Zamel EXTA ASM-02 User manual

STAIRCASE LIGHTING TIMER ASM-02 INSTRUCTION MANUAL
Zakład Mechaniki i Elektroniki
ZAMEL sp.j.
J.W. Dzida, K. Łodzińska
ul. Zielona 27, 43-200 Pszczyna, Poland
Tel. [phone], Fax [phone]
www.zamelcet.com, e-mail: [email protected]
VER. 001_16.02.2009
FEATURES
TECHNICAL PARAMETERS
DESCRIPTION
APPEARANCE
ASM-02
Input (supply) terminals: L, N
Input rated voltage: 230 V~
Input voltage tolerance: from -15 to +10 %
Nominal frequency: 50 / 60 Hz
Rated power consumption: 35 mA
Release terminals: IN, IN, IN
Release control current: 300 µA
Time adjustment range: from 2 sec to 10 min (rotational potentiometer)
Time accuracy adjustment: ±10 %
Time repeatability adjustment: ±5 %
Power/relay supply indicator: red LED
Output relay parameters: 1NO - 16 A / 250 V AC1 4000 VA
Number of terminal clamps: 8
Section of connecting cables: from 0,2 to 2,50 mm2
Ambient temperature range: from -20 to +45 oC
Operating position: free
Mounting: TH35 rail (PN-EN 60715)
Protection degree: IP20 (PN-EN 60529)
Protective class: II
Overvoltage category: II
Pollution degree: 2
Rated impulse withstand voltage: 1 kV (PN-EN 61000-4-5)
Dimensions (height / width / depth): monomodular (17,5 mm) 90x17,5x66 mm
Weight: 76 g
Reference standards: PN-EN 60669-1; PN-EN 60669-2-1
PN-EN 61000-4-2,3,4,5,6,11
● Staircase lighting control,
● operating time adjustment from 2 sec
to 10 min,
● power supply indicator – red LED,
● cooperation with monostable push-
buttons equipped with illumination
lamps,
● anti blocking function,
● cooperation with 4-wire installation,
● voltage relay output - one NO contact
max 16 A capacity,
● monomodular casing,
● TH 35 DIN rail installation.
The staircase lighting time delay
switch ASM-02 is used to control lighting
devices on staircases and corridors. After
releasing the system it switches on the
lighting for the preset time by the user.
After that it switches off automatically.
The operating time can be adjusted from
2 s to 10 min by means of the potentio-
meter placed on the front panel of the
device. The device is equipped with an
anti-blocking function. The staircase li-
ghting time delay switch ASM-02 can be
used as standard time delay relay.
The device is designed
for one-phase instal-
lation and must be in-
stalled in accordance
with standards valid
in a particular country.
The device should be
connected according to the details inc-
luded in this operating manual. Installa-
tion, connection and control should be
carried out by a qualied electrician staff,
who act in accordance with the service
manual and the device functions. Disas-
sembling of the device is equal with a
loss of guarantee and can cause electric
shock. Before installation make sure the
connection cables are not under voltage.
The cruciform head screwdriver 3,5 mm
should be used to instal the device. Im-
proper transport, storage, and use of the
device inuence its wrong functioning.
It is not advisable to instal the device in
the following cases: if any device part is
missing or the device is damaged or de-
formed. In case of improper functioning
of the device contact the producer.
CAUTION
Output(load)relay
Time adjustment
Power/relaysupplyindicator
Inputsupplyterminal (L)Inputsupplyterminal (N)
terminals (11,11,14)
Release terminals
(IN,IN,IN)

VER. 001_16.02.2009
RELAY CAPACITY
MOUNTING, FUNCTIONING
1. Disconnect the power supply from the
mains by the phase fuse, the circuit-
breaker or the switch-disconnector
that are joined to the proper circuit,
2. Check if there is no voltage on con-
nection cables by means of a spe-
cial measure equipment,
3. Install ASM-02 device in the switch-
board on TH 35 DIN rail,
4. Connect the cables with the terminals
according to installing diagram,
5. Switch on the power supply from the
mains,
6. Adjust the demanded switch on time
by means of a potentiometer.
After proper mounting and installa-
tion the device is ready to work. Rele-
asing the system with the monostable
pushbutton causes the lighting to switch
on for the preset time. After the preset
time is over the lighting is automatically
switched off till its another release. The
staircase lighting time delay switch co-
operates with 4-wire system. The stair-
case lighting time delay switch ASM-02
has the anti blocking system. It means
the light is switched off after the adju-
sted time in cases the pushbutton is
blocked.
DIMENSIONS
GUARANTEE CARD
There is 24 months guarantee on the product
Salesman stamp and signature, date of sale
1. ZAMEL provides a two-year warranty for its products.
2. The ZAMEL warranty does not cover:
a) mechanical defects resulting from transport, loading / unloading or other circumstances,
b) defects resulting from incorrect installation or operation of ZAMEL products,
c) defects resulting from any changes made by CUSTOMERS or third parties, to products sold or equipment necessary
for the correct operation of products sold,
d) defects resulting from force majeure or other aleatory events for which ZAMEL is not liable.
3. All complaints in relation to the warranty must be provided by the CUSTOMER in writing to the retailer after discovering
a defect.
4. ZAMEL will review complaints in accordance with existing regulations.
5. The way a complaint is settled, e.g. replacement of the product, repair or refund, is left to the discretion of ZAMEL.
CONNECTING
EXAMPLE OF INSTALLATION
PRODUCT FAMILY
The staircase lighting time delay switch
ASM-02 belongs to staircase lighting time
delay switches ASx family.
INNER DIAGRAM
TIME COURSE
Device symbol
Type of casing:
M – monomodular
N – surface mounting
H – hermetical
P – for junction box mounting
Device version:
01 – three - or four-conductor
wiring
02 – anti-lock system
10 – dimmer function
Version 24 V AC/DC
for ASM-02 available
Typical application:
The staircase lighting time delay switch ASM-02 operating the staircase ligh-
ting works in 4-wire installation. Monostable pushbutton (equipped with illumination)
can be connected parallely.
t
t t t
500 W
2000 W 1000 W
750 W
NL
11
11
14
IN
IN
IN
t
