YOKOGAWA AQ1210 Series User manual

User’s
Manual
IM AQ1210-02EN
4th Edition
AQ1210A, AQ1215A, AQ1210D,
AQ1210E, AQ1215E, AQ1215F, AQ1216F
OTDR Multi Field Tester
Getting Started Guide

IM AQ1210-02EN 1
4th Edition: April 2021 (YMI)
All Rights Reserved, Copyright © 2019, Yokogawa Test & Measurement Corporation
Thank you for purchasing the AQ1210A, AQ1215A, AQ1210D, AQ1215E, AQ1215F, AQ1216F OTDR (Optical Time Domain
Reflectometer) Multi Field Tester. This Getting Started Guide focuses on the handling precautions, basic operations, and specifications
of this instrument.
To ensure correct use, please read this manual thoroughly before operation. Keep this manual in a safe place for quick reference.
The following manuals, including this one, are provided as manuals for this instrument.
Please read all manuals.
Manual Title Manual No. Description
AQ1210A, AQ1215A, AQ1210D, AQ1210E,
AQ1215E, AQ1215F, AQ1216F OTDR Multi
Field Tester User’s Manual
IM AQ1210-01EN A PDF file of the manual is contained in the internal memory of this
instrument. The manual explains all the features and how to use them.
For instructions on how to view the manual, see page 17.
AQ1210A, AQ1215A, AQ1210D, AQ1210E,
AQ1215E, AQ1215F, AQ1216F OTDR Multi
Field Tester Getting Started Guide
IM AQ1210-02EN This guide. The guide explains the handling precautions and basic
operations of this instrument and provides a list of specifications.
AQ1210A, AQ1215A, AQ1210D, AQ1210E,
AQ1215E, AQ1215F, AQ1216F OTDR
Multi Field Tester Communication Interface
User’s Manual
IM AQ1210-17EN A PDF file of the manual is contained in the internal memory of this
instrument. This manual explains the communication interface features
of this instrument and how to use them.
Model 739884 Battery Pack Handling
Precautions
IM 739884-01EN Explains the handlling precautions for the battery pack.
AQ1210A, AQ1215A, AQ1210D, AQ1210E,
AQ1215E, AQ1215F, AQ1216F OTDR Multi
Field Tester User’s Manual
IM AQ1210-92EN Document for China
The “-EN” in the manual number is the language code.
Contact information of Yokogawa offices worldwide is provided on the following sheet.
Document No. Description
PIM113-01Z2 List of worldwide contacts

2IM AQ1210-02EN
Notes
• The contents of this manual are subject to change without prior notice as a result of continuing improvements to the instrument's
performance and functions. The figures given in this manual may differ from those that actually appear on your screen.
• Every effort has been made in the preparation of this manual to ensure the accuracy of its contents. However, should you have any
questions or find any errors, please contact your nearest YOKOGAWA dealer.
• Copying or reproducing all or any part of the contents of this manual without the permission of YOKOGAWA is strictly prohibited.
Trademarks
• Microsoft, Windows, MS-DOS are registered trademarks or trademarks of Microsoft Corporation in the United States and/or other
countries.
• Adobe, Acrobat, and PostScript are either registered trademarks or trademarks of Adobe Systems Incorporated.
• In this manual, the ® and TM symbols do not accompany their respective registered trademark or trademark names.
• Other company and product names are trademarks or registered trademarks of their respective holders.
Revisions
April 2019 1st Edition April 2021 4th Edition
September 2020 2nd Edition
January 2021 3rd Edition
Product Registration
Thank you for purchasing YOKOGAWA products.
YOKOGAWA provides registered users with a variety of information and services.
Please allow us to serve you best by completing the product registration form accessible from our
homepage.
https://tmi.yokogawa.com/

IM AQ1210-02EN 3
Checking the Contents of the Package
Unpack the box, and check the contents before operating the instrument. If the wrong items have been delivered, if items are missing, or
if there is a problem with the appearance of the items, contact your nearest YOKOGAWA dealer.
AQ1210A, AQ1215A, AQ1210D, AQ1210E, AQ1215E, AQ1215F, AQ1216F
Check that the product that you have received is the same product that you ordered. For reference, the model name, suffix code, and
specifications of the products are listed below.
front panel
MODEL Suffix Code1Specifications
AQ1210A 2 wavelengths 1310/1550 nm, DR 37/35 dB
AQ1215A 2 wavelengths 1310/1550 nm, DR 42/40 dB
AQ1210D 4 wavelengths 1310/1550 nm, 850/1300 nm, DR 37/35 dB, 25/27 dB
AQ1210E 3 wavelengths 1310/1550 nm, 1625 nm, DR 37/35 dB, 35 dB
AQ1215E 3 wavelengths 1310/1550 nm, 1625 nm, DR 42/40 dB, 39 dB
AQ1215F 3 wavelengths 1310/1550 nm, 1650 nm, DR 42/40 dB, 37 dB
AQ1216F 3 wavelengths 1310/1550 nm, 1650 nm, DR 42/40 dB, 40 dB
Language -HJ Japanese/English
-HE English
-HC Chinese/English
-HM Chinese
-HK Korean/English
-HR Russian/English

4IM AQ1210-02EN
MODEL Suffix Code1Specifications
Optical connector2-USC Universal adapter (SC)
-UFC Universal adapter (FC)
-ULC Universal adapter (LC)3
-ASC Universal adapter (SC angled-PC)4
Options /PC Power checker (OTDR port)
/SPM Standard optical power meter, auto loss test included
/HPM High power optical power meter, auto loss test included
/PPM PON power meter
/VLS Visible light source (2.5ɸ ferrule connector)
/FST Fiber Surface Test function
/SB Shoulder belt
1 For products whose suffix code contains “Z,” an exclusive manual may be included. Please read it along with the standard manual.
2 The optical connector that you selected is attached to the OTDR ports and the OPM port prior to shipping.
3 1.25 mm diameter ferrule type for the optical power meter.
4 SC type for the optical power meter and the OTDR port (PORT2) of AQ1210D.
No. (Instrument number)
When contacting the dealer from which you purchased the instrument, please give them the instrument number.
Standard Accessories
The following accessories are included. Make sure that all accessories are present and undamaged.
IMAQ1210-02
PIM113-01Z2
IMAQ1210-92Z1
IM739884-01Z1
USB type C cable
A1681WL
Manuals*
•IM AQ1210-02EN
(this manual)
•PIM113-01Z2
(List of contacts)
•IM AQ1210-92Z1
(for Chaina)
• IM 739884-01Z1
(Battery pack)
* IM AQ1210-01EN and IM AQ1210-17EN are contained in a PDF file in this
instrument internal memory. A printed manual can also be purchased separately.
Contact your nearest YOKOGAWA dealer to purchase a copy.
Battery pack
(lithium-ion)
739884
Hand strap
B8070CX

IM AQ1210-02EN 5
Optional Accessories
The following optional accessories are available for purchase separately. For information about ordering accessories, contact your
nearest YOKOGAWA dealer.
Item Model/Part No. Note
Soft carrying case SU2006A —
Shoulder strap B8070CY —
USB Cable (Type C to Type C) A1681WL —
Battery pack 739884 —
Universal adapter (SC) 735482-SCC For the OTDR port (SC type), fixing screws (2 pcs.)
For the PON -OPM port (/PPM option), fixing screws (2 pcs.)
Universal adapter (FC) 735482-FCC For the OTDR port (FC type), fixing screws (2 pcs.)
For the PON - OPM port (/PPM option), fixing screws (2 pcs.)
Universal adapter (LC) 735482-LCC For the OTDR port (LC type), fixing screws (2 pcs.)
For the PON -OPM port (/PPM option), fixing screws (2 pcs.)
Universal adapter (SC Angled-PC) 735482-ASC For the OTDR port, fixing screws (2 pcs.)
For the PON -OPM port (/PPM option), fixing screws (2 pcs.)
Connector adapter (SC) 735480-SCC For the OPM ports with an SC connector.
For products with the /SPM or /HPM option.
Connector adapter (FC) 735480-FCC For the OPM ports with an FC connector.
For products with the /SPM or /HPM option.
Ferrule adapter (ɸ1.25) 735481-LMC For the OPM ports.
For products with the /SPM or /HPM option.
Ferrule adapter (ɸ2.5) 735481-SFC For the OPM ports.
For products with the /SPM or /HPM option.
Additional Option License for
AQ1210
735051-FST Fiber surface test function
Emulation software AQ7933 Software for PC. Analysis of trace data function, report creation wizard
function.
Accessories (sold separately) are not covered by warranty.

6IM AQ1210-02EN
Conventions Used in This Guide
Notes
The notes and cautions in this guide are categorized using the following symbols.
Improper handling or use can lead to injury to the user or damage to the instrument. This symbol appears on the
instrument to indicate that the user must refer to the user’s manual for special instructions. The same symbol appears
in the corresponding place in the user’s manual to identify those instructions. In the manual, the symbol is used in
conjunction with the word “WARNING” or “CAUTION.”
WARNING Calls attention to actions or conditions that could cause serious or fatal injury to the user, and precautions that can
be taken to prevent such occurrences.
CAUTION Calls attention to actions or conditions that could cause light injury to the user or damage to the instrument or
user’s data, and precautions that can be taken to prevent such occurrences.
French
Une manipulation ou une utilisation incorrectes risquent de blesser l’utilisateur ou d’endommager l’instrument. Ce
symbole apparaît sur l’instrument pour indiquer à l’utilisateur qu’il doit se reporter au manuel de l’utilisateur afin d’y lire
les instructions spécifiques correspondantes. Ce même symbole apparaît à la section correspondante du manuel de
l’utilisateur pour signaler lesdites instructions. Dans le manuel de l’utilisateur, ce symbole est accompagné des termes
AVERTISSEMENT et ATTENTION.
AVERTISSEMENT Attire l’attention sur des gestes ou des conditions susceptibles de provoquer des blessures graves (voire
mortelles), et sur les précautions de sécurité pouvant prévenir de tels accidents.
ATTENTION Attire l’attention sur des gestes ou des conditions susceptibles de provoquer des blessures légères ou
d’endommager l’instrument ou les données de l’utilisateur, et sur les précautions de sécurité susceptibles de
prévenir de tels accidents.
Note Calls attention to information that is important for the proper operation of the instrument.

IM AQ1210-02EN 7
Safety Precautions
This product is designed to be used by a person with specialized knowledge. The general safety precautions described herein must be
observed during all phases of operation. If the product is used in a manner not specified in this manual, the protection provided by the
product may be impaired. This manual is part of the product and contains important information. Store this manual in a safe place close
to the instrument so that you can refer to it immediately. Keep this manual until you dispose of the instrument.
YOKOGAWA assumes no liability for the customer’s failure to comply with these requirements.
The following symbols are used on this instrument.
Warning: handle with care. Refer to the user’s manual or service manual. This symbol appears on dangerous locations on the
instrument which require special instructions for proper handling or use. The same symbol appears in the corresponding place in
the manual to identify those instructions.
Hazard, radiation of laser apparatus
Direct current
French
Avertissement : À manipuler délicatement. Toujours se reporter aux manuels d’utilisation et d’entretien. Ce symbole a été apposé
aux endroits dangereux de l’instrument pour lesquels des consignes spéciales d’utilisation ou de manipulation ont été émises.
Le même symbole apparaît à l’endroit correspondant du manuel pour identifier les consignes qui s’y rapportent
Danger : Appareil laser à rayonnement.
Courant direct
Stand-by
Veille

8IM AQ1210-02EN
Failure to comply with the precautions below could lead to injury or death or damage to the instrument.
WARNING
Use the Instrument Only for Its Intended Purpose
This optical measuring instrument is designed to measure the optical characteristics of light sources and evaluate their
performance. Do not use this instrument for anything other than as an optical measuring instrument.
Check the Physical Appearance
Do not use the instrument if there is a problem with its physical appearance.
Battery
• This instrument contains a battery (lithium-ion cell). The battery cannot be removed. For information on replacing the
battery, contact your nearest YOKOGAWA dealer.
• Use only the supplied USB cable to charge the instrument.
• With the instrument turned off, when the battery pack is charged using the USB-AC adapter that YOKOGAWA
recommends , if the battery pack is still charging after 8 hours, stop charging it immediately.
• Do not charge the instrument under direct sunlight (such as on the car dashboard or by a window), inside a vehicle
under the blazing sun, near a stove or other heat source, or other hot locations.
• Your clothing may be damaged or you may be injured if you come in contact with the electrolyte in the battery due to
fluid leakage or the battery exploding. Because the electrolyte may cause loss of eyesight, if it comes in contact with
your eyes, immediately wash the affected area with clean water, and consult a doctor as soon as possible.
• Do not throw the instrument into fire or heat it. Such actions are dangerous as they may cause the battery to explode
or the electrolyte to be sprayed about.
• For information on transporting lithium-ion batteries by air, see the requirement for each packing instruction (lithium
batterying instruction Section II) in the latest IATA Dangerous Goods Regulations.
Laser Beam
Do not look directly or indirectly into the laser beam or at a specular reflection of the beam without protective equipment.
Do not aim the laser beam at the eye. Doing so may cause blindness or damage to your eyes. Attach the cover to the
optical connector when it is not in use. Be sure to turn off this instrument before you clean it.

IM AQ1210-02EN 9
Connecting Optical Fiber Cables
Use optical fiber cables that are compatible with the universal adapter (the universal adapter is specified with a suffix
code).
Type A USB port
Only use the USB memory device or USB dongle that YOKOGAWA recommends. YOKOGAWA provides no guarantee
if you use the device that YOKOGAWA do not recommend. This instrument may be powered off without alarm forcibly if
you use the device that YOKOGAWA do not recommend.
Applying Light to the Optical Connector
Do not apply light that is –5 dBm or greater to the optical connector of the OTDR port. Doing so can damage the
instrument. Do not apply light that is +10 dBm or greater to the OPM port/PON-OPM port (1310 nm/1490 nm). Do not
apply light that is +27 dBm or greater to the high power OPM port/PON-OPM port (1550 nm). Doing so may damage
the OPM port.
Do Not Operate in an Explosive Atmosphere
Do not use this instrument in the presence of flammable gases or vapors. Doing so is extremely dangerous.
Do Not Remove Covers or Disassemble or Alter the Instrument
Only qualified YOKOGAWA personnel may remove the covers and disassemble or alter the instrument.
Installation Location
Using a stand in an unstable location is extremely dangerous. If you are installing the instrument using a stand, install
in a stable location.
CAUTION
Operating Environment Limitations
This product is a Class A (for industrial environments) product. Operation of this product in a residential area may cause
radio interference in which case the user will be required to correct the interference.

10 IM AQ1210-02EN
French
AVERTISSEMENT
Utiliser l’instrument aux seules fins prévues
Cet instrument de mesure optique est prévu pour mesurer les caractéristiques optiques des sources lumineuses et
évaluer leur performance. Ne pas utiliser cet instrument à d’autres fins que celles de mesure optique.
Inspecter l’apparence physique
Ne pas utiliser l’instrument si son intégrité physique semble être compromise.
Batterie
• Cet instrument contient une batterie (cellule au lithium-ion). La batterie ne peut être retirée. Pour plus d'informations
sur le remplacement de la batterie, contacter votre fournisseur YOKOGAWA le plus proche.
• Utiliser uniquement le câble USB fourni pour charger l'instrument.
• Avec l'instrument hors tension, lorsque le pack de batteries est chargé à l'aide de l'adaptateur USB-CA recommandé
par YOKOGAWA, si le pack de batteries est encore en charge après 8 heures, arrêter le chargement immédiatement.
• Ne pas charger l'instrument en plein soleil (par exemple sur le tableau de bord de la voiture ou sur le rebord d'une
fenêtre), dans un véhicule stationné sous un soleil de plomb, à proximité d'une gazinière ou de toute autre source de
chaleur ou dans tout autre endroit chaud.
• Tout contact avec l'électrolyte échappé en raison d'une fuite ou d'une explosion du pack de batteries peut
endommager les vêtements ou causer des blessures. L'électrolyte peut entraîner la cécité, par conséquent, en cas
de contact avec les yeux, rincer immédiatement à l'eau et consulter un médecin dans les plus brefs délais.
• Tenir le pack de batteries éloigné de toute source de chaleur et des flammes pour éviter le risque d'explosion du
pack de batteries ou de déversement d'électrolyte.
• Pour toute information sur le transport aérien des batteries au lithium-ion, consulter les exigences énoncées dans le
Règlement de l'IATA sur le transport des marchandises dangereuses (instruction sur les batteries au lithium).
Faisceau laser
Ne pas fixer directement ou indirectement le faisceau laser, ni la réflexion spéculaire du faisceau en l’absence
d’équipement de protection. Ne pas orienter le faisceau laser en direction des yeux. Le faisceau laser peut entraîner la
cécité ou causer des lésions oculaires. Recouvrir le connecteur optique à l’aide du cache pendant les périodes de non-
utilisation. Mettre cet instrument HORS tension pendant son nettoyage.

IM AQ1210-02EN 11
Connexion des câbles à fibre optique
Utiliser des connecteurs de câbles à fibre optique conformes à l’adaptateur universel fourni (adaptateur universel
indiqué par le suffixe).
Port USB de Type A
Utiliser uniquement le dispositif de mémoire USB ou le dongle USB recommandés par YOKOGAWA. YOKOGAWA n’offre
aucune garantie si vous utilisez un dispositif que YOKOGAWA ne recommande pas. Cet instrument peut être mis hors
tension de force sans alarme si vous utilisez un dispositif que YOKOGAWA ne recommande pas.
Envoyer un signal au connecteur optique
Ne pas appliquer un signal de -5 dBm ou plus au connecteur optique du port OTDR. Cela pourrait endommager
l'instrument. Ne pas appliquer de signal de +10 dBm ou plus au port OPM/PON-OPM (1310 nm/1490 nm). Ne
pas appliquer de signal de +27 dBm ou plus au port OPM/PON-OPM (1550 nm) haute puissance. Cela pourrait
endommager le port OPM.
Ne pas utiliser dans un environnement explosif
Ne pas utiliser l’instrument en présence de gaz ou de vapeurs inflammables. Cela pourrait être extrêmement
dangereux.
Ne pas retirer le capot, ni démonter ou modifier l’instrument
Seul le personnel YOKOGAWA qualifié est habilité à retirer le capot et à démonter ou modifier l’instrument. Certains
composants à l’intérieur de l’instrument sont à haute tension et par conséquent, représentent un danger.
Position d’installation
Lorsque vous manipulez les pieds ou le support escamotable, soutenez toujours l’instrument fermement. Prendre les
précautions suivantes.
ATTENTION
Limitations relatives à l’environnement opérationnel
Ce produit est un produit de classe A (pour environnements industriels). L’utilisation de ce produit dans un zone
résidentielle peut entraîner une interférence radio que l’utilisateur sera tenu de rectifier.

12 IM AQ1210-02EN
Safety Precautions for Laser Products
This instrument uses a laser light source. This instrument is a Class 1M laser product and Class 3R laser product as defined by
IEC60825-1:2007 Safety of Laser Products-Part 1: Equipment classification and requirements. In addition, this instrument complies with
21 CFR 1040.10 and 1040.11 except for deviations pursuant to Laser Notice No. 50, dated June 24, 2007.
Laser Class 1M Label
Using an optical instrument, such as a loupe, magnifying glass, or microscope, when
observing the laser beam from a distance of less than 100 mm may cause eye injury.
Laser Class 3R Label
Avoid direct eye exposure.
Laser Class 1 Label
Avoid direct eye exposure.
front panel
When AQ1210D
Laser Class 3R Label
Avoid direct eye exposure.

IM AQ1210-02EN 13
OTDR Port
Model Class1Center
Wavelength
Maximum Output Power 2Mode Field
Diameter
Beam Divergence
Angle
AQ1210A
OTDR port (PORT1) 1M or 1 1310 nm/1550 nm CW: 50 mW,
Pulse: 200 mW, Pulse width: 20 μs, Duty: ≤ 3.0%
9 μm 11.5°
VLS port 33R 650 nm CW: 5 mW 9 μm 11.5°
AQ1215A
OTDR port (PORT1) 1M or 1 1310 nm/1550 nm CW: 50 mW,
Pulse: 200 mW, Pulse width: 20 μs, Duty: ≤ 3.0%
9 μm 11.5°
VLS port 33R 650 nm CW: 5 mW 9 μm 11.5°
AQ1210D
OTDR port (PORT1) 1M or 1 1310 nm/1550 nm CW: 50 mW,
Pulse: 200 mW, Pulse width: 20 μs, Duty: ≤ 3.0%
9 μm 11.5°
OTDR port (PORT2) 3R 850 nm CW: 24 mW,
Pulse: 200 mW, Pulse width: 1 μs, Duty: ≤ 2.5%
50 μm 23.1°
1M or 1 1300 nm CW: 50 mW,
Pulse: 200 mW, Pulse width: 5 μs, Duty: ≤ 1.2%
50 μm 23.1°
VLS port 33R 650 nm CW: 5 mW 9 μm 11.5°
AQ1210E
OTDR port (PORT1) 1M or 1 1310 nm/1550 nm CW: 50 mW,
Pulse: 200 mW, Pulse width: 20 μs, Duty: ≤ 3.0%
9 μm 11.5°
OTDR port (PORT2) 1M or 1 1625 nm CW: 50 mW, Pulse: 200 mW,
Pulse width: 20 μs, Duty: ≤ 3.0%
9 μm 11.5°
VLS port 33R 650 nm CW: 5 mW 9 μm 11.5°
AQ1215E
OTDR port (PORT1) 1M or 1 1310 nm/1550 nm CW: 50 mW,
Pulse: 200 mW, Pulse width: 20 μs, Duty: ≤ 3.0%
9 μm 11.5°
OTDR port (PORT2) 1M or 1 1625 nm CW: 50 mW,
Pulse: 200 mW, Pulse width: 20 μs, Duty: ≤ 3.0%
9 μm 11.5°
VLS port 33R 650 nm CW: 5 mW 9 μm 11.5°

14 IM AQ1210-02EN
Model Class1Center
Wavelength
Maximum Output Power 2Mode Field
Diameter
Beam Divergence
Angle
AQ1215F
OTDR port (PORT1) 1M or 1 1310 nm/1550 nm CW: 50 mW,
Pulse: 200 mW, Pulse width: 20 μs, Duty: ≤ 3.0%
9 μm 11.5°
OTDR port (PORT2) 1M or 1 1650 nm CW: 50 mW,
Pulse: 200 mW, Pulse width: 20 μs, Duty: ≤ 3.0%
9 μm 11.5°
VLS port 33R 650 nm CW: 5 mW 9 μm 11.5°
AQ1216F
OTDR port (PORT1) 1M or 1 1310 nm/1550 nm CW: 50 mW,
Pulse: 200 mW, Pulse width: 20 μs, Duty: ≤ 3.0%
9 μm 11.5°
OTDR port (PORT2) 1M or 1 1650 nm CW: 50 mW,
Pulse: 200 mW, Pulse width: 20 μs, Duty: ≤ 3.0%
9 μm 11.5°
VLS port 33R 650 nm CW: 5 mW 9 μm 11.5°
1 Class 1M: IEC 60825-1:2007, GB 7247.1-2012,
Class 1: EN 60825-1:2014
2 Under single fault conditions.
3 Applicable to models with the /VLS option.
Regulations and Sales in Various Countries and Regions
Waste Electrical and Electronic Equipment
(This directive is valid only in the EU.)
This product complies with the WEEE Directive marking requirement. This marking indicates that you must not discard this
electrical/electronic product in domestic household waste.
Product Category
With reference to the equipment types in the WEEE directive, this product is classified as a “Monitoring and control instruments ”
product. When disposing of products in the EU, contact your local Yokogawa office in Europe.
Do not dispose in domestic household waste.

IM AQ1210-02EN 15
EU Battery Directive
(This directive is valid only in the EU.)
Batteries are included in this product. This marking indicates they shall be sorted out and collected as ordained in the EU battery
directive.
Battery type:
1. Lithium battery
You cannot replace batteries by yourself. When you need to replace batteries, contact your local Yokogawa office in
Europe.
2. Lithium-ion battery
When you remove batteries from this product and dispose them, discard them in accordance with domestic law
concerning disposal. Take a right action on waste batteries, because the collection system in the EU on waste batteries
are regulated. For instructions on how to remove the battery pack, see page 64.
Recycle Mark
Do not dispose together with normal garbage. To protect the environment, please dispose according to the recycling ordinances
in your area.
Authorized Representative in the EEA
Yokogawa Europe B.V. is the authorized representative of Yokogawa Meters & Instruments Corporation for this product in the EEA. To
contact Yokogawa Europe B.V., see the separate list of worldwide contacts, PIM 113-01Z2.

16 IM AQ1210-02EN
How to View the User’s Manual
The following PDF file is stored in the USERS_MANUAL folder in this instruments internal memory.
File Name Manual Title Manual No.
Features & Operation Manual_*.pdf
“*“ is used to indicate the revision number.
AQ1210A, AQ1215A, AQ1210D, AQ1210E, AQ1215E,
AQ1215F, AQ1216F OTDR Multi Feild Tester User’s
Manual
IM AQ1210-01EN
Communication Interface_*.pdf
“*“ is used to indicate the revision number.
AQ1210A, AQ1215A, AQ1210D, AQ1210E, AQ1215E,
AQ1215F, AQ1216F OTDR Multi Feild Tester
Communication Interface User’s Manual
IM AQ1210-17EN
To view the PDF file above, you need Adobe Reader 5.0 or later. Follow the procedure below to open the PDF file.
1. Turn on the instrument.
2. Connect the type C USB port on the top panel of the instrument to the type C USB port of the PC with the supplied USB cable. For a
description of the top panel, see “Component Names and Functions.” If the instrument is connected to the PC for the first time as a
mass storage device, a USB driver is automatically installed in the PC.
USB cable
PC Type C
AQ1210A, AQ1215A,
AQ1210D, AQ1210E,
AQ1215E, AQ1215F,
AQ1216F
The ends of the USB cable supplied with
the product are both Type C. If the USB
port on your PC is of a different type,
prepare your own USB cable.
Type C
3. On your PC, start Explorer or other browser. The folder in the instruments internal memory will be displayed.
4. Open the /USER/DATA/USERS_MANUAL folder. The following PDF file will be displayed.
5. Open the PDF file. The user’s manual appears on the computer screen.

IM AQ1210-02EN 17
Product Registration................................................................2
Checking the Contents of the Package...................................3
Conventions Used in This Guide.............................................6
Safety Precautions..................................................................7
Regulations and Sales in Various Countries and Regions....14
How to View the User’s Manual ............................................16
Component Names and Functions...........................19
Front Panel............................................................................19
Top Panel ..............................................................................20
Rear and Side Panels ...........................................................21
Making Preparations for Measurements................22
Handling Precautions............................................................22
Attaching the Strap................................................................23
Attaching the Battery Pack....................................................24
Connecting the USB-AC Adapter and Charging
the Instrument .......................................................................27
Connecting Optical Fiber Cables ..........................................31
Turning the Power On ...........................................................34
Screen Operations............................................................35
MENU Screen .......................................................................35
OTDR Measurement Screen.................................................36
Using the Rotary Knob and Arrow Keys................................38
Using the Touch Panel ..........................................................39
Entering Text .........................................................................40
Setting the Language and Date and Time.............41
Selecting the Language to Display........................................41
Selecting the Date and Time to Display ................................42
Setup .......................................................................................43
Setting Measurement Conditions (Measure).........................43
Setting the Analysis Conditions (Analysis)............................44
Setting Display Conditions (OTDR).......................................45
Waveform Measurement................................................46
Performing Real-time Measurement .....................................46
Performing High-Precision Waveform Monitoring
in Real-time...........................................................................47
Cutting the Waveform Display Noise ....................................47
Performing Averaged Measurements....................................48
Analyzing Waveforms and Events............................49
Measuring the Distance and Loss between Two Points........49
Measuring the Return Loss...................................................50
Measuring the Splice Loss....................................................51
Zooming In on or Out of Waveforms .....................................52
Analyzing Events...................................................................53
Creating Reports ...............................................................55
Exporting the Waveforms on the Screen to Report Files ......55
Exporting File List Data to Report Files.................................56
Contents

18 IM AQ1210-02EN
Background Information on Measurements ........58
How to View Optical Pulse Measurement Waveforms
(TRACE screen)....................................................................58
How to View the Icon Display (MAP Screen) ........................59
Terminology...........................................................................60
Analysis using the Emulation Software.................61
Maintenance and Inspection........................................62
Replacing the Optical Adapter...............................................62
Removing the Battery Pack...................................................64
Recommended Part Replacement........................................66
Disposing of the Instrument ..................................................66
Specifications .....................................................................67
Optical Pulse Measurement (OTDR) ....................................67
Power Checker (/PC option) .................................................68
Optical Power Meter (Option)................................................69
Visible Light Source (/VLS option) ........................................70
Functions...............................................................................70
General Specifications ..........................................................71
External Dimensions .............................................................72

IM AQ1210-02EN 19
Component Names and FunctionsComponent Names and Functions
Front Panel
Power switch (POWER LED)
Press to turn the instrument on and off. Illuminates in green when the instrument is running. Illuminates in red when the
battery is low. The LED illuminates in red for an instant during startup, but this does not indicate the battery level.
CHARGE LED
Illuminates in red when the battery is being
charged. It turns off when charging is complete.
AVG Key
Press to start or stop the averaged measurement of optical pulses.
REAL TIME key
Press to start or stop the real-time measurement of optical pulses.
ENTER key
Press to confirm procedures and settings.
Arrow keys
Press to change values, move between digits,
move cursors, and zoom waveforms.
MENU key
Press to select the features (OTDR, Smart
Mapper or like) used this istrument.
LCD
Used to perform touch panel operations.
LASER LED
Illuminates in red when the light is being emitted
from the light source port.
Rotary knob
Turn to select features, change settings, and
move the cursor.
ESC key
Press to return to the previous menu
or to cancel the current operation.
SETUP key
Press to display the measurement conditions,
system setup, and file operation menus.
