6kVA & 10kVA Online UPS
6kVA, 10kVA Models
User & Installaon Manual
www.xpcc.com | © 2015 Xtreme Power Conversion Corporaon. All rights reserved. (Rev 8/27/15)

Xtreme Power Conversion Corporaon
TX90 6kVA & 10kVA User’s Manual
Page 2
Uninterrupble Power Supply
Table of Contents
Safety Instrucons And Baery Care............................................................4
Safety Instrucons...........................................................................................................................4
Baery Care.................................................................................................................................... 5
Product Introducon....................................................................................6
General Characteriscs....................................................................................................................6
Symbols on the LCD Display Panel...................................................................................................8
Panel Explanaons.........................................................................................................................10
Communicaon Port..................................................................................................................... 11
Installaon And Operaon.........................................................................12
Unpacking .................................................................................................................................... 12
Selecng Installaon Posion........................................................................................................12
Terminal Block Explanaon............................................................................................................12
Input Conguraon........................................................................................................................13
Output Conguraon.....................................................................................................................14
Start Up in Normal Mode..............................................................................................................15
Check Measured Values and Figures Detected by the UPS...........................................................17
Viewing the UPS Default Sengs..................................................................................................19
Changing the UPS Default Sengs................................................................................................21
Troubleshoong Guide...............................................................................24
Troubleshoong.............................................................................................................................24
Communicaon Soware...........................................................................25
Hardware Setup.............................................................................................................................25
Soware Installaon......................................................................................................................25
Oponal Interface Cards.............................................................................26
Relay (Dry Contact) Card............................................................................................................... 26
SNMP Card.................................................................................................................................... 26
Interface Card Installaon.............................................................................................................27
Replacing Baeries.....................................................................................28

Xtreme Power Conversion Corporaon
TX90 6kVA & 10kVA User’s Manual
Page 3
Uninterrupble Power Supply
Specicaons.............................................................................................30
Obtaining Service.......................................................................................31
Xtreme Power Conversion Limited Warranty...............................................32
Xtreme Power Conversion Load Protecon Policy.......................................33
Appendix A: T90-EBP920, EBP940, EBP960 User Guide...............................36
Introducon To The Rear Panel.....................................................................................................37
Installaon And Operaon............................................................................................................38
Selecng Installaon Posion........................................................................................................38
Installaon of Casters Cover...........................................................................................................39
Installaon Instrucons.................................................................................................................39
Specicaons.................................................................................................................................40

Xtreme Power Conversion Corporaon
TX90 6kVA & 10kVA User’s Manual
Page 4
Uninterrupble Power Supply
Safety Instrucons And Baery Care
Safety Instrucons
• For Parallel System installaon please refer to TX90 6kVA & 10kVA Parallel System Installaon Guide
• Due to small leakage currents generated by the EMI lter in the UPS it is necessary to double check that
the ground wire of the UPS is properly grounded before connecng the UPS to the AC mains.
• To ensure safety in all applicaons where a UPS is hard wired to the electrical supply, ensure that the sys-
tem is installed by a qualied electrical contractor.
• The UPS has its own internal energy source (baery). Should the baery be switched on when no AC
power is available there could be voltage at the output terminals.
• Make sure that the AC ulity outlet is correctly grounded.
• Do not open the case as there are no serviceable parts inside. Opening the case voids the warranty.
• Do not try to repair the unit yourself; contact your local supplier. Repairing the unit yourself voids the war-
ranty.
• Please make sure that the input voltage of the UPS matches the supply voltage.
• Use a cered input power cable with the correct plugs and sockets for the appropriate system voltage.
• To prevent any overheang of the UPS keep all venlaon openings free from obstrucon, and do not
store things on top of the UPS. Keep the UPS 30 cm away from the wall.
• Ensure that the UPS is installed within the proper environmental range. (0-40°C and 0-90% non-condens-
ing humidity)
• Do not install the UPS in direct sunlight. Your warranty may be void if the baeries fail.
• Install the UPS indoors as it is not designed for installaon outdoors.
• Dusty, corrosive and salty environments can damage any UPS.
• Install the UPS away from objects that give o excessive heat and areas that are excessively wet.
• If liquids are spilled onto the UPS or foreign objects dropped into the unit the warranty will be null and
void.
• The baery will discharge naturally if the system is unused for a long period of me.
• The UPS should be recharged every 2-3 months if unused. If this is not done then the warranty will be
null and void. When installed and being used the baeries will be automacally recharged and kept in top
condion.
• Do not install the UPS in an environment with sparks, smoke or hazardous gas.
• Make sure the UPS is completely turned o when transporng it. It might cause electrical shock if the
output is not cut completely.
• The UPS includes a Maintenance Bypass Switch. Please follow the procedures strictly when switching on
or o the Maintenance Bypass Switch.
• The UPS oers a CVCF (Constant Voltage Constant Frequency) seng funcon.
1. For correct seng and wiring please contact with your local ulity agent.
2. Do not set it yourself or your warranty will be void.
• This UPS has been designed and constructed to protect your assets from the wide range of power aberra-
ons experienced on ulity power lines today. It is your insurance for a reliable, clean and stable voltage
supply. It is worth taking care to install the system correctly and to have it maintained correctly by your
local dealer.
• SAVE THESE INSTRUCTIONS. This manual contains important instrucons that should be followed during
installaon and maintenance of the UPS and baeries.
• The UPS is intended for installaon in a controlled environment.
• CAUTION: A disconnect switch must be provided by others for the AC output circuit. To reduce the risk of
re connect only to a circuit provided with branch circuit over-current protecon for 30 amperes for 6kVA
(See below for 10 kVA details) rang in accordance with the Naonal Electric Code, ANSI/NFPA 70.

Xtreme Power Conversion Corporaon
TX90 6kVA & 10kVA User’s Manual
Page 5
Uninterrupble Power Supply
10 kVA tower Output No. Output rang Rangs of output branch circuit
over-current protecon
No.1 (L21-N21) 6 kVA, 120 V 45
No.2 (L22-N22) 6 kVA, 120 V 45
No.3 (L23-N22) 10 kVA, 208 V 50
No.4 (L21-N22) 10 kVA, 240 V 45
• CAUTION: To reduce the risk of re connect the UPS input to a circuit provided with branch circuit over-
current protecon for 40A for 6kVA and 60A for 10kVA rang in accordance with the Naonal Electric
Code, ANSI/NFPA 70.
• Install the UPS so that it is not likely to be contacted by people.
• The maximum ambient operang temperature is 40°C or equivalent.
• Units are considered acceptable for use in a maximum ambient 40°C.
• Servicing of baeries should be performed or supervised by personnel knowledgeable about baeries and
the required precauons.
• When replacing baeries, replace with the same type and number of baeries or baery packs.
• CAUTION – Risk of re hazard, UPS can be used with four Baery Cabinets.
• CAUTION - RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT TYPE. DISPOSE OF USED BAT-
TERIES ACCORDING TO THE INSTRUCTIONS.
• CAUTION - Do not dispose of baeries in a re. The baeries may explode.
• CAUTION – Do not open or mulate baeries. Released electrolyte is harmful to the skin and eyes. It may
be toxic.
• CAUTION– A baery can present a risk of electrical shock and high short circuit current. The following
precauons should be observed when working on baeries:
1. Remove watches, rings, or other metal objects.
2. Use tools with insulated handles.
3. Wear rubber gloves and boots.
4. Do not lay tools or metal parts on top of baeries.
5. Disconnect charging source prior to connecng or disconnecng baery terminals.
6. Determine if baery is inadvertently grounded. If inadvertently grounded, remove source from
ground. Contact with any part of a grounded baery can result in electrical shock. The likelihood
of such shock can be reduced if such grounds are removed during installaon and maintenance
(applicable to equipment and remote baery supplies not having a grounded supply circuit).
Baery Care
If the UPS is unused for an extended period of me it must be stored in a moderate climate. The baeries should
be charged for twelve hours every three months by plugging the UPS power cord into a wall receptacle and turn-
ing on the input breaker on the front panel. Repeat this procedure every two months under a high-temperature
environment.

Xtreme Power Conversion Corporaon
TX90 6kVA & 10kVA User’s Manual
Page 6
Uninterrupble Power Supply
Product Introducon
General Characteriscs
• True online architecture connuously supplies your crical device with stable, regulated, transient-free,
pure-sine-wave AC power.
• 20 kHz PWM sine-wave topology yields excellent overall performance. The high crest factor of the inverter
handles all high-inrush current loads without a need to upgrade the power rang.
• The mul-funconal LCD/LED panel displays various states of the UPS. The LED display shows the UPS
working status, ulity status and abnormal status. The LCD display shows input/output voltage, frequency,
load status, inner cabinet temperature, and abnormal phenomena.
• To protect the unit from overloading, it automacally switches to bypass mode in 160 seconds at 100-
105% load, or 40ms if loading is at 105 ~150% of rang. In case of overloading at 150% of rang, it switches
to bypass mode immediately. It will automacally switch back to inverter mode once the overload condi-
on ceases.
• Should the output become short-circuited, the UPS cuts the output automacally unl the short-circuit
situaon is removed manually.
• Should the unit become overheated, the internal thermal switch will detect the heat and switch to bypass
mode and vice versa.
• The fully digitalized control circuit built into the UPS allows upgrading the funconality of the UPS as well
as reaching a high-level of protecon of the UPS. Powerful communicaon capability enhances its ability
for remote control and monitoring.
• Maintenance-free, sealed baeries minimize aer-sales service.
• The maintenance bypass switch provides an easy and safe troubleshoong or maintenance funcon when
the ulity is normal.
• Providing four dierent working modes (Normal, ECO, CF50 and CF60) it may be used in a wide variety of
applicaons.
• The DC-start funcon ensures the start-up of the UPS during power outages.
• A revoluonary baery management circuit analyzes baery discharging status to adjust the baery cut-
o point and extend baery life.
• The intelligent, temperature-controlled fan may not only extend the life of the fan but also reduce noise
because of sudden fan spin. This helps keep your oce quiet and comfortable.
• When the UPS is out of order you can read the possible reason directly from the LCD screen, which re-
duces unnecessary repairs.
• When the UPS is operated in CF50 or CF60 mode, the recommended load connected shall be 75% of rated
capacity if the input voltage is 176-280 VAC and 50% of rated capacity if the input voltage is 160-280 VAC.

Xtreme Power Conversion Corporaon
TX90 6kVA & 10kVA User’s Manual
Page 7
Uninterrupble Power Supply
Single input System Block
1. UPS Ulity Input: to provide the AC source to the UPS recer circuit and charger.
2. UPS Ulity Input Breaker: to protect the UPS Recer circuit from over-current.
3. EMI Filter on UPS Ulity Input : to eliminate the magnec interference from AC Source or UPS Ulity Input.
4. Recer and Booster: When Ulity is normal, they will converts the AC to DC and correct input power
factor. When Ulity is abnormal, the baeries will be boosted to provide the DC voltage to the Inverter.
5. Internal Baery: When AC abnormal, it provide the backup power from the baeries.
6. Charger: the baery charging device.
7. Inverter: To convert the DC voltage to AC voltage
8. Auto Bypass Loop: When the UPS is overloaded or abnormal, the UPS will Switch the UPS from inverter
output to bypass output automacally.
9. UPS Output EMI Filter: To eliminate the magnec interference from the UPS Output and avoid the interfer-
ence caused by the output load and the UPS.
10. Maintenance Bypass Switch: Transfers system to maintenance bypass switch for maintenance.
11. Output isolaon transformer with adjustable input taps.
12
3
6
4789 10 11
5

Xtreme Power Conversion Corporaon
TX90 6kVA & 10kVA User’s Manual
Page 8
Uninterrupble Power Supply
Symbols on the LCD Display Panel
Item Symbol Descripon
1LINE Ulity or Bypass Source
2Baery Low
3Baery Abnormal
4UPS Overloaded
5UPS Working in specied mode*
6A Blackout Transfer occurred in UPS Output.
7
Bypass Input Abnormal, UPS fails to transfer to bypass, Bypass
Abnormal at ECO mode
8
Ulity Input Abnormal
9OFF UPS Shut o
10 LINE OFF UPS Abnormal Lock
11 UPS Flow Display
12 4-Digit Measurement Display
13 Indicates the item to be measured
14 UPS ON Switch or Alarm Silence
15 UPS OFF Switch
16 Previous Page or Seng Change
17 Next Page
18 Special Funcon Log In/Out
19 Enter or Reconrm

Xtreme Power Conversion Corporaon
TX90 6kVA & 10kVA User’s Manual
Page 9
Uninterrupble Power Supply
20 Ulity Input Normal LED
21 Bypass Input Normal LED
22 UPS under Redundancy Mode
23 UPS under ECO Mode
24 UPS Fault or Abnormal Warning LED
25 EPO Emergency Power O
26 Er05 Baery Weak or Dead
27 Er06 Output Short Circuit
28 Er10 Inverter Over-current
29 Er11 The UPS is overheated.
30 Er12 UPS Output Overloading
31 Er14 Fan Error
32 Er15 Wrong Procedure to Enter Maintenance Mode
33 Er16 Output Parameters Set Error in Parallel System
34 Er17 ID Numbers are in conict in Parallel System or ID number error
in single unit
35 Er21 Parallel communicaon error (communicaon wire disconnect-
ed or failure to nd ID1 UPS) in Parallel System
36 Er24 CVCF mode with Bypass input
37 Er27 The UPS must be operated in normal mode in Parallel System.
38 Er28 Bypass Overload Time out and cut o output
39 Er31 Control board and driver board sengs do not match.
40 Er33 Isolated transformer is overheated.
41 Er** Other Error code
*The specied modes include Normal mode, ECO mode, CVCF mode, etc.

Xtreme Power Conversion Corporaon
TX90 6kVA & 10kVA User’s Manual
Page 10
Uninterrupble Power Supply
Panel Explanaons
Front Panel
1 3 4 2 11 12
5 9 7 10 6 8
1 2 3 4 5 6 7
8
9
10
11
12
1. LCD
2. Green LED indicates that the UPS is able to run under redundancy mode.
3. Solid green LED indicates that the ulity input voltage is within the acceptable window. Flashing green LED
indicates that the ulity input voltage is outside the acceptable window.
4. Green LED indicates that Bypass Input is normal.
5. UPS ON/Alarm Silence
6. Go to previous page or change the seng of the UPS.
7. Conrm a changed seng.
8. Go to the next page.
9. UPS OFF Switch
10. Special funcons log in/out
11. UPS is working under ECO (Economy) mode.
12. UPS Fault or Abnormal
A. RS-232 Port
B. Terminal Resistor for Parallel funcon
C. CAN Bus Connecon Port for Parallel System
D. Oponal Communicaon Slot 1
E. Oponal Communicaon Slot 2
F. Cooling Fans

Xtreme Power Conversion Corporaon
TX90 6kVA & 10kVA User’s Manual
Page 11
Uninterrupble Power Supply
G. External Baery Connector
H. External Charger Connector
I. Ulity Input Breaker CB1
K. CAM Switch (Maintenance Bypass Switch)
L. Input/Output Terminal Block (shown with cover removed)
M. Mounng Holes for External Charger Cabinet
N. EPO (Emergency Power O): Short to enable the funcon
O. Thermal breaker for the protecon of Load in abnormal condion: CB3 (TX90-10K only)
P. Air Venlaon Hole
Communicaon Port
The communicaon port on the UPS provides for RS-232 communicaon with the UPS soware to remotely moni-
tor the power and UPS status.
You may use oponal interface cards for Relay (Dry Contact) and SNMP. These cards may be used simultaneously.
The soware bundled with the UPS is compable with many operang systems such as Windows 98, 2000, ME,
NT and XP. For other applicaons such as Novell NetWare, Unix, or Linux please contact your local distributor for
a proper soluon.
When the oponal interface cards are used together with the onboard RS-232 port the EPO signals will get highest
priority, then the SNMP/WEB card, then the shutdown command at the relay card, and then nally the onboard
RS-232 port gets the lowest priority.
True RS-232
Interface Sengs
The RS-232 interface shall be set as follows:
Baud Rate 2400 bps
Data Length 8 bits
Stop Bit 1 bit
Parity None
Pin Assignments
The Pin Assignments of true RS-232 are as follows (The connector is male):
Pin 3: RS-232 Rx
Pin 2: RS-232 Tx
Pin 5: Ground

Xtreme Power Conversion Corporaon
TX90 6kVA & 10kVA User’s Manual
Page 12
Uninterrupble Power Supply
Installaon And Operaon
Carefully inspect the UPS for shipping damage before installaon. Retain the packing material for future use.
Unpacking
Standard package contents:
• Quick start guide
• User manual
• Upsilon 2000 soware CD
• (3) Output jumpers
• (4) Small Phillips head screws
• RS-232 cable
• Oponal skirt assembly including: (2) 22 3/4” side skirt, (2) 11.5” front and rear skirt, and (1) plasc skirt
Selecng Installaon Posion
Install the UPS in a proper environment to minimize the possibility of damage to the UPS and to extend the life of
the UPS. Please follow these requirements:
1. Keep at least 12 inches clearance from the rear panel of the UPS to the wall.
2. Keep at least 8 inches clearance from the rear panel of the External Baery Pack (EBP) to the wall. Refer to
the T90-EBP920, EBP940, EBP960 user manual for more details.
3. Do not block the air ow to the venlaon openings of the unit.
4. Ensure that the installaon site is not excessively hot or moist.
5. Do not place the UPS in an environment near dust, corrosive or salty material, or ammable objects.
6. Do not expose the UPS to the outdoors.
Terminal Block Explanaon

Xtreme Power Conversion Corporaon
TX90 6kVA & 10kVA User’s Manual
Page 13
Uninterrupble Power Supply
L11 NOT USED: all systems are single input
N1, L12, G1: the terminals for ulity input with single input connecon
G1: the terminal for UPS input ground
N1: line 1 (L1) input
L12: line 2 (L2) input
G2, N22, L22, N21, L23, L21: the terminals for UPS output, see below output opons for conguraon details
G2: the terminal for UPS output ground
Remarks:
1. The maximum current for each terminal is 30 Amps for 6 kVA, 50 Amps for 10 kVA.
2. The UPS is always a Single Input conguraon. The Dual Input conguraon is not used. The AC source can
be 208V or 240V landed to the L12 and N1 terminals.
3. Use No. 6 AWG, 75°C minimum copper wire and 23 lb-in Torque force when connecng to terminal block.
4. The transformer has two input voltage opons, 208V and 240V. If the input is congured at 208V but the
actual input is 240V, then the output voltages will boost up 15%.
Input Conguraon
208V input applicaons: 208V input with a 120/240V output is the default for these systems. This means the in-
verter output is programmed to 208V and the output transformer primary tap is set to the 208V seng. These are
the default sengs for this system. Please refer to output Opon 1 in this secon.
240V input applicaons: If the input voltage is 240V, the following steps must be performed to obtain a 120/240V
output with a 240V input.
1. With no AC applied to the unit, change the transformer primary tap from 208V default seng to 240V
shown below. Access to tap sengs is gained by removing the side covers.
TX90-6K Input Taps TX90-10K Input Tap Board
2. The UPS inverter output voltage must also be programmed to 240V. Refer to the Changing the UPS Default
Sengs secon for more details. Opon 1 below provides a 120/240V output with a 240V input.
Move red
wire to here
when there is
a 240V input
Tap shown
on the 208V
seng
240V tap

Xtreme Power Conversion Corporaon
TX90 6kVA & 10kVA User’s Manual
Page 14
Uninterrupble Power Supply
Output Conguraon
All of the output opons shown below apply to 208V input systems and 240V input systems.
Opon 1: 120V/240VAC - THIS IS THE DEFAULT OPTION FOR ALL UNITS: Each branch max loading 50%. Please
note the jumpers between G2-L22 and L22-N21 for this opon.
Opon 2: 120V full capacity output. Please note the jumpers between G2-N22, N22-N21, and L22-L21 for this
opon. See below.
For any other output conguraons needed, please contact Xtreme Power Tech Support.
Please refer to the specicaons of input current, output current and recommended conductors listed below.
a. AC input and output (minimum 75°C copper wire)
Model Maximum Input
Current
Input Breaker Size Input & Output
Conductor Secon
Terminal Torque
Force
6KVA 33 A 40 A AWG #8 17.7/11 lb-in
10KVA 54.3 A 60 A AWG #6 23 lb-in
b. Baery input
Model Maximum Current Conductor Secon
6KVA 25 A AWG #10
10KVA 41 A AWG #10

Xtreme Power Conversion Corporaon
TX90 6kVA & 10kVA User’s Manual
Page 15
Uninterrupble Power Supply
Start Up in Normal Mode
• Open the terminal block cover on the rear panel. Before starng the installaon make sure the wiring is
connected properly.
• Make sure the ulity input breaker and the UPS’ input breaker are in the “O” posion.
• Switch on the ulity input breaker on the distribuon panel and the UPS input breaker. Then the UPS will
start up. Green LEDs and show that the Ulity and Bypass inputs are normal. UPS will display rst gure
A1 and then gure B.
A1
B
• The UPS is now in Bypass Mode. It will proceed to self-test automacally. If no abnormal message appears
then the pre-startup of the UPS was successful and the charger begins to charge the baeries
• Press the UPS On switch for approximately three seconds. The Buzzer sounds twice and the LCD display
changes from gure B to gure C.
C
• The UPS is in self-test mode again. The LCD display will change from gure C to gure D, and the UPS will
remain in baery mode for approximately four seconds. Then the display will change from gure E1 to
gure F if the self-test was successful.
D
“test”

Xtreme Power Conversion Corporaon
TX90 6kVA & 10kVA User’s Manual
Page 16
Uninterrupble Power Supply
E1
“OK” in self-test
E2
“Fail” in self-test
F
“208 VAC” in Ulity Input
• If the self-test fails the LCD display will change from gure D to gure E2. Then an error code or error status
will appear on the screen.
• Your start-up operaon of the UPS is complete now. Make sure the UPS is connected to ulity and charging
at least 8 hours and the baeries are fully charged before connecng the device to be protected.
Start-up in Baery Mode (Cold Start)
• Make sure the UPS has at least one string (20 pcs) of baeries.
• Push the UPS On switch once for approximately 5 seconds to wake the UPS. The buzzer will sound
twice. The LCD display will change from gure A to gure G for approximately 15 seconds.
• Press the UPS On switch again for about three seconds unl the LCD display changes from gure G to
gure H. Then the UPS will be in self-test mode. The UPS may oer energy to the output in a minute, and
the LCD displays gure I. In case of failure in pushing the UPS On switch for 15 seconds, the UPS will auto-
macally turn o. You must then repeat steps.
G
“O”, which means the UPS pre-start was successful

Xtreme Power Conversion Corporaon
TX90 6kVA & 10kVA User’s Manual
Page 17
Uninterrupble Power Supply
H
Ulity input is “0” and Ulity Abnormal.
I
Check Measured Values and Figures Detected by the UPS
• If you would like to check the measured values and gures detected by the UPS, use the scroll up
and scroll down keys. When you scroll down the LCD will display gure C (Voltage from Ulity Input)
→ gure I1 (Voltage from Bypass Input) → gure J (Frequency from Ulity Input) → gure K (Frequency
from Bypass Input) → gure L (UPS Output Voltage) → gure M (UPS Output Frequency) → gure N (UPS
Output Load %) → gure O (UPS Baery Voltage) → gure P (UPS Inner Temperature).
I1
Voltage comes from Bypass Input.
J
Frequency of Ulity Input

Xtreme Power Conversion Corporaon
TX90 6kVA & 10kVA User’s Manual
Page 18
Uninterrupble Power Supply
K
Frequency of Bypass Input
L
UPS output voltage
M
UPS output frequency
N
UPS output load level (%)
O
Baery voltage

Xtreme Power Conversion Corporaon
TX90 6kVA & 10kVA User’s Manual
Page 19
Uninterrupble Power Supply
P
UPS inner temperature
Viewing the UPS Default Sengs
• Aer the UPS completely starts up, press the (funcon) key to change the LCD display to gure Q1.
Q1
Buzzer “On”. Use the key to toggle the seng and then save.
Q2
Buzzer “O”
• Press the key to scroll through the UPS sengs. The LCD will display in sequence gure Q1 (buzzer) →
gure R (Self-test) → gure S (Bypass Voltage Windows) → gure T (Output Frequency Synchronizaon
Window) → gure U (Inverter Output Voltage) → gure V (UPS Operaon Mode) → gure W (Output Volt-
age Micro Tune Value) → gure X (UPS Id) → gure Y (Parallel funcon status).
• Buzzer and Self-test can only be changed in this mode while the UPS is on. All other sengs must be
changed while the inverter is o in this mode. See Changing the UPS Default Sengs on page 22.
• Default sengs shown below.
R
Self-test is not “On”. Use the key to toggle the seng and then save.

Xtreme Power Conversion Corporaon
TX90 6kVA & 10kVA User’s Manual
Page 20
Uninterrupble Power Supply
S
Bypass Voltage is adjusted to narrow range. Selectable to Lo or Hi.
T
Frequency Window is +/-3 Hz. Selectable to ± 1Hz.
U
Inverter output voltage set to 208V. Selectable to 200, 208, 220, 230, 240V. This is the voltage
sent to the output transformer primary. The UPS output voltages depend on what output con-
guraon is chosen. Please refer to the Output Conguraon secon of this manual.
V
The UPS is operang in “normal mode”. Selectable to ECO, CF50, CF60, and Normal.
W
Output Voltage Adjustment (-1, -2, -3, 0, 1, 2, 3%)
