Yealink SIP VP-T49G User manual

Ultra-elegant Gigabit IP Phone
SIP VP-T49G
Quick Start Guide (V80.11)
www.yealink.com Applies to firmware version 51.80.0.10 or later.

1
Packaging Contents
The following items are included in your package. If you find anything missing, contact your system administrator.
IP Phone Handset
Handset Cord
Stand
Ethernet Cable
Camera Quick Start Guide
Power Adapter
Assembling the Phone
1. Attach the stand, as shown below:
2. Insert the camera, as shown below:
USB3.0 Cable 3M Dual Lock
40
Adjust Shutter Switch
Adjust Camera Angle

2
3. Connect the handset and optional headset, as shown below:
Note: The headset should be purchased separately.
5. Connect the external monitor and attach the camera to the external monitor, as shown below:
4. Connect the optional USB flash drive, as shown below:
Steps：Remove one piece of the fastener’s liner; take the gap of the camera as the touchline and
attach to the camera from the top; connect one end of the USB3.0 cable to the camera.
1
2
3
4
Connect the other end of the USB3.0 cable to the IP phone.
Remove the other piece of the fastener’s liner; attach to the external monitor; attach the
camera to the external monitor by pressing two sides of Dual Lock together. Make sure the
camera is vertical and not askew otherwise the near-site video image will be crooked. You
are advised to attach the camera to the external monitor whose back is straight.
Connect one end of the HDMI cable to the HDMI port on the phone, and connect the other
end to the HDMI port on the external monitor.
3
4
2
1

3
1) Tap -> Basic -> Wi-Fi.
3) Select an available wireless network from the list of networks.
4) If the network is secure, enter its password in the PIN field.
5) Tap OK to connect to the wireless network.
b) Connect to the wireless network:
The phone will automatically search for available wireless networks in your area.
2) Tap On from the radio box of Wi-Fi.
6. Connect the AC power, as shown below:
You have two options for network connection. Your can select one of them according to the current office
environment.
7. Connect to the network, as shown below:
a) Connect to the wired network:
Note: The IP phone shoule be used with Yealink original power adapter (12V/2A) only.

4
Hardware Component Instructions
19
20
Camera
Item Item
10
11
12
Power Indicator LED
Touch Screen
MESSAGE Key
HEADSET Key
TRANSFER Key
MUTE Key
Volume Key
Speakerphone Key
REDIAL Key
HOLD Key
VIDEO Key
2
3
4
5
6
8
Item
Shutter Switch
15 Hookswitch
Speaker
Keypad
13
17 Camera Indicator LED
18 Camera Lens
1
7
9
14
16
19
20
HDMI port
USB2.0 port
12
3
2
1
14
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16 17
18

5
After the IP phone is connected to the network and
supplied with power, it automatically begins the
initialization process. After startup, the phone is
ready for use. You can configure the phone via web
user interface or phone user interface.
Startup
Welcome
Initializing... Please wait
It is provided by ITSP for registration (required).
Server Host:
WelcomeWelcome
It is provided by ITSP for registration (required).
It is provided by ITSP for registration (required).
It is an authenticated ID for authentication provided by ITSP (required).
Display Name:
Line Active: You can select Enabled/Disabled to enable/disable the account.
Register Name:
User Name:
Password:
Label: It is shown on the touch screen to identify the account.
Configuring Your Phone
1. Tap ->Status when the phone is idle to obtain the IP address of the phone.
2. Open a web browser on your computer, enter the IP address into the address bar
(e.g., "http://192.168.0.10" or "192.168.0.10"), and then press Enter.
3. Enter the user name (default: admin) and password (default: admin) in the login page and click Confirm.
Network Settings: Click on Network->Basic->IPv4 Config
Static IP Address: If the phone cannot contact a DHCP server for any reason, you need to configure
IP address, subnet mask, gateway address, primary DNS address and secondary
DNS address for the phone manually.
Accessing the web user interface:
Configuring via web user interface
PPPoE: If you are using an xDSL modem, you can connect your phone to the Internet via PPPoE
mode. Contact the ITSP for the user name and password.
You can configure the network settings in the following ways:
DHCP: By default, the phone attempts to contact a DHCP server in your network to obtain its valid
network settings, e.g., IP address, subnet mask, gateway address and DNS address.
Account Settings: Click on Account->Register ->Account X(X=1,2,3...15,16)
Parameters of the account:
Note: The IP phone also supports IPv6, but IPv6 is disabled by default.
Register Status: It shows the register status of the current account.
It is shown as Caller ID when placing a call.

6
Configuring via phone user interface
When the phone is idle, tap ->Advanced (default password: admin)->Account to configure the account.
Registering
Register status icons on the touch screen:
Note: Check with your system administrator if any error appears during the registration process or a specific
configuration is required for your registration.
Registered Register Failed (Green) (Gray) (Green and Flashing)
Account Settings:
Network Settings:
When the phone is idle, tap ->Advanced (default password: admin)->Network->WAN Port/VLAN/Webserver Type
/802.1x/ VPN/ LLDP/CDP/NAT to configure the network.
To enter the main menu, tap .
To return to the idle screen, tap .
To go back to the previous menu, tap .
To select an item, tap the item.
(You can wait for the scrolling to come to a stop, or touch the screen to stop it immediately.)
Drag up and down to scroll.
Navigating the Touch Screen
Using Your Phone
The icons on the status bar of the touch screen give information about phone:
Status Icons
Icons Description
Shows that camera is not detected.
Shows that the phone is connected to wireless network successfully.
(Green)
(White) Shows that Wi-Fi is turned on.
Shows that network is unavailable.
Shows that Bluetooth is turned on.
Shows that you have unread voice mails.
Shows that “Do Not Disturb” is turned on.
Shows that the phone is locked.
Shows that you have missed calls.
Shows that “Forward” is turned on.
Shows that “Auto Answer” is turned on.
Shows that ringer volume is 0.
Shows that a USB flash drive is detected.
(White)
(Green) Shows that Bluetooth headset is paired successfully.
Shows that you have unread text messages.
(Green) Shows that Bluetooth-Enabled mobile phone is paired successfully.
Shows that an external monitor is connected.
Shows that the phone fails to connect to wireless network.

Basic Call Features
1. Pick up the handset.
Placing a Video/Voice Call
Using the handset:
1. With the handset on-hook, press .
2. Enter the number, and then tap the Send soft key.
Using the speakerphone:
2. Enter the number, and then tap the Send soft key.
1. With the headset connected, press to activate the headset mode.
Using the headset:
Entering and Updating Data
1.Tap the field you want to edit, the onscreen keyboard will display on the touch screen:
To use keypad:
To select a field option:
Tap the field name, tap the desired option from the pop-up dialog box.
Control Center and Notification Center
To turn on/off common functions quickly, tap
corresponding icons.
Notification Center
Notification center displays the list of Missed Calls,
Voice Mail and Forwarded Calls.
To delete a specific record, tap .
To delete all records, tap .
Drag the slider to adjust the screen brightness.
Swipe down from the top of the screen to enter the control center and the notification center.
Control Center
Swipe up to hide this screen.
Tap to backspace.
Tap to wrap.
Tap to switch between uppercase and lowercase.
Tap to switch among input modes. Tap to move the cursor.
Tap to hide the onscreen keyboard.
2.When you finish entering, tap .
To use onscreen keyboard:
7
3.Tap the Save soft key to accept the change.
Dial or enter number.
2. Enter the number, and then tap the Send soft key.

8
If there is more than one call on hold, tap the call you want to resume, and press or tap the
Resume soft key.
Call Hold and Resume
To place a call on hold:
To resume the call, do one of the following:
If there is only one call on hold, press or tap the Resume soft key.
Press or tap the Hold soft key during an active call.
Ending a Video/Voice Call
Using the handset:
Hang up the handset or tap the EndCall soft key.
Using the speakerphone:
Using the headset:
Press or tap the EndCall soft key.
Tap the EndCall soft key.
Redial
Press to enter the Placed Calls list, and then tap the desired entry.
Press twice when the phone is idle to dial out the last dialed number.
Call Mute and Un-mute
Press to mute the microphone during a call.
Press again to un-mute the call.
Using the headset:
Using the handset:
Pick up the handset.
Press .
Press
.
Controlling Video During a Call
Tap or .
Swipe down from the top of the screen to enter the control center, tap Video to turn on/off the video.
To change the video view:
Answering a Video/Voice Call
To turn on/off video during a call:
Press .
Adjust the shutter switch.
Using the speakerphone:

9
To listen to voice messages:
2. Follow the voice prompts to listen to your voice messages.
(Ensure the voice mail code is already configured on the phone.)
1. Swipe down from the top of the screen to enter the notification center, tap Voice Mail and select the
desired item , or press .
4. Tap the EndCall soft key to disconnect all parties.
2. Enter the number of the second party, and then press or tap the Conference soft key.
3. Tap the Conference soft key again when the second party answers. All parties are now joined in the
conference.
Note: You can split the conference call into two individual calls by tapping the Split soft key.
Voice Message
Message waiting indicator on the idle screen indicates that one or more voice messages are waiting at
the message center.
The power indicator LED slowly flashes red.
Semi-Attended Transfer
Blind Transfer
Call Transfer
You can transfer a call in the following ways:
1. Press or tap the Transfer soft key during a call. The call is placed on hold.
1. Press or tap the Transfer soft key during a call. The call is placed on hold.
2. Enter the number you want to transfer to, and then press .
3. Press or tap the Transfer soft key when you hear the ring-back tone.
3. Press or tap the Transfer soft key.
2. Enter the number you want to transfer to.
Call Forward
To enable call forward:
Always Forward----Incoming calls are forwarded unconditionally.
Busy Forward----Incoming calls are forwarded when the phone is busy.
No Answer Forward----Incoming calls are forwarded if not answered after a period of time.
1. When the phone is idle, tap ->Features->Call Forward.
2. Select the desired forward type:
4. Tap the Save soft key to accept the change.
Call Conference
1. Tap the Conference soft key during an active call. The call is placed on hold.
Attended Transfer
1. Press or tap the Transfer soft key during a call. The call is placed on hold.
2. Enter the number you want to transfer to, and then press .
3. Press or tap the Transfer soft key when the second party answers.
3. Enter the number you want to forward to. For No Answer Forward, tap the After Ring Time filed, and then tap
the desired ring time to wait before forwarding.

Tap Send to place a call.
Ta p Add to add the entry to the local directory.
1. When the phone is idle, tap , and select the desired call list on the left.
Customizing Your Phone
Call History
2. Drag up and down to scroll.
3. Tap after the desired entry, and then you can do the following:
Ta p Edit to edit the phone number of the entry before placing a call.
Ta p Blacklist to add the entry to the blacklist.
Ta p Delete to delete the entry from the list.
Contact Directory
To add a contact:
1. When the phone is idle, tap , and select the desired group.
Volume Adjustment
To edit a contact:
To delete a contact:
Press during a call to adjust the receiver volume of the handset/speakerphone/headset.
Press when the phone is idle to adjust the ringer volume.
1. When the phone is idle, tap , and select the desired group.
2. Tap after the desired contact.
3. Edit the contact information.
3. Tap OK when the touch screen prompts “Delete selected item?”.
Note: You can add contacts from call history easily. For more information, refer to Call History above.
1. When the phone is idle, tap , and select the desired group.
2. Tap after the desired contact and then tap Delete.
2. Tap Add to add a contact.
3. Enter a unique contact name in the Name field and contact numbers in the corresponding fields.
4. Tap the Save soft key to accept the change.
4. Tap the Save soft key to accept the change.
10

About us
Founded in 2001, Yealink, a leading provider of VoIP Phone and IP communication solutions, has been focusing on VoIP
products characterized by reliable quality, easy deployment and affordable price for more than a decade. Today, customers
from over 140 countries rely on Yealink as the backbone of global collaboration to extend the value of network communications.
More about Yealink
Since 2001, Yealink has continued to develop state-of-the art, hi-tech VoIP communication terminals that include IP video
phones, IP phones and USB phones. With a worldwide market in more than 140 countries, the company has also established
a first-class international service network.
Our priorities are quality, functionality, ease-of-use, customer support and competitive pricing. To provide new solutions for the
future in this fast-evolving sector, Yealink’s large, talented and highly-experienced VoIP R&D team is totally committed to the
pursuit of excellence.
To date, we have passed more than 80 interoperability tests and meet certification requirements set by leading VoIP system and
platforms. Yealink works in close partnership with T-Mobile, Telefonica, Portugal Telecom and other leading telecommunication
service providers.
YEALINK NETWROK TECHNOLOGY CO.,LTD.
Web: www.yealink.com
Addr: 4th-5th Floor, South Building, No.63
Wanghai Road, 2nd Software Park,
Xiamen, China(361008)
Copyright
©2015Yealink Inc.All right reserved.
