Zest 4 Leisure Harriet Wide Chair User manual

Assembly Instructions
(W x D x H): 0.80m x 0.62m x 0.845m
Product Name: Harriet Wide Chair
Pressure Treated products should not be treated with any other products for the first month.
PLEASE KEEP THIS INSTRUCTION
Zest4Leisure
01352 752555 option 1 –[e-mail]
V1-10.16

Harriet Wide Chair Assembly Instructions
Requires 2 person assembly.
Tools required: Corded / Cordless Drill, Pozi-drive Bit / Screwdriver, 3mm Drill Bit
required in order for you to drill all screw holes before construction.
The colour version of this document can be downloaded from:
www.zest4leisure.co.uk/downloads/category/C1
Harriet Wide Chair Pack List
Item Description Quantity
A Seat Assembly 1
B LegAssembly 2
C Back Assembly 1
Fixings
80mm screws 10
www.zest4leisure.co.uk

Please take a few moments to check all pack contents listed.
Assembly requires 2 persons.
Tools required: Corded/Cordless Drill, Pozi-drive Bit/Screwdriver, 3mm Drill Bit
required in order for you to drill all screw holes before construction.
Harriet Wide Chair is now complete.
1. Place Seat AssemblyA onto Leg Assemblies B and fix in place using 6no screws
(3no per side). (See Figs 1a & 1b)
2. Position Back Assembly C to top of LegAssemblies B and fix using 4no screws
(2no per side). (See Fig. 2)
1b
1a
2
