Yale 3000 Series User manual

3/16”
#7
1/4-20
forWood drill 7/32
Machine Screws
#7 Drill, 1/4-20 Tap
Sleeve Nut and Bolt
Thru Bolt and Grommet Nut
Drill 9/32 thru from Closer Side
3/8 Drill other side
Drill 9/32 thru from Closer Side
3/8 Drill other Side
(Optional)
Metal Wood
Installation Instructions
80-9303-2206-010 (10-07)
Non Hold Open Models
Sized
(Sizes 2,3,4,5,6)
3100
3300
3500
Adjustable
(Sizes 1 thru 6)
3301
3501
Tri-Style
3000 Series
NOTE: For special applications a separate
door and frame preparation template is
packed with these instructions. Use this
instruction sheet for installation sequence
and closer adjustments only.
Doors should be hung on ball bearing or
anti-friction hinges.
A separate door stop is recommended.
Door and frame must be properly
reinforced.
Always adjust spring power before
adjusting control.
Adjust closing time speed between 3 and 7
seconds from 90° to 0°. Greater closing
times may be required for elderly or
handicapped.
These door closers should NOT be installed on the exposed side (weather side) of exterior doors.
Left Hand Door - LH
Right Hand Reverse - RHR
Right Hand Door - RH
Left Hand Reverse - LHR
Right Hand Door - RH
Left Hand Reverse - LHR
Regular Arm
Installation
See Page 2
Left Hand Door - LH
Right Hand Reverse - RHR
Left Hand Door - LH
Right Hand Reverse - RHR
Top Jamb
Installation
See Page 5
Regular Arm
Installation
See Page 2
Parallel Arm
Installation
See Pages
3&4
Parallel Arm
Installation
See Pages
3&4
Self Drilling Screws
Wood and Metal
For Wood drill 3/16 hole
Non Handed Door Closer
"DL” suffix (Delayed Action) is an optional
feature.
CAUTION
CAUTION
An Incorrectly installed or
improperly adjusted door closer can
cause property damage or personal
injury. These installation instructions
should be followed to avoid the
possibility of misapplication or
misadjustment.
!
Optional 3500MA Series
Architectural Metal Cover
Cover Screw
Cover Screws
Standoffs
Screw Pack
Optional 3500A Series
Architectural Plastic Cover
Insert Cutouts
Cover
Insert
Standoff
Standoff
Cover Clips
Cover Screw
Cover Screws
Optional 3500M
Series Metal Cover
Backcheck Valve Power Adjustment Shaft
Latch Valve
Sweep Valve
Closer Body
Regular Arm/Top
Jamb Shoe
Connecting Rod
Forearm
Screw
Main Arm
Closer Arm
289A Parallel
Arm Bracket
Cover
Insert
Standard 3500P Series
Full Cover
Insert Cutouts
NOTE: Architectural Cover
CAN NOT be used for doors
swinging over 120 using
parallel mount
°
Standard 3300 Series Narrow Cover
Pinion Cap (1639)
3400A Cover
3400P Cover
3400MA Cover
3400M Cover
* Pilot Hole
Required
3200P Cover
Top Jamb
Installation
See Page 5
Right Hand Door - RH
Left Hand Reverse - LHR

+
-
2
3
Non Hold Open Door Closers — Regular Arm
80-9303-2206-010 (10-07)
*Door/Wall/Hardware/Jamb
conditions permitting
Right Hand Shown
Inches
(mm)
—2—
3000 Series
Opening
To 100°
101° to 130°
131° to *180°
7-1/2
(191)
6
(152)
4-1/2
(114)
Dimension "A"
5-1/2
(140)
1-3/4
(44)
12
(304.8)
1
(25.4)
A
1-3/8
(35) 3/4
(19)
Spring Power Adjust
(If Necessary)
F
A
90°
E
C
L
Y
S
Z
R
B
D
+
-
Mark and Drill Holes
Installation Sequence
G
Optional
Optional
Covers
1
Parts
7
Pinion Cap or Optional Cover
or
(2)
3300 Series
Screw pinion cap onto pinion shaft by
hand or with a Phillips screw driver -
DO NOT OVER TIGTHEN.
Optional 3500M
Metal Cover Installation
2 Cover
Screws
3400M Cover
2 Clips for metal
covers 3500M
+
-
4
5
Latch
Sweep
+
-
6
Backcheck
Caution:
Don't completely
close valve
!
A

5
3
D
46
2
80-9303-2206-010 (10-07)
3000 Series Non Hold Open Door Closers — Parallel Arm
Door
Opening
To 120°
*121° to 180°
A
9-1/2
(241)
7
(178)
B
3-3/4
(95)
1-1/4
(32)
Close Valves
Latch
Sweep
++
3-1/2
(89)
3/4
(19) 12
(304.8)
Top of
Door
Inches
(mm)
Frame
B
C
L
1/2
(13)
7/16
(11)
2
(51)
2-3/4
(70) 3/8
(10)
A
Remove Arm
from Spindle
Place Arm on
Spindle
—3—
Mark and Drill Holes
Install Closer and Bracket Preload Closer
Installation Sequence
Right Hand Shown
G
Optional
A
B
E
C
1-1/2”
F
Parts 1
Optional
Cover
R
o
t
a
t
e
*Door/Wall/Hardware/Jamb
conditions permitting.
3500A and 3500MA Series
cannot be installed
for this door opening range.

7 98
80-9303-2206-010 (10-07)
3000 Series Non Hold Open Door Closers — Parallel Arm
10
— 4 —
Assemble Arm
Arm Screw
L
Y
S
Z
R
L
Y
S
Z
R
Left Hand
Door
Right Hand
Door
or
B
A
Flat
Flat
Open Valves
Caution:
Don't remove
valves
Latch
Sweep
!
11
Spring Power Adjust
(If necessary) 12
Sweep
+
-
14
or
(2)
Pinion Cap
or Optional Cover
3300 Series
Screw pinion cap onto
pinion shaft by hand or
with a Phillips screw driver
- DO NOT OVER TIGHTEN.
Backcheck
Caution:
Don't completely
close valve
+
-
!
2 Clips for metal
covers 3500M
2 Cover
Screws
Optional 3500M
Metal Cover Installation
3400M Cover
15
13
Latch
+
-
+
-
1-1/2
(38)
(Use 5/16” socket or adjustable wrench
for this Adjustment)

6
7
3
2
Spring Power Adjust
(If Necessary)
G
1
3000 Series
*Door/Wall/Hardware/Jamb
conditions permitting
Inches
(mm)
—5—
Parts
A longer connecting
rod, 400-11A, is
required for reveals
greater than 3" (76)
Optional
Covers
Reveal
Opening
To 100°
101° to 130°
131° to *180°
7-1/2
(191)
6
(152)
4-1/2
(114)
Dimension "A"
Right Hand Shown
Non Hold Open Door Closers — Top Jamb Arm
80-9303-2206-010 (10-07)
12
(304.8)
A
3/4
(19)
1/2
(13)
5-1/2
(140)
1-7/8
(38)
1-3/4
(44) C
L
Top of
Frame
Installation Sequence
D
A
C
L
Y
S
Z
R
E
90°
H
Optional
Mark and Drill Holes
BF
(2)
—5—
or
Pinion Cap
or Optional Cover
3300 Series
Screw pinion cap onto pinion shaft
by hand or with a Phillips screw
driver - DO NOT OVER TIGHTEN.
3400M Cover
2 Clips for metal
covers 3500M
2 Cover
Screws
Optional 3500M
Metal Cover Installation
Backcheck
Caution:
Don't completely
close valve
5
Latch
+
-
+
-
!
4
Sweep
+
-
+
-

—6—
3000 Series
80-9303-2206-010 (10-07)
EXTERIOR
INTERIOR
Regular Arm
Top Jamb
Regular Arm
Top Jamb
Parallel Arm
Parallel Arm
FULL 360° TURNS OF
1/8 POWER
ADJUSTMENT WRENCH
3100/3300/3500
DOOR
TYPE OF
INST. *
32”
(0.85M)
36”
(0.90M)
42”
(1.00M)
48”
(1.20M)
5811 13
710
13 16
710 13 16
912 15 18
MAXIMUM DOOR SIZE
Number of Turns Required
To identify your model:
Closer Size
Mfg.
Date
1FA
1-6
= 3301/3501
= 3302/3502
= 3303/3503
= 3304/3504
= 3305/3505
= 3306/3506
1-6
(
2
3
4
5
6
Size 1-6)
Arm Placement in Shoe
or
or
7-1/2 % Stronger
7-1/2 % Weaker
+
-
CLOSED
70°
10°
Spring Power Adjust
*
20 FULL (360°) TURNS MAXIMUM AVAILABLE
(Use 5/16” socket or adjustable wrench for this Adjustment)
(Use 1/8" Hex Wrench for these
Adjustments)
Backcheck
+
-
Latch
+
-
Sweep
+
-
Closer is shipped set at mid range setting = 10 turns
Adjust Closing Speed Time to between 3 to 7 seconds from 90°.
Use of the door by handicapped, elderly or small children may
require greater closing time.
!
The closing force for series 3301 & 3501 door closers is adjustable
from a size 1 to a size 6, as outlined in ANSI Standard A156.4.
When these series of door closers are installed and adjusted to
conform to ADA reduced opening force requirements (5 lbs max.) for
interior doors, they may not have adequate closing force to reliably
close and latch the door. Power adjustments charted on this page are
recommended where possible, to ensure proper door control.
By law the Americans with
Disabilities Act (ADA) may
require that door closer
installation comply with
accessability guidelines.
!
Delayed Action
(Optional)
+
-
Adjustment Chart
(3301 & 3501 Only)
+
-
An ASSA ABLOY Group brand
3000Highway74East • Monroe,NC28112
Tel:[phone] • Fax:[phone]
www.yalecommercial.com
Yale ® is a registered trademark of the respective ASSA ABLOY Group company.Copyright © 2007, ASSA ABLOY Group company.All rights reserved.
Reproduction in whole or in part without the express written permission of the respective ASSA ABLOY Group company is prohibited.
