Z3 Technology Z3-HE265-DEC User manual

User Instructions
Z3-HE265-DEC
DOC-USR-0137-01
Before attempting to connect or operate this product, please read these instructions carefully and save this manual for future use.
Copyright © 2017 Z3 Technology, LLC. All rights reserved.
Z3 Technology and ZEUS are registered trademarks of Z3 Technology, LLC.
This document contains proprietary information of Z3 Technology, LLC ("Z3"). This document may not be used, reproduced, disclosed, or
disseminated to anyone without the prior written approval of an authorized representative of Z3. Z3 reserves the right to change this product at any
time and without notice. All product names, trademarks, trade names, service marks, or service names mentioned in this document are the property
of their respective owners.

REVISION HISTORY
Version
Date
Change Note
Author
01
10/30/2017
Original Document for HE265-DEC
SI

HE265-DEC User Instructions
DOC-USR-0137-01
1
Z3 Technology, LLC ♦100 N 8th ST, STE 250 ♦Lincoln, NE 68508-1369 USA ♦+1.402.323.0702
TABLE OF CONTENTS
1.1 Connecting to the HE265-DEC....................................................................................... 3
1.2 User Name and Password ............................................................................................ 3
1.3 Gigabit Ethernet (GigE) port values................................................................................ 3
1.4 Zero-configuration (zeroconf) Host Name ........................................................................ 3
1.5 Logging into a Z3 using a Host Name .............................................................................. 4
1.6 Logging into Z3 using a known IP Address......................................................................... 5
5.1 4K ....................................................................................................................... 7
5.2 3G SDI Rear ............................................................................................................ 7
5.3 GigE 1 (Default to DHCP) ............................................................................................ 7
5.4 GigE 2 (Default IP Address 192.168.2.7)........................................................................... 8
5.5 Antenna 1 and 2 for optional WiFi/LTE............................................................................ 8
5.6 USB 3.0 ................................................................................................................. 8
5.7 USB 2.0 ................................................................................................................. 8
5.8 12V DC In............................................................................................................... 9
5.9 mUSB Com Port System Terminal .................................................................................. 9
5.10 3.5 mm Analog AV Jack (Apple iPOD compatible) .............................................................. 9
7.1 Upgrading from the Web UI ........................................................................................10
7.2 Uploading new firmware from a USB drive (thumb-drive).....................................................11

HE265-DEC User Instructions
DOC-USR-0137-01
2
Z3 Technology, LLC ♦100 N 8th ST, STE 250 ♦Lincoln, NE 68508-1369 USA ♦+1.402.323.0702
LIST OF FIGURES
Figure 1: User Name and Password for Login ............................................................................ 3
Figure 2: Z3 Serial number entered into URL ............................................................................ 4
Figure 3:URL after entering in the serial number ....................................................................... 4
Figure 4: User Name and Password page ................................................................................. 4
Figure 5: IP address enterd into URL ...................................................................................... 5
Figure 6: URL after entering IP Address................................................................................... 5
Figure 7: RTSP Streaming Configured ..................................................................................... 5
Figure 8: File Recording Simultaneously .................................................................................. 6
Figure 9: Example Streaming UDP ......................................................................................... 6
Figure 10: Front Panel of HE265-DEC...................................................................................... 7
Figure 11: Back Panel of HE265-DEC ...................................................................................... 7
Figure 12: Web Display Page for Upgrading from the Web UI ........................................................10
Figure 13: Choose Firmware File Page ...................................................................................10
Figure 14: Update Firmware confirmation page ........................................................................11
Figure 15: Reboot Warning Prompt .......................................................................................11
Figure 16: System Status Prompt .........................................................................................11
Figure 17: FW version page example .....................................................................................12
Figure 18: Firmware Update Log..........................................................................................12

HE265-DEC User Instructions
DOC-USR-0137-01
3
Z3 Technology, LLC ♦100 N 8th ST, STE 250 ♦Lincoln, NE 68508-1369 USA ♦+1.402.323.0702
HE265-DEC QUICK START GUIDE
Connecting to the HE265-DEC
The HE265-DEC uses a modern HTML5-embedded Web server for user configuration. Users can connect
to the Z3 device via Gigabit Ethernet (GigE) port 1 or GigE port 2. GigE port 1 is factory defaulted to
DHCP and GigE port 2 is factory defaulted to 192.168.2.7.
User Name and Password
Gigabit Ethernet (GigE) port values
Zero-configuration (zeroconf) Host Name
The HE265-DEC supports the multicast DNS zero configuration (zeroconf) host naming scheme. Z3 devices
are addressable using their hostname (serial number) on a local area network. The zeroconf access is
enabled (default) for GigE port 1. Zeroconf is disabled (default) for GigE port 2, though users can change the
Field
Value
Enter username
z3tech
Enter password
z3tech
Gigabit Ethernet Port
Configuration
GigeE 1
DHCP
GigeE 2
192.168.2.7
z3tech
Figure 1: User Name and Password for Login

HE265-DEC User Instructions
DOC-USR-0137-01
4
Z3 Technology, LLC ♦100 N 8th ST, STE 250 ♦Lincoln, NE 68508-1369 USA ♦+1.402.323.0702
Figure 4: User Name and Password page
enabled zeroconf port in the HOST/Ethernet tab in the GUI. Zeroconf allows users to enter the device’s
serial number followed by “.local/”to resolve a device’s web page with an unknown DHCP-issued IP address.
“9261-00404.local/” will resolve to the Z3 device with serial number 9261-00404 without knowing the
devices IP Address. Zeroconf will also work with ping and ssh.
Logging into a Z3 using a Host Name
Type the Z3 serial number into the URL modal in Chrome, Safari, Firefox, or Edge
1
.
1
The Bonjour plugin for Windows is required for zeroconf when using Edge. Bonjour for Windows URL
Field
Value
Enter username
z3tech
Enter password
z3tech
Figure 2: Z3 Serial number entered into URL
Figure 3:URL after entering in the serial number

HE265-DEC User Instructions
DOC-USR-0137-01
5
Z3 Technology, LLC ♦100 N 8th ST, STE 250 ♦Lincoln, NE 68508-1369 USA ♦+1.402.323.0702
Figure 5: IP address enterd into URL
Figure 6: URL after entering IP Address
Figure 7: RTSP Streaming Configured
Logging into Z3 using a known IP Address
Type the Z3 IP Address into the URL modal in Chrome, Safari, Firefox, or Edge
STREAMING RTSP AND RECORDING SIMULTANEOUSLY
Pictured is a screencap of RTSP streaming configured. At the end of ‘Decoding’ there is a light green
indicator bar showing the HE265-DEC is decoding. To stop the stream, click on the grey stop square.

HE265-DEC User Instructions
DOC-USR-0137-01
6
Z3 Technology, LLC ♦100 N 8th ST, STE 250 ♦Lincoln, NE 68508-1369 USA ♦+1.402.323.0702
Figure 8: File Recording Simultaneously
Figure 9: Example Streaming UDP
Below is a screencap of the file recording at the same time. Along with the light green indicator bar there is
now an additional red bar that shows it is recording. To stop the file recording change protocol to Off and
click Apply.
STEAMING UDP
To stream UDP choose the protocol UDP/RTP option. Indicate which interface the UDP traffic will be
coming in on. For the ‘Address’ use 0.0.0.0 and type in the Port number. Click 'Apply.

HE265-DEC User Instructions
DOC-USR-0137-01
7
Z3 Technology, LLC ♦100 N 8th ST, STE 250 ♦Lincoln, NE 68508-1369 USA ♦+1.402.323.0702
Figure 10: Front Panel of HE265-DEC
Figure 11: Back Panel of HE265-DEC
HE265-DEC FRONT AND BACK
HE265-DEC IO CONNECTIONS
4K
HDMI
3G SDI Rear
Connector
Center
Sleeve
High Density BNC x2 (HDBNC)
SDI Signal
Ground (GND)
GigE 1 (Default to DHCP)
RJ45 Pin
Signal
Color Code (Typ)
1
BI_DA+
White/Green
2
BI_DA-
Green
3
BI_DB+
White/Orange
4
BI_DC+
Blue
5
BI_DC-
White Blue
6
BI_DB-
Orange
7
BI_DD+
White/Brown
8
BI_DD-
Brown

HE265-DEC User Instructions
DOC-USR-0137-01
8
Z3 Technology, LLC ♦100 N 8th ST, STE 250 ♦Lincoln, NE 68508-1369 USA ♦+1.402.323.0702
GigE 2 (Default IP Address 192.168.2.7)
Same pinout as GigE 1
Antenna 1 and 2 for optional WiFi/LTE
Connector
Sleeve
Center (Tip)
SMA
Ground (GND)
Signal
USB 3.0
USB Standard A
Signal
Descriptor
1
VBus
+5 Volts DC Power
2
USB D-
USB 2.0 Data -
3
USB D+
USB 2.0 Data +
4
GND
Ground
5
StdA_SSRX-
Super Speed Receiver -
6
StdA_SSRX+
Super Speed Receiver +
7
GND_DRAIN
Ground
8
StdA_SSTX-
Super Speed Transmitter -
9
StdA_SSTX+
Super Speed Transmitter +
USB 2.0
USB Standard A
Signal
Descriptor
1
VBus
+5 Volts DC Power
2
USB D-
USB 2.0 Data -
3
USB D+
USB 2.0 Data +
4
GND
Ground

HE265-DEC User Instructions
DOC-USR-0137-01
9
Z3 Technology, LLC ♦100 N 8th ST, STE 250 ♦Lincoln, NE 68508-1369 USA ♦+1.402.323.0702
12V DC In
Connector
Left
Right
2-Pin Removable
Screw Terminal
Ground (GND)
12 Volts DC (Regulated)
mUSB Com Port System Terminal
115,200, 8, 1, N USB Serial Port
2
USB Standard
Micro-B
Signal
Color Code (Typ)
1
VBus
+5 Volts DC Power
2
USB D-
USB 2.0 Data -
3
USB D+
USB 2.0 Data +
4
No Connect
NC
5
GND
Ground
3.5 mm Analog AV Jack (Apple iPOD compatible
3
)
(Only functional when screen format is 1080P or lower)
Connector
Pin 3
Pin 2
Pin 4
Pin 1
3.5 mm 4 Pole
Right Audio
Left Audio
Ground (GND)
Video
CONTACT Z3 TECHNOLOGY
Telephone
+1.402.323.0702
Z3 Information
[email protected]
Z3 Web Page
www.z3technology.com
Shipping Address
100 N 8th Street, Ste 250
Lincoln, NE 68508
USA
2
Does not require external USB to TTL adaptor. The cp210x silicon is installed on the HE265-DEC circuit board. cp210x driver may be required for PC
to Z3 serial communications.
3
Apple and iPOD are registered trademarks of Apple Inc.

HE265-DEC User Instructions
DOC-USR-0137-01
10
Z3 Technology, LLC ♦100 N 8th ST, STE 250 ♦Lincoln, NE 68508-1369 USA ♦+1.402.323.0702
UPGRADING Z3 FIRMWARE
Upgrading from the Web UI
1. Navigate to the HOST Tab. Download the firmware to a disk and folder on your Windows/MAC/Linux
computer.
2. From the HOST tab, select the SYSTEM sub-tab, and click “Check for Space.”
3. Choose File (firmware) from your computer’s disk and folder.
4. Click “Check for Space,” then choose the FW file from your PC local disk.
4
5. Click “Upload” button to upload the firmware from your computer to the HE265-DEC.
4
If prompted with “Not Enough Space,” try logging out and back into the GUI. If the prompt persists, please remove media from the SD card to ensure
enough space for uploading the firmware package.
Figure 12: Web Display Page for Upgrading from the Web UI
Figure 13: Choose Firmware File Page

HE265-DEC User Instructions
DOC-USR-0137-01
11
Z3 Technology, LLC ♦100 N 8th ST, STE 250 ♦Lincoln, NE 68508-1369 USA ♦+1.402.323.0702
6. Select “OK” to confirm or “Cancel” to end the upgrading process.
7. Warning prompt and System Status prompt are informative only. Select “OK” to close.
Uploading new firmware from a USB drive (thumb-drive)
The HE265-DEC supports USB2 and USB3 media devices. To upload the new firmware from a
USB media device (thumb-drive), follow the steps below.
1. Download the firmware to a disk and folder on your computer.
2. Copy the firmware file from your computer’s disk and folder to the USB media device.
Figure 14: Update Firmware confirmation page
Figure 15: Reboot Warning Prompt
Figure 16: System Status Prompt

HE265-DEC User Instructions
DOC-USR-0137-01
12
Z3 Technology, LLC ♦100 N 8th ST, STE 250 ♦Lincoln, NE 68508-1369 USA ♦+1.402.323.0702
i. There must ONLY be one copy of the firmware on the media device. Remove previous
versions before inserting the media device into the HE265-DEC USB interface.
3. Safely remove the media device from your PC.
4. Insert the media device into the USB interface on the HE265-DEC
5. The fan and top blue LED will go off once the system mounts the media device and starts the
upgrade script. The disk mount and script start takes about 10 seconds. The upgrade will take a
little over a minute to complete. The device will reboot automatically.
6. You can remove the USB media device from the HE265-DEC after the unit reboots and starts
decoding.
7. To confirm the update was successful:
i. Check the firmware version on the Web UI on the right side just above the tabs. The
version should reflect the name of the firmware file loaded onto the USB media device.
ii. Insert the USB media device into your PC and open the firmwareUpdate log.
8. If more that one unit is upgraded using the same USB media device, there will be a firmware
update log for each unit. The naming scheme for the firmware update log is as follows.
<SN>-firmwareUpdate.log
Figure 17: FW version page example
Figure 18: Firmware Update Log

HE265-DEC User Instructions
DOC-USR-0137-01
13
Z3 Technology, LLC ♦100 N 8th ST, STE 250 ♦Lincoln, NE 68508-1369 USA ♦+1.402.323.0702
Z3 Technology’s Express Limited Warranty will be void if the label on the hardware bearing the Serial Number is removed,
tampered with or defaced. You can view Z3 Technology’s full hardware warranty at http://z3technology.com/Support/ZEUS-HW-
Warranty.html
To submit a warranty claim, complete a Return Material Authorization (RMA) request form online at
http://z3technology.com/Support/Report-RMA.html. Your receipt or invoice with the original purchase and ship date is required
for warranty coverage.
