Yealink SIP-T2 Series User manual

Table of Contents
i

Table of Contents
iii
Table of Contents......................................................................iii
Summary of Changes..............................................................vii
Changes for Release 72, Guide Version 72.25.................................................................vii
Changes for Release 72, Guide Version 72.2...................................................................vii
Changes for Release 72, Guide Version 72.1...................................................................vii
Changes for Release 71, Guide Version 71.165..............................................................viii
Changes for Release 71, Guide Version 71.140..............................................................viii
Changes for Release 71, Guide Version 71.125..............................................................viii
Changes for Release 71, Guide Version 71.120..............................................................viii
Changes for Release 71, Guide Version 71.110..............................................................viii
Changes for Release 70, Guide Version 1.3......................................................................ix
Introduction............................................................................... 1
Getting Started......................................................................... 3
Obtaining Configuration Information ................................................................................ 3
Obtaining Configuration Files ......................................................................................... 3
Obtaining Phone Information.......................................................................................... 4
Managing Configuration Files............................................................................................ 4
Editing Common CFG File................................................................................................ 5
Editing MAC-Oriented CFG File...................................................................................... 7
Encrypting Configuration Files ...................................................................................... 14
Customizing Resource Files............................................................................................ 14
Customizing a Ring Tone............................................................................................. 14
Customizing an LCD Language ................................................................................. 15
Customizing an LCD Logo........................................................................................... 16
Customizing a Wallpaper ........................................................................................... 17
Customizing a Local Contact File .............................................................................. 18
Customizing a Replace Rule File................................................................................ 21
Customizing a Dial-now File....................................................................................... 22
Customizing a Directory Template ............................................................................ 23
Customizing a Super Search Template..................................................................... 24
Upgrading Firmware................................................................................................... 25

Yealink IP Phones Auto provisioning Guide
iv
Configuring a TFTP Server...................................................... 27
Preparing a Root Directory................................................................................................ 27
Configuring a TFTP Server................................................................................................. 28
Obtaining the Address of Provisioning Server ...................... 29
Zero Touch........................................................................................................................... 29
Plug and Play (PnP) Server ............................................................................................... 31
DHCP Options..................................................................................................................... 32
Phone Flash......................................................................................................................... 33
Update Mode......................................................................... 35
Power On............................................................................................................................. 35
Repeatedly.......................................................................................................................... 36
Weekly................................................................................................................................. 37
Auto Provision Now ............................................................................................................ 38
Multi-mode Mixed ............................................................................................................. 39
SIP NOTIFY Message ......................................................................................................... 39
Downloading and Verifying Configurations .......................... 41
Downloading Configuration Files..................................................................................... 41
Resolving and Updating Configurations ......................................................................... 41
Verifying Configurations .................................................................................................... 42
Troubleshooting ...................................................................... 45
Glossary.................................................................................. 47
Appendix ................................................................................ 49
Configuring an FTP Server ................................................................................................ 49
Preparing a Root Directory ............................................................................................ 49
Configuring an FTP server.............................................................................................. 50
Configuring an HTTP Server.............................................................................................. 52
Preparing a Root Directory ............................................................................................ 52
Configuring an HTTP Server .......................................................................................... 52
Configuring a DHCP server............................................................................................... 55
Customizing a Ring Tone Using Cool Edit Pro ................................................................. 63
Customizing a Logo File Using PictureExDemo .............................................................. 64

Table of Contents
v
Description of Configuration Parameters in CFG Files .................................................. 65
Time Zones........................................................................................................................ 225
BLF LED Mode................................................................................................................... 228

Yealink IP Phones Auto provisioning Guide
vi

Summary of Changes
vii
This section describes the changes to this guide for each release and guide version.
Major updates have occurred to the following sections:
Description of Configuration Parameters in CFG Files on page 65
This version is updated to incorporate SIP-T48G IP phones. The following sections are
new for this version:
Customizing a Directory Template on page 23
Customizing a Super Search Template on page 24
Major updates have occurred to the following sections:
Editing Common CFG File on page 5
Editing MAC-Oriented CFG File on page 7
Customizing Resource Files on page 14
Description of Configuration Parameters in CFG Files on page 65
BLF LED Mode on page 228
This version is updated to incorporate SIP-T46G, SIP-T42G and SIP-T41P IP phones. The
following sections are new for this version:
Time Zones on page 225
BLF LED Mode on page 228
Major updates have occurred to the following sections:
Editing Common CFG File on page 5
Editing MAC-Oriented CFG File on page 7
Customizing Resource Files on page 14
Description of Configuration Parameters in CFG Files on page 65

Yealink IP Phones Auto provisioning Guide
viii
Documentations of the newly released SIP-T21P and SIP-T19P IP phones have also been
added.
Major updates have occurred to the following sections:
Editing Common CFG File on page 5
Editing MAC-Oriented CFG File on page 7
Encrypting Configuration Files on page 14
Customizing an LCD Logo on page 16
Customizing a Local Contact File on page 18
Description of Configuration Parameters in CFG Files on page 65
Major updates have occurred to the following section:
Customizing an LCD Logo on page 16
Major updates have occurred to the following section:
Description of Configuration Parameters in CFG Files on page 65
The following sections are new for this version:
Encrypting Configuration Files on page 14
Update Mode on page 35
SIP NOTIFY Message on page 39
Resolving and Updating Configurations on page 41
Description of Configuration Parameters in CFG Files on page 65
Major updates have occurred to the following sections:
Customizing a Local Contact File on page 18
Customizing a Replace Rule File on page 21

Summary of Changes
ix
Customizing a Dial-now File on page 22
The following sections are new for this version:
Customizing a Wallpaper on page 17
Customizing a Replace Rule File on page 21
Customizing a Dial-now File on page 22
Major updates have occurred to the following sections:
Customizing a Local Contact File on page 18
Upgrading Firmware on page 25

Introduction
1
Yealink IP phones are full-featured telephones that can be plugged directly into an IP
network and can be used easily without manual configuration.
This guide provides instructions on how to provision Yealink IP phones with the minimum
settings required. Yealink IP phones support FTP, TFTP, HTTP, and HTTPS protocols for auto
provisioning and are configured by default to use the TFTP protocol.
The purpose of this guide is to serve as a basic guidance for provisioning Yealink IP
phones, including:
Yealink SIP-T28P
Yealink SIP-T26P
Yealink SIP-T22P
Yealink SIP-T21P
Yealink SIP-T20P
Yealink SIP-T19P
Yealink SIP-T48G
Yealink SIP-T46G
Yealink SIP-T42G
Yealink SIP-T41P
The auto provisioning process outlined in this guide applies to Yealink IP phones
running firmware V72 or later. We recommend that IP phones running firmware V72 or
later CANNOT be downgraded to an earlier firmware version. The new firmware is
compatible with old configuration parameters, but not vice versa.
This guide is also applicable to SIP-T21/T20/T19 IP phones.

Yealink IP Phones Auto provisioning Guide
2

Getting Started
3
This section provides instructions on how to get ready for auto provisioning. The auto
provisioning process discussed in this guide uses the TFTP server as the provisioning
server.
To begin the auto provisioning process, the following steps are required:
Obtaining Configuration Information
Managing Configuration Files
Before beginning provisioning, you need to obtain configuration files. There are two
configuration files both of which are CFG-formatted. We call these two files Common
CFG file and MAC-Oriented CFG file. The phone tries to download these CFG files from
the server during provisioning.
The MAC-Oriented CFG file is only effectual for the specific phone. It uses the 12-digit
MAC address of the phone as the file name. For example, if the MAC address of the
phone is 0015651130F9, the MAC-Oriented CFG file name must be 0015651130F9.cfg.
However, the Common CFG file is effectual for all the phones with the same model. It
uses a fixed name “y0000000000XX.cfg”or “y00000000000X.cfg”as the file name,
where "XX" or “X”equals to the first two digits or the first digit (except 0 for SIP-T28P) of
the hardware version of the phone model.
The names of the Common CFG file for each phone model are:
Phone Model
Common CFG File
SIP-T28P
y000000000000.cfg
SIP-T26P
y000000000004.cfg
SIP-T22P
y000000000005.cfg
SIP-T21P
y000000000034.cfg
SIP-T20P
y000000000007.cfg
SIP-T19P
y000000000031.cfg
SIP-T48G
y000000000035.cfg
SIP-T46G
y000000000028.cfg

Yealink IP Phones Auto provisioning Guide
4
Phone Model
Common CFG File
SIP-T42G
y000000000029.cfg
SIP-T41P
y000000000036.cfg
You can ask the distributor or Yealink FAE for configuration files. The IP phones running
firmware version 71 or later can only recognize configuration files using UTF-8 or ANSI
encoding.
Before beginning provisioning, you also need the phone information. For example, MAC
address and the SIP account information of the phone.
MAC Address: The unique 12-digit serial number of the phone. You can obtain it from the
bar code on the back of the phone.
SIP Account Information: This may include SIP credentials such as user name, password
and IP address of the SIP server. Ask your system administrator for SIP account
information.
Auto provisioning enables Yealink IP phones to update themselves automatically via
downloading Common CFG and MAC-Oriented CFG files. Before beginning
provisioning, you may need to edit and customize your configuration files. For more
information on configuration parameters in configuration files, refer to Description of
Configuration Parameters in CFG Files on page 65.

Getting Started
5
Common CFG file contains configuration parameters which apply to phones with the
same model, such as language and volume.
The following figure shows a portion of the common CFG file:
The partial parameters in the Common CFG file are described as follows:
####################################################
## Common CFG File ##
####################################################
#!version:1.0.0.1
##File header "#!version:1.0.0.1" cannot be edited or deleted, and must be placed in
the first line. This template file is applicable to
SIP-T28P/T26P/T22P/T21P/T20P/T19P/T48G/T46G/T42G/T41P IP phones running firmware
version 72 or later. For more information on configuration parameters, refer to
Yealink_SIP-T2_Series_T19P_T4_Series_IP_Phones_Auto_Provisioning_Guide. ##
######################################################
## Hostname ##
######################################################
network.dhcp_host_name =
######################################################
## PPPOE(Except SIP-T42GP/T41P Models) ##
######################################################
network.pppoe.user =
The line beginning with “#”is considered to be a comment.
The file header “#!version:1.0.0.1”is not a comment and must be placed in the
first line. It cannot be edited or deleted.

Yealink IP Phones Auto provisioning Guide
6
network.pppoe.password =
######################################################
## PC Port(Only SIP-T28P/T26P/T22P/T20P Models support) ##
######################################################
network.bridge_mode =
network.pc_port.ip =
network.pc_port.mask =
network.dhcp.start_ip =
network.dhcp.end_ip =
######################################################
## Network Advanced ##
######################################################
network.pc_port.enable =
network.internet_port.speed_duplex =
network.pc_port.speed_duplex =
network.pc_port.dhcp_server =
network.static_dns_enable =
network.ipv6_static_dns_enable =
##Only T41P/T42G/T46G/T48G Models support this parameter##
network.vlan.pc_port_mode =
######################################################
## VLAN ##
######################################################
network.vlan.internet_port_enable =
network.vlan.internet_port_vid =
network.vlan.internet_port_priority =
network.vlan.pc_port_enable =
network.vlan.pc_port_vid =
network.vlan.pc_port_priority =
network.vlan.dhcp_enable =
network.vlan.dhcp_option =
######################################################
## WEB Port ##
######################################################
network.port.http =
network.port.https =
wui.https_enable =
wui.http_enable =
######################################################
## QoS ##
######################################################
network.qos.rtptos =
network.qos.signaltos =
######################################################
## 802.1X ##
######################################################
network.802_1x.mode =
network.802_1x.identity =
network.802_1x.md5_password =

Getting Started
7
network.802_1x.root_cert_url =
network.802_1x.client_cert_url =
######################################################
## OpenVPN(Except SIP-T19P Model) ##
######################################################
network.vpn_enable =
openvpn.url =
######################################################
## LLDP ##
######################################################
network.lldp.enable =
network.lldp.packet_interval =
MAC-Oriented CFG file contains configuration parameters which are expected to be
updated per phone, such as the registration information.
The following figure shows a portion of the MAC-Oriented CFG file:

Yealink IP Phones Auto provisioning Guide
8
The partial parameters in the MAC-Oriented CFG file are described as follows:
####################################################
## MAC-Oriented CFG File ##
####################################################
#!version:1.0.0.1
##File header "#!version:1.0.0.1" cannot be edited or deleted, and must be placed in
the first line. This template file is applicable to SIP-T28P/T26P/T22P/T21P/T20P/T19P/
T48G/T46G/T42G/T41P IP phones running firmware version 72 or later. For more
information on configuration parameters, refer to
Yealink_SIP-T2_Series_T19P_T4_Series_IP_Phones_Auto_Provisioning_Guide. ##
######################################################
## Account1 Basic Settings ##
######################################################
account.1.enable =
account.1.label =
account.1.display_name =
account.1.auth_name =
account.1.user_name =
account.1.password =
account.1.outbound_proxy_enable =
account.1.outbound_host =
account.1.outbound_port =
account.1.sip_listen_port =
account.1.transport =
######################################################
## Failback ##
######################################################
account.1.reregister_enable =
account.1.naptr_build =
account.1.fallback.redundancy_type =
account.1.fallback.timeout =
account.1.sip_server.1.address =
account.1.sip_server.1.port =
account.1.sip_server.1.expires =
account.1.sip_server.1.retry_counts =
account.1.sip_server.1.failback_mode =
account.1.sip_server.1.failback_timeout =
account.1.sip_server.1.register_on_enable =
account.1.sip_server.2.address =

Getting Started
9
account.1.sip_server.2.port =
account.1.sip_server.2.expires =
account.1.sip_server.2.retry_counts =
account.1.sip_server.2.failback_mode =
account.1.sip_server.2.failback_timeout =
account.1.sip_server.2.register_on_enable =
######################################################
## Account2 Basic Settings (except SIP-T19P Model) ##
######################################################
account.2.enable =
account.2.label =
account.2.display_name =
account.2.auth_name =
account.2.user_name =
account.2.password =
account.2.outbound_proxy_enable =
account.2.outbound_host =
account.2.outbound_port =
account.2.sip_listen_port =
account.2.transport =
######################################################
## Failback ##
######################################################
account.2.reregister_enable =
account.2.naptr_build =
account.2.fallback.redundancy_type =
account.2.fallback.timeout =
account.2.sip_server.1.address =
account.2.sip_server.1.port =
account.2.sip_server.1.expires =
account.2.sip_server.1.retry_counts =
account.2.sip_server.1.failback_mode =
account.2.sip_server.1.failback_timeout =
account.2.sip_server.1.register_on_enable =
account.2.sip_server.2.address =
account.2.sip_server.2.port =
account.2.sip_server.2.expires =
account.2.sip_server.2.retry_counts =

Yealink IP Phones Auto provisioning Guide
10
account.2.sip_server.2.failback_mode =
account.2.sip_server.2.failback_timeout =
account.2.sip_server.2.register_on_enable =
######################################################
## Account3 Basic Settings (except SIP-T21P/T20P/T19P Models) ##
######################################################
account.3.enable =
account.3.label =
account.3.display_name =
account.3.auth_name =
account.3.user_name =
account.3.password =
account.3.outbound_proxy_enable =
account.3.outbound_host =
account.3.outbound_port =
account.3.sip_listen_port =
account.3.transport =
######################################################
## Failback ##
######################################################
account.3.reregister_enable =
account.3.naptr_build =
account.3.fallback.redundancy_type =
account.3.fallback.timeout =
account.3.sip_server.1.address =
account.3.sip_server.1.port =
account.3.sip_server.1.expires =
account.3.sip_server.1.retry_counts =
account.3.sip_server.1.failback_mode =
account.3.sip_server.1.failback_timeout =
account.3.sip_server.1.register_on_enable =
account.3.sip_server.2.address =
account.3.sip_server.2.port =
account.3.sip_server.2.expires =
account.3.sip_server.2.retry_counts =
account.3.sip_server.2.failback_mode =
account.3.sip_server.2.failback_timeout =
