Xtreme T90 Online 700VA Guide

T90 Online UPS
700VA, 1000VA, 1500VA, 2000VA, 3000VA Models
User & Installaon Manual
www.xpcc.com | © 2015 Xtreme Power Conversion Corporaon. All rights reserved. (Rev 4/15/15)

Xtreme Power Conversion Corporaon
T90 User’s Manual
Page 2
Uninterrupble Power Supply
Table of Contents
EMC Statements - FCC Part 15......................................................................4
ICES-003...........................................................................................................................................4
Declaraon of Conformity Request.................................................................................................4
Special Symbols...............................................................................................................................6
Introducon.................................................................................................7
Product Descripon.....................................................................................7
Double Conversion Online Technology............................................................................................7
Eciency Opmizer Funcon..........................................................................................................8
Free Run Mode................................................................................................................................8
Diagnosc Tests...............................................................................................................................8
System Conguraon...................................................................................................................... 8
System Conguraon...................................................................................9
Storage.......................................................................................................10
Installaon.................................................................................................10
Environment..................................................................................................................................10
Rear Panel Views...........................................................................................................................10
Connecon To Mains and Loads....................................................................................................13
Computer and Alarm Connecons..............................................................14
Connecng the UPS to a Computer...............................................................................................14
RS-232 Standard Interface Port.....................................................................................................14
USB Port (opon)...........................................................................................................................14
EPO Port (Emergency Power O)..................................................................................................15
Network Transient Protector..........................................................................................................15
Load Segments..............................................................................................................................15
User’s Guide To Operaons........................................................................15
Starng and Shung Down the UPS.............................................................................................15
Buon Operaon.......................................................................................................................... 15
Control Panel Funcons.................................................................................................................16

Xtreme Power Conversion Corporaon
T90 User’s Manual
Page 3
Uninterrupble Power Supply
Troubleshoong.............................................................................................................................19
Maintenance..............................................................................................20
Replacing Baeries........................................................................................................................20
Technical Specicaons..............................................................................21
Terminal Block........................................................................................... 22
Obtaining Service.......................................................................................23
Xtreme Power Conversion Limited Warranty...............................................24
Xtreme Power Conversion Load Protecon Policy.......................................25

Xtreme Power Conversion Corporaon
T90 User’s Manual
Page 4
Uninterrupble Power Supply
EMC Statements - FCC Part 15
Noce: Pursuant to secon 15 of the FCC rules, this product has been tested and thereby complies to the condi-
ons of a Class B (700-1500VA) and Class A (2000-3000VA) digital device, which have been established for oering
sucient protecon against dangerous interference for installaon in a residenal area. Installaon and use of the
equipment should comply with the instrucons provided in order to avoid such interference due to the amount
of radio frequency energy that is radiated and generated by the equipment. In spite of this, we cannot assure that
a certain amount of interference may not occur in some installaons. If, by turning on and o, it can be deduced
that your radio or television recepon is found to be inuenced by harmful interference from the equipment, it is
recommended to use one of the following prevenve measures:
• Place the receiving antenna in a separate locaon or orientaon.
• Ensure a greater distance is achieved between the receiver and the equipment.
• Ensure that your equipment is connected to an outlet on a separate circuit than the receiver.
• Contact a technician experienced with radio and TV or a dealer for further assistance.
ICES-003
This Class B Interference Causing Equipment meets all requirements of the Canadian Interference Causing Equip-
ment Regulaons ICES-003.
Declaraon of Conformity Request
Units labeled with a CE mark comply with the following standards and direcves:
• Harmonic Standards: EN 50091-1-1, EN 62040-1-1 1st / IEC 62040-1-1 1st and EN 50091-2 / EN62040-2
1st / IEC 62040-2 1st.
• EU Direcves:73/23/EEC, Council Direcve on equipment designed for use within certain voltage limits:
2006/95/EC, Amending Direcve 93/68/EEC and 73/23/EEC
89/336/EEC, Council Direcve relang to electromagnec compability
2004/108/EC, Amending Direcve 92/31/EEC and 89/336/EEC relang to EMC
The EC Declaraon of Conformity is available upon request for products with a CE mark.
IMPORTANT SAFETY INSTRUCTIONS: (SAVE THESE INSTRUCTIONS)
• This Manual Contains Important Instrucons that should be Followed during Installaon and Maintenance
of the UPS and Baeries.
• WARNING: Intended for installaon in a controlled environment. Maximum ambient temperature 40°C.
• CAUTION: Risk of electric shock. Refer to top or rear or boom of UPS for cauonary markings.
• CAUTION: Risk of electric shock. Heat sinks are live. Disconnect unit before servicing.
• CAUTION (UPS Having Internal Baeries): Risk of electric shock - Hazardous live parts inside this unit are
energized from the baery supply even when the input AC power is disconnected.
• CAUTION (No User serviceable Parts): Risk of electric shock, do not remove cover. No user serviceable
parts inside. Refer servicing to qualied service personnel.

Xtreme Power Conversion Corporaon
T90 User’s Manual
Page 5
Uninterrupble Power Supply
• CAUTION (Non-isolated Baery supply): Risk of electric shock, baery circuit is not isolated from AC in-
put, hazardous voltage may exist between baery terminals and ground. Test before touching.
• WARNING (Fuses): To reduce the risk of re, replace only with the same type and rang of fuse.
• CAUTION: Do not disconnect baery connector under load.
• ATTENTION: Risk of electrical shock. With disconnecon of this unit from the mains, hazardous voltage
sll may be accessible through supply from the baeries. The baery supply should therefore be discon-
nected in the plus and the minus pole when maintenance or service work inside the baery cabinet or
UPS is considered.
• CAUTION (For any pluggable only): With the installaon of this equipment the sum of the leakage current
of the UPS and connected consumer should not exceed 3.5 mA.
• CAUTION (For permanent connecon only): HIGH LEAKAGE CURRENT, Earth connecon essenal before
supply connecon.
• CAUTION: Do not dispose of baeries in a re, the baery may explode.
• CAUTION: Do not open or mulate the baery, released electrolyte is harmful to the skin and eyes.
• CAUTION: A baery can present a risk of electric shock and high short circuit current. The following pre-
cauon should be observed when working on baeries:
A. Remove watches, rings or other metal objects.
B. Use only tools with insulated handles.
C. Wear rubber gloves and boots.
D. Do not lay tools or metal parts on top of baeries.
E. Disconnect charging source prior to connecng or disconnecng baery terminals.
• CAUTION: Servicing of baeries should be performed or supervised by personnel knowledge of baeries
and the required precauons. Keep unauthorized personnel away from baeries.
• CAUTION: When replacing baeries, replace with the same type and number of baeries: One Sealed lead
acid baery, rated 12 V, 8.5 Ah max.
• CAUTION: To reduce the risk of re, use only No. 26 AWG or larger telecommunicaon line cord.
• CAUTION (FOR 1500VA HV Only): To reduce the risk of re. Connect only to a circuit provided with 20
amperes maximum branch circuit overcurrent protecon in accordance with the Naonal Electric Code,
ANSI/NFPA 70”.
• CAUTION (FOR 3000VA Only): To reduce the risk of re. Connect only to a circuit provided with 30 amperes
maximum branch circuit overcurrent protecon in accordance with the Naonal Electric Code, ANSI/NFPA
70”.
• CAUTION (FOR 700-2000VA Only): To reduce the risk of re. Connect only to a circuit provided with 20
amperes maximum branch circuit overcurrent protecon in accordance with the Naonal Electric Code,
ANSI/NFPA 70”.

Xtreme Power Conversion Corporaon
T90 User’s Manual
Page 6
Uninterrupble Power Supply
The instrucons contained within this safety manual are deemed important and should be closely followed at all
mes during installaon and follow-up maintenance of the UPS and baeries.
CAUTION
The unit has a dangerous amount of voltage. If the UPS indicator is on, the unit’s outlets may have a
dangerous amount of voltage even when not plugged into the wall outlet because the baery may
connue to supply power.
Care should be taken to undertake installaon indoors, free from electrically-conducve parcles
which are under temperature and humidity control, in order to reduce the risk of electric shock.
It is best to disconnect the device using the power supply cord. Ensure that the equipment is placed
in a posion near the outlet where easily accessible.
Except for replacing the baeries, all servicing on this equipment must be carried out by qualied
service personnel.
Before conducng any maintenance, repair, or shipment, rst ensure that everything is turned o
completely and disconnected.
For addional safety instrucons, please use the Safety Manual as a reference.
Special Symbols
The following symbols used on the UPS warn you of precauons:
RISK OF ELECTRIC SHOCK - Please observe the warning that a risk of electric shock is present
CAUTION: REFER TO OPERATOR’S MANUAL - Refer to the operator’s manual for addional informaon,
such as important operang and maintenance instrucons.
SAFE GROUNDING TERMINAL - Indicates primary safe ground
LOAD ON/OFF – Pressing the buon turns on/o the output receptacles and the indicator light.
RJ45 RECEPTACLE – The receptacle provides network interface connecons and telephone or telecommu-
nicaons equipment should not be plugged into it.
Please do not discard the UPS or the UPS baeries as the UPS may have valve-regulated lead-acid baer-
ies. Please recycle baeries appropriately.

Xtreme Power Conversion Corporaon
T90 User’s Manual
Page 7
Uninterrupble Power Supply
Introducon
The informaon provided in this manual covers single phase T90 700–3000VA UPS, their basic funcons, operat-
ing procedures, and emergency situaons, also including informaon on how to ship, store, handle and install the
equipment. Only detailed requirements of the UPS units are described herein, and installaon must be carried out
in accordance with this manual. Electrical installaons must also carefully follow local legislaon and regulaons.
Only qualied personnel should conduct these installaons as failure to acknowledge electrical hazards could
prove to be fatal.
Product Descripon
Several dierent kinds of sensive electrical equipment stay protected by a UPS (Uninterrupble Power Supply)
including computers, workstaons, process control systems, telecommunicaons systems, sales terminals, other
crical instrumentaon, etc. The purpose of the UPS is to protect these systems from poor quality ulity power,
complete loss of power, or other associated problems.
Electrical interference abounds in many forms causing problems in AC power, from lightning, power company ac-
cidents and radio transmissions to motors, air condioners, and vending machines, among others. So protecon of
sensive electrical equipment is vital to protect against power outages, low or high voltage, slow voltage uctua-
ons, frequency variaons, dierenal and common-mode noises, transients, etc.
In order to prevent power line problems reaching crical systems causing damage to soware, hardware and
causing equipment to malfuncon, the UPS helps by maintaining constant voltage, isolang crical load output if
needed, and cleaning the ulity AC power.
Double Conversion Online Technology
A double conversion on-line technology UPS provides clean, uninterrupted single-phase power to your crical sys-
tems, while maintaining the baeries for their maximum potenal. In the event that the power failure lasts longer
than the UPS backup me, the UPS will shut down avoiding baery damage. When the input AC voltage returns,
the UPS will automacally return online to recharge the baeries.
As shown in block diagram:
• An input lter reduces transients on the mains
• For maintaining full baery charge, AC-power is reced and regulated in the recer feeding power to
the inverter and baery converter.
• DC power is converted to AC in the inverter passing it on to the load.
• Power is maintained from the baery during a power failure.
• The converter increases voltage appropriately for the inverter

Xtreme Power Conversion Corporaon
T90 User’s Manual
Page 8
Uninterrupble Power Supply
Eciency Opmizer Funcon
The Eciency Opmizer funcon is a feature of the UPS adding cost eecveness, minimizing power loss and
reducing power consumpon. Alternang between bypass and on-line modes is achieved automacally and in
accordance with the condions of the ulity power. On-line mode may be used during mes of irregular power
condions, and bypass mode when power ows smoothly in order to obtain greatest eciency. Irregularies can
be detected in less than a second, and on-line mode reacvated immediately. Switching back to online mode oc-
curs when input voltage is outside ±10% or nominal (±15% selectable), when input frequency is outside of ±3Hz
or when no input line is available.
Although high eciency is standard, the default operaon is in on-line mode. Bypass can be acvated in the LCD
panel, though on-line can be run permanently if preferred.
Free Run Mode
The UPS operates in free run mode when input frequency is outside of the selected input frequency range. Free
run mode is when output frequency does not match input frequency. When starng the UPS, the frequency regu-
laon detected is 50 or 60 Hz ±0.25Hz.
Diagnosc Tests
When you start the UPS, a diagnosc test is automacally executed that checks electronics, baery, and reports
any problems on the LCD display.
An advanced baery management system always monitors the condions of the baeries sends any fore warn-
ings if replacement is needed. Otherwise every 30 days of normal mode operaon, a baery discharge test is
performed and any problems reported on the LCD display.
Except during the rst 24 hours aer startup while the UPS is in charging mode, diagnosc tests can be performed
manually from the front panel at any me.
System Conguraon
The UPS device and the internal backup baery make up the system. Depending on the site and load requirements
of the installaon, certain addional opons are available as a tailored soluon.
Planning a UPS system, the following should be taken into consideraon:
• The total demand of the protected system shall dictate the output power rang (VA). Allow a margin for
future expansion or calculaon inaccuracies from measuring power requirements.
• Backup me needed will indicate the baery size needed. If load is less than the UPS nominal power rang
then actual backup me is longer.
• The following opons are available:
»External Baery Cabinets
»Maintenance bypass switches
»Connecvity opons (relay card, SNMP/WEB card)

Xtreme Power Conversion Corporaon
T90 User’s Manual
Page 9
Uninterrupble Power Supply
The following UPS models are available:
Model Backup me with internal baeries Recharge me to 90% capacity
T90-700 7 min 3 hours
T90-1000 7 min 3 hours
T90-1500 6 min 3 hours
T90-2000 7 min 3 hours
T90-3000 6 min 3 hours
Addional External Baery Cabinets are available if more back-up me is needed.
System Conguraon
Informaon presented here is vital to all personnel. Please read carefully.
Storage and Transportaon
Please handle with extreme cauon since a high amount of energy is contained in the baeries. Always keep the
unit in an upright posion as marked on the packaging and never drop the unit.
Installaon
If ammable substances such as gases or fumes are present or if the room is airght, a safety hazard situaon ex-
ists, in which no electrical equipment should be operated.
The instrucons in this manual explain how to install the UPS safely. Not acknowledging such electrical hazards
may be fatal, so keep this manual for all future reference.
WARNING!
It is strongly recommended that the UPS cabinet not be opened as the components have very high
voltage and touching them may be fatal. Only a qualied technician or an authorized agent may
service the unit.
This UPS unit’s output receptacles carry live voltage even when not connected to a power supply as
it has its own energy source.
User’s Operaons
The only operaons that users are permied to do are:
• Turning the UPS unit on and o
• Operang the users interface
• Connecng data interface cables
• Changing the baeries
All such operaons are to be performed exactly as instructed in this manual. The greatest care possible must be
taken for any of these operaons and any change thereof may prove very hazardous to the operator.

Xtreme Power Conversion Corporaon
T90 User’s Manual
Page 10
Uninterrupble Power Supply
Storage
Please adhere to the following instrucons if the UPS is not installed immediately:
• Store the equipment as is in its original packing and shipping carton
• Do not store in temperatures outside the range of +15°C to +25°C.
• Ensure that the equipment is fully protected from wet or damp areas and from moist air.
In order to maintain the vitality of the baeries, ensure that the UPS is recharged every 6 months for at least 8
hours.
Installaon
Environment
Ensure that all environmental concerns and requirements are met according to these technical specicaons, oth-
erwise the safety of installaon personnel cannot be guaranteed and the unit may malfuncon.
Ensure the following when selecng a locaon for the UPS system and baery opons:
• Avoid extremes of temperature and humidity. Maximum baery life can be aained with a recommended
temperature range of 15 °C to 25 °C.
• Provide protecon for the equipment from moisture.
• Space and venlaon requirements must be met. Ensure there is 100mm behind and 50mm on the sides
of the UPS for venlaon.
• Ensure that the front of the UPS remains clear for user operaon.
The External Baery Cabinets may be installed next to the UPS or under the UPS.
Rear Panel Views
T90-700, T90-1000, T90-1500 rear view

Xtreme Power Conversion Corporaon
T90 User’s Manual
Page 11
Uninterrupble Power Supply
T90i-1500 rear view
T90-15HW rear view

Xtreme Power Conversion Corporaon
T90 User’s Manual
Page 12
Uninterrupble Power Supply
T90-2000 rear view
T90-3000 rear view

Xtreme Power Conversion Corporaon
T90 User’s Manual
Page 13
Uninterrupble Power Supply
Connecon To Mains and Loads
• Ensure that the UPS is disconnected from mains and loads while connecng the External Baery Cabinets,
if needed.
• Use the baery cable that comes with the External Baery Cabinet to connect the External Baery Cabinet
to the UPS. Connect a second baery cabinet to the rst one with the cable provided if more than one is
to be installed.
• Be aware of UPS parameters and changing the Baery pack quanty when using the external baery
cabinets.
• Connect the UPS line cord to a grounded outlet. The baeries will automacally charge when connected
to the mains. Please realize that although you may start using the UPS immediately, maximum back-up
me will sll not be available, so it is recommended to charge the baeries for a minimum of 8 hours
before use.
• If unit instantly shows a “Site Wiring Fault”, rotate the connector (Schuko).
• Aer charging, connect the loads to the UPS.
• Do not connect any devices that have the possibility of overloading the UPS or drawing half-wave reced
current, such as hair dryers or vacuum cleaners.
• Should computer or alarm connecons be used, use connecons according to the manual provided with
that opon. The connecons can be referred to on the rear panel.
The installaon is now complete.
Example of Installaon of Plug & Play products

Xtreme Power Conversion Corporaon
T90 User’s Manual
Page 14
Uninterrupble Power Supply
Computer and Alarm Connecons
On the rear of the UPS is an interface allowing direct communicaon with your computer system. There is a RS232
serial data interface, one USB data interface and an emergency power o switch supplied. However, the RS232
port cannot be used when the USB interface is in use.
In addion there is an oponal interface slot that allows you to install dierent communicaons cards. It can be
used parallel with either the RS232 or USB ports.
Currently there are two cards available for the oponal interface slot. An SNMP/WEB card allows management and
monitoring over a network or internet, and the Relay card allows voltage free relay contacts. Your local dealer will
have more informaon about these opon cards.
Connecng the UPS to a Computer
The communicaon device for the UPS and PC comes as a complete package with power management soware.
Only the communicaon cable provided with the UPS may be used to connect to your computer, which is ac-
complished through the UPS RS232 port. Also ensure that the operang system on your computer is supported.
Instrucons provided in the power management soware will help with this installaon.
RS-232 Standard Interface Port
The RS-232 interface uses a 9-pin female D-sub connector. This informaon consists of data about ulity, load and
the UPS. The interface port pins and their funcons are idened in the following table.
Pin # Signal name Direcon (re UPS) Funcons
2TxD Output TxD Output
3RxD Input RxD / Inverter O Input
5 Common Common
6 AC Fail Output Ac Fail Output
8 Low Baery Output Low Baery Output
9 Output 12 VDC Power
Cauon! Max rated values 12Vdc
USB Port (opon)
Connecng the UPS to your computer may be accomplished through the USB port on the back of your computer.
USB compliant hardware and operang system will be necessary including installaon of a UPS driver. The serial
port cannot be used when using the USB port. The USB cable is standard.

Xtreme Power Conversion Corporaon
T90 User’s Manual
Page 15
Uninterrupble Power Supply
EPO Port (Emergency Power O)
A customer-supplied switch located remotely can be used to open the EPO connecon and allows UPS output re-
ceptacles to be switched o. Since the EPO shuts down the equipment immediately, orderly shutdown procedures
are not followed. The UPS must be manually restarted in order to regain power to the outlets.
Network Transient Protector
The network transient protector, located on the back panel, has both IN and OUT jacks, and houses a single RJ-45
(10BaseT) network connector. Connect the input connector to the jack labeled IN, and the output connector to
the jack labeled OUT.
Load Segments
The power management soware controls the sets of receptacles known as load segments which provides orga-
nized shutdown and startup of the equipment. Less crical equipment can be turned o during power outages
saving baery power for crical loads. The power management soware manual has more details regarding this.
The load group status can be viewed from the LCD display and can be changed if necessary. These load segments
are usually handled with the UPS management soware.
User’s Guide To Operaons
Necessary informaon for operaon of the unit is covered in this chapter. Normally the UPS runs automacally,
but for those few occasions such as just aer installaon, the starng and shung down procedures are described
herein.
Starng and Shung Down the UPS
Starng the UPS
• Ensure that installaon was correct and successful and that the input power cable is connected to a well-
grounded outlet.
• The UPS can be started by pushing the
buon on the front panel.
• The UPS should now start its inspecon of: internal funcons, mains synchronizaon and inverter startup.
Then output power will be supplied via the outlets.
• During this inspecon, the LCD will display “Ready on”. The LED shall light up when output power has com-
menced and the LCD will display “Line mode”.
• Switch on the loads.
Shung down the UPS
• Shut down and turn o the loads.
• Push the
buon on the front panel for three seconds. The alarm will sound and the UPS will shut down.
• The LCD will display UPS OFF for a few seconds.
• In emergency situaons, the EPO located on the back of the unit should be used.
Buon Operaon
There are three operang buons on the front panel.
1. ON / OFF BUTTON
a. Push the ON / OFF BUTTON for at least 3 seconds to turn on the UPS
b. Push the ON / OFF BUTTON for at least 5 seconds to turn the UPS o

Xtreme Power Conversion Corporaon
T90 User’s Manual
Page 16
Uninterrupble Power Supply
2. ENTER BUTTON
a. Push the ENTER BUTTON for at least 2 seconds to check content of the UPS. There are een funcons
that can be checked.
b. If you do not press the ENTER BUTTON within 10 seconds, the LCD will return to its original status.
3. FUNCTION BUTTON
a. Push the FUNCTION BUTTON for at least 2 seconds to choose the funcon you’d like. Each seng will
be displayed by pressing once, with fourteen funcons that can be checked.
b. Aer choosing the funcon, push the ENTER BUTTON to enter the funcon that you want.
c. Push the FUNCTION BUTTON to choose other funcons.
d. Push the ENTER BUTTON to enable the funcon selected.
e. Push the ENTER BUTTON again to conrm and fully enable the funcon.
f. If the ENTER BUTTON is not pressed within 10 seconds, the UPS will return to its original status.
Control Panel Funcons
Operaon of the UPS is indicated on the monitor panel with ve LED indicators and an LCD screen. This display is
also capable of alerng the user with audible alarms.
ON /
This LED is green when the UPS has been turned on and normal ulity power is available.
ONLINE / This LED is green when the UPS is in normal or stac bypass modes, and there is voltage
at the output receptacles.
ON-BAT / This LED is red when the UPS is operang in baery mode.
BYPASS / This LED is yellow when the UPS is in bypass mode.
FAULT / This LED is red if any internal error occurs in the UPS. An audible alarm will also be present.
Press any of the buons on the front panel to silence the alarm.
Status of the UPS, measurements and alarms are all indicated on the LCD screen.
Control panel
Normal display
The UPS status is shown in normal display mode. From here you have a choice to go to UPS meters display and the
Seng display by pushing the buon.
UPS meters display
Various measurements are available through the UPS meters display; pressing the buon will scroll through the
following meters:

Xtreme Power Conversion Corporaon
T90 User’s Manual
Page 17
Uninterrupble Power Supply
LCD message Descripon
O/P VOLT= xxx, xV Output AC voltage
O/P FREQ= xx, x Hz Output Frequency
I/P VOL T= xxx, xV Input AC voltage
I/P FREQ= xx, x Hz Input Frequency
BAT VOLT= xx,xV Baery Voltage
O/P LOAD%= xx% Load % of max load
O/P W= xW Output Was
O/P VA= xVA Output VA
O/P CURR= xA Output Current
BACKUP TIME= xx min Esmated Backup me in minutes
BAT CHARG= xx% Approximate percentage of Baery capacity
TEMPERATURE= xxC Approximate ambient temperature
BAT PACK NUM= x External Baery Pack Number
RATING = xxxxVA UPS Rang
CPU VERSION xx.x CPU Version
UPS conguraons
1. Various sengs that have been chosen are shown in the UPS seng display.
2. To enter conguraon mode, press the
buon for one second. The rst conguraon parameter will be
shown on the LCD display.
3. Press the buon to scroll through the parameters.
4. Press the buon to select the parameter.
5. Press the buon to scroll through the opons for the selected parameter; Press the buon to select
the opon.
6. You may be prompted to save the selecon, if so press the buon to either conrm or save your selec-
on. Other opons are saved and started automacally. See the table below for further details.
7. If no buons are pressed (or user inacvity) for ten seconds, the UPS shall exit the conguraon mode and
return to normal mode displaying Line mode.
Cauon!
The factory default sengs do not necessarily have to be changed, although you are free to tailor the UPS to your
specic needs.
Sengs LCD display Explanaon Selecon Factory
Default
Output
Volt. Seng O/P V Seng Select Nominal Voltage 208/220/230/240V 230V
100/110/115/127V 120V
Input/
Frequency I/P F Seng Select input frequency range when UPS goes into free run mode
±2%
±5%
±7%
±5%
Input/
Bypass Voltage I/P Bypass Set Select Input Voltage range when bypass is available
±10%
+10/-15%
+15/-20%
+10/-15%
Free Run Mode Free Run Set Select if UPS can run in Free run
mode (unsynchronized) ON/OFF ON

Xtreme Power Conversion Corporaon
T90 User’s Manual
Page 18
Uninterrupble Power Supply
Bypass Enable/
Disable at free
run mode
Bypass
disable
If Enable is chosen, the UPS can go
to bypass when unsynchronized. Disable/Enable Disable
HE mode seng HE Mode Set Select if UPS runs in high eciency
mode ON/OFF OFF
Force
Manual Bypass
Manual
bypass
Permanently force UPS to bypass.
For service only.** ON/OFF OFF
Management
of load groups Outlet Seng You can put the two load groups on and o form front panel
1 ON & 2 ON
1 OFF & 2 ON
1OFF & 2 OFF
1 ON & 2 OFF
Both load
segments
ON
Do Baery Test Baery Test Detect baery is normal or not.
Silence Funcon Silence Set Enable or disable silence funcon ON/OFF OFF
Number of
external baery
Packs
Bat Cabinet
Set
This seng is needed For UPS to
predict backup me
0 (only internal baeries)
1(one external cabinet)
2 (two external cabinets)
0
Site wiring alarm Sit Fault Set You can enable or disable the site
wiring alarm Enable /Disable Disable
Select language Language Select load language English, German, French,
Spanish, Italian. English
Set Generator
Mode Generator Set unit in generator mode. *** ON/OFF OFF
Set RS232
communicaon
RS232 Con-
trol
Set RS232 communicaon enable
or disable Enable/Disable Enable
Manual Test of UPS
A manual UPS or manual baery test can be conducted from the UPS conguraon menu.
Manual Baery Test: Scroll the parameters unl MANUAL BAT TEST displays on the LDC. Press the ENTER BUTTON
twice.
Note: In order for the UPS and power management soware to operate normally, MANUAL BYPASS should
always be set to OFF as the load will not be protected by the UPS when MANUAL BYPASS is ON. The MANUAL
BYPASS is intended to operate like an external maintenance bypass switch.
Note: The UPS should be turned OFF and inialized via AC power before using the GENERATOR MODE func-
on.
Interpreng UPS Messages
Troubleshoong procedures described here give simple instrucons in determining UPS malfuncons. Start the
troubleshoong procedure if you witness any alarm indicaon on the control panel.
Alarm Indicators
• The UPS gives the following audible alarms:
• If UPS is on baery and the ON BATTERY LED is on, UPS will beep every 5 seconds.
• If the baery capacity is low and the ON BATTERY LED is ashing, the UPS will beep twice every 5 seconds.
• If UPS is on bypass and the BYPASSED LED is on, UPS will no beep.
• If UPS has an internal fault and the ALARM LED is on, the UPS will give a constant audible alarm displaying
the cause on the LCD display.

Xtreme Power Conversion Corporaon
T90 User’s Manual
Page 19
Uninterrupble Power Supply
Silencing an Alarm
By pressing any of the three buons on the front panel, the alarm can be turned o, except when the baery is
low, which will cause the alarm to resound.
On the LCD display, you can also choose silent alarm mode which will not warn you of any malfuncon audibly.
Troubleshoong
Displayed on LCD Audible Alarm Alarm Descripon What You Should Do
Output Overload Two Beeps
per second
The UPS is overloaded (in Line
Mode). Your equipment needs
more power than the UPS can
provide. The UPS operates in
bypass.
Shut o the least important equip-
ment connected to the UPS. If this
solves the overload problem, the
UPS will switch from bypass back to
normal operaon.
Baery Test No Beeps The UPS is doing a baery test.
No acon needed. The UPS will
return to normal operaon when it
successfully completes the baery
test.
Over-Charge Constant beep Baeries are overcharged. Turn o protected loads. Turn o
UPS and call your local dealer
Low Baery 2 beeps every 5
seconds
The unit is operang on Baery
Power and will shut down soon
due to very low baery voltage
The unit will restart Automacally
when acceptable power returns.
On-Baery Once every 5
seconds
The unit is operang on Baery
Pow er.
Save your data and perform a con-
trolled shutdown.
Charger Failure Constant beep Charger has failed. Phone the local dealer
Over-Temperature Constant beep High ambient Temperature.
Make sure the unit’s fans and vent
holes are not blocked, and make
sure the ambient surrounding tem-
perature is not above 40 degree C.
If these condions did not solve the
problem, call your service represen-
tave.
Output Short Constant beep Output short circuit Call the Local dealer
High output Voltage Constant beep High output voltage Call the Local dealer
Low Output Voltage Constant beep Low output voltage Call the Local dealer
Bus Fault 2 Beeps per
second High internal DC bus Voltage. Turn o protected loads. Turn o UPS and call your local dealer
Site wiring Fault 1 Beep per
second
Voltage detected Between Neu-
tral and Ground
UPS mains connector polar-
ity Wrong. Rotate the connector
(Schuko). UPS installed to mains
supply without ground. See page
15 on how to disable the Site wiring
alarm
Line abnormal 1 Beep per
second
Wrong AC Line backed up
during auto restart

Xtreme Power Conversion Corporaon
T90 User’s Manual
Page 20
Uninterrupble Power Supply
Maintenance
With a minimal amount of maintenance, you can expect the UPS to applicaon, otherwise consider changing the
baeries. have a long life free of trouble. The most crical issues for the reliability of the UPS are environmental
issues. Ensure that the temperature and humidity are always according to specicaons and keep the area around
the unit clean and dust free.
At a temperature of 25°C, the typical baery lifeme is 4 years.
Replacing Baeries
The baeries may be replaced without having to turn the UPS o or disconnecng the load due to the hot swap-
pable baery feature.
CAUTION! Read and follow the IMPORTANT SAFETY INSTRUCTIONS before servicing the baery. Service the bat-
tery under the supervision of Qualied Service Personnel knowledgeable of baeries and their precauons.
CAUTION! Use only the specied type of baery. See your dealer for replacement baeries.
CAUTION! The baery may present risk of electrical shock. Do not dispose of baeries in a re as it may explode.
Follow all local ordinances regarding proper disposal of baeries.
CAUTION! Do not open or mulate the baeries. Released electrolyte is harmful to skin and eyes and may be toxic.
CAUTION! Although the baery voltage is only 12VDC, the baery can present a high risk of short circuit current
and electrical shock. The short circuit current capability of the baery is sucient to burn wire or tools very rap-
idly, producing molten metal. Observe these precauons when replacing the baery:
1. Remove all watches, rings or other metal objects.
2. Only use tools with insulated handles.
3. Do not lay tools or metal parts on top of baery or any terminals.
4. Wear protecve eye wear (goggles), rubber gloves, and boots.
5. Disconnect the charging source before connecng or disconnecng the baery terminals.
6. Determine if the baery is inadvertently grounded. If inadvertently grounded, remove the source of the
ground. Contact with a grounded baery can result in electrical shock! The likelihood of such shock will
be reduced if such grounds are removed during installaon and maintenance (applicable to a UPS and a
remote baery supply not having a grounded circuit).
Replacing baeries (700 - 3000 VA)
The following is a step-by-step tutorial for replacing the baeries:
1. The front panel of the UPS can be removed by pushing where the arrows indicate in the pictures above.
Next, unscrew the screws and remove the metal baery cover.
2. Remove the baery cartridge from the UPS. The voltage in all models will be less than 48Vdc once the bat-
tery is disconnected from the UPS.
3. Replace the baeries.
4. Push the cartridge with the new baeries back into the UPS.
5. Reinstall the metal plate and the front panel.
