Z3 Technology FSDI-DCK-10 User manual

Users Guide
Model Name: FSDI-DCK-10
DOC-USR-0313 -01
Before attempting to connect or operate this product, please read these instructions carefully and save this manual for future use.
Copyright © 2017 Z3 Technology, LLC. All rights reserved.
Z3 Technology and ZEUS are registered trademarks of Z3 Technology, LLC.
This document contains proprietary information of Z3 Technology, LLC ("Z3"). This document may not be used, reproduced, disclosed, or
disseminated to anyone without the prior written approval of an authorized representative of Z3. Z3 reserves the right to change this product at
any time and without notice. All product names, trademarks, trade names, service marks, or service names mentioned in this document are the
property of their respective owners.

FSDI-DCK-10 User Instructions
DOC-USR-0313-01
______________________________________________________________________________________
Z3 Technology, LLC ♦ 100 N 8th ST, STE 250 ♦ Lincoln, NE 68508-1369 USA ♦ +1.402.323.0702
2
REVISION HISTORY
Version
Date
Change Note
Author
01
10/25/2017
Original Document for FSDI-DCK-10
SI

FSDI-DCK-10 User Instructions
DOC-USR-0313-01
______________________________________________________________________________________
Z3 Technology, LLC ♦ 100 N 8th ST, STE 250 ♦ Lincoln, NE 68508-1369 USA ♦ +1.402.323.0702
3
TABLE OF CONTENTS
1.0 GENERAL DESCRIPTION.................................................................................................7
2.0 FEATURES ................................................................................................................8
2.1 Supported Resolutions ............................................................................................... 8
3.0 PACKAGE OPTIONS ......................................................................................................9
4.0 OPERATING CONTROLS ............................................................................................... 10
5.0 GETTING STARTED WITH THE FSDI-DCK-10 ........................................................................ 11
5.1 Access the User Interface Using ZFinder .........................................................................14
6.0 STREAMING CONTROL ................................................................................................ 16
6.1 Stream UDP...........................................................................................................16
6.2 Stream RTP ...........................................................................................................19
6.3 Stream RTSP ..........................................................................................................21
6.4 Stream RTMP .........................................................................................................23
6.5 Tuning for Latency...................................................................................................31
6.6 Stream Multiple Resolutions........................................................................................33
6.7 Record to USB ........................................................................................................34
6.8 Microphone Input ....................................................................................................36
6.9 Composite Pass-Through ............................................................................................37
7.0 CAMERA CONTROL .................................................................................................... 38
7.1 Zoom...................................................................................................................38
7.2 Preview Image........................................................................................................38
7.3 Color Controls ........................................................................................................39
7.4 Sony VISCA Camera Control ........................................................................................39
7.5 ONVIF Profile S......................................................................................................42
8.0 PERFORMING OTHER OPERATIONS WITH THE FSDI-DCK-10...................................................... 43
8.1 Save Current Settings ...............................................................................................43
8.2 Advanced Settings Mode ............................................................................................44
8.3 Set a Static IP Address ..............................................................................................46
8.4 Upgrade Firmware...................................................................................................48
8.5 Setting a Password...................................................................................................49
8.6 Factory Reset .........................................................................................................50
9.0 DECODE OPTIONS ..................................................................................................... 50
9.1 PC Configuration for HD HEVC/H.265 Decode ...................................................................50
9.2 ZEUS SME-01 Decode...............................................................................................53
10.0 SUMMARY OF OPTIONS .............................................................................................. 54
10.1 The System Setup Tab .............................................................................................54

FSDI-DCK-10 User Instructions
DOC-USR-0313-01
______________________________________________________________________________________
Z3 Technology, LLC ♦ 100 N 8th ST, STE 250 ♦ Lincoln, NE 68508-1369 USA ♦ +1.402.323.0702
4
10.2 The User Presets Tab...............................................................................................56
10.3 The Status Tab ......................................................................................................56
10.4 The Camera Tab ....................................................................................................58
10.5 The Term Tab........................................................................................................60
10.6 The CH1 Tab (Channel 1) ..........................................................................................60
10.7 The CH2 & CH3 Tabs (Channels 2 & 3)..........................................................................65
10.8 Values Appearing at the Bottom of All Tabs ....................................................................66
10.9 ZFinder...............................................................................................................66
APPENDIX A: Finding the IP Address of Your Computer.............................................................. 67
APPENDIX B: Configuring the Wowza Server for RTMP .............................................................. 68
APPENDIX C: Example Camera Controller Application .............................................................. 70
APPENDIX D: Troubleshooting ........................................................................................... 74

FSDI-DCK-10 User Instructions
DOC-USR-0313-01
______________________________________________________________________________________
Z3 Technology, LLC ♦ 100 N 8th ST, STE 250 ♦ Lincoln, NE 68508-1369 USA ♦ +1.402.323.0702
5
LIST OF FIGURES
Figure 1: FV2K -DCK-10 Board Stack Dimensions ........................................................................ 7
Figure 2 FSDI-DCK-10 Package Options ................................................................................... 9
Figure 3 Z3Cam-HD Interfaces............................................................................................10
Figure 4 Camera Compatibility Warning .................................................................................11
Figure 5 FSDI-DCK-10 Physical Block Diagram (Cameras Not Included) .............................................11
Figure 6 Interface Front End PCB .........................................................................................12
Figure 7 FSDI-DCK-10 Connected to FCB-EV7520 (Camera Not Included) ..........................................13
Figure 8 KEL and Flex I/O Connections completed .....................................................................13
Figure 9 ZFinder with the FSDI-DCK-10 Selected ......................................................................14
Figure 10 Z3Cam-HD User Interface – System Setup Tab..............................................................15
Figure 11 CH1 Tab Configuration – UDP..................................................................................17
Figure 12 VLC Open Network Stream Screen for UDP .................................................................18
Figure 13 Example of Video Streaming to VLC (UDP)..................................................................18
Figure 14 CH1 Tab Configuration – RTP ..................................................................................19
Figure 15 Example of Encoded Video Streaming to VLC (RTP) .......................................................20
Figure 16 CH1 Tab Configuration – RTSP.................................................................................21
Figure 17 Finding your Camera’s IP Address ............................................................................22
Figure 18 VLC Open Network Stream Screen for RTP .................................................................22
Figure 19 Example of Z3 Video Streaming to VLC (RTSP) .............................................................23
Figure 20 CH1 Tab Configuration – RTMP Streaming to Wowza Streaming Engine™ ...............................24
Figure 21 Navigating to the Wowza Test Player ........................................................................25
Figure 22 Viewing Streamed Content on Wowza Test Player .........................................................26
Figure 23 YouTube Live Dashboard – Encoder Setup ...................................................................27
Figure 24 CH1 Tab Configuration – RTMP Streaming to YouTube Live ...............................................28
Figure 25 Facebook “Create Post” dialog box...........................................................................29
Figure 26 Facebook Live Streaming Dialog ..............................................................................29
Figure 27 Facebook Live Stream Encoder Settings .....................................................................30
Figure 28 Enable TS Lowlat Mode ........................................................................................31
Figure 29 VLC Media Player Tools Menu ..................................................................................32
Figure 30 VLC Media Player Advanced Preferences.....................................................................32
Figure 31 Recommended Settings ........................................................................................33
Figure 32 Create Additional Output Channels ..........................................................................33
Figure 33 USB Connection .................................................................................................34
Figure 25 CH1 Tab Configuration – TSFILE..............................................................................35

FSDI-DCK-10 User Instructions
DOC-USR-0313-01
______________________________________________________________________________________
Z3 Technology, LLC ♦ 100 N 8th ST, STE 250 ♦ Lincoln, NE 68508-1369 USA ♦ +1.402.323.0702
6
Figure 35 Microphone Connection........................................................................................36
Figure 36 CH1 Tab Configuration – Microphone Audio Settings.......................................................36
Figure 37 Composite Connection .........................................................................................37
Figure 38 Set Composite Pass-Through Resolution.....................................................................37
Figure 39 Camera Zoom Slider............................................................................................38
Figure 40 Camera Tab Preview Image ...................................................................................38
Figure 41 Color Controls...................................................................................................39
Figure 42 Com2TCP Configuration .......................................................................................40
Figure 43 Camera Controller Software Configuration .................................................................41
Figure 44 The User Presets Tab ...........................................................................................43
Figure 45 Entering a User Preset Name .................................................................................43
Figure 46 Saving a User Preset............................................................................................43
Figure 47 Accessing Advanced Settings ..................................................................................45
Figure 48 Default UDP Settings (Left) and Advanced UDP Settings (Right).........................................45
Figure 49 Saving Updated Network Settings ............................................................................47
Figure 50 Updating Device Firmware ....................................................................................48
Figure 51 Software Updater Screen......................................................................................48
Figure 52 Creating or Changing the Password ..........................................................................49
Figure 53 Password Entry Screen.........................................................................................49
Figure 54 Pinhole Reset.....................................................................................................50
Figure 55 LAV Filters Configuration ......................................................................................51
Figure 56 Disable Hardware Decoding in VLC ..........................................................................52
Figure 57 ZEUS SME-01 H.264 Decoder ..................................................................................53
Figure 58 ZEUS HE265-DEC Decoder .....................................................................................53
Figure 59 Using the Command Prompt to Determine Your PC’s IP Address.........................................67
Figure 60 Locating Your Computer’s IP Address ........................................................................67
Figure 61 Wowza Performance Settings .................................................................................68
Figure 62 Wowza Security Settings.......................................................................................69
Figure 63 Running the Example Application ............................................................................70

FSDI-DCK-10 User Instructions
DOC-USR-0313-01
______________________________________________________________________________________
Z3 Technology, LLC ♦ 100 N 8th ST, STE 250 ♦ Lincoln, NE 68508-1369 USA ♦ +1.402.323.0702
7
1.0 GENERAL DESCRIPTION
The FSDI-DCK-10 is a H.265/H.264 video encoder designed to be a video encoder for SDI cameras, Sony FCB-
EV7520 block cameras, and thermal/IR cameras. It is capable of accepting HD video from the camera at 60
frames per second and producing IP streams that can be sent on a standard Ethernet cable. The FV2K-DCK10
has one KEL connector for Sony EV7520 cameras or compatible, one 3G-SDI input with loop, one analog
composite input accepting PAL or NTSC, a digital multi-format input which can accept video from LVDS or
Cameralink (CMOS as customized option) sources inputs and is capable to simultaneously encode and stream
video from two separate sources.
Figure 1: FSDI -DCK-10 Board Stack Dimensions
58 mm
58 mm

FSDI-DCK-10 User Instructions
DOC-USR-0313-01
______________________________________________________________________________________
Z3 Technology, LLC ♦ 100 N 8th ST, STE 250 ♦ Lincoln, NE 68508-1369 USA ♦ +1.402.323.0702
8
2.0 FEATURES
▪HEVC/H.265 encode and stream up to 1080p at 60 fps
▪H.264 encode and stream up to 1080p at 60 fps
▪Encode modes of operation: HEVC/H.265, H.264 and MJPEG
▪Low bandwidth, low latency video encoding
▪Simultaneously output two different resolutions from a single video source
▪Remote camera control via HTTP-based interface or pass VISCA camera control commands over IP
▪Inputs: powered line audio
▪Outputs: composite
▪Additional Interfaces include Gigabit Ethernet, USB 2.0, Micro SD Card and RS-232 Serial
▪RS485, alarm input and output interfaces available internally
▪Supports streaming in MPEG-2 TS (UDP), RTP, RTSP, RTMP* and TSRTP
▪Supports unicast and multicast streaming
▪Compatible with CDN’s including Wowza Streaming Engine™ *, YouTube Live* and Facebook Live*
▪Record a compressed .ts file to a USB storage device
▪Easily mounts to tripods or mounting brackets (1/4 20 UNC screw hole on bottom of unit)
▪ONVIFprofile S compliant
▪Compatible with the ZEUSZ3-SME-01 H.264 decoder* and Z3-HE265-DEC H.265 decoder (also
available from Z3 Technology)
▪HTTP-based configuration software for user-friendly configuration, control and update
▪RS-232 serial port for technical configuration and control
▪Supports Power over Ethernet (PoE) when present
▪Operating Temp: -5 to 70 degrees C at 20-80% relative humidity (non-condensing) with proper
thermal solution
▪Storage Temp: -10 to 75 degrees C at 20-80% relative humidity (non-condensing)
▪Measurements: 58 x 58 mm
▪Weight: 87.9g
2.1 Supported Resolutions
Follow input (1080p60, 1080p59.94, 1080p50)
Resize down to 1080p, 720p and 480p
The FSDI-DCK-10 supports simultaneous output of up to three streams encoded at different resolutions,

FSDI-DCK-10 User Instructions
DOC-USR-0313-01
______________________________________________________________________________________
Z3 Technology, LLC ♦ 100 N 8th ST, STE 250 ♦ Lincoln, NE 68508-1369 USA ♦ +1.402.323.0702
9
frame rates and bitrates. Supported stream resolutions are:
1080p (2MP), 1280x1024, 720p (1MP), 480p, 576p, 1024x576, 704x576, 640x480, 640x360, 420x380,
352x576, 352x288, 352x240, 320x240, and 320x180
In addition to scaling the resolution, the camera is also capable of scaling down the frame rate to save
bandwidth. Each channel can select from full frame rate, half frame rate, quarter or sixth frame rate.
For example, it is possible to configure a primary stream of 1920x1080 at 60 fps simultaneously with a
secondary stream at 480p at 10 fps.
The maximum performance for two channels is two 1080p60 streams.
3.0 PACKAGE OPTIONS
Figure 2 FSDI-DCK-10 Package Options
*NOTE: additional cables may be required to connect your secondary camera. Contact Sales for more
information about available cables and compatible cameras.
FSDI PCB Assembly
MCX to Flex I/O Connector
KEL Ribbon Cable
12V 2.5Amp AC Adapter
Serial Cable
Gender Changer
MMCX to BNC Conncector

FSDI-DCK-10 User Instructions
DOC-USR-0313-01
______________________________________________________________________________________
Z3 Technology, LLC ♦ 100 N 8th ST, STE 250 ♦ Lincoln, NE 68508-1369 USA ♦ +1.402.323.0702
10
4.0 OPERATING CONTROLS
1: RS-232 Serial Port
1
5: Status Light
2
2: USB 2.0 6: Composite Output
3: Microphone Input 7: 12V Power (optional)
4: GigE (PoE)
1
For advanced debugging purposes only. Not needed by typical users.
2
LED light will blink green when streaming.
Figure 3 Z3Cam-HD Interfaces

FSDI-DCK-10 User Instructions
DOC-USR-0313-01
______________________________________________________________________________________
Z3 Technology, LLC ♦ 100 N 8th ST, STE 250 ♦ Lincoln, NE 68508-1369 USA ♦ +1.402.323.0702
11
5.0 GETTING STARTED WITH THE FSDI-DCK-10
WARNING: Use ONLY FCB-EV7520 or compatible camera with the FSDI-DCK-10. Using an incompatible
camera may permanently damage the camera and the FSDI-DCK-10.
Figure 4 Camera Compatibility Warning
Figure 5 FSDI-DCK-10 Physical Block Diagram (Cameras Not Included)
(1) Once received, the FSDI-DCK-10 assembly will need to be connected to a SDI camera ( or the Sony
FCB-EV7520 HD camera block) and the secondary camera with Composite Out. The Interface Front
End PCB of the FSDI-DCK-10 assembly (see Figure 7) has SDI input or 30-pin KEL connectors that
allow a flexible ribbon cable to be used to connect the encoder assembly to an identical connector
on the Sony FCB-EV7250. The Composite Out secondary camera is connected to the FSDI-DCK-10
assembly via the MMCX or Flex I/O Connector (see Figure 6 8). The KEL cable (ordering part number:
SDI Camera
BNC
MMCX
MMCX
BNC

FSDI-DCK-10 User Instructions
DOC-USR-0313-01
______________________________________________________________________________________
Z3 Technology, LLC ♦ 100 N 8th ST, STE 250 ♦ Lincoln, NE 68508-1369 USA ♦ +1.402.323.0702
12
CBL-0028-01), MCX to Flex I/O cable (number CBL-0027-01), MMCX to MCX (CBL-0035-01) and MMCX
to BNC (CBL-0033-01) are sold separately
Figure 6 Interface Front End PCB
WARNING: ONLY USE THE CORRECT KEL RIBBON CABLE PROVIDED BY Z3 TECHNOLOGY.
Using an incorrect cable can permanently damage the camera body.
Flex I/O Connector
Primary KEL
Connector
SDI Input
Composite Video
Input
SDI Loop Input

FSDI-DCK-10 User Instructions
DOC-USR-0313-01
______________________________________________________________________________________
Z3 Technology, LLC ♦ 100 N 8th ST, STE 250 ♦ Lincoln, NE 68508-1369 USA ♦ +1.402.323.0702
13
(2) Next locate the Flex I/O connector on the Front End PCB Use the Flex I/O to MCX cable provided by
Z3 technology.
Figure 8 MMCX and Flex I/O Connections completed
NOTE: Other Cameras may require RCA or BNC connectors for composite output. Contact the camera
manufacturer if there is uncertainty and sales to purchase the correct cable. Connect camera to power if
required.
Figure 7 FSDI-DCK-10 Connected to FCB-EV7520 (Camera Not Included)
KEL Ribbon Cable
(Sold Separately)
Sony FCB EV7520
(Not Included)
KEL Ribbon
Cable
(Sold Separately)
Flex I/O to MCX Cable
MMCX to BNC Cable

FSDI-DCK-10 User Instructions
DOC-USR-0313-01
______________________________________________________________________________________
Z3 Technology, LLC ♦ 100 N 8th ST, STE 250 ♦ Lincoln, NE 68508-1369 USA ♦ +1.402.323.0702
14
(3) Connect an Ethernet cable from Ethernet on the back of the camera to a switch, router or other
DHCP server on the same network as your Windows PC.
(4) Connect the 12V power supply to +12V on the camera and plug into a power outlet.
If Power over Ethernet (PoE) is available, then no connection to the power supply is required.
It will take 15-30 seconds to boot.
5.1 Access the User Interface Using ZFinder
ZFinder is a PC utility that allows you to find any Z3 Technology product on your network. If you have
not yet downloaded this to your computer, you can find this program at Z3Stream.com/downloads .
(5) Verify your PC is set to DHCP. If it is set to a static IP address, ZFinder may be unable to discover
your camera.
Note: The FSDI-DCK-10 is set to DHCP by default. If no DHCP server is available on the network, a static IP address
of 192.168.0.120 and a netmask of 255.255.0.0 will be assigned. The IP address can be manually entered
as the URL in a browser window to access the user interface.
(6) Run the ZFinder PC utility on your PC. You may need to allow it past any firewalls or security
programs on your PC. The ZFinder window appears and completes a scan of the network. ZFinder
then lists all Z3 systems connected to the network. The FSDI-DCK-10 appears.
(7) Click on the FSDI-DCK-10 entry in the window to select it. This will cause the Edit Device, Open
Device and Flash LEDs buttons to activate.
Figure 9 ZFinder with the FSDI-DCK-10 Selected
Note: Selecting Edit Device allows for manual changes to network settings. See Section 10.9, ZFinder, for more
information.
Note: If the device appears in red, there is a network error, and network settings will need to be modified in
order to access the user interface.

FSDI-DCK-10 User Instructions
DOC-USR-0313-01
______________________________________________________________________________________
Z3 Technology, LLC ♦ 100 N 8th ST, STE 250 ♦ Lincoln, NE 68508-1369 USA ♦ +1.402.323.0702
15
(8) Click on Open Device. An internet browser window is opened in your default web browser (for best
results, Firefox or Chrome are recommended) and the user interface appears with the System Setup
tab open.
(9) By default, the system will have automatically started encoding. Click on the CH1 tab for channel
one configuration settings. If the encoder status message in the bottom right corner of the screen
shows RUNNING, you will need to click the stop or Stop All button in order to change any settings.
Figure 10 Z3Cam-HD User Interface – System Setup Tab

FSDI-DCK-10 User Instructions
DOC-USR-0313-01
______________________________________________________________________________________
Z3 Technology, LLC ♦ 100 N 8th ST, STE 250 ♦ Lincoln, NE 68508-1369 USA ♦ +1.402.323.0702
16
6.0 STREAMING CONTROL
This section gives step-by-step instructions on setting the FSDI-DCK-10 to output and stream video using
each of the output format options: UDP, RTP, RTSP and RTMP. In addition to the FSDI-DCK-10, a Windows PC
with the VLC media player
3
downloaded is required. Please see Section 8.4, Decoder Options, for more
information on compatible decoders and PC configuration and requirements for H.265/HEVC decode at HD
resolutions.
6.1 Stream UDP
6.1.1 UDP Camera Setup
Note: Settings in the user interface cannot be changed if the unit is currently encoding.
(1) If necessary, click on the Stop button in the Channel Controls section of the user interface CH1 tab
or the Stop All button in the lower right corner of the screen of any tab.
(2) Verify the Output Resolution is set to Follow Input to output a HD stream. If a lower resolution
output is desired, select this in the dropdown menu and resizing will occur.
(3) Select the Video Codec you would like to use for your video encoding. In the pictured example
H265(HEVC) is selected.
(4) Under Output Setup, select UDP in the Output Format dropdown menu.
(5) Set Dest Address to:
a. the IP address of your PC that will be running the VLC media player. To determine the correct
IP address of your PC, see APPENDIX A: Finding the IP Address of Your Computer. In the
example pictured, 192.168.0.6 is used.
b. or a multicast address. An example multicast address would be 225.1.2.3. If you are on a
shared network, check with your Network Administrator.
(6) Make note of the value listed for Dest Port. This will be 8600 by default when your system is first
received.
Note: By default a limited selection of video encoding settings are available in the user interface. See Section
8.2, “Advanced Settings Mode”, for more information on accessing additional settings.
3
VLC is an open source media player from the VideoLAN organization that can be downloaded for free online.

FSDI-DCK-10 User Instructions
DOC-USR-0313-01
______________________________________________________________________________________
Z3 Technology, LLC ♦ 100 N 8th ST, STE 250 ♦ Lincoln, NE 68508-1369 USA ♦ +1.402.323.0702
17
(7) Click on the Start button. After a moment, the encoder status will change to RUNNING and the fields
above will appear in dark grey. The status LED on the unit will blink green when streaming.
6.1.2 Run VLC to View UDP Stream
Note: Verify your PC is set up to handle decode of H.265 content at HD resolutions. See Section 9.1, “PC
Configuration for HD HEVC/H.265 Decode”, for more information.
(8) Open the VLC media player on your PC.
(9) Select the Media menu.
(10) Select Open Network Stream.
(11) Under the Network tab, enter “udp://@Dest_Address:Dest_Port” for the network URL.
c. Dest_Address will be values of the IP address or multicast address entered in the Dest
Address field in the user interface CH1 tab. The IP address used in this example is
192.168.0.6.
Figure 11 CH1 Tab Configuration – UDP
(4) Change
to “UDP”
(1) If necessary, click “Stop”
(7) Click “Start”
(2) Verify is
“Follow input”
(3) Verify is
“H265(HEVC)”
(5) Set to PC
IP Address or
Multicast Address
(6) Note value

FSDI-DCK-10 User Instructions
DOC-USR-0313-01
______________________________________________________________________________________
Z3 Technology, LLC ♦ 100 N 8th ST, STE 250 ♦ Lincoln, NE 68508-1369 USA ♦ +1.402.323.0702
18
d. Dest_Port will match the value found in the Dest Port field in the Encoder tab. The default
value is 8600.
e. In this example, the full network URL would be “udp://@192.168.0.6:8600”.
(12) Press Enter or click Play.You will see your camera’s video streaming to VLC.
Figure 13 Example of Video Streaming to VLC (UDP)
Figure 12 VLC Open Network Stream Screen for UDP

FSDI-DCK-10 User Instructions
DOC-USR-0313-01
______________________________________________________________________________________
Z3 Technology, LLC ♦ 100 N 8th ST, STE 250 ♦ Lincoln, NE 68508-1369 USA ♦ +1.402.323.0702
19
6.2 Stream RTP
6.2.1 RTP Camera Setup
Note: Settings in the user interface cannot be changed if the unit is currently encoding.
(1) Return to the user interface, and if necessary, click on the Stop button in the Channel Controls
section of the user interface CH1 tab or the Stop All button in the lower right corner of the screen of
any tab.
(2) Verify Output Resolution is set to Follow Input to output a HD stream. If a lower resolution output is
desired, select this in the dropdown menu and resizing will occur.
(3) Select the codec you would like to use for your video encoding. In the pictured example,
H265(HEVC) is selected.
(4) Under Output Setup, select RTP in the Output Format dropdown menu.
Note: By default a limited selection of video encoding settings are available in the user interface. See Section
8.2, “Advanced Settings Mode”, for more information on accessing additional settings.
(5) Click on the Start button. After a moment, the encoder status will change to RUNNING and the fields
above will appear in dark grey. The status LED on the unit will blink green when streaming.
Figure 14 CH1 Tab Configuration – RTP
(4) Change
to “RTP”
(1) If necessary, click “Stop”
(5) Click “Start”
(3) Note value
(2) Verify is
“Follow Input”

FSDI-DCK-10 User Instructions
DOC-USR-0313-01
______________________________________________________________________________________
Z3 Technology, LLC ♦ 100 N 8th ST, STE 250 ♦ Lincoln, NE 68508-1369 USA ♦ +1.402.323.0702
20
6.2.2 Run VLC to View RTP Stream
An SDP file is needed to view an RTP stream from the FSDI-DCK-10 in the VLC media player. If you have
not yet downloaded these files to your computer, you can find them at Z3Cam-4k.Z3technology.com.
Note: Verify your PC is set up to handle decode of H.265 content at HD resolutions. See Section 9.1, “PC
Configuration for HD HEVC/H.265 Decode”, for more information.
(6) Open the VLC media player on your PC.
(7) Select the Media menu.
(8) Select Open File.
(9) Find and select the SDP file corresponding to the video codec you selected previously.
a. H265(HEVC) video: use the SDP file entitled “z3-h265-he4k-dck.sdp”
b. H264(AVC) video: use the SDP file entitled “z3-h264-he4k-dck.sdp”
(10) Press Enter or click Open. You will see your camera’s video streaming to VLC.
Figure 15 Example of Encoded Video Streaming to VLC (RTP)
