Zest 4 Leisure Rustic Arch User manual

Assembly Instructions
(W x D x H) m1.83 x m0.54 x m2.77
Product Name: Rustic Arch
PLEASE KEEP THIS INSTRUCTION
Zest4Leisure
01352 752555 option 1 –[e-mail]

Rustic Arch Assembly Instructions
Requires 2 person assembly.All screw holes to be pre-drilled.
Tools required: Corded / Cordless Drill, Pozi-drive Bit / Screwdriver, 3mm Drill Bit,
13mm Spanner.
Rustic Arch Pack List
Item Description Quantity
A Roof Panel 2
B Side Panel 2
C Diagonal Bracings 4
Fixings
Bolt, Nut & Washer 2
100mm Screw 8
www.zest4leisure.co.uk

Please take a few moments to check all pack contents listed.
Please contact “Zest4Leisure” directly if any of the pack contents are damaged
or missing. Contact telephone: [phone] option 1 or email:
[email protected]
Assembly requires 2 persons. All screw holes to be pre-drilled.
Tools required: Corded/Cordless Drill, Pozi-drive Bit/Screwdriver, 3mm Drill Bit,
13mm Spanner.
Rustic Arch is now complete.
1. Align Roof PanelsA to form an apex (Fig.1a) and attach using 2no M8 Bolts, Nuts
and Washers (Fig.1b).
2. Position Side Panel B as shown in Fig.2.
3. Connect Side Panel B to Roof Panel A using 2no Diagonal Bracings C (Fig.3)
using 4no 100mm Screws –2no per bracing.
Repeat stages 2 & 3 for remaining Side Panel B and Bracings C.
1b1a
2 3
