Yale Power Track Series User manual

Combination Door Closer-Holder
and Releasing Device
Integral Smoke Detector
WITH
80-9344-0705-010 (7-01)
An incorrectly installed or improperly
adjusted door closer can cause property
damage or personal injury. These instructions
should be followed to avoid the possibility
of misapplication or misadjustment.
CAUTION
Hinge (Pull) Side of
Door Application Stop (Push) Side of Door Application
NOTE: For special applications a separate door and frame preparation template is packed with these instructions.
Use this instruction sheet for installation sequence and closer adjustments only.
Use of an auxiliary door stop is always recommended.
For wiring see "Power Track"
"Wiring Instructions"
Hinge edge of door
Cover with Insert
Closer Body
Stop (Push) Side
Slide Track Hinge (Pull) Side Slide Track
Hook-Up Box Chassis
And Cover
Arm Assembly
9/64"
Hex Drive
Socket Screw
Power Adjustment Nut
Smoke Detector Smoke Detector

Page 2
Pinion Flat Pinion Flat
RH Door LH Door
7. ith spring adjustment nut
toward lock edge of door and closer valves
Facing for door
Facing for door.
8. and install 9/64" hex drive socket
head screw from screw pack.
9. using Arm Indexing
instructions above.
10.
11. in track assembly. Secure by
pushing in on the retainer clip that extends from the slide block
in the track, until it is flush with the slide block.
w
1. Locate and drill 1-1/8" (29mm) diameter hole in frame face
for the conduit.
2. using above
template:holes for
holes for . holes for
3. using "Preparation for
Fasteners" chart above.
4. with smoke detector
toward lock edge of frame and open side facing down.
5. from hook-up box assy.
Units with a 120V to 24V transformer require that
hook-up board be removed from chassis to enable
mounting.
6. with
conduit hole openings away from hinge edge of frame.
Place Hook-Up Box straps between frame and
chassis. Special conduit nut supplied to anchor 3/4"
conduit fitting.
Opening
Metal Frame
Metal
Door or Frame
Wood or
Composite
Door
Fasteners
8-32 Machine Screw
1/4-20 Machine Screw
3/8 Dia. Sex Nut
Fastener Preparation
Drill: #29 [.136" (3.45mm) dia.]
8-32 UNC Tap
Drill: #7 [.201" (5.10mm) dia.]
1/4"-20 UNC Tap
3/8" [.375" (9.50mm) dia.]
through
1-7/16
(36.5)
4 Holes for Closer:
1/4-20 Machine Screw
or 3/8 Dia. Sex-Nuts
2 Holes for Hook-Up Box
8-32 Machine Screw
For Concealed
Wiring Only
1-1/8 (29mm) Hole
For Conduit
1-1/4
(32)
8
(203.2)
3-5/8
(92) 19 (482.6)
34-11/16 Ref.
(881.1)
11-1/4
(285.7)
12-1/16
(306.4)
2 Holes for Track:
1/4-20 Machine Screw
Hinge or Pivot
• From centerline of pivot point to end
of track and hook-up box is 35-25/32
(909mm)
• Right hand door shown
• Do not scale drawing
• Dimensions are given in inches (mm)
• Closer mounted with sex nuts
requires that door silencers be used
• Minimum ceiling clearance for unit is
2" (50mm)
• Maximum door opening is 110°
5-1/8
(130)
3/4
(19)
6-3/4
(171.4)
2-3/8
(60.3)
Attaching Arm Stud to Slide
Retainer Clip
2
1
80-9344-0705-010 (7-01)

Page 3
80-9344-0705-010 (7-01)
7. ith spring adjustment nut toward lock edge of door
and closer valves:
Facing for door
Facing for door
8. and install 9/64" hex drive socket
head screw from screw pack.
9. using Arm Indexing
instructions above.
10.
11. in track assembly. Secure by
pushing in on the retainer clip that extends from the slide block
in the track, until it is flush with the slide block.
w
1. Locate and drill 1-1/8" (29mm) diameter hole in frame soffit
for the conduit.
2. using above
template:holes for or
holes for . holes for
3. using "Preparation for
Fasteners" chart above.
4. with smoke detector
toward lock edge of frame and open side facing down.
5. from hook-up box assy.
6. with
conduit hole openings away from hinge edge of frame.
Place Hook-Up Box straps between frame and
chassis. Special conduit nut supplied to anchor 3/4"
conduit fitting.
Units with a 120V to 24V transformer require that
hook-up board be removed from chassis to enable
mounting.
Opening
Metal Frame
Metal
Door or Frame
Wood or
Composite
Door
Fasteners
8-32 Machine Screw
1/4-20 Machine Screw
3/8 Dia. Sex Nut
Fastener Preparation
Drill: #29 [.136" (3.45mm) dia.]
8-32 UNC Tap
Drill: #7 [.201" (5.10mm) dia.]
1/4"-20 UNC Tap
3/8" [.375" (9.50mm) dia.]
through
4-1/4
(108) 6-3/4 (171.4)
• From centerline of pivot point to end
of track and hook-up box is 35-9/32
(896mm)
• Left hand door shown
• Do not scale drawing
• Dimensions are given in inches
(mm)
• Maximum door opening is 110°
2-3/8
(60.3)
Pinion Flat Pinion Flat
RH Door
LH Door
2-5/8
(66.7)
4
(101.6) 4 (101.6)
1/4
(6.4)
4-3/4
(120.6)
5/16
(7.9)
1-1/8
(29)
4 Holes for Closer 4 Holes for Drop Plate
1/4-20 Machine Screw
or 3/8 Dia. Sex-Nuts
Ref. – Bottom of Frame Stop
1
(25)
3-1/8
(79) 12
(304.8)
Hinge or Pivot
19
(482.6)
2 Holes for Hook-Up Box:
8-32 Machine Screw
3 Holes for Track:
1/4-20 Machine Screw
8
(203.2)
11-1/4
(285.7)
12-1/16
(306.4)
34-3/16
(868.4)
For Concealed Wiring Only
1-1/8 (29) Hole for Conduit
Attaching Arm Stud to Slide
Retainer Clip
2
1

Insert arm stud into slide block in track.
Secure by pushing in on the retainer clip that extends from
the slide block, until it is flush with the slide block, see
illustration on page 2 of these instructions.
Place door in the Hold Open position. Remove 9/64" hex
drive socket head screw from arm. Open door to desired
angle and install hex-drive socket head screw into hole in
adjusting rod that is aligned with the hole in the adjusting
tube.
Closing Power can be increased by 50%.
To increase power, see Figure 1, rotate "Spring Adjustment
Nut using a wrench or socket. 15 full turns
(360°) will provide maximum available power.
(hydraulic control)
Valve "L" controls door speed in .
Valve "S" controls door speed in .
Use 1/8" hex-key furnished and adjust as shown in figure 3.
(hydraulic control)
Valve "B" cushions (slows) door opening in the
Note: Never close this valve completely or damage to closer
may occur.
Valve "P" allows "backcheck" to begin later in the opening
cycle.
Use 1/8" hex-key furnished and adjust as shown in figure 4.
If more hold open power is required, the power may be
increased by turning the adjustment screw in the end of the
track nearest the hinges. Use 9/64" hex wrench provided
and rotate adjustment screw clockwise to increase holding
power.
Fasten cover to closer with two screws provided:
• Molded Cover fastened at the top of closer.
• Metal Cover fastened at each end of closer.
Using four screws provided, fasten metal hook-up box cover.
Refer to "PowerTrack" "Wiring Instructions"
for making wiring connections.
• Turn power to unit . Green LED should be illuminated.
• Open door to the hold open position. Manually pull door
out of hold open and release ... door should close.
• Again, open door to the hold open position.
... door should close.
1/8"
Hex
Key
1/8"
Hex
Key
Increase
Decrease
Backcheck Valve*
close this valve completely.
Slow
Fast
Latch Valve
Sweep Valve
Opening CycleClosing Cycle
Backcheck
Range
Closed
5°
L
a
t
c
h
R
a
n
g
e
S
w
e
e
p
R
a
n
g
e
11/16"
wrench
Spring-Adjustment-Nut
Position Valve
(Normally Closed)
Open to relocate
backcheck-start to a
point farther in door-
opening cycle.
Page 4 80-9344-0705-010 (7-01)
