About This Guide
v
Thank you for choosing the SIP-T28P IP phone, exquisitely designed to provide business
telephony features, such as Call Hold, Call Transfer, Busy Lamp Field, Multicast Paging
and Conference over an IP network.
This guide provides everything you need to quickly use your new phone. First, verify
with your system administrator that the IP network is ready for phone configuration. Also
be sure to read the Packaging Contents and Regulatory Notices sections in this guide
before you set up and use the SIP-T28P IP phone.
Note
Topics provided in this guide include:
Chapter 1 Overview
Chapter 2 Getting Started
Chapter 3 Customizing Your Phone
Chapter 4 Basic Call Features
Chapter 5 Advanced Phone Features
This section describes the changes to this guide for each release and guide version.
The following section is new:
Optional Accessor on page 10
Major updates have occurred to the following sections:
DSS Keys on page 53
Appendix A - Time Zones on page 147
Shared Line, Network Directory and Network Call Log features are hidden for IP phones
in neutral firmware version, which are designed for the BroadWorks environment. Please
contact your system administrator for more information.

User Guide SIP-T28P IP Phone
vi
The following sections are new:
BLF List on page 111
Major updates have occurred to the following sections:
LED Instructions on page 4
Ring Tones on page 29
Anonymous Call Rejection on page 107
Multicast Paging on page 119
Troubleshooting on page 133
Appendix A - Time Zones on page 147
Major updates have occurred to the following sections:
Documentations on page 8
Packaging Contents on page 9
Phone Installation on page 11
Phone Status on page 14
Major updates have occurred to the following sections:
LED Instructions on page 4
Contrast on page 19
Backlight on page 20
Anonymous Call on page 106
Major updates have occurred to the following sections:
Appendix A - Time Zones on page 147
Major updates have occurred to the following sections:

About This Guide
vii
LED Instructions on page 4
Ring Tones on page 29
Remote Phone Book on page 46
Anonymous Call on page 106
Troubleshooting on page 133
Major updates have occurred to the following sections:
Phone Status on page 14
Call Transfer on page 95
Appendix A - Time Zones on page 147
Major updates have occurred to the following sections:
Phone Status on page 14
Remote Phone Book on page 46
The following sections are new:
Recent Call In Dialing on page 78
Major updates have occurred to the following sections:
Basic Network Settings on page 15
Phone Lock on page 25
Contact Management on page 31
DSS Keys on page 53
Major updates have occurred to the following sections:
Phone Lock on page 25
Volume on page 28
Ring Tones on page 29
Call Completion on page 81

User Guide SIP-T28P IP Phone
viii
DSS Keys on page 53
Do Not Disturb (DND) on page 84
Call Forward on page 88
Call Pickup on page 101
Busy Lamp Field (BLF) on page 109

Table of Contents
ix
About This Guide ...................................................................... v
In This Guide ....................................................................................................................v
Summary of Changes......................................................................................................v
Changes for Release 73, Guide Version 73.40 ............................................................v
Changes for Release 73, Guide Version 73.16 ...........................................................vi
Changes for Release 72, Guide Version 72.25 ...........................................................vi
Changes for Release 72, Guide Version 72.1 ............................................................. vi
Changes for Release 71, Guide Version 71.165 ......................................................... vi
Changes for Release 71, Guide Version 71.140 ......................................................... vi
Changes for Release 71, Guide Version 71.125 ........................................................ vii
Changes for Release 71, Guide Version 71.120 ........................................................ vii
Changes for Release 71, Guide Version 71.110 ........................................................ vii
Changes for Release 70, Guide Version 70 ............................................................... vii
Table of Contents..................................................................... ix
Overview .................................................................................. 1
Hardware Component Instructions.................................................................................1
Icon Instructions ...............................................................................................................3
LED Instructions ................................................................................................................4
User Interfaces.................................................................................................................5
Phone User Interface ....................................................................................................6
Web User Interface.......................................................................................................6
Documentations...............................................................................................................8
Getting Started......................................................................... 9
Packaging Contents.........................................................................................................9
Optional Accessories.................................................................................................. 10
Phone Installation...........................................................................................................11
Phone Initialization.........................................................................................................13
Phone Status................................................................................................................... 14
Basic Network Settings.................................................................................................. 15
Registration ....................................................................................................................17
Idle Screen ..................................................................................................................... 17
Customizing Your Phone ......................................................... 19

User Guide SIP-T28P IP Phone
x
General Settings............................................................................................................ 19
Contrast....................................................................................................................... 19
Backlight......................................................................................................................20
Language.................................................................................................................... 20
Time & Date.................................................................................................................21
Administrator Password .............................................................................................23
Key as Send ................................................................................................................24
Phone Lock ..................................................................................................................25
Audio Settings................................................................................................................ 28
Volume......................................................................................................................... 28
Ring Tones ...................................................................................................................29
Contact Management...................................................................................................31
Directory......................................................................................................................31
Local Directory............................................................................................................ 33
Blacklist........................................................................................................................44
Remote Phone Book....................................................................................................46
Call History Management.............................................................................................48
System Customizations.................................................................................................. 50
Logo Customization ....................................................................................................50
Headset Use ...............................................................................................................51
DSS Keys ..................................................................................................................... 53
Account Management ............................................................................................... 62
Dial Plan ......................................................................................................................65
Emergency Number....................................................................................................70
Live Dialpad................................................................................................................ 71
Hotline ......................................................................................................................... 72
Basic Call Features ................................................................. 73
Placing Calls...................................................................................................................73
Answering Calls .............................................................................................................75
Ending Calls ................................................................................................................... 77
Redialing Numbers ........................................................................................................ 77
Recent Call In Dialing ....................................................................................................78
Auto Answer...................................................................................................................79
Auto Redial..................................................................................................................... 79
Call Completion .............................................................................................................81
Recall ..............................................................................................................................82
Call Mute........................................................................................................................ 83
Call Hold/Resume ..........................................................................................................83
Do Not Disturb (DND) ....................................................................................................84
Call Forward................................................................................................................... 88
Call Transfer ...................................................................................................................95
Call Waiting.................................................................................................................... 96
Conference.....................................................................................................................97

Table of Contents
xi
Local Conference........................................................................................................ 97
Network Conference ..................................................................................................98
Call Park .......................................................................................................................100
Call Pickup....................................................................................................................101
Anonymous Call........................................................................................................... 106
Anonymous Call Rejection...........................................................................................107
Advanced Phone Features....................................................109
Busy Lamp Field (BLF)..................................................................................................109
BLF List ..........................................................................................................................111
Call Recording..............................................................................................................113
Hot Desking.................................................................................................................. 115
Intercom .......................................................................................................................117
Outgoing Intercom Calls ..........................................................................................117
Incoming Intercom Calls........................................................................................... 117
Multicast Paging .......................................................................................................... 119
Sending RTP Stream ................................................................................................. 119
Receiving RTP Stream...............................................................................................123
Music on Hold ..............................................................................................................124
Messages.....................................................................................................................126
Short Message Service (SMS)................................................................................. 126
Voice Mail..................................................................................................................129
Message Waiting Indicator (MWI) ..........................................................................130
Troubleshooting .....................................................................133
Regulatory Notices ................................................................143
Service Agreements ....................................................................................................143
Limitations of Liability ..................................................................................................143
Safety Instructions........................................................................................................ 143
Appendix A - Time Zones......................................................147
Index ......................................................................................151

Overview
1
This chapter provides the overview of the SIP-T28P IP phone. Topics include:
Hardware Component Instructions
Icon Instructions
LED Instructions
User Interfaces
Documentations
If you require additional information or assistance with your new phone, contact your
system administrator.
The main hardware components of the SIP-T28P IP phone are the LCD screen and the
keypad.

User Guide for the SIP-T28P IP Phone
2
Hardware component instructions of the SIP-T28P IP phone are:
Item
Description
①
LCD Screen
Shows information about calls, messages, soft keys,
time, date and other relevant data:
• Call information —caller ID, call duration
• Icons (for example, )
• Missed call text or second incoming caller information
• Prompt text (for example, "Saving config file!")
• Time and date
②
Power Indicator LED
Indicates phone power status and phone status.
③
Line Keys
Use these keys to activate up to six accounts and assign
various features.
④
Memory Keys
Use these keys to assign various features.
⑤
MESSAGE Key
Indicates and accesses voice mails.
⑥
HEADSET Key
Toggles and indicates the headset mode.
⑦
HOLD Key
Places a call on hold or resumes a held call.
⑧
TRAN Key
Transfers a call to another party.
⑨
MUTE Key
Mutes or un-mutes an active call.
⑩
Speakerphone Key
Toggles the hands-free speakerphone mode.
⑪
RD Key
Redials a previously dialed number.
⑫
CONF Key
Conducts a conference call with multiple other parties.
⑬
Volume Key
Adjusts the volume of the handset, headset, speaker,
and ringer.
⑭
Keypad
Provides the digits, letters and special characters in
context-sensitive applications.
⑮
Scroll through the displayed information.
Confirms actions or answers incoming calls.
Cancels actions or rejects incoming calls.
⑯
Soft Keys
Label automatically to identify their context-sensitive
features.
⑰
Speaker
Provides ringer and hands-free (speakerphone) audio
output.
⑱
Hookswitch
Picking up the handset from the handset cradle, the
hookswitch bounces and the phone connects to the line,
laying the handset down on the handset cradle, the
phone disconnects from the line.

Overview
3
Icons appearing on the LCD screen are described in the following table:
Icons
Description
Network is unavailable
Registered successfully
Register failed
Registering
Hands-free speakerphone mode
Handset mode
Headset mode
Multi-lingual lowercase letters input mode
Multi-lingual uppercase letters input mode
Alphanumeric input mode
Numeric input mode
Multi-lingual uppercase and lowercase
letters input mode
Voice Mail
Text Message
Auto Answer
Do Not Disturb
Call Forward/Forwarded Calls
Call Hold

User Guide for the SIP-T28P IP Phone
4
Icons
Description
Call Mute
Ringer volume is 0
Phone Lock
Received Calls
Placed Calls
Missed Calls
Recording box is full
A call cannot be recorded
Recording starts successfully
Recording cannot be started
Recording cannot be stopped
Power Indicator LED (Hardware version must be 1.0.0.2 or higher)
LED Status
Description
Solid green
The phone is initializing.
The phone is busy.
The phone is idle.
The call is placed on hold or is held.
The phone receives a text message or voice mail.
Fast flashing green (300ms)
The phone is ringing.
The call is muted.
Off
The phone is powered off.

Overview
5
Line key LED
LED Status
Description
Solid green
The line is in conversation.
The line is seized.
Fast flashing green
The line receives an incoming call.
Slow flashing green
The call is placed on hold.
Off
The line is inactive.
Line key LED (configured as a BLF key or a BLF List key)
LED Status
Description
Solid green
The monitored user is idle.
Fast flashing green (200ms)
The monitored user receives an incoming call.
Slow flashing green (500ms)
The monitored user is dialing.
The monitored user is talking.
The monitored user’s conversation is placed on
hold (This status requires server support).
Slow flashing green (1s)
The call is parked against the monitored user’s
phone number.
Off
The monitored user does not exist.
Memory key LED (configured as a BLF key or a BLF List key)
LED Status
Description
Solid green
The monitored user is idle.
Fast flashing red (200ms)
The monitored user receives an incoming call.
Solid red
The monitored user is dialing.
The monitored user is talking.
Slow flashing red (1s)
The call is parked against the monitored user’s
phone number.
The monitored user’s conversation is placed on
hold (This status requires server support).
Off
The monitored user does not exist.
Note
Two ways to customize configurations of your SIP-T28P IP phone:
The user interface on the IP phone.
The above introduces the default LED status. The statuses of the power indicator LED and
BLF key are configurable via web user interface. For more information, refer to
Yealink_SIP-T2xP_IP_Phones_Administrator_Guide.

User Guide for the SIP-T28P IP Phone
6
The user interface in a web browser on your PC.
The hardware components keypad and LCD screen constitute the phone user interface,
which allows the user to execute all call operation tasks and basic configuration
changes directly on the phone. In addition, you can use the web user interface to
access all configuration settings. In many cases, either the phone user interface and/or
the web user interface interchangeably. However, in some cases, it is only possible to
use one or the other interface to operate the phone and change settings.
You can customize your phone by pressing the Menu soft key to access the phone user
interface. The Advanced Settings option is only accessible to the administrator, and the
default administrator password is “admin”(case-sensitive). For more information on
customizing your phone with the available options from the phone user interface, refer
to Customizing Your Phone on page 19.
In addition to the phone user interface, you can also customize your phone via web user
interface. In order to access the web user interface, you need to know the IP address of
your new phone. To obtain the IP address, press the OK key on the phone when the
phone is idle. Enter the IP address (e.g., http://192.168.0.10 or 192.168.0.10) in the
address bar of a web browser on your PC. The default administrator user name and
password are both “admin”(case-sensitive).
The options you can use to customize the IP phone via phone user interface and/or via
web user interface are listed in the following table:
Options
Phone User Interface
Web User Interface
Status
√
√
--IP Address
--MAC
--Firmware
--Network
--Phone
--Accounts
Basic Phone Settings
√
--Contrast
√
--Backlight
√
--Language
√
--Time & Date
√
--Administrator Password
√
--Key as Send
√

Overview
7
Options
Phone User Interface
Web User Interface
-- Phone Lock
√
--Ring Tones
√
--Contact Management
×
--Directory
×
--Local Directory
√
--Blacklist
√
--Remote Phone Book
×
--Call History Management
√
--Logo Customization
×
--DSS Keys
√
--Account Registration
√
--Dial Plan
×
--Emergency Number
×
--Live Dialpad
×
--Hotline
√
Basic Call Features
√
--Recent Call In Dialing
×
--Auto Answer
√
--Auto Redial
√
--Call Completion
√
--Recall
√
--Do Not Disturb (DND)
√
--Call Forward
√
--Call Transfer
√
--Call Waiting
√
--Conference
×
--Call Park
√
--Call Pickup
√
--Anonymous Call
√
--Anonymous Call Rejection
√
Advanced Phone Features
√
--Busy Lamp Field (BLF)
√
--BLF List
×
--Call Recording
√
--Hot Desking
√
--Intercom
√
--Multicast Paging
×
--Music on Hold
×
--Messages
√
SIP Account
√
--User Options
×

User Guide for the SIP-T28P IP Phone
8
Options
Phone User Interface
Web User Interface
--Account Status
√
--Label
√
--Display Name
√
--Register Name
√
--User Name
√
--Password
√
--SIP Server1/2
√
--Server Option
×
--Registrar Port
×
--Outbound Status
√
--Outbound Proxy
√
--NAT Traversal
--STUN Status
√
--STUN Server
√
Note
The following table shows documentations available for the SIP-T28P IP phone.
Name
Contents
Where found
Language
Quick Start Guide
Basic call features
and phone
customizations
In the package
English
User Guide
Phone/ Web user
interface settings
Basic call features
and advanced
phone features
On the website
English
Note
The table above lists most of the feature options. Please refer to the relevant sections for
more information.
You can also download the latest documentations online:
http://www.yealink.com/SupportDownloadfiles_detail.aspx?CateId=184&flag=142.
