Claranet Hosted Voice v2
Yealink T48S
User Guide
July 2018

...................................................................................................................................................................1
Claranet Hosted Voice v2 ........................................................................................................................1
Yealink SIP-T48S......................................................................................................................................3
Phone Installation ....................................................................................................................................4
Provisioning..............................................................................................................................................7
Getting to know your phone..................................................................................................................8
Hardware Component Instructions...................................................................................................8
Icon Instructions...............................................................................................................................9
Phone Display (Views)...................................................................................................................10
Basic Call Features.............................................................................................................................12
Placing Calls ..................................................................................................................................12
Answering Calls .............................................................................................................................13
Transferring Calls...........................................................................................................................13
Ending Calls...................................................................................................................................13
Conference Calls............................................................................................................................14
Do Not Disturb (DND) ....................................................................................................................14
History............................................................................................................................................14
Contact Directory ...........................................................................................................................14
Voicemail........................................................................................................................................15
General information...............................................................................................................................16

Yealink SIP-T48S
IP Phone User guide
This user guide provides you with all the information you need to get the most from your phone. You must first
set up your phone before you can use it. This doesn’t take long as it is easy to do. Just follow the simple
instructions in this user guide or the quick start guide included with the phone.
Got everything?
•IP Phone
•Handset
•Handset cord
•Ethernet cable
•Phone stand
•Quick start guide
•Power adapter (Optional)
•Wall mount bracket (Optional)
Need help?
If you have any problems
setting up or using your
Yealink IP Phone, please
contact your Service Provider.

Emergency Calls –important information please note
Access to Emergency Services is provided but calls including emergency calls to 999 or 112, made via Hosted Voice may
not work in the event of power or broadband connection failure. These failures may be caused by reasons outside our
control. Location information, provided to the emergency services, is limited to the location details entered into the system
by your Service Provider; this may not be where the call was originated.
Phone Installation
1. Attach the stand or the optional wall mount bracket

Wall Mount Method (Optional)
2. Connect the handset and optional headset
3. Connect the network and power
You have two options for power and network connections. Your system administrator will advise you which one
to use.
1. AC power (Optional)
2. Power over Ethernet (PoE)
AC Power (Optional)
To connect the AC power:
1. Connect the DC plug on the power adapter to the DC5V port on the phone and connect the other end of
the power adapter into an electrical power outlet.
2. Connect the included or a standard Ethernet cable between the Internet port on the phone and the one
on the wall or switch/hub device port.

Power over Ethernet
With the included or a regular Ethernet cable, the SIP-T48S IP phone can be powered from a PoE-compliant
switch or hub.
To connect the PoE:
1. Connect the Ethernet cable between the Internet port on the phone and an available port on the in-line
power switch/hub.
If in-line power switch/hub is provided, you don’t need to connect the phone to the power adapter. Make sure
the switch/hub is PoE-compliant. The phone can also share the network with another network device such as a
PC (personal computer). It is an optional connection. Important, do not unplug or remove power to the phone
while it is updating firmware and configurations.

Provisioning
Your Yealink SIP-T48S IP Phone will be pre-loaded with all the information it needs to automatically provision
the Hosted Voice service once all the connections have been made.
1. Once connected to the network port that is providing network access the phone will do a series of
firmware updates (please allow the phone time to complete).
3. Your phone has provisioned correctly if this symbol is
showing against the phones line key
4. Your phone has not provisioned correctly if this symbol
is showing against the phones line key
2. Once complete the phone will now show the line number against a line key.
Note: If the handset fails to provision please contact your Service Provider.

Getting to know your phone
Hardware Component Instructions
The main hardware components of the SIP-T48S IP phone are the LCD screen and the keypad.
Item
Description
①
Power Indicator LED
Indicates phone power and some feature statuses.
②
Touch Screen
The screen is touch-sensitive. Tap to select and highlight
screen items.
Shows information about calls, messages, soft keys, time, date
and other relevant data:
• Call information—caller ID, call duration
• Icons (for example, )
• Missed call text or second incoming caller information
• Prompt text (for example, “Saving config file！”)
• Time and date
③
HEADSET Key
Toggles and indicates the headset mode.
④
MUTE Key
Toggles and indicates mute feature.
⑤
HOLD Key
Places a call on hold or resumes a held call.
⑥
TRANSFER Key
Transfers a call to another party.
⑦
Speakerphone Key
Toggles the hands-free speakerphone mode.
⑧
MESSAGE Key
Accesses voice messages.
⑨
REDIAL Key
Redials a previously dialed number.
⑩
Position the cursor within text you’re updating.
Enable or disable fields.
Turn pages or scroll through values for a field.
Scroll through items.
Access to History and Directory respectively.
Confirms actions or answers incoming calls.

Cancels actions or rejects incoming calls.
⑪
Volume Key
Adjusts the volume of the handset, headset, speakerphone and
ringer.
⑫
Keypad
Provides the digits, letters and special characters in context-
sensitive applications.
⑬
Speaker
Provides ringer and hands-free (speakerphone) audio output.
⑭
Hookswitch Tab
Secures the handset in the handset cradle when the IP phone
is mounted vertically.
⑮
Hookswitch
Picking up the handset from the handset cradle, the hookswitch
bounces and the phone connects to the line, laying the handset
down on the handset cradle, the phone disconnects from the
line.
Icon Instructions
Icons appearing on the LCD screen are described in the following table:
Icons
Description
Network is unavailable
Registered successfully
Register failed
(Flashing)
Registering
Hands-free speakerphone mode
Handset mode
Headset mode
Multi-lingual lowercase letters input mode
Multi-lingual uppercase letters input mode
Alphanumeric input mode
Numeric input mode
Multi-lingual uppercase and lowercase letters input
mode
Voice Mail
Auto Answer
Do Not Disturb
Call Forward
Call Hold

Icons
Description
Call Mute
Ringer volume is 0
Received Calls
Placed Calls
Missed Calls
Forwarded Calls
Recording box is full
A call cannot be recorded
Recording starts successfully
Recording cannot be started
Recording cannot be stopped
Bluetooth mode is on
Bluetooth headset is both paired and connected
The default caller photo and contact icon
Phone Display (Views)
Idle Status
If the phone has successfully started up, the idle screen will be displayed. The following figure is an example of
what is displayed on the touch screen
