Waste bottle not installed / halfway installed to valve at
front panel +Check connection at waste bottle mount
Waste tube clogged -Unclog or replace waste tube
Waste bottle vent clogged -Check and unclog cap vent or replace cap
Service Station
Overflowing
Waste Bottle not plugged in properly +Check connection of Waste Bottle to check valve
“Before printing you must
fix this problem” Message Main harness disconnected at PCI card. +Check main harness connection at PCI card
Binder leaking from back
of machine Binder filter leaking +Check filter o-ring and filter body for proper
assembly
Wet piston seal has dried against build box wall +Replace piston seal
(see 08632 Benchwork manual)
Debris jamming the piston -Check for any debris and remove; clean the build
box walls if ant buildup has occurred
Energizer jamming the piston -Replace energizer and seal
(see 08632 Benchwork manual)
Build piston is stuck and
or will not move through
its full range of travel
Faulty PCI card -Replace PCI card
(see 08632 Benchwork manual)
Build piston will not come
all the way to the top of
the build box
Piston positions incorrect. Pistons not re-zeroed after
PCI / E Box replacement. +Re-zero pistons
Excessive overspread into
service station / gantry
jams Feed piston raised too far before spreading +Clean away excess powder, clean print head
and reboot printer
Powder is contaminated or over-recycled +Discard old powder and fill feed box with fresh
powder
Roller scraper worn -Replace roller scraper
(See 08632 Benchwork manual)
Binder/powder caked on roller -Check scraper for wear or clean roller
Spreader roller motor failing -Replace spreader roller motor
(See 08632 Benchwork manual)
Uneven or rough
spreading
Roller belt skipping teeth See 09813 Service bulletin for instructions
