Xtreme C60-800 Guide

C60 Standby UPS
800VA Models
User & Installaon Manual
© 2015 Xtreme Power Conversion Corporaon. All rights reserved. (Rev 6/23/15)
For more information, visit www.247technology.com/on-line-ups/c60-standby-ups

Xtreme Power Conversion Corporaon
C60 User’s Manual
Page 2
Uninterrupble Power Supply
Table of Contents
Package Contents.........................................................................................3
Product Introducon....................................................................................3
Product Overview........................................................................................ 3
Installaon & Inial Startup.........................................................................4
Indicators & Alarm Condions......................................................................5
Troubleshoong...........................................................................................6
Specicaons...............................................................................................7
Obtaining Service.........................................................................................8
Xtreme Power Conversion Limited Warranty................................................9

Xtreme Power Conversion Corporaon
C60 User’s Manual
Page 3
Uninterrupble Power Supply
Package Contents
You should be receiving the following items inside the package:
• UPS Unit
Product Introducon
Thank you for selecng this uninterrupble power supply (UPS). It provides you with protecon for connected
equipment. Please read this manual before installing the C60 Series UPS models C60‐800 and C60i‐800 as it pro‐
vides important informaon that should be followed during installaon and maintenance of the UPS and baeries,
allowing you to correctly set up your system for the maximum safety and performance. Included is informaon
on customer support and service, if it is required. If you experience a problem with the UPS, please refer to the
Troubleshoong secon in this manual to correct the problem. If the problem is not corrected, please collect in‐
formaon so that the Technical Support personnel can more eecvely assist you.
Product Overview
The C60 Series UPS provides comprehensive protecon in a small and economical package. This UPS is compact,
oering greater power. The C60 has been designed with a microprocessor to guarantee high reliability, and pro‐
vides stable power to connected equipment, enabling shutdown of your equipment safely during a power failure.
Front view
Rear view - C60-800

Xtreme Power Conversion Corporaon
C60 User’s Manual
Page 4
Uninterrupble Power Supply
Rear view - C60i-800
Installaon & Inial Startup
Note: Before installaon, inspect the unit and packaging to make sure that nothing inside has been damaged.
Placement & Storage
Install the UPS in a protected area that is free of excessive dust and has adequate air ow. Place the UPS away
from other units at least 7.8 in (20 cm) to avoid interference. DO NOT operate the UPS where the temperature and
humidity is outside the specied limits. (See Specicaons for details).
Connect UPS to Ulity and Charging
Before the inial use of the UPS, plug the UPS input cord into a wall outlet and turn the UPS on by depressing the
Power switch on the front of the UPS. For best results, the baeries in the UPS should be charged for at least 8
hours before use. The UPS charges its baery while it is connected to AC ulity power and powered on.
Connecng the Loads
Plug the loads to be supported by the UPS into the output receptacles on the rear of the UPS. Simply turn the
power switch on the UPS on and the devices connected to the UPS will be protected by the UPS unit.
CAUTION: NEVER connect a laser printer or scanner to the UPS. This may cause damage to the unit.
Turn UPS ON/ OFF
To turn the UPS unit on, press the Power switch on the front of the UPS. To turn the UPS unit o, press the Power
switch on the front of the unit again.
Connecng Local Monitoring Soware
If it is desired to use the Local Monitoring Soware, and if your UPS is equipped with USB communicaons, con‐
nect a USB cable from your computer to the UPS,and install the soware from the CD.

Xtreme Power Conversion Corporaon
C60 User’s Manual
Page 5
Uninterrupble Power Supply
Indicators & Alarm Condions
Condion Visual Indicator Alarm
AC mode Green LED illuminated No Audible Alarm
Baery mode Green LED ashes every 10 seconds Audible Alarm sounds every 10
seconds
Low baery mode Green LED ashes every 1 second Audible Alarm sounds every 1
second
Fault Red LED is illuminated Audible Alarm is connuous
Overload Audible Alarm sounds every 0.5
seconds
IMPORTANT SAFETY INSTRUCTIONS: (SAVE THESE INSTRUCTIONS)
CAUTION! (UPS having Internal Baeries): Risk of electrical shock – Hazardous live parts inside this unit are ener‐
gized from the baery supply even when the input AC power is disconnected.
CAUTION! (No User serviceable Parts): Risk of electrical shock, do not remove cover. No user serviceable parts
inside. Refer servicing to qualied service personnel.
CAUTION! (Non‐isolated Baery supply): Risk of electric shock, baery circuit is not isolated from AC input, haz‐
ardous voltage may exist between baery terminals and ground. Test before touching.
WARNING! Unit intended for installaon in a controlled environment.
CAUTION! Do not dispose of baeries in a re, the baery may explode.
CAUTION! Do not open or mulate the baery, released electrolyte is harmful to the skin and eyes.
CAUTION! A baery can present a risk of electric shock and high short circuit current. The following precauon
should be observed when working on baeries:
Remove watches, rings or other metal objects.
Use tools with insulated handles.
To reduce the risk of electric shock, disconnect the UPS from the main supply before installing a computer inter‐
face signal cable. Reconnect the power cord only aer signaling interconnecons have been made. Servicing of
baeries should be performed or supervised by personnel with knowledge of baeries and the required precau‐
ons. Keep unauthorized personnel away from baeries.
The instrucons contained within this safety manual are deemed important and should be closely followed at all
mes during installaon and follow‐up maintenance of the UPS and baeries.
CAUTION: The unit has a dangerous amount of voltage. If the UPS indicator is on, the unit’s outlets may have
a dangerous amount of voltage even when not plugged into the wall outlet because the baery may connue to
supply power. Care should be taken to undertake installaon indoors, free from electrically‐conducve parcles
which are under temperature and humidity control, in order to reduce the risk of electric shock. It is best to dis‐
connect the device using the power supply cord. Ensure that the equipment is placed in a posion near the outlet
where easily accessible. All servicing on this equipment must be carried out by qualied service personnel. Before
conducng any maintenance, repair, or shipment, rst ensure that everything is turned o completely and discon‐
nected.

Xtreme Power Conversion Corporaon
C60 User’s Manual
Page 6
Uninterrupble Power Supply
Troubleshoong
Condion Visual Indicator Alarm
No LED display on the front UPS
panel
Low baery Charge the UPS at least 8 hours
Baery fault Replace the baery with the same
type of baery
The UPS is not turned on Press the Power Switch on the front
of the UPS
Alarm connuously sounds when
the AC input is normal
The UPS is overloaded Remove some of the load from the
output of the UPS
UPS fault Return the unit for service
Alarm sounds every 2 seconds
when the AC input is normal
Baery defect Replace the baery with the same
type of baery
Charging circuit is damaged Return the unit for service
When power fails, backup me is
shorter than expected
The UPS is overloaded Remove some of the load from the
output of the UPS
Baery voltage is too low Charge the UPS at least 8 hours
Baery defect Replace the baery with the same
type of baery
The AC input is normal but the
green LED is ashing Power cord is loose Reconnect the input power cord properly

Xtreme Power Conversion Corporaon
C60 User’s Manual
Page 7
Uninterrupble Power Supply
Specicaons
MODEL NUMBER C60‐800 C60i‐800
INPUT Capacity 800VA (480W)
Nominal voltage 120VAC 230VAC
Voltage range 80–135VAC ± 5% 175–254VAC
Frequency range 55–65Hz at 60Hz ± 1Hz 45–55Hz at 50Hz ± 1Hz
Surge protecon 158 J
AC power cord 6 , IEC C13 to 5–15P IEC C14 inlet only
OUTPUT Voltage (line mode) 80–135VAC ± 5% 175–254VAC
Voltage (baery mode) 120VAC ± 10% 230VAC ± 10%
Voltage regulaon ± 2%
Frequency (line mode) 55–65Hz at 60Hz ± 1Hz 45–55Hz at 50Hz ± 1Hz
Frequency (baery mode) 60Hz ± 1Hz 50Hz ± 1Hz
Waveform Sine wave (normal), simulated sine wave (baery mode)
Transfer me 2–6 ms
Outlets (2) NEMA 5–15R (2) IEC C13
Overload capacity 110% +20% / ‐10% for 5 min; 120% +20% / ‐10% immediately o
Eciency > 95%
BATTERY UPS baery type (1) 12V 9AH / 12VDC
UPS charge current 1A maximum
Recharge me 8 hours to 90% capacity
PHYSICAL Dimensions (W x D x H) 4.0 x 13.0 x 5.7 in
Weight 7.5 lbs
ENVIRONMENT Temperature 32–104°F (0–40°C)
Humidity 0–90%
Altude 11,500  above sea level
INDICATORS & Line mode Green LED illuminated
ALARMS Baery mode Green LED ashing every 10 sec
Baery low Green LED ashing every 1 sec
Fault mode O
Audible alarm Baery mode ‐ every 10 sec; low baery ‐ every 1 sec; overload ‐ ever 0.5 sec;
fault ‐ constant alarm
APPROVALS UL 1778, FCC Class A, RoHS S‐Mark, EN62040‐1, EN62040‐2, RoHs
WARRANTY 3 years electronics, 3 years baery (USA and Canada)

Xtreme Power Conversion Corporaon
C60 User’s Manual
Page 8
Uninterrupble Power Supply
Obtaining Service
If the UPS requires Service:
1. Use the TROUBLESHOOTING secon in this manual to eliminate obvious causes.
2. Verify there are no circuit breakers tripped.
3. Call your dealer for assistance. If you cannot reach your dealer, or if they cannot resolve the problem, call Xtreme
Power Conversion Corp Technical Support at 800.582.4524. Technical support inquiries can also be made at
[email protected]. Please have the following informaon available BEFORE calling the Technical Support
Department:
• Your name and address.
• The serial number of the unit.
• Where and when the unit was purchased.
• All of the model informaon about your UPS.
• Any informaon on the failure, including LED’s that may or may not be illuminated.
• A descripon of the protected equipment, including model numbers if possible.
• A technician will ask you for the above informaon and, if possible, help solve your problem over the
phone. In the event that the unit requires factory service, the technician will issue you a Return Mate‐
rial Authorizaon number (RMA).
If you are returning the UPS to Xtreme Power for service, please follow these procedures:
1. Pack the UPS in its original packaging. If the original packaging is no longer available, ask the Technical Sup‐
port Technician about obtaining a replacement set of packaging material. It is important to pack the UPS
properly in order to avoid damage in transit. Never use Styrofoam beads for a packing material.
2. Include a leer with your name, address, dayme phone number, RMA number, a copy of your original
sales receipt, and a brief descripon of the problem.
3. Mark the RMA number on the outside of all packages. Xtreme Power cannot accept any package without
the RMA number marked on the outside of the boxes.
4. Return the UPS by insured, prepaid carrier to the address provided by the Technician.
5. Refer to the Warranty statements in this manual for addional details on what is covered.

Xtreme Power Conversion Corporaon
C60 User’s Manual
Page 9
Uninterrupble Power Supply
Xtreme Power Conversion Limited Warranty
Xtreme Power Conversion (XPC) Corporaon warrants Xtreme Power Conversion equipment, when properly ap‐
plied and operated within specied condions, against faulty materials or workmanship for a period of two years
for C60 Series products from the date of purchase. XPC Corporaon warrants internal baeries for a period of
two years from the date of purchase. For equipment sites within the United States and Canada, this warranty cov‐
ers repair or replacement, at the sole discreon of XPC Corporaon. The customer is responsible for the costs of
shipping the defecve product to XPC Corporaon. XPC Corporaon will pay for ground shipment of the repaired
or replacement product. This warranty applies only to the original purchaser.
If equipment provided by XPC Corporaon is found to be Dead‐on‐Arrival (DOA), XPC Corporaon will be respon‐
sible for the costs of shipping product to and returning equipment from the customer in a mely manner as agreed
to with the customer, once the customer has requested and received a Return Material Authorizaon (RMA)
number. DOA equipment is dened as equipment that does not properly funcon according to user documenta‐
on when inially received and connected in conjuncon with proper procedures as shown in the user documen‐
taon or via support provided by XPC Corporaon personnel or authorized agents.
This warranty shall be void if (a) the equipment is repaired or modied by anyone other than XPC Corporaon or
a XPC Corporaon approved third party; (b) the equipment is damaged by the customer, is improperly used or
stored, is subjected to an adverse operang environment, or is operated outside the limits of its electrical speci‐
caons; or (c) the equipment has been used or stored in a manner contrary to the equipment’s operang manual,
intended use or other wrien instrucons. Any technical advice furnished by XPC Corporaon or a XPC Corpora‐
on authorized representave before or aer delivery with regard to the use or applicaon of Xtreme Power Con‐
version equipment is furnished on the basis that it represents XPC Corporaons best judgment under the situaon
and circumstances, but it is used at the recipient’s sole risk.
EXCEPT AS STATED ABOVE, XPC Corporaon DISCLAIMS ALL WARRANTIES, EXPRESSED OR IMPLIED, INCLUDING
WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE.
EXCEPT AS STATED ABOVE, IN NO EVENT WILL XPC Corporaon BE LIABLE FOR DIRECT, INDIRECT, SPECIAL, INCI‐
DENTAL, OR CONSEQUENTIAL DAMAGES ARISING OUT OF THE USE OF Xtreme Power Conversion EQUIPMENT,
including but not limited to, any costs, lost prots or revenue, loss of equipment, loss of use of equipment, loss
of soware, loss of data, cost of substutes, or claims by third pares. Purchaser’s sole and exclusive remedy for
breach of any warranty, expressed or implied, concerning Xtreme Power Conversion equipment, and the only
obligaon of XPC Corporaon under this warranty, shall be the repair or replacement of defecve equipment,
components, or parts; or, at XPC Corporaons sole discreon, refund of the purchase price or substuon of an
equivalent replacement product.
[email protected]
24/7 Technology Inc
1349 Old 41 Hwy Suite 135, Marietta, GA 30060
Phone: [phone] Fax: [phone]
www.247technology.com
