Yale Smart Latch 2 User manual

Please read the intructions
before fitting and using the
Yale Smart Latch 2.
The functions and design of this
product can be changed without
prior notice for performance
and quality improvements.
The smarter way to protect your home.
Smart Latch 2
Manual

2
Safety Precautions
3
Product Features 4
Getting to Know Your Lock 5
Opening the Lock with a PIN Code/
Key Card or Tag
7
Set/Change Master Code
Connecting with Yale Home App.
- Insert a Module
- Download the Yale Home App.
- Removing the Module
8
8
Set a User Code
Delete a User Code
9
Set/Delete One Day Code
9
Adding a Key Tag
10
Delete a Key Tag
Change Auto-lock Time
Auto-lock On/Off
Volume Settings
Intrusion Alarm
Incorrect PIN Lockout
Emergency Power
Resetting the Lock
Specifications
User Credential Log (Pin/Key Tag)
11
12
13
14
15
16
17
18
19
20
21
22
23
Getting Started
Introduction
Contents
6
Security Features
Specifications
User Log

3
Make sure to follow the above instructions to avoid any injuries or damage to the product.
Safety Precautions
Please read this carefully
• Be careful not to let any
unauthorised user discover
your PIN code
• Please keep your PIN code
safe
• To maintain a high quality
finish, clean regularly with
a soft damp cloth taking care
not to scratch the finish
• Do not use any chemicals
when cleaning as this may
affect your warranty
• The Yale Smart Latch 2
requires you to
place your palm on the
touch screen
• This is a safety feature so
finger prints showing the
PIN code are wiped
Caution
Introduction
Thank you for choosing the Yale Smart Latch 2.
The new Smart Lock uses the latest technology to make your life easier.
This user manual enables you to operate the product safely and to its full potential.
Please ensure you read it completely before using the Yale Smart Latch 2.

4
4 - 10 digit PIN code Yes (20 codes max.) Yes (unlimited) register
via Yale Home App
Unlimited
User/Temporarily
code with any
period of valid
time can be set up
from Yale Home
App when the
Module is
connected
Unlimited Tags
can be registered
when the Access
Module is
connected
Low battery warning
will be received from
the Yale Home App
If the Yale Home App is used
as a credential to unlock the
door, then the re-lock time will
always be 7 seconds.
Bluetooth on the mobile
should be ON
Yes (unlimited) and
only can be registered
via Yale Home App
Yes (1 code max.)
Security
Introduction
Product Features
You can use a mix of up to 20 PIN codes, Key Tags when Yale Home App Module is not connected.
NOTE: All below functions are local access only, the Yale Connect Bridge is sold separately to achieve remote
control and access.
For more information on Yale Home App, please visit www.yalehome.com/nz
How To Open The Lock Smart Latch 2 Description
Smart Latch 2
+ Yale Home App Module
Smart Latch 2 Description
Smart Latch 2
+Yale Home App Module
Smart Latch 2 Description
Smart Latch 2
+ Yale Home App module
Temporarily PIN code for visitor
Key Tag (includes two tags)
Features
3 minute lock out if code is
entered incorrectly 5 times
Change Auto-lock time
Tamper alarm
Local Access (lock and unlock)
via Bluetooth
Touchscreen with backlit Keypad
Battery operated
Auto-unlock/Auto-lock
Auto-lock On/Off
Audit Trails
Door position sensor
Yes
Yes
Yes
Yes
Yes Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
No
No
No
No
Low battery indicator with
emergency battery connection
User codes and settings remain
if batteries are replaced

5
Front (Front body installed on the outside of the door)
Keypad (10-key)
Button
Thumbturn
Reset Button
Button
Emergency 9V power
supply terminal
Low Battery Indicator
7
Battery Pack Cover
Button
1.5V AA Alkaline Batteries
Fixing Plate
Cover Release Button: Press
Both Simutaneously to
Release
Module Slot
R
Getting to Know Your Lock
Back (Back body installed on the inside of the door)

Step Icon Expected Feedback
KeyTag
PIN Code
Getting Started
Opening the Lock with a PIN code
Opening the Lock with a Key Tag
Description
Step Icon Expected Feedback Description
Touch the keypad with
the palm of your hand
Enter a valid user code
Keypad will illuminate
followed by 2 tone beep Touch the keypad to begin
Press * key
3 tone ascending beep Default code is ‘123456’
Turn the thumbturn to
open the door
3 tone ascending beep
Present a valid Key
Tag to the lock
Turn the Thumbturn to
open the door
Turn the Thumbturn to
open the door
LoseYourKeys. For Good
If you connected the Yale Home
App module, follow the Yale Home
App Guide to add key tags. Or on
page 13 if you decide not connect
with the Yale Home App module
6

Set /Change Master Code
Registration
Keypad will illuminate
followed by 2 tone beep
2 tone beep after each
button pressed
3 tone ascending beep
followed by your new
code being illuminated
Touch the keypad to begin
Touch the keypad with
the palm of your hand
Enter the master code,
followed by # key
Select the [1] button
followed by # key
Enter a new master code
Press # to complete
2 tone beep
If you are setting the code
for the first time the default
code is 123456
You are now in the lock’s
menu, choose option number
[1] to change the master code
The master code must be
6 digits
This completes the master
code setup
For security reasons the master code must be
changed during installation.
Step Icon Expected Feedback Description
The master code is the main password to the lock. As well as allowing entry through the door, it is also used to
configure the lock including adding and removing users when the Yale Home App module is not connected
7

Connecting with the Yale Home App
8
The Smart Latch 2 Smart Deadlatch comes with the Yale Home App module to allow users to
connect your lock with the Yale Home App to achieve a smart locking solution. Once you insert the
Yale Home App module and batteries, the lock will be ready to pair with the Yale Home App.
NOTE: TO ENABLE MOBILE APP FUNCTIONALITY WE HIGHLY RECOMMEND TO
CONNECT YOUR LOCK WITH YALE HOME APP IMMEDIATELY AFTER SETTING
UP THE MASTER CODE.
For security reason when the lock get registered with Yale Home App, the lock enables
‘Home App mode’ and preventing the user to register the credentials from keypad
(such as: add/remove user code / key tag except the master code).
All existing credentials (user code / key tag) will be erased as initialisation except the
master code.
It is HIGHLY RECOMMENDED to register the credentials through Yale Home App only.’
Inserting the Yale Home App Module
Removeabattery from
the lock
The module has 8 pins that are plugged into the small
black connector above the batteries on the top left of
the lock
Remove any of the batteries to cutpower to the lock
Remove inside cover Press the two release buttons on the sideof the
battery pack and removecover
Insert the module
R
R
R
R
Step Icon Description
Insert all batteriesReinsert all batteries into the lock

Download the Yale Home App:
Step 1: Download the Yale Home App from the Google Play Store or Apple App Store.
Step 2: Scan the below QR code for more information on how to use the Yale Home App
App and product information.
Removing the Yale Home App Module will remove all access to features available in the
Yale Home App. You may want to remove the module from the lock
if you would like to move it into another lock.
9
Removeabattery from
the lock
The module is situated in the top leftcorner above
the batteries. It canbeunplugged by pulling itout
Remove any of the batteries to cutpower to the lock
Remove inside cover
Press the two release buttons on the sideof the battery
pack and removecover
Remove the module
Step Icon Description
R
R
R
R
RemovingtheYale Home App module

10
Set a User Code
Enter the master code,
followed by the # key
If you have forgotten the master code
please see the ‘Resetting the Lock’
section of the manual (page 19)
Touch the keypad with
the palm of your hand
Option number [1] adds or modifies
a user code
This is the number of the slot in
memory where the code will be
saved (1-20)
Enter the slot number for
the user code followed by
# key
The user code can be between
4-10 digits
Enter the new user code
Step Icon Expected Feedback Description
The new user code will now be
added to the lock
Press the # button to
complete
Getting Started
To set a user code, please follow Yale Home App Guide if you connected module. Or refer to the below
section if you decide not connect with the Yale Home App module.
The lock can hold up to 20 unique user codes, each one has a slot in the locks memory from 1 to 20. If a new
code is written to a slot that already holds a code it will overwrite it. To save overwriting someones code it is
important to record who’s codes are stored in each slot. Please use the User Credential Log section in the
back of the book to record this.
Keypad will illuminate
followed by 2 tone beep
2 tone beep after each
button pressed
2 tone beep
Touch the keypad to begin
2 tone beep after each
button pressed
You are now in the lock’s
menu, choose option number
[1] to change the master code
2 tone beep
3 tone ascending beep
followed by your new
code being illuminated
3 tone ascending beep
Select the [2] button
followed by # key
Press the [1] button
followed by # key

11
Delete a User Code
Step Icon Expected Feedback Description
To delete a user code, please follow Yale Home App Guide if you connected the Yale Home App module. Or refer to below
section if you decide not connect with the Yale Home App module.
To discontinue a user’s access their code will need to be deleted. Before removing a user code please refer to the
User Credential Log at the back of this guide to determine the slot number of the code desired for deletion.
Touch the keypad with
the palm of your hand Touch the keypad to begin
Enter the master code,
followed by the # key
If you have forgotten the master code
please see the ‘Resetting the Lock’
section of the manual (page 19)
2 tone beep
2 tone beep after each
button pressed
You are now in the lock’s
menu, choose option number
[1] to change the master code
Select the [2] button
followed by # key
Option number [3] deletes
a user code
2 tone beep after each
button pressed
Press the [3] button
followed by # key
Enter the slot number for
the user code followed by
# key
3 tone ascending beep
This is the number of the slot in
memory where the code will be
saved (1-20)
Press the # button to
complete 3 tone ascending beep The user code will now be
deleted from the lock
Keypad will illuminate

12
Set a One Day Code
Please refer to ‘Access Schedules’ section from Yale Home App Guide if you connected the Yale Home App module.
Or refer to below section to set up a One day Code if you decide not connect with the Yale Home App module.
The one day code is a code that will automatically expire after 24 hours. This allows short term access to be
granted to someone.
Step Icon Expected Feedback Description
Keypad will illuminate
Touch the keypad with
the palm of your hand Touch the keypad to begin
Enter the master code,
followed by the # key
If you have forgotten the master code
please see the ‘Resetting the Lock’
section of the manual (page 19)
2 tone beep
2 tone beep after each
button pressed
You are now in the lock’s
menu, choose option number
[5] to enter the one day code settings
Select the [5] button
followed by # key
Enter the new user code 2 tone beep The user code must be 4 digits
Press the # button to
complete
3 tone ascending beep
followed by your new
code being illuminated
The code will now be active for
24 hours
Delete a One Day Code
Please refer to ‘Access Schedules’ section from Yale Home App Guide if you connected the Yale Home App module.
Or refer to below section to delete a One day Code if you decide not connect with the Yale Home App module.
A one day code can be deleted if it is no longer wanted. If not, it will automatically expire at the end of the 24 hour
period.
Step Icon Expected Feedback Description
Keypad will illuminate
followed by 2 tone beep
Touch the keypad with
the palm of your hand
Press any button on the
keypad to begin
Enter the master code,
followed by the # key
If you have forgotten the master code
please see the ‘Resetting the Lock’
section of the manual (page 19)
2 tone beep
2 tone beep after each
button pressed
You are now in the lock’s
menu, choose option number
[5] to enter the one day code settings
Select the [5] button
followed by # key
Press the # button to
complete 3 tone ascending beep Press the # to confirm code deletion
KeyTag

Adding a Key Tag
The lock can hold up to 20 Key Tags, each one has a slot in the locks memory from 1 to 20. If you try to
add a Tag to a slot that already holds one it will sound an error beep. It will also sound an error beep if
you try to add a Tag that has already been added. Because of this it is important to record which Tags are
stored in each slot. Please use the User Credential Log section in the back of this guide to record this.
Step Icon Expected Feedback Description
Keypad will illuminate
followed by 2 tone beep
Touch the keypad with
the palm of your hand Touch the keypad to begin
Enter the master code,
followed by the # key
If you have forgotten the master code
please see the ‘Resetting the Lock’
section of the manual (page 19)
2 tone beep
2 tone beep after each
button pressed
You are now in the lock’s
menu, choose option number
[0] to select the Key Tag menu
Select the [0] button
followed by # key
Option number [1] adds a Key Tag
2 tone beep after each
button pressed
Press the [1] button
fand then #
Enter the slot number for
the user code followed by
# key
This is the number of the slot in
memory where the Tag will be
saved (1-20)
2 tone beep
Present the Key Card/Tag
to the lock
Single tone beep
followed by slot
number illuminating
Hold a Key Tag against
the Keypad until you hear the beep
Press # to complete 3 tone ascending beep The Tag is now added
and will unlock the door
13
LoseYourKeys. For Good
KeyTag

Step Icon Expected Feedback Description
14
Getting Started
Delete a Key Tag
To delete a keytag, please follow Yale Home App Guide if you connected the Yale Home App module.
Or refer to below section if you decide not connect with the Yale Home App module.
To stop a user having access, their Tag will need to be deleted. Before doing this, you will need
to know which slot in the locks memory, their existing Tag is in. Please see the User Credential Log at the
back of the guide.
Keypad will illuminate
followed by 2 tone beep
Touch the keypad with
the palm of your hand Touch the keypad to begin
Enter the master code,
followed by the # key
If you have forgotten the master code
please see the ‘Resetting the Lock’
section of the manual (page 19)
2 tone beep
2 tone beep after each
button pressed
You are now in the lock’s
menu, choose option number
[0] to select the Key Tag menu
Select the [0] button
followed by # key
Option number [3] removes a
Lockwood Tag
2 tone beep after each
button pressed
Press the [3] button
fand then #
Enter the slot number for
the user code followed by
# key
This is the number of the slot in
memory where the Lockwood Tag
will be saved (1-20)
2 tone beep
Press # to complete 3 tone ascending beep The Lockwood Tag is now deleted
and will no longer unlock the door
KeyTag

15
Change Auto-lock Time
Step Icon Expected Feedback Description
Auto-lock On/Off time can only be changed via the Yale Home App once connected to the App.
The relock time is the amount of time it takes for the lock to relock after it has been unlocked
with a correct credential (PIN, KeyTag). The default is 7 seconds.
Note: If the Yale Home App is used as credential to unlock the door, then the re-lock time will be always 7 seconds.
Keypad will illuminate
followed by 2 tone beep
Touch the keypad with
the palm of your hand Touch the keypad to begin
Enter the master code,
followed by the # key
If you have forgotten the master code
please see the ‘Resetting the Lock’
section of the manual (page 19)
2 tone beep
2 tone beep
Select the [6] button
followed by # key
The relock time can be between
7 and 60 seconds. ie 50 = 50
seconds
2 tone beep after each
button pressed
Input the relock time (7-60)
Press # to complete 3 tone ascending beep The relock time will now be set

16
Press # to complete
Step Icon Expected Feedback Description
3 tone ascending beep
[9] contains auto-lock
configuration settings
Select between the two modes
Press [1] for auto-lock ON,
or [3] for auto-lock OFF
2 tone beep
Getting Started
Auto-lock On/Off can only be changed via the Yale Home App once connected to the App.
The lock can be changed between two modes. With auto-lock mode ON the lock will automatically re-lock after
the configured time. With auto-lock mode OFF the lock will not re-lock until you touch the Keypad with the palm
of your hand.
Keypad will illuminate
followed by 2 tone beep
Touch the keypad with
the palm of your hand Touch the keypad to begin
Enter the master code,
followed by the # key
If you have forgotten the master code
please see the ‘Resetting the Lock’
section of the manual (page 19)
2 tone beep
Select the [9] button
followed by # key
2 tone beep after each
button pressed
Auto-lock On/Off

17
Volume Settings
The volume can be adjusted from both the Yale Home App and keypad. The setting is automatically synchronised
if the setting is changed on either App or keypad. Please refer to Yale Home App Guide to adjust volume from App
and refer to below section for adjusting volume from keypad.
The lock can be switched between three volume modes. In silent mode only programming beeps will be heard.
In quiet mode the keypad beeps will be quieter, in loud mode they will be loud.
Step Icon Expected Feedback Description
Keypad will illuminate
followed by 2 tone beep
Touch the keypad with
the palm of your hand Touch the keypad to begin
Enter the master code,
followed by the # key
If you have forgotten the master code
please see the ‘Resetting the Lock’
section of the manual (page 19)
2 tone beep
Select the [8] button
followed by # key
2 tone beep after each
button pressed
You are now in the lock’s
menu, option [8] contains the volume
mode settings
Press [1] for silent mode,
[2] for quiet mode, or [3]
for loud mode
2 tone beep Select between the three modes
Press # to complete 3 tone ascending beep

18
Security Features
Intrusion Alarm
Damage Alarm:
If the lock is attacked by attempting to remove the lock
from the door on the outside, an 80dB alarm will sound.

19
Security Features
Security Features
For security, if the wrong PIN is entered 5 consecutive times the lock will lockout for 3 minutes.
This is indicated by the numbers [3] on the keypad flashing.
To Release Lockout
Incorrect PIN Lockout
Present valid Key Tag or unlock via the App.

Emergency Power
If the batteries in the lock have completely failed emergency power can be provided by a 9V battery on the
front body.
To Supply Emergency Power
Expiry Period
The product uses four 1.5V (LR6) alkaline AA batteries. The batteries will last approximately 1 year based
on the lock being used 10 times per day.
You will also receive the low battery warning from Yale Home App
and email once you connected to Yale Home App.
(Users are advised to use authentic alkaline batteries.)
Low Battery Alarm
You must replace all 4 batteries for the following cases:
* The Low Battery indicator on the front of the lock illuminates
* The Host connected system indicates a low battery in the lock
The battery life varies according to ambient temperature, humidity, frequency of use and the quality of the
battery. Do not use rechargeable batteries. Only alkaline batteries are recommended.
Contact the 9V battery
Touch the Keypad with
the palm of your hand
Enter PIN code Enter the registered PIN code in the Keypad
Press * key Press button to unlock the Keyless Digital Deadlatch Lock
Place 9V battery onto the emergency power supply terminal
Emergency Power Supply for Discharged Batteries
20
Step Icon Description
RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN
INCORRECT TYPE. DISPOSE OF USED BATTERIES ACCORDING
TO THE WASTE BATTERIES REGULATIONS.
Low battery alert (red)
