About This Guide
v
About This Guide
Thanks for choosing Yealink CP960 IP conference phone, which comprises the power of the
Android 5.1 operating system and is exquisitely designed for medium-to-large conference room.
CP960 is a 5-inch touchable conference phone which simply putting all of the key conferencing
functions at your fingertips, allowing users to enjoy its powerful business telephony features,
such as Call Hold, Call Transfer, Call and Conference Recording, Multicast Paging and five-way
Conference over an IP network. Meanwhile, users can benefit from two optional expansion
microphones for wider voice pickup range.
This guide provides everything you need to quickly use your new phone. First, verify with your
system administrator that the IP network is ready for phone configuration. Also be sure to read
the Packaging Contents in this guide, and see the Yealink Products Regulatory Notices guide for
all regulatory and safety guidance before you set up and use the CP960 IP phone.
In This Guide
Topics provided in this guide include:
Chapter 1 Overview
Chapter 2 Getting Started
Chapter 3 Customizing Your Phone
Chapter 4 System Applications
Chapter 5 Basic Phone Features
Chapter 6 Advanced Phone Features
Chapter 7 Connecting Bluetooth Devices and PC
Chapter 8 Using the CP Wired Expansion Mic CPE90
Chapter 9 Using the CP Wireless Expansion Mic CPW90

User Guide for CP960 IP Phone
vi
