User’s
Manual AQ1300/AQ1301 ETHERNET
Multi Field Tester
IM AQ1300-01EN
9th Edition

i
IM AQ1300-01EN
Thank you for purchasing the AQ1300/AQ1301 ETHERNET Multi Field Tester. This user’s manual
explains the features, operating procedures, and handling precautions of the AQ1300/AQ1301. To
ensure correct use, please read this manual thoroughly before operation. Keep this manual in a safe
place for quick reference in the event that a question arises. This manual is one of five AQ1300/
AQ1301 manuals. Please read all the manuals.
List of Manuals
Manual Title Manual No. Description
AQ1300/AQ1301 ETHERNET Multi Field
Tester Operation Guide
IM AQ1300-02EN This guide focuses on the handling precautions,
basic operations, and specifications of the AQ1300/
AQ1301.
AQ1300/AQ1301 ETHERNET Multi Field
Tester User’s Manual (included in CD)
IM AQ1300-01EN This manual. It explains all the AQ1300/AQ1301
features and how to use them.
AQ1300/AQ1301 ETHERNET Multi Field
Tester Communication Interface User’s
Manual (included in CD)
IM AQ1300-17EN The manual explains the AQ1300 communication
interface features and instructions on how to use
them.
AQ1300 MFT10GbE Setup Software
User’s Manual (included in CD)
IM AQ1300-61EN This manual explains how to use a PC to create
AQ1300/AQ1301 setup files, display result files, and
generate CSV files.
AQ1300/AQ1301 Remote Control
Software User’s Manual (in CD)
IM AQ1300-63EN This manual explains how to remotely control the
AQ1300/AQ1301 from a PC.
The “-EN” in the manual number is the language code.
Notes
• This manual (IM AQ1300-01EN 7th edition) applies to AQ1300/AQ1301 ETHERNET Multi Field
Testers with firmware version R1.10.01.001 and later.
If you are using an older version, you will not be able to use all the features described in this
manual.
Check the firmware version of your product on the product information screen. For information
on how to view the product information, see section 15.4. For information on how to update the
firmware, see section 15.5.
• Thecontentsofthismanualaresubjecttochangewithoutpriornoticeasaresultofcontinuing
improvements to the instrument’s performance and functionality. The figures given in this manual
may differ from those that actually appear on your screen.
• Everyefforthasbeenmadeinthepreparationofthismanualtoensuretheaccuracyofits
contents. However, should you have any questions or find any errors, please contact your nearest
YOKOGAWA dealer.
• Copyingorreproducingalloranypartofthecontentofthismanualwithoutthepermissionof
YOKOGAWA is strictly prohibited.
Trademarks
• Microsoft,Windows,WindowsXP,andWindowsVistaareeitherregisteredtrademarksor
trademarks of Microsoft Corporation in the United States and/or other countries.
• AdobeandAcrobatareeitherregisteredtrademarksortrademarksofAdobeSystemsIncorporated.
• Inthismanual,the®andTMsymbolsdonotaccompanytheirrespectiveregisteredtrademarkor
trademark names.
• Othercompanyandproductnamesareregisteredtrademarksortrademarksoftheirrespective
holders.
9th Edition: October 2017 (YMI)
All Rights Reserved, Copyright © 2009, Yokogawa Electric Corporation
All Rights Reserved, Copyright © 2010, Yokogawa Test & Measurement Corporation

ii IM AQ1300-01EN
Revisions
1st Edition: November 2009
2nd Edition: March 2010
3rd Edition October 2010
4th Edition June 2012
5th Edition March 2013
6th Edition June 2014
7th Edition September 2015
8th Edition July 2016
9th Edition October 2017

iii
IM AQ1300-01EN
Conventions Used in This Manual
Notes
The notes and cautions in this manual are categorized using the following symbols.
Improper handling or use can lead to injury to the user or damage to the
instrument. This symbol appears on the instrument to indicate that the user must
refer to the user’s manual for special instructions. The same symbol appears in
the corresponding place in the user’s manual to identify those instructions. In the
user'smanual,thesymbolisusedinconjunctionwiththeword“WARNING”or
“CAUTION.”
WARNING Callsattentiontoactionsorconditionsthatcouldcauseseriousorfatalinjuryto
the user, and precautions that can be taken to prevent such occurrences.
CAUTION Callsattentiontoactionsorconditionsthatcouldcauselightinjurytotheuser
or cause damage to the instrument or user’s data, and precautions that can be
taken to prevent such occurrences.
French
AVERTISSEMENT Attire l’attention sur des gestes ou des conditions susceptibles
de provoquer des blessures graves (voire mortelles), et sur les
précautions de sécurité pouvant prévenir de tels accidents.
ATTENTION Attire l’attention sur des gestes ou des conditions susceptibles de
provoquer des blessures légères ou d’endommager l’instrument ou les
données de l’utilisateur, et sur les précautions de sécurité susceptibles
de prévenir de tels accidents.
Note Calls attention to information that is important for proper operation of the
instrument.
Symbols and Conventions Used in Procedural Explanations
The contents of the procedural explanations are indicated using the following symbols.
Procedure Carry out the procedure according to the step numbers. All procedures are
written under the assumption that you are starting operation at the beginning
of the procedure, so you may not need to carry out all the steps in a procedure
when you are changing the settings.
Explanation This section describes the setup items and the limitations regarding the
procedures. It may not give a detailed explanation of the feature. For a detailed
explanation of the feature, see chapter 1.
Character Notations
Hard Key Names and Soft Key Names in Bold Characters
Indicate panel keys that are used in the procedure and soft keys and menu items that appear on the screen.
Unit
k Denotes 1000. Example: 12 kg, 100 kHz

iv IM AQ1300-01EN
Contents
Conventions Used in This Manual ................................................................................................... iii
Chapter 1 Features
1.1 Interaction between the Setup Software and the AQ1300/AQ1301 ................................. 1-1
1.2 Test Menu (Top Menu)...................................................................................................... 1-2
1.3 Test Modes ....................................................................................................................... 1-4
1.4 Test Configurations........................................................................................................... 1-5
1.5 Layer 1 Control................................................................................................................. 1-8
1.6 Transmission Features ................................................................................................... 1-10
1.7 Reception Features ........................................................................................................ 1-16
1.8 Statistics ......................................................................................................................... 1-20
1.9 Emulation ....................................................................................................................... 1-31
1.10 Ping and Traceroute Testing........................................................................................... 1-36
1.11 Logging Statistics ........................................................................................................... 1-37
1.12 Simple Test Creation and Execution............................................................................... 1-38
1.13 Displaying Test Pass/Fail Results................................................................................... 1-39
1.14 File.................................................................................................................................. 1-40
1.15 Optical Power Measurement (AQ1300 Option).............................................................. 1-41
1.16 RFC2544 Measurement (AQ1300 Option)..................................................................... 1-42
1.17 VLAN Test....................................................................................................................... 1-49
1.18 Telnet Remote Control.................................................................................................... 1-50
1.19 E-OAM Test .................................................................................................................... 1-51
1.20 Y.1564 Test ..................................................................................................................... 1-54
Chapter 2 Screen Explanations
2.1 Measurement Screens (Common Items) ......................................................................... 2-1
2.2 Measurement Screens (Test-mode-specific items) .......................................................... 2-6
Chapter 3 Common Operations
3.1 Key, Rotary Knob, and Arrow Key Operations.................................................................. 3-1
3.2 Entering Strings................................................................................................................ 3-5
Chapter 4 Automatic Test Settings (Auto)
4.1 Selecting a Setup File ...................................................................................................... 4-1
4.2 Setting Up a Test .............................................................................................................. 4-4
4.3 Configuring Link and Address Settings ............................................................................ 4-5
4.4 Configuring Test Items.................................................................................................... 4-16
4.5 Configuring a Traffic Test................................................................................................ 4-17
4.6 Configuring a Loopback Test.......................................................................................... 4-21
4.7 Configuring a QoS Test .................................................................................................. 4-22
4.8 Configuring a Ping Test .................................................................................................. 4-24
4.9 Configuring a BERT........................................................................................................ 4-26
4.10 Displaying Pass/Fail Judgment Conditions .................................................................... 4-27
4.11 Configuring Options (Auto)............................................................................................. 4-28

v
IM AQ1300-01EN
3
2
1
4
5
6
7
8
9
10
11
12
13
14
15
16
App
Index
Contents
Chapter 5 Automatic (Remote Control) Test Settings (Auto(Remote))
5.1 Selecting a Setup File ...................................................................................................... 5-1
5.2 Setting Up a Test .............................................................................................................. 5-3
5.3 Configuring Link Settings ................................................................................................. 5-4
5.4 Configuring the Master Settings ....................................................................................... 5-6
5.5 Configuring the Slave Settings ....................................................................................... 5-13
5.6 Switching between the Master and Slave Settings ........................................................ 5-15
5.7 Controlling the Other Device Remotely .......................................................................... 5-16
Chapter 6 Manual Test Settings (Manual)
6.1 Selecting a Setup File ...................................................................................................... 6-1
6.2 Setting Up a Test .............................................................................................................. 6-2
6.3 Configuring Link and Address Settings ............................................................................ 6-3
6.4 Selecting a Test Mode .....................................................................................................6-11
6.5 Configuring a Traffic Test................................................................................................ 6-12
6.6 Configuring a Loopback Test.......................................................................................... 6-29
6.7 Configuring a QoS Test .................................................................................................. 6-30
6.8 Configuring a Ping Test .................................................................................................. 6-43
6.9 Configuring a BERT........................................................................................................ 6-45
6.10 Configuring the Statistics Log......................................................................................... 6-50
6.11 Configuring Options (Manual) ........................................................................................ 6-52
Chapter 7 Measuring
7.1 Starting and Stopping Measurement................................................................................ 7-1
7.2 Performing L1 Control ...................................................................................................... 7-8
7.3 Changing the Tx Rate..................................................................................................... 7-10
7.4 Inserting Errors................................................................................................................7-11
7.5 Performing a Traceroute Test ......................................................................................... 7-12
7.6 Displaying Test Results .................................................................................................. 7-14
7.7 Comparing Transmission and Reception ....................................................................... 7-15
7.8 Customizing the Display................................................................................................. 7-17
7.9 Displaying Detailed Statistics ......................................................................................... 7-19
7.10 Changing the Displayed Screen..................................................................................... 7-21
7.11 Operating the Other Device............................................................................................ 7-23
7.12 Switching between the Master and Slave Displays........................................................ 7-24
7.13 Clearing the History........................................................................................................ 7-25
7.14 Displaying the Header Information of Received Frames................................................ 7-26
Chapter 8 Configuring RFC2544 Measurement Settings (AQ1300 Option)
8.1 Selecting a Setup File ...................................................................................................... 8-1
8.2 Setting Up a Test .............................................................................................................. 8-4
8.3 Configuring Link Address Settings ................................................................................... 8-5
8.4 Configuring Common RFC2544 Test Items.....................................................................8-11
8.5 Configuring Throughput Test Settings ............................................................................ 8-15
8.6 Configuring Latency Test Settings.................................................................................. 8-17
8.7 Configuring Frame Loss Rate Test Settings................................................................... 8-19
8.8 Configuring Back to Back Test Settings.......................................................................... 8-21
8.9 Configuring Packet Jitter Test Settings........................................................................... 8-22
8.10 Configuring RFC2544 Options ....................................................................................... 8-24

vi IM AQ1300-01EN
Contents
Chapter 9 Performing RFC2544 Measurements (AQ1300 Option)
9.1 Starting Measurement ...................................................................................................... 9-1
9.2 Displaying the Test Results .............................................................................................. 9-4
9.3 Displaying Throughput Test Results ................................................................................. 9-6
9.4 Displaying Latency Test Results....................................................................................... 9-8
9.5 Displaying Frame Loss Rate Test Results...................................................................... 9-10
9.6 Displaying Back to Back Test Results ............................................................................ 9-12
9.7 Displaying Packet Jitter Test Results.............................................................................. 9-13
9.8 Changing the Displayed Screen..................................................................................... 9-15
Chapter 10 Optical Power Measurement (AQ1300 Option)
10.1 Pre-Measurement Calibration ........................................................................................ 10-1
10.2 Setting Optical Power Measurement Conditions and Holding the Display..................... 10-2
Chapter 11 VLAN Test
11.1 Selecting a Setup File .....................................................................................................11-1
11.2 Configuring the Test Settings...........................................................................................11-3
11.3 Configuring Link Address Settings ..................................................................................11-4
11.4 Configuring the Tx Settings .............................................................................................11-9
11.5 Configuring the VLAN ID Tx Settings ............................................................................11-10
11.6 Configuring the VLAN ID Rx Settings............................................................................11-14
11.7 Starting and Stopping Measurement.............................................................................11-17
11.8 Switching Screens and Saving Measured Results........................................................11-20
Chapter 12 E-OAM Test
12.1 Selecting a Setup File..................................................................................................... 12-1
12.2 Configuring the Test Settings.......................................................................................... 12-3
12.3 Setting the Test Mode..................................................................................................... 12-4
12.4 Configuring Link Address Settings ................................................................................. 12-5
12.5 Configuring the LB Test .................................................................................................12-11
12.6 Configuring the CC Test ............................................................................................... 12-12
12.7 Setting Options (E-OAM).............................................................................................. 12-16
12.8 Starting and Stopping an LB Test................................................................................. 12-17
12.9 Starting and Stopping a CC Test .................................................................................. 12-19
12.10 Executing an LT and Multicast LB ................................................................................ 12-22
Chapter 13 Y.1564 Test
13.1 Selecting a Setup File .................................................................................................... 13-1
13.2 Selecting the Configuration Type.................................................................................... 13-4
13.3 Setting Up a Test ............................................................................................................ 13-5
13.4 Configuring Link Address Settings ................................................................................. 13-7
13.5 Configuring Common Y.1564 Test Items ...................................................................... 13-14
13.6 Configuring the Detailed Settings (Service Setup) of the Y.1564 Test.......................... 13-17
13.7 Configuring Y.1564 Options.......................................................................................... 13-23
13.8 Configuring the AQ1300/AQ1301 as a Master Device ................................................. 13-26
13.9 Configuring the AQ1300/AQ1301 as a Slave Device ................................................... 13-31
13.10 Starting Measurement .................................................................................................. 13-33
13.11 Displaying the Test Results .......................................................................................... 13-36
13.12 Displaying the IR Load Test Results............................................................................. 13-37
13.13 Displaying the Burst Size Test Results......................................................................... 13-38
13.14 Displaying the Performance Test Results..................................................................... 13-39
13.15 Displaying a Table of Test Results................................................................................ 13-40

vii
IM AQ1300-01EN
3
2
1
4
5
6
7
8
9
10
11
12
13
14
15
16
App
Index
13.16 Changing the Displayed Screen................................................................................... 13-41
Chapter 14 File Operation
14.1 Connecting a USB Storage Medium to the USB Port .................................................... 14-1
14.2 Saving and Loading Data ............................................................................................... 14-2
14.3 Deleting and Copying Files ............................................................................................ 14-6
14.4 Changing File Names..................................................................................................... 14-8
14.5 Creating Directories........................................................................................................ 14-9
14.6 Deleting and Copying Directories................................................................................. 14-10
14.7 Specifying the Items That Are Displayed in the File List................................................14-11
Chapter 15 Other Operations
15.1 Configuring the Language, Beep, and USB Function .................................................... 15-1
15.2 Setting the Date and Time.............................................................................................. 15-2
15.3 Configuring Power Save Settings................................................................................... 15-3
15.4 Configuring Network Settings......................................................................................... 15-4
15.5 Resetting the AQ1300/AQ1301 to Its Factory Default Settings...................................... 15-6
15.6 Setting the Top Menu Type............................................................................................. 15-7
15.7 Using the Utility Menu .................................................................................................... 15-9
Chapter 16 Troubleshooting, Maintenance, and Inspection
16.1 If a Problem Occurs........................................................................................................ 16-1
16.2 Messages and Corrective Actions .................................................................................. 16-2
16.3 Performing a Self Test .................................................................................................... 16-4
16.4 Viewing the Product Information..................................................................................... 16-5
16.5 Updating the Firmware ................................................................................................... 16-6
16.6 Replacing the Battery Pack ............................................................................................ 16-7
16.7 Routine Maintenance ................................................................................................... 16-10
16.8 Recommended Replacement Parts ..............................................................................16-11
16.9 Calibration .................................................................................................................... 16-12
Appendix
Appendix 1 Data File Format ................................................................................................App-1
Index
Contents

1-1
IM AQ1300-01EN
Features
3
2
1
4
5
6
7
8
9
10
11
12
13
14
15
16
App
Index
1.1 Interaction between the Setup Software and
the AQ1300/AQ1301
Create a test scenario with the setup software PC application, and then save the scenario to a setup
file. Upload the saved setup file to the AQ1300/AQ1301 (AQ1300 and AQ1301), and then use the test
scenario to perform a test. The test results are saved to a result file. Use the PC to download the result
file, and then use the setup software to print a report.
You can upload and download files using the Ethernet (FTP), USB storage media, and USB memory.
Setup
file
Result
file
Report
Upload/
download
Download
Setup Software
(Windows APP)
Setting
configuration
Result display
Report output
• After loading a setup file, begin measurement simply by pressing START.
• You can also change the parameters based on the loaded settings.
AQ1300/AQ1301
AQ1300/AQ1301
PC
Create a test scenario. • Ping test • BERT • QoS test • Traffic test
(These items can be executed in order automatically.)
Save a measurement setup file. Transfer a measurement setup file. Select a measurement setup file. Select a test item.
Change the test parameters (if necessary).
Judge the measurement results. Automatically save the measurement results. End testing. Send the report of the measurement results. Create a report of the measurement results.
Operation Example (for Auto Mode)
Setup software
operations
AQ1300/AQ1301 operations
Setup software
operations
For details about the setup software, see the Setup Software User’s Manual, IM AQ1300-61EN.
Chapter 1 Features

1-2 IM AQ1300-01EN
1.2 Test Menu (Top Menu)
Auto
Select Auto to perform automatic testing on a device according to the test items in the selected setup
file. You can execute up to eight test items in order or at the same time. You can display pass/fail
results for each test and automatically save the measurement results to a file.
You can configure setup files and test items using the setup software, which runs on Windows PC.
Auto(Remote)
Select Auto(Remote) to use a master device to perform automatic testing of a remote slave device
according to the test items in the selected setup file. You can execute up to eight test items in
order or at the same time. You can display pass/fail results for each test and automatically save the
measurement results to a file.
Because the master device controls the slave device remotely, a single person can perform the tests.
The slave device can be configured remotely, and its measurements can be collected by the master
device.
You can configure setup files and test items using the setup software, which runs on Windows PC.
Manual
Select Manual to perform manual testing on a device using a single test item in the selected setup file.
You can generate traffic and perform analysis in greater detail than you can when you select Auto or
Auto(Remote).
You can configure setup files and test items using the setup software, which runs on Windows PC.
OPM (AQ1300 Option)
Select OPM to measure optical input power using the optical power meter.
RFC2544 (AQ1300 Option)
An automated test function in conformity with RFC2544, the standard benchmarking methodology for
a performance examination of Ethernet service and network systems.
• Throughput:Maximumframetransferratewithoutframeloss.
• Latency:Delaytimeofaframe
• Framelossrate:Incidencerateofframelosswithexcesstraffic.
• Back-toback:Maximumburstvaluenotcausingaframeloss.
• Packetjitter:Variationoflatency
VLAN Test
The VLAN Test is used to check the VLAN trunk configuration. You can compare the VLAN ID list that
you plan to receive with the actual received VLAN ID list. The VLAN Test consists of transmission,
reception, analysis, and result display and storage features.
E-OAM Test
Ethernet Operation, Administration and Maintenance (hereafter referred to as E-OAM) tests can be
performed in compliance with the ITU-T Y.1731 Recommendation and IEEE802.1ag Standard.
This is supported in firmware version R1.10.01.001 and later.
• CC(continuitycheck)test:Connectioncheckbetweennetworkdevices
• LB(loopback)test:Responsecheckbetweennetworkdevices
• LT(linktrace):Linkcheckbetweennetworkdevices

1-3
IM AQ1300-01EN
Features
3
2
1
4
5
6
7
8
9
10
11
12
13
14
15
16
App
Index
System
Select System to configure the AQ1300/AQ1301 system settings.
Language, Beep, USB Function, Date & Time Set, Power Save mode, Network Setup, Factory Setting,
Product Info. display, Selftest, Version Up
Y.1564 Test
An automated test function in conformity with ITU-T Y.1564, the standard benchmarking methodology
for a performance examination of Ethernet service and network systems.
• IRsteptest
Measurement of information rate (IR), frame loss (FL), frame transfer delay (FTD), frame delay
variation (FDV)
• Burstsizetest
Measurement of frame loss (FL), frame transfer delay (FTD), frame delay variation (FDV)
• Serviceperformancetest
Measurement of information rate (IR), frame loss (FL), frame transfer delay (FTD), Frame delay
variation (FDV), availability
(AVAIL)
1.2 Test Menu (Top Menu)

1-4 IM AQ1300-01EN
1.3 Test Modes
Traffic Test Mode
In this mode, you generate traffic and measure the network throughput by defining a single Tx frame
and specifying the frame length and Tx rate.
When the other device is in Loopback Test mode, you can perform latency measurement.
Loopback Test Mode
In this mode, the source and target addresses of received frames are reversed, and the frames are
sent back to their source. The AQ1300/AQ1301 takes statistics of the received frames.
Testing is performed with the other device set to Traffic Test, QoS Test, or BERT mode.
QoS Test Mode
In this mode, you can generate QoS measurement traffic and measure the network QoS performance
by defining a Tx frame with up to eight channels of QoS parameters and specifying the frame length
and Tx rate. The AQ1300/AQ1301 takes statistics of each individual QoS channel.
When the device under test is in Loopback Test mode, you can perform latency measurement on
individual QoS channels.
PING Test Mode
In this mode, you can verify layer 3 connectivity. You can ping a single host at intervals of 1 s or less (1
ms minimum).
You can also use traceroute testing to check the route to the target (the other device).
BERT Mode
In this mode, bit error rate testing is performed. The AQ1300/AQ1301 inserts a pseudo-random pattern
(PN15) into the payload of the Tx frame and checks whether or not bit errors are occurring between
itself and the other device.
The other device must be set to BERT mode or Loopback Test mode.

1-5
IM AQ1300-01EN
Features
3
2
1
4
5
6
7
8
9
10
11
12
13
14
15
16
App
Index
1.4 Test Configurations
The test configurations in which the AQ1300/AQ1301 can be used are listed below.
Two-Way Traffic Test
The AQ1300/AQ1301 and the other device measure the network throughput by sending and receiving
traffic between themselves.
Traffic
Traffic
Network
Other device
Loopback Traffic Test (Latency measurement)
The other device is set to Loopback Test mode so that the AQ1300/AQ1301 receives the traffic that it
sends, and the AQ1300/AQ1301 measures the network round-trip latency.
Traffic
Loopback
• MAC address DA/SA switching
• IP address DA/SA switching
• TCP/UDP Dst/Src port switching
Network
Other device
QoS Test
The AQ1300/AQ1301 measures the network QoS performance by sending and receiving up to eight
channels of QoS traffic.
QoS
QoS
QoS traffic
Up to 8CH when the Test menu is set to Manual
Up to 4CH when the Test menu is set to Auto
Other device
QoS CH1
CH2
CH3
Network

1-6 IM AQ1300-01EN
Ping Test
The AQ1300/AQ1301 verifies layer 3 connectivity.
PING
emulation
Reply
PING
Ping traffic generation
Interval: 1 ms to 1 s
Ping reply
emulation
Network
Other device
Traceroute Test
You can also use traceroute testing to check the route to the target (the other device).
Traceroute
ICMP
emulation
Network
Other device
BERT Test
The AQ1300/AQ1301 performs a bit error rate test.
BERT
BERT
PN pattern
PN pattern
Network
Other device
1.4 Test Configurations

1-7
IM AQ1300-01EN
Features
3
2
1
4
5
6
7
8
9
10
11
12
13
14
15
16
App
Index
Inband Remote
This is the test configuration for an Auto(Remote) test.
You can use dedicated remote commands to perform testing on the slave, change settings, and
acquire measurement results. Because the slave device can be controlled remotely, a single person
can perform this test.
Master
Slave 3
Search response
Search
Slave 1
Slave 2
The master can control the slaves remotely through the measured
connection.
• Searching for slaves: The AQ1300 can search for up to 64 slaves.
• Controlling slaves: The AQ1300 can only control one slave at a time.
Just bring the slave device, connect the cables, and turn it on.
Control through dedicated remote commands
• Testing can be performed on the slave.
1.4 Test Configurations

1-8 IM AQ1300-01EN
1.5 Layer 1 Control
Tx Clock Master/Slave Synchronization
WhenManualhasbeenselectedintheTestmenuandtheinterfaceisXFPorSFP,youcanselectthe
Tx clock source.
Tx Clock Source
Internal CLK: The internal clock is used.
Received CLK: The AQ1300/AQ1301 synchronizes with the Rx line signal.
Rx Clock Measurement
WhentheinterfaceisXFP,SFP,orRJ-45100BASE-TX,youcanmeasurethefrequencydeviationof
the Rx clock.
Link State Measurement Result Display
Linkdown “---” is displayed.
Linkup The frequency deviation of the Rx clock is displayed [ppm].
When the interface is RJ-45, the AQ1300/AQ1301 cannot measure the frequency deviation of the Rx
clock for 1000BASE-T or 10BASE-T connections. To measure the frequency deviation of the Rx clock
throughtheRJ-45interface,usea100BASE-TXconnection.
LF and RF Transmission and Detection
WhentheinterfaceisXFP,becausetheAQ1300/AQ1301supportsthenotificationofphysicallayer
failures through LFS (link fault signaling), it can transmit and detect LF (local fault) and RF (remote
fault) signals.
The AQ1300/AQ1301 can transmit LF and RF signals consecutively (start/stop).
Also, when Manual has been selected in the Test menu, the AQ1300/AQ1301 can automatically send
an RF signal upon linkdown detection or LF signal reception.
RxLF (Local Fault reception)
Detection: Four or more sequence columns that indicate LF at an interval less than 128 columns.
Sequence columns that indicate RF must not be received during this period.
Clear: When sequence columns that include LFs are not received 128 times.
RxRF (Remote Fault reception)
Detection: Four or more sequence columns that indicate RF at an interval less than 128 columns.
Sequence columns that indicate LF must not be received during this period.
Clear: When sequence columns that include RFs are not received 128 times.
Simple Optical Power Monitor
WhentheinterfaceisXFPorSFP,theAQ1300/AQ1301canmonitorthereceivedopticalpowerlevel
and indicate it using three levels.
Indication Colors Description
Black and black WhentheRJ-45interfaceisbeingusedorwhentheXFPorSFPinterfaceis
being used and the interface module is not installed
Red and black When the level of received light is too low
Green and green When the level of received light is appropriate
Red and red When the level of received light is too high

1-9
IM AQ1300-01EN
Features
3
2
1
4
5
6
7
8
9
10
11
12
13
14
15
16
App
Index
Turning the Optical Output Off and On
WhentheinterfaceisXFPorSFP,youcanturntheopticaloutput(laser)offandon.
You can force the link of the device under test down or up.
Linkdown Transmission Continuation
WhenManualhasbeenselectedintheTestmenuandtheinterfaceisXFP,youcanchooseto
continue or stop transmission during linkdown detection.
Sync Loss Detection of 66 Bits Blocks
WhentheinterfaceisXFP,the AQ1300/AQ1301 detects the condition when the signal reception
changes from a block sync (block lock) state of 66 bits blocks to a loss of sync (block lock loss) state
as defined in IEEE802.3. When a sync loss of 66 bits blocks is detected, the link is disconnected. This
feature is supported in firmware version (FW Ver.) R1.08.01.001 and later.
66B Sync Error Detection
WhentheinterfaceisXFP,the AQ1300/AQ1301 detects 66 bits blocks whose sync header (2 bits) is
except 00 or 11 when signal reception is in a sync (block lock) state as defined in IEEE802.3.
This feature is supported in firmware version (FW Ver.) R1.08.01.001 and later.
66B Sync hi-ber Detection/Clear
WhentheinterfaceisXFP,the AQ1300/AQ1301 detects and clears 66B Sync hi-ber on the basis of
the following conditions when signal reception is in a sync (block lock) state as defined in IEEE802.3.
This feature is supported in firmware version (FW Ver.) R1.08.01.001 and later.
Detection: When16ormoresyncheaders(2bits)setto00or11aredetectedina125μswindow
when signal reception is in a sync (block lock) state as defined in IEEE802.3.
Clear: When less than 16 sync headers (2 bits) that are not set to 01 or 10 are detected in a 125
µs window when signal reception is in a sync (block lock) state as defined in IEEE802.3.
Note
IEEE802.3 defines the sync (block lock) state of 66 bits blocks as follows:
Detection: When 64 consecutive sync headers (2 bits) set to 01 or 10 are received correctly.
Clear: When 16 sync headers (2 bits) that are not set to 01 or 10 are detected within 64 sync headers in a
sync (block lock) state.
Link Setting Acquisition
If the interface is SFP(GbE) or RJ-45, this feature is used to check the link settings of the DUT (the
device on the user side). You can acquire and display link setting information of the other device
connected to the AQ1300/AQ1301 or the DUT connected to the AQ1300/AQ1301 on the slave side
as well as the status of the differences in the negotiation settings. In addition, you can check the UTP
cable condition and display the results.
1.5 Layer 1 Control

1-10 IM AQ1300-01EN
1.6 Transmission Features
Transmission Load Configuration
When the test mode is Traffic Test, QoS Test, or BERT, you can set the transmission load by setting
the Tx rate and the Tx mode.
When the mode is Traffic Test or BERT, you can define a single frame. In QoS test mode, you can
define up to eight frames and assign them to the various transmission channels.
Tx Rate Settings
Traffic Format
When Manual has been selected in the Test menu, you can select a traffic format.
Constant
When the traffic format is Constant, frames are sent continuously at a constant interval. You can
change the interframe gap (IFG) by changing the Tx rate.
Frame
Preamble Data FCS
Frame Frame Frame Frame Frame Frame Frame
• • • • •
Frame IFG
Tx rate
Time
Burst
When the traffic format is Burst, frames are transmitted in bursts: frame transmission starts and
stops repeatedly at a specified interval. You can change the interframe gap (IFG) by changing the
Tx rate. You can specify the number of Tx frames in the burst interval by setting Burst Number, and
you can specify the interval of repetition by setting Interval.
Frame
Preamble Data FCS
Frame Frame Frame Idle Frame Frame
• • • • •
Frame IFG
Tx rate
Time
Number of burst frames
Interval
Interval
Idle

1-11
IM AQ1300-01EN
Features
3
2
1
4
5
6
7
8
9
10
11
12
13
14
15
16
App
Index
If the burst transmission interval determined by the value you set for Burst Number is greater than
the value you set for Interval, the AQ1300/AQ1301 will transmit frames at a constant rate without
any idle condition.
Tx Rate
When the Mode is Traffic Test or BERT
When Manual has been selected in the Test menu, you can set the Tx rate as a percentage or in
units of bits or fps. You can only set values that exceed 100% in units of bits. When Test Interface
is set to SFP(FE), you cannot set values that exceed 100%.
You can only set values as percentages when Auto or Auto(Remote) has been selected in the
Test menu.
Note
When the you set the Tx rate in bits, specify the number of bits in the IFG.
In QoS Test Mode
Regardless of the Test menu, you can only set the Tx rate as a percentage.
Tx Mode Settings
Continuous
In this mode, frames are transmitted continuously. After you start transmission, it continues until you
stop it.
Frames
In this mode, a specified number of frames is transmitted. After you start transmission, the specified
number of frames is sent, and then transmission is stopped automatically.
Tx Time
In this mode, frames are transmitted for a specified period of time. After you start transmission, it
continues for the specified period of time and is then stopped automatically.
1.6 Transmission Features

1-12 IM AQ1300-01EN
Tx Frame Definition
For the Tx frame definition, in addition to basic frame editing, you can also set the payload, variable
field setting, error addition, etc.
Frame Editing
When Manual has been selected in the Test menu, you can edit the following frames.
 • WhenthetestlayerisL2: MAC+TYPE
 • WhenthetestlayerisL3-IPv4: MAC+TYPE+IPv4
        MAC+TYPE+IPv4+UDP
 • WhenthetestlayerisL3-IPv6: MAC+TYPE+IPv6
        MAC+TYPE+IPv6+UDP
The fields and settings that you can edit are listed below.
Field Setting
MAC Destination Manual, the same as Destination Setting
Address value format **-**-**-**-**-**
Source Manual, the same as Source Setting
Address value format **-**-**-**-**-**
VLAN Flag use Used, Source Address
VLAN stacks None, 1, 2
VLAN-[1-2]TPID 0x0000-0xFFFF
VLAN-[1-2]CoS 0-7
VLAN-[1-2]CFI 0-1
VLAN-[1-2]VLANID 0-4095
IPv4 Destination address Manual, the same as Destination Setting
Address value format ***.***.***.***
Source address Manual, the same as Source Setting
Address value format ***.***.***.***
ToS/DS(DSCP) Manual, IPv4-ToS, IPv4-DSCP
Service type value 0x00-0xFF (manual), 0-7 (IPv4-ToS), 0-63 (IPv4-DSCP)
Protocol 0-255(whenFrameStructureisMAC+TYPE+IPv4)
IPv6 Destination address Manual, the same as Destination Setting
Address value format ****:****:****:****:****:****:****:****
Source address Manual, the same as Source Setting
Address value format ****:****:****:****:****:****:****:****
ToS/DS(DSCP) 0x00-0xFF (manual), 0-7 (IPv6-TrafficClass), 0-63 (IPv6-DSCP)
NextHeader 0-255(whenFrameStructureisMAC+TYPE+IPv6)
UDP Destination port
number
0 to 65535
Source port number 0 to 65535
When Auto or Auto(Remote) has been selected in the Test menu, the frame structures are fixed as
indicated below, and frames cannot be edited.
Test Layer Add UDP to Tx Frame
OFF ON
L2 MAC+TYPE —
L3-IPv4 MAC+TYPE+IPv4 MAC+TYPE+IPv4+UDP
L3-IPv6 MAC+TYPE+IPv6 MAC+TYPE+IPv6+UDP
1.6 Transmission Features
