ZKTeco PA10 User manual

PA10 Fingerprint & Palm Terminal
QUICK START GUIDE
Version: 1.0
Date: August,2017
Time Attendance & Access Control

 

Palm Sensor
Before the installation, please connect the cables to the connectors.(Recommended installation
height: 1.1m)
1) Post the installation template on the wall and drill. 2) Fix back plate to the wall.
3) Mount the device on the back plate 4) Secure the device and back plate..
1
93.0mm
246.5mm
51.13mm
45mm
1 Overview
Front Side
Fingerprint Sensor
2.4 Inch TFT LCD
Keypad
Door Bell & IndicatorLED
2 Installation of Wall-mount
Back Bottom
7 (Beep/ /Weigand In/PIN LED
Power Out)
8 ( / 232/Weigand Out)PIN RS485 RS
2 (Power In)PIN
6PIN (Alarm/Lock/Exit Button/
Sensor/Bell/ )Auxiliary In)
Tamper Alarm Button
6PIN RS485 RS( / 232/Weigand Out)
Ethernet Port USB Slot
Reset Button
Speaker
Star-shaped screw hole
for xing device to the
back plate
3Cautions3Cautions
1 Power cable is connected after other wirings and shut down the power rstly when making),,
some necessary checking.
2 We recommend that use the C12V 3A power supply)/.D
) .3 Please read the terminals description carefully and wiring by rule strictly
)4 Please connect the ND before other wirings especially under the serious electrostaticG
environment.

RS485
U Disk
TCP IP/
Printer

R 485S
%
Description Color
Alarm AL+ Red
Alarm AL- Black
Sensor SEN Yellow
Ground GND Red
Button BUT Blue
Normal Open No1 White
COMM COM1 Black
Normal Close NC1 Gray
Bell BELL+ Orange
Bell BELL- Green
AL+
AL-
NC1
COM1
NO1
BUT
GND
SEN
BELL+
BELL-
J17
J21
-+
-
%
-+
-
+AL
-AL
1NC
1COM
1NO
BUT
GND
SEN
BELL+
-BELL
GND
AUX
GND
AUX
+
+
Ground GND Purple
Auxiliary AUX Brown
2
),.5 Do not install the device in a place subject to direct sunlight humidity or dust
4 Wiring Diagram
Server
Lock Door
Sensor
Alarm
Exit Button
485 Reader
Wiegand
Card Reader
Door Bell
Door
5 Door Bell Door Connection& Sensor & Exit Button & Alarm5 Door Bell Door Connection& Sensor & Exit Button & Alarm
Alarm Power
Alarm
Exit Button
Bell Power
Door Bell Door Sensor

3
+12V
GND
J19
485A
GND
J18
485B
How to enable 485 Reader Function?
1. Enable RS485 Reader Function: Press M/OK > Comm. > Serial Comm > Serial port ,
select [master unit].
2. Setting 485 Reader veri cation mode: Press M/OK > Access Control > Access Control Options
>Verify mode by RS485,to choose veri cation mode.
Description Color
Power Out +12V Red
Ground GND Black
Wiegand In IWD1 Green
Wiegand In IWD0 White
Red LED RLED Blue
Green LED GLED Gray
Beep BEEP Purple
+12V
GND
IWD1
IWD0
RLED
GLED
BEEP
J19
+12V
IDW1
IDW0 WD0
WD1
+12V
+12V
GND
GND
485A
485B
+12V
GND
GND
485+
485-
GND GND
6 485 Reader Connection
7 Wiegand Card Reader Connection
Wiegand Card Reader

1.The device supports "Dry Mode" and "Wet Mode" by setting the jumper. The factory default
jumper setting is set as "Dry Mode", that is, shorten 1-2 and 3-4 .
2. If there is no enough power supply under the working circumstance, "Wet Mode" can also be used,
namely, shorten 2-3 and 4-5 .
3. If you want to switch "Dry Mode" to "Wet Mode", you must take off the jumpers and plus them.
4
12V ± 10%, at least 500mA.
To share the power with other devices, use a power supply with higher current ratings.
Description Color
Power In +12V Red
Ground GND Black
GND
12V DC
+12V
GND
J20
To connect device with a PC directly, connect both devices with a straight network cable.
Such as the following figure.
IP Address: 192.168.1.201
Subnet Mask: 255.255.255.0
IP Address: 192.168.1.130
Subnet Mask: 255.255.255.0
485A
RXD RXD RXD
WD1
GND
GND
WD0
J18
485B
TXD TXD
GND
TXD
GND
55 44
33 22
11
Take off jumpers
Jumpers
8 Power Connection
10 Communication with Via Ethernet CablePC10 Communication with Via Ethernet CablePC
9 Printer Connection
11 Lock Relay Connection

Press M/OK > Comm. > Ethernet to enter the Ethernet interface.
The Parameters below are the factory default values. Please adjust them according to the actual network.
IP Address: 192.168.1.201
Subnet Mask: 255.255.255.0
Gateway: 0.0.0.0
DNS: 0.0.0.0
TCP COMM. Port: 4370
DHCP: Dynamic Host Con guration Protocol, which is to dynamically allocate IP addresses for
clients via server. If DHCP is enabled, IP cannot be set manually.
Display in Status Bar: To set whether to display the network icon on the status bar.
Press M/OK > System > Date Time to enter the DateTime interface.
Press M/OK > User Mgt. > New User to enter the New User interface.
The setting include entering a name, modifying user roles (Super Admin / Normal User), enrolling
fingerprint/palm/badge number /password, modifying access control role.«
Adding a Super Admin: Select Super Admin in User Role to add a super admin.
Adding a Normal User: Select Normal User in User Role to add a normal user.
5
12 Date/Time Setting
13 Adding a User
14 Ethernet Setting

6
16 Auxiliary Input Setting
Press M/OK > Access Control > Access Control Options > Auxiliary input configuration.
Auxiliary Output/Lock open Time: It is de ned as the time interval between the lock receiving
signals and automatically closing under Normal Closed mode.
Auxiliary Output Types
Trigger Door open: The lock will turn to Normally Open after the device receives signals.
Trigger Alarm: The alarm will be triggered after the device receives signals.
Trigger Door open and Alarm: The lock will turn to Normal Open and the alarm will be triggered
after the device receives signals.
Press M/OK > Access Control to enter the Access Control interface.
To unlock, the enrolled user must accord with the following conditions:
1) The current unlock time should be in the effective time of user time zone or group zone.
2) The group which user is must be in Combined Verification.
Access Control Options: Set parameters to control locks and related device.
Time Zone: It is the minimum unit of access control option.
Holidays: Set some days as holidays, and then set Time Schedule of those days.
Access Groups: Grouping is to manage employees in groups. Employee in groups use group time
zone by default. Group members can also set user time zone.
Combined Verification: Make various groups into different access controls to achieve
multi-verification and improve security.
Anti-pass Back: To prevent someone following the employee into the company.
Duress alarm parameter: The device will open the door as usual, but the alarm signal will be sent
to backstage alarm when employee comes across duress.
15 Access Control Setting

17 17 
7
Press M/OK > Personalize > User Interface, set IdleTime To Slide Show(s) to be None, or set
Slide Show Interval(s) to be disabled.
16 16 
17 Disabled Slide Show
18 Trouble shooting
1) Fingerprint can not be read or it takes too long.
Check whether a nger or ngerprint sensor is stained with sweat, water, or dust.
Retry after wiping off nger and ngerprint sensor with dry paper tissue or a mildly wet cloth.
If a ngerprint is too dry, blow on the nger and retry.
2) Fingerprint is veri ed but authorization keeps failing.
Check whether the user is restricted by door zone or time zone.
3) Authorized but door does not open.
Check the user role is permissible.
Check the lock connection is corrected.
4) When the device is tampered, the device will send a signal to the speaker then the icon is
displayed on the top right corner and the speaker is ringing. Only the [Speaker Alarm]
(Access Control Options Speaker Alarm) is can user heard the ringing.> Access Control > [ ]ON
Please install the device properly.
!
