Youin You-Go Electric scooter L User manual

Electric scooter
size L
You-Go.
Electric Scooter L
SC3000
Hop on. Fly.
Questo manuale d’istruzione è fornito da trovaprezzi.it. Scopri tutte le offerte per Youin You-Go L o
cerca il tuo prodotto tra le migliori offerte di Monopattini Elettrici

Thanks for choosing our product.
Have fun with this electric scooter.
YOUmove
YOUup
YOUdown
YOUfold
YOUtravel
YOUrule
2YOUgo / L

3
ENGLISH
1. The Device & Accessories 4
2. Functions 5
3. Assembling 6
4. Charging 7
5. Driving Instructions 7
6. Safety Instructions 9
7. Fold and Transportation 14
8. Care and Storage 15
9. Product parameters 18
10. Presence of toxic and harmful substances 19
11. Warranty 19
Contents

4
YOU-Go / L
Accessories
Instructions Fitting for
wheels swap Screws x 2 Hex Wrench Charging Adapter
1. The Device & Accessories
Vehicle

5ENGLISH
Mode Indicators
The control panel has 4 LEDs, indicating a level of charge.During consumption
of a battery, status indicators are lit, then flashes and final o one by another.
If all 4 LEDs are lit, a battery level is 100%-86%; if 3 LEDs are lit, and one is
blinking, charging level-85%-71%; so all charge level lights begin to flicker, and
then does not light.
Lowest charge level indicator may be white or green . When the vehicle is in normal
operation, LED glows white; if the scooter running in power saving mode, indicator lit
green. ( In power saving mode: the maximum speed is 18km/h, speed level is adjusted
more smoothly, that is more suitable for beginners.)
2. Functions
Speed lever
Brake lights
Clamp
Brake disc
Control panel
Headlight
Folding mechanism
Wheel motor
Brake handle
Charging port Brake compartment
Signal
Stand

6
YOU-Go / L
1. Fix the steering rod and open
the parking bridge.
Power Button
Press power button to turn on the vehicle. Press and hold a button for 2 seconds to
turn on the device. When switched on : press power button to turn on/o a flashlight ;
press a power button twice to normal mode and power saving mode.
3. Using hex wrench in the packing box to
tighten the screws on handle bar.
2. Set handle bars vertical.
4. Testing the power switch after finish
assembling.
3. Assembling the device

7ENGLISH
4. Charging scooter
5. Driving Instructions
Please wear helmet and knee pads
when practice 1 . Power on and check the battery led light
Open the cover / connect the charger / close the cover

8YOU-Go / L
2. Stand on pedal with one leg, hit the
ground with the other leg.
5. Lean your body left slightly to turn
left, lean your body right slightly to
turn right. And turn the handlebar
slowly.
3. Step on the other leg when the scooter
is moving, then press the accelerate
button (only accelerate when the scooter
speed is beyond 5km/h).
4. Loose the accelerate button when
slow down. Energy recovery systems
will open itself to slow down. Press
the left disc brake tightly if want to
brake urgently.

9ENGLISH
6. Safety Instructions
It is not recommended driving on
the rain.
Entering into any room, elevator,
etc. Be careful not be injured by a
door frame.
It is recommend to slightly bend knees to
better adjust to a rough road. If you are
travelling on a rough road, stick to low
speed (5-10km/h).
Please not add speed when
descending a hill.

10 YOU-Go / L
While walking with a scooter,
do not press a speed knob. When driving it is recommended to go around various obstacles.
Please do not hang backpacks
and other heavy objects on
handle bars.
When driving is forbidden to place
one foot on the running board or
on the ground.

11ENGLISH
6.1. Preventing dangerous driving
It is forbidden to leave a scooter
on a scooter wheel at high
roadway for motor vehicles or ride
in at a high speed.
It is forbidden to drive through
puddles, to which exceeds depth
of 2cm.
Never rider a scooter more than
or one person, hold a child in
your arms.
It is forbidden to sharply turn a
residential area with a large flow
of passers-by.

12 YOU-Go / L
Do not tread the back
of the fender. Do not touch the disc brake.
Do not driving leaving
your hands. Do not riding electric scooter up, down steps or jump over obstacles.

13
ENGLISH
1) Electric scooter - it is only a device for
entertainment, not vehicle.But once you
driving to public area, the electric scooter
brings certian risks for your safety .For
the sake of your safety and others safety,
you must strictly follow the instructions,
outlined in this driving manual .
2) You should understand that is you ride
a scooter in a public place , you must
comply with all recommendations for
safety. Also do not forget that there is
a possiblity of collision, due to violation
of pedestrians or vehicles trac rules
, there is also a risk of injury , due to
improper operation of the unit. As in
other types of vehicles, the higher a
speed of electric scooter, the greater a
braking distance. On some smooth road
emergency braking may cause skidding
of scooter, loss of balance and even
fall. Therefore, during moving of scooter
you need to be vigilant,to adhere to an
appropriate speed, keep a safe distance
from pedestrians and / or with other
vehicles. Riding on unfamiliar terrain, keep
vigilance and appropriate speed.
3) While riding scooter , respect rights of
pedestrians . Do not scare them,especially
children.Reduce speed,passing by them.
If you are moving in the same direction
with pedestrians,try to stick to the left
side as much as possible(for right-hand
trac countries ). If you are moving in the
opposite direction, stick to the right and
slow down.
4) Please strictly following your country
road rules to driving,and also strictly
abide by rules, set out in the instructions
and safety recommendations. Violation
of the above rules may result financial
expenses, personal injury, occurrence of
trac accidents, legal disputes, conflict
and other unpleasant situations. Our
company does not bear any direct or joint
and serveral liability.
5) To avoid personal injury , do not loan
electric scooter to others whom do not
know how to drive. Please spend a
training before you transfer your scooter
to friends, as well as teach he (her) must
be wear the proper safety gear .
6) Please do inspect scooter carefully
before each use.If you find shattered
parts, battery life has decreased
obviously, tires leak air or there are signs
of excessive wear, uncharacteristic
sounds when turning or other abnormal
symptoms, please discontinue use of
the scooter immediately , don’t drive it
reluctantly.
6.2. Safety Recommendations

14 YOU-Go / L
7. Fold and Transportation
You can transfer folded scooter with one hand.
Make sure scooter be o, hold the front pole , loosen a lock lever and lower a steering
rack . Adding a steering rack in a horizontal position and secure it by inserting a hook
through a special ring, which is located on the rear wheel mudguard. To Assemble the
scooter ,disconnect a steering rack lock from a hook of a mudguard, and then lift it into a
vertical position and lock a lever .
Fold
Transportation

15ENGLISH
8. Care and Storage
8.1. Clean and store
Electric Scooter
If you find any stains on electric scooter
housing, use a soft,damp cloth to wipe
the vehicle;You can use toothpaste and
a toothbrush to clean the scooter from
stains, and then wipe it clean with a damp
cloth. If you find scratched on parts ,
made of plastic, use sandpaper or other
grinding materials for their polishing .
Warning : Do not use alcohol,
petrol,kerosene or other corrosive
solutions, volatile chemical solvents to
clean the vehicle. Otherwise,it will cause
serious damage to the scooter body
and can disrupt a structure of internal
elements. Do not wash electric scooter
under a strong pressure of the water,
make sure the scooter in the o status.
In addition, after charging of the vehicle,
it is necessary to insert a plug back to a
charging connector,otherwise you may
get an electric shock or may have serious
water damage cause from water falling
into this hole ,may have serious water
damage.
If you do not use the scooter ,store it in
a dry ,cool place and do not leave the
unit for a long time on the street.Leaving
the device under the sun/in extremely
high temperature/over-low temperature
can cause rapid aging of an outer body
and wheels of Electric Scooter or reduce
battery life.
8.2. Maintenance
of Electric Scooter battery
1) Do not use batteries from other brands
in order to avoid a dangerous situation;
2) Do not open or disassemble the
battery to prevent electric shock.
Avoid contact with metal objects
to prevent an occurrence of a short
circuit. Otherwise,the battery may have
malfunction or can injure the user;
3) It is recommended to use an
AC adapter, that comes in original
configuration of the device, to prevent an
occurrence of an accident or fire of the
vehicle;
4) Improper disposal of used batteries
and accumulators is the cause of severe
environmental pollution. Please,dispose
of batteries in accordance with local
laws. Please do not dispose of batteries
together with food waste. Protecting the
environment together!
5) After each use of the device, charge
the battery to prolong its service life.
Do not store the scooter battery in rooms
with temperatures,that exceed 50ºC or
-20ºC (for example, do not leave the
battery of Electric Scooter and other
batteries in cars in summer time on the hot
sun), do not leave the battery near fire. As
a result of these actions may deteriorate
the battery, overheating and can even
cause inflammation.
If within 30 days the scooter is not used,

16
YOU-Go / L
charge the battery and keep the device in
a cool,dry place. Every 60 days you need
to charge the battery otherwise there is
the likelihood of its failure, which is not
subject to warranty services.
Avoid a full discharge of the device,it
will to extend battery life. When using
the device at normal room temperature,
the battery will be able to ride much
greater distance and its performance
will be better; but if you use the scooter
at temperatures below 0ºC, vehicle
performance and permeability decrease.
At -20ºC a traveled distance is less,than
the scooter in the normal conditions of
half or even less.If a temperature rises,
a traveled distance by the vehicle will
also increase. You can check remaining
distance in the Application.
Note: A fully charge scooter runs about
120-180 days of standby time. The battery
has a smart chip,that stores information
about its charging-discharging. If you are
not charging the battery for a long time,
it can cause serious damage, for which it
is impossible to charge the device again.
This kind of damage is not included in
free warranty service. Caution: Do not
disassemble the device by unauthorized
people, as there is a risk of electric shock
or serious injury as result of a short circuit.

17
ENGLISH
8.3. Adjusting a brake disc
If a brake is very tight:using M5 hex wrench and scroll counterclockwise screws of
brake disc tensioner pulley,slightly shorten a length of a tail brake cable,then tighten a
tensioner pulley.If you think that brake is very free,loosen a tension pulley,pull a brake
cable to slightly increase a length of its tail.Tighten a tension pulley.
8.4. Adjusting a handle bars
Staggering of steering rack: using a M5 hex wrench, tighten two screws near the folding
mechanism.
8.5. Using a connecting pipe to pump wheels
If a rear wheel of Electric Scooter deflated,connect a connecting pipe to a wheel nipple
to pump it .First,remove the a cap of pin,then tighten a fitting,and then you start to pump
a wheel.

18
YOU-Go / L
9. Product parameters
Operating parameters Name SC3000
Dimensions Length x Width x Height 106 x 42 x 48 cm
Folded: Length x Width x Height 106 x 42 x 48 cm
Weight Gross weight 12.5 kg
Conditions Max load 100 kg
Age 16-50
Height (cm) 120-200
Main Parameters Max speed (km/h) 25
Possibility in average
condition [2] (km) Up to 30
Maximum slope (%) 14
Suitable area Solid road surface,smooth clay surface to
overtime, obstacles high less than 1cm, a
depth of pools no more than 2cm
Operating temperature range (ºC) -10-40
Temperature of storage (ºC) -20-45
Waterproof level IP54
Battery Parameters Rated voltages (VDC) 36v
Max voltage charging (VDC) 42v
Rated power (Wh) 280
Smart battery management system Stress, insucient voltage, short circuit,
auto sleep/wake up, overheating
protection, control of battery using
Motor Parameters Rated power (W) / Max power (W) 350 / 500
Power adaptor
parameters Rated power (W) 71
Rated input voltage (VAC) 100-240V
Rated output voltage (VDC) 42V
Rated current (A) 1.5
Certificate CE, EMC, RoHS
Charging time (h) Est. 5h

19
ENGLISH
10. Presence of toxic
and harmful substances
Name Toxic and harmful substances elements
Pb Hg Cd Cr6+ PBB PBDE
Power adaptor X00000
Battery X 0 0 0 0 0
Connecti
ng pipe X00000
Charging
port X00000
Indicators X 0 0 X X X
Circuit
board X 0 0 X X X
Motor X 0 0 X 0 0
Housing X00000
Date provided in accordance with provisions of SJ/T 11364.
O: toxic and harmful substances in all components of the device are contained in an amount below the limit
value, according to standard GB/T 26572-2011.
X: presence of toxic and hazardous substances at least one of components of the device in an amount,that
exceeds the threshold, according to GB/T 26572-2011
11. Warranty
Carefully read all instructions before using the electric kick scooter.
This product is warranted according to the local laws.
The warranty shall not apply to any products that have been subjected to misuse,
negligence, accidental or abnormal conditions of operation, and does not covers the
natural capacity fade out.
Please refer to qualified and authorized people for the repair of the electric kick scooter.
A non-professional repair may cause malfunction and risks and void your warranty rights.

20
YOU-Go / L
Gracias por elegir nuestro producto.
Diviértete con este patinete eléctrico.
YOUmove
YOUup
YOUdown
YOUfold
YOUtravel
YOUrule
20 YOUgo / L
