YOKOGAWA DL6000 Series User manual

IM DLM6054-01EN
1st Edition
Digital Oscilloscope/
Mixed Signal Oscilloscope
DL6000/DLM6000 Series

Product Registration
Thank you for purchasing YOKOGAWA products.
YOKOGAWA provides registered users with a variety of information and
services.
Please allow us to serve you best by completing the product registration
form accessible from our homepage.
http://tmi.yokogawa.com/
PIM 103-03E

i
IM DLM6054-01EN
Thank you for purchasing a DL6000 Series Digital Oscilloscope or a DLM6000 Series Mixed Signal
Oscilloscope (hereinafter, the DL6054, DL6104, DL6154, DLM6054, and DLM6104 will all be referred
to as “the DL6000/DLM6000”). This user’s manual explains the features, operating procedures,
and handling precautions of the DL6000/DLM6000. To ensure correct use, please read this manual
thoroughly before beginning operation.
Keep this manual in a safe place for quick reference in the event a question arises. The following
manuals, including this one, are provided as manuals for the DL6000/DLM6000. Please read all the
manuals.
List of Manuals
The following four manuals, including this one, are provided as manuals for the DL6000/DLM6000.
Read them along with this manual.
Manual Title Manual No. Description
DL6000/DLM6000 Series Digital
Oscilloscope/Mixed Signal Oscilloscope
User’s Manual
IM DLM6054-01EN This manual. Explains all DL6000/DLM6000
series features, except for the communication
features, and how to use them.
DL6000/DLM6000 Series Digital
Oscilloscope/Mixed Signal Oscilloscope
Communication Interface User’s Manual
(included in CD)
IM DLM6054-17EN Explains the DL6000/DLM6000 series
communication interface features and how to
use them.
DL6000/DLM6000 Series Digital
Oscilloscope/Mixed Signal Oscilloscope
Serial Bus Signal Triggering and Analysis
Function User’s Manual
IM DLM6054-51EN Explains the optional I2C bus signal, CAN bus
signal, LIN bus signal, SPI bus signal, and UART
bus signal triggering and analysis features and
how to use them.
DL6000/DLM6000 Series Digital
Oscilloscope/Mixed Signal Oscilloscope
Power Supply Analysis Function User’s
Manual
IM DLM6054-61EN Explains the optional power supply analysis
features and how to use them.
Notes
• You can check the firmware version of the instrument in the overview screen. For instructions on
how to display the overview screen, see section 17.4 in this manual. For information about different
firmware versions and updates, see the following webpage.
http://tmi.yokogawa.com/
• The contents of this manual are subject to change without prior notice as a result of continuing
improvements to the instrument’s performance and functionality. The figures given in this manual
may differ from those that actually appear on your screen.
• Every effort has been made in the preparation of this manual to ensure the accuracy of its
contents. However, should you have any questions or find any errors, please contact your nearest
YOKOGAWA dealer.
• Copying or reproducing all or any part of the content of this manual without the permission of
YOKOGAWA is strictly prohibited.
1st Edition: October 2009 (YK)
All Rights Reserved, Copyright ©2009, Yokogawa Electric Corporation

ii IM DLM6054-01EN
Trademark Acknowledgements
• DLM is pending trademark of Yokogawa Electric Corporation.
• Microsoft, Internet Explorer, MS-DOS, Windows, Windows NT, Windows 2000, Windows ME, and
Windows XP are either registered trademarks or trademarks of Microsoft Corporation in the United
States and/or other countries.
• Adobe,
Acrobat, and PostScript are trademarks of Adobe Systems Incorporated.
• In this manual, the TM and ® symbols do not accompany their respective registered trademark or
trademark names.
• Other company and product names are registered trademarks or trademarks of their respective
holders.
Revisions
• 1st Edition:October 2009

iii
IM DLM6054-01EN
Checking the Package Contents
After receiving the product and opening the package, check the items described below. If the wrong
items have been delivered, if items are missing, or if there is a problem with the appearance of the
items, contact your nearest YOKOGAWA dealer.
DL6000/DLM6000
Check that the product that you received is what you ordered by referring to the model name and suffix
code given on the name plate on the rear panel.
Name Plate
MODEL Suffix Code Description
DL6054 DL6054 Digital Oscilloscope, 4 ch, 5 GS/s, 500 MHz, max 6.25 Mpoints/
CH
DL6104 DL6104 Digital Oscilloscope, 4 ch, 5 GS/s, 1 GHz, max 6.25 Mpoints/CH
DL6154 DL6154 Digital Oscilloscope, 4 ch, 10 GS/s, 1.5 GHz, max 6.25 Mpoints/
CH
DLM6054 DLM6054 Mixed Signal Digital Oscilloscope, 4 ch + 16 or 32 bits, 5 GS/s,
500 MHz, max 6.25 Mpoints/CH
DLM6104 DLM6104 Mixed Signal Digital Oscilloscope, 4 ch + 16 or 32 bits, 5 GS/s,
1 GHz, max 6.25 Mpoints/CH
Power cord -D UL/CSA Standard power cord (Part No.: A1006WD)
[Maximum rated voltage: 125 V]
-F VDE Standard Power Cord (Part No.: A1009WD)
[Maximum rated voltage: 250 V]
-Q BS Standard Power Cord (Part No.: A1054WD)
[Maximum rated voltage: 250 V]
-R AS Standard Power Cord (Part No.: A1024WD)
[Maximum rated voltage: 250 V]
-H GB Standard Power Cord (Part No.: A1064WD)
[Maximum rated voltage: 250 V]
Logic input -L161
-L321
16-bit logic input
32-bit logic input
Language
(Menu and
Pannel)
-HE
-HJ
-HC
-HK
-HG
-HF
-HL
-HS
English
Japanese + English
Chinese + English
Korean + English
German + English
French + English
Italian + English
Spanish + English
Options /B5
/P22
/P42
/C93
/C123
/G24
/G44
/F35
/F45
Built-in printer
2 probe power terminals
4 probe power terminals
Internal storage + LXI-compatible Ethernet interface (LXI option)
LXI-compatible Ethernet interface (LXI option)
User-defined computation
Power supply analysis feature (includes user-defined computation)
UART + I2C + SPI Triggering and Analysis Features
UART + CAN + LIN Triggering and Analysis Features
1 Suffix codes -L16 and -L32 are not available for the DL6054, DL6104, or DL6154.
2 /P2 is an option for the DL6054, DL6104, and DL6154, while /P4 is for the DLM6054 and DLM6104.
3 Options /C9 and /C12 cannot both be installed on the same instrument.
4 Options /G2 and /G4 cannot both be installed on the same instrument. Option /G4 includes option /G2.
5 Options /F3 and /F4 cannot both be installed on the same instrument.

iv IM DLM6054-01EN
No. (Instrument number)
When contacting the dealer from which you purchased the instrument, please tell them the
instrument number.
Accessories
The instrument is shipped with the following accessories. Make sure that all accessories are present
and undamaged.
Printer roll paper (1 roll)1
B9988AE (for the DL6000 series)
B9850NX (for the DLM6000 series)
Soft case4
B8059GG
Communication Interface
User’s Manual2
B8081RH (CD)
Front-panel protective
cover
B8081FD
500 MHz passive probes
701939 (4 probes)
1 Included with models that have the /B5 option installed.
2 You can purchase the printed IM DLM6054-17EN manual separately. Contact your
nearest YOKOGAWA dealer to purchase a copy.
3 Included with models that have the /F3, /F4, or /G4 option installed.
4 You can attach the soft case to the front-panel protective cover.
Rubber stoppers (DLM6000)
A9088ZM × 2 (4 stoppers)
Manuals
• This manual
• Serial Bus Signal Analysis Manual (1) or Power
Supply Analysis Manual (1)3
• Miscellaneous
Rubber stoppers (DL6000)
B8080FR (6 stoppers)
UL/CSA Standard
A1006WD
VDE Standard
A1009WD
BS Standard
A1054WD
AS Standard
A1024WD
DFQR
Power Cord (one of the following power cords
is supplied according to the instrument’s suffix codes)
GB Standard
A1064WD
H
Checking the Package Contents

v
IM DLM6054-01EN
How to Use the CD-ROM (User's Manuals)
The CD-ROM contains PDF file of the following manual.
• DL6000/DLM6000 Series Digital Oscilloscope/Mixed Signal Oscilloscope Communication Interface
User's Manual (IM DLM6054-17EN)
To view the above manual, you need Adobe Reader 5.0 or later.
WARNING
Never play this CD-ROM on an audio CD player. Doing so may cause loss of hearing or
speaker damage due to the large sounds that may be produced.
Optional Accessories (Sold separately)
The following optional accessories are available for purchase separately. For information about
ordering accessories, contact your nearest YOKOGAWA dealer.
Product Name Model Notes
Probes with YOKOGAWA probe interfaces
Active probes PBA1000 701912 DC to 1 GHz bandwidth, 100 kΩ, 0.9 pF
PBA2500 701913 DC to 2.5 GHz bandwidth, 100 kΩ, 0.9 pF
PBA1500 701914 DC to 1.5 GHz bandwidth, 100 kΩ, 0.9 pF
PBA1000 701912 DC to 1 GHz bandwidth, 100 kΩ, 0.9 pF
Differential probes PBD2000 701923 DC to 2 GHz bandwidth, 50 kΩ, 1.1 pF
PBDH1000 701924 DC to 1 GHz bandwidth, 1 MΩ, ±35 V max.
Current probes PBC100 701928 DC to 100 MHz bandwidth, 30 Arms
PBC050 701929 DC to 50 MHz bandwidth, 30 Arms
Passive probe PB500 701939 DC to 500 MHz bandwidth, 10 MΩ
50 Ωpassive probes
Resistance probe PBL5000 701974 DC to 5 GHz bandwidth, 500 Ωor 1 kΩ, 0.25 or 0.4 pF,
SMA-BNC conversion adapter included
DC block 701975 For 50 Ωinput, SMA, 30 MHz to 6 GHz
High-voltage passive probes
100:1 probes 701944 DC to 400 MHz bandwidth, 1000 Vrms, 1.2 m in length
701945 DC to 250 MHz bandwidth, 1000 Vrms, 3 m in length
Logic probes 701980 1 MΩ, 100 MHz toggle frequency, 8 bits
701981 10 kΩ, 250 MHz toggle frequency, 8 bits
701988 1 MΩ, 100 MHz toggle frequency, 8 bits
701989 100 kΩ, 250 MHz toggle frequency, 8 bits
FET probe 700939 900 MHz bandwidth, 2.5 MΩ, 1.8 pF
Differential probes 700924 DC to 100 MHz bandwidth, ±1400 V max
700925 DC to 15 MHz bandwidth, ±500 V max
701920 DC to 500 MHz bandwidth, ±30 V maximum (common-mode
input)
701921 DC to 100 MHz bandwidth, ±700 V maximum
701922 DC to 200 MHz bandwidth, ±60 V maximum (common-mode
input)
701926 DC to 50 MHz bandwidth, ±5000 V maximum (common-mode
input)
Current probes 701932 DC to 100 MHz bandwidth, 30 Arms
701933 DC to 50 MHz bandwidth, 30 Arms
Deskew signal source 701935 Approx. 0 to 5 V, approx. –100 to 0 mA, approx. 15 kHz
GO/NO-GO cable 366973 —
Rack mount kit 701983-01 For EIA
701983-02 For JIS
Consumables (Sold Separately)
The following consumables are available for purchase separately. For information about ordering
consumables, contact your nearest YOKOGAWA dealer.
Product Name Part No. Min. Q’ty Notes
Printer Roll Paper B9988AE 10 111 mm × 10 m heat sensitive paper for the
DL6000 series
Printer Roll Paper B9850NX 5 111 mm × 30 m heat sensitive paper for the
DLM6000 series
Checking the Package Contents

vi IM DLM6054-01EN
Safety Precautions
This instrument is an IEC safety class I instrument (provided with a terminal for protective earth
grounding).
The general safety precautions described herein must be observed during all phases of operation.
If the instrument is used in a manner not specified in this manual, the protection provided by the
instrument may be impaired. YOKOGAWA assumes no liability for the customer’s failure to comply
with these requirements.
The following symbols are used on this instrument.
Handle with care. To protect the instrument and its users, refer to the explanation
in the User’s Manual or Service Manual.
Protective earth ground or protective earth ground terminal
Ground or the functional ground terminal (do not use as the protective earth
ground terminal)
Alternating current
Direct current
Power on
Power off
Power-on state
Power-off state

vii
IM DLM6054-01EN
Failure to comply with the precautions below could lead to injury
or death.
WARNING
Power Supply
Make sure that the power supply voltage matches the instrument’s rated supply voltage and
that it does not exceed the maximum voltage range specified for the power cord.
Use the Correct Power Cord and Plug
To prevent fire and electric shock, use only a power cord supplied by YOKOGAWA. The
main power plug must be plugged into an outlet with a protective earth terminal. The earth
protection will be nullified if you use an ungrounded extension cord.
Connect to a Protective Earth Terminal
To prevent electric shock, be sure to connect to a protective earth terminal before turning on
the power. The power cord that comes with the instrument is a three-prong cord. Connect the
power cord to a properly grounded three-prong outlet.
Do Not Impair the Protective Grounding
Never cut off the internal or external protective earth wire or disconnect the wiring to the
protective earth terminal. Doing so may result in electric shock or damage to the instrument.
Do Not Operate with Defective Protective Grounding or Fuses
Do not operate the instrument if its protective grounding or one of its fuses might be defective.
Check the grounding and the fuses before operating the instrument.
Do Not Operate in an Explosive Atmosphere
Do not operate the instrument in the presence of flammable gasses or vapors. Doing so is
extremely dangerous.
Do Not Remove Covers
Only qualified YOKOGAWA personnel should remove the instrument’s covers. The inside of
the instrument is dangerous because parts of it have high voltages.
Ground the Instrument before Making External Connections
Securely connect the protective grounding before connecting to the item under measurement
or to an external control unit. Before touching a circuit, turn off its power and check that it has
no voltage.
To prevent accidents and electric shock, connect the grounds of probes and input connectors
to the earth potential (ground) of the device under measurement.
Operating Environment Limitations
CAUTION
This is a class A instrument designed for an industrial environment. Operation of this
equipment in a residential area can cause radio interference, in which case users will be
required to correct the interference.
Safety Precautions

viii IM DLM6054-01EN
Waste Electrical and Electronic Equipment
Waste Electrical and Electronic Equipment (WEEE), Directive 2002/96/EC
(This directive is only valid in the EU.)
This product complies with the WEEE Directive (2002/96/EC) marking
requirement. This marking indicates that you must not discard this electrical/
electronic product in domestic household waste.
Product Category
With reference to the equipment types in the WEEE directive Annex 1, this
product is classified as a “Monitoring and Control instrumentation” product.
Do not dispose in domestic household waste. When disposing products in the EU,
contact your local Yokogawa Europe B. V. office.
