ZOLL AED PLUS Trainer2 Manual

Automated External Defibrillator Trainer2
Operator's Guide
Extra and/or replacement Remote Controllers are available
Contact your distributor or ZOLL Medical.
NOTE
1. Keep Trainer2 and Remote Controller clean, undamaged,
and free of excessive wear.
2. Verify that there are no cracks or loose parts in Trainer2 and
Remote Controller.
3. Replace Training electrodes as necessary.
MAINTENANCE
Trainer2 does not respond
(green light in status window
is not lit) when On/Off
button is pushed
TROUBLESHOOTING
Clean the Trainer2 unit and remote controller with soft, damp
cloth using soap and water, then wipe dry immediately.
Do not immerse any parts in water.
Do not clean with ketones (e.g., MEK, acetone).
Avoid using abrasives on any surface.
Do not sterilize the Trainer2 or the Remote Controller.
CLEANING
© ZOLL Medical Corporation 2007
TRAINING USE ONLY - NOT FOR CLINICAL USE
REF 9650-XXXX-XX Rev. A
CPR Metronome On/Off
This control activates the Trainer2's metronome
which begins to beep at 60 compressions per minute
(CPM) then automaticallyaccelerates to 100 CPM
after a few seconds. Metronome beeps are inde-
pendent of the student's actual compression rate
and continue until the CPR interval times out or until
the Metronome On/Off button is pressed again. The
control and the metronome functions are only active
during periods when the Trainer2 has prompted
the rescuer to perform CPR.
PUSH HARDER Button
Pressing this control button causes the Trainer2 to
emit a single "PUSH HARDER" voice prompt.
Instructors should depress this button when the
student's chest compressions are too shallow.
Good Compressions Control
Pressing this control button causes the Trainer2 to
emit a "GOOD COMPRESSIONS" voice prompt. To
simulate operation of the AED PLUS defibrillator,
instructors should use this control to provide
students with positive feedback about improve-
ments in chest compression depth when they
respond to "PUSH HARDER" prompts.
Remote Controller: Description:
CPR FEEDBACK OPERATION
The AED PLUS Trainer2 includes controls that allow instructors to simulate
the voice prompts and text messages issued by the AED PLUS when
rescuers perform CPR. These controls include:
Product intended for indoor use only.
WARNING
Do not attempt to plug AED Plus or AED Pro
simulator into connector of Trainer2.
WARNING
This device is for training only. It will not deliver
defibrillation energy.
WARNING
Replace all four “D” batteries
in Trainer2 unit.
Remote Controller does not
respond (scenario
selection is not lit)
when view/enter
button is pushed
Replace both “AA” batteries in
Remote Controller.
With new batteries in both,
Trainer2 fails to respond to
Remote Controller
AED Trainer problem / display: Action:
Contact ZOLL
Technical Service
Do not attempt to take Trainer2 or Remote
Controller apart. Remove and replace battery
compartment doors only and replace
immediately.
WARNING
On
Off
Trainer2 does not beep or
react to Remote Controller
during CPR interval.
Re-set scenario and make
certain that CPR metronome
light is on.
No prompt to “GIVE TWO
BREATHS” after “CHECK
BREATHING”
Unit is configured for ERC.
Change to AHA configuration.
(See Chaning AHA/ERC
Configurations section of this
Operator’s Guide).
SWITCHING AHA/ERC CONFIGURATION
American Heart Association (AHA) configuration: Prompt to “GIVE TWO
BREATHS” after “CHECK BREATHING”.
European Resuscitation Council (ERC) configuration: NO prompt to “GIVE
TWO BREATHS” after “CHECK BREATHING”.
Prompt to “GIVE TWO BREATHS” can be configured into (AHA configuration),
or out of (ERC configuration) the prompt sequence by doing the following:
With the Trainer2 unit off, hold down the Shock Button. Press On/Off Button
once. Green light will illuminate at status window to indicate AHA config-
uration (prompt sequence will contain “GIVE TWO BREATHS”).
Press On/Off Button again. Green light will turn off and red light will illuminate
at status window to indicate ERC configuration (prompt sequence will NOT
contain “GIVE TWO BREATHS”).
Press On/Off Button again to revert to AHA configuration (green light on
and red light off).
When configured as desired (green = AHA, red = ERC), hold down On/Off
button to turn unit off and store configuration.
ZOLL Medical Corporation
269 Mill Road
Chelmsford, MA USA 01824-4105
978-421-9655 800-348-9011
Fax: [phone]
For technical support or repair:
Technical Service Department
Trainer2

Accurately imitating the AED Plus requires that instruc-
tors be familiar with the protocol currently followed by the
AED Plus for PUSH HARDER and GOOD COMPRESSIONS prompts.
For further information about the functioning of the
clinical AED Plus, see the AED Plus Operator’s Guide and Admin-
istrator’s Guide.
The Remote Controller lights indicate the current training
settings while the Trainer2 simulates the actual AED Plus behavior.
The Remote Controller will turn itself off after 10 seconds.
The Trainer2 will remember the last scenario setting which will re-
appear the next time the view/enter button is pushed.
NOTE
SCENARIOS
VF 1
VF 2
VF 3
VF 4
Done
Shock
CPR
Shock
CPR
1Simulated heart rhythm: Student Response:
ASYSTOLE 1
ASYSTOLE 2
VF 1
VF 2
Done
No Shock
CPR
Shock
CPR
2Simulated heart rhythm: Student Response:
VF 1
VF 2
NSR 1
NSR 2
Done
Shock
CPR
No Shock
CPR
3Simulated heart rhythm: Student Response:
ASYSTOLE 1
ASYSTOLE 2
ASYSTOLE 3
ASYSTOLE 4
Done
No Shock
CPR
No Shock
CPR
4
Simulated heart rhythm: Student Response:
SETUP and TEST
1
SELECT SCENARIO SETTINGS
2
Scenario 3: SHOCK - NO SHOCK
Scenario 2: NO SHOCK - SHOCK
Scenario 1: SHOCK - SHOCK
Manual Scenario mode
CONTROLS / INDICATORS
Handheld Remote Controller:
PUSH HARDER prompt
(only when metronome is beeping)
NO SHOCK advised on next heart analysis
(manual mode only)
Pads attached/not attached to victim’s bare chest
(toggle-switch)
CPR Metronome set up to beep or not beep
(Real CPR Help
®
during CPR interval)
Push to turn Trainer2 on
Push again to start current scenario
(as defined using Remote Controller)
Hold to turn Trainer2 off
ZOLL AED Plus Trainer:
View/Enter scenario
Show current scenario selection (press once)
Start scenario (press again)
Move Up to next scenario.
Scenario 4: NO SHOCK - NO SHOCK
Scenario Set-up Controls:
Training Controls:
GOOD COMPRESSIONS prompt
(only when metronome is beeping)
Pause (resume) current scenario
End current scenario
Green light remains on = Trainer2 is on and ready for use
Green light off = Trainer2 is turned off or has no battery power
Red Light steady = Last command from Remote Controller accepted
Red Light 3 flashes = Last command from Remote Controller is invalid
NOTE
Install 4 “D” batteries in the AED Plus Trainer2.
Trainer2 unit: Action:
Press On/Off button to turn Trainer2 on.
Green light turns on, indicating Trainer2 is
ready for use.
Remote Controller:
Install 2 “AA” batteries in handheld remote.
Turn the Remote Controller on by pushing the
view/enter button.
Point Remote Controller at unit and press
view/enter button again. Green light on Remote
Controller will show Manual Scenario Mode is
selected.
Manual Scenario Mode
View/Enter Button
Trainer2 unit: Action:
Turn Trainer2 unit off (hold down On/Off button).
Setup test is now complete. Trainer2 unit and
Remote Controller are ready for use.
Trainer2 unit: Action:
Turn Trainer2 on by pushing the On/Off button.
Action:
Remote Controller: Action:
Press view/enter button once to turn on Remote
Controller.
Use move up button to select desired scenario.
Use CPR Metronome button to turn Real CPR Help
(beeping) on or off for this scenario.
Push view/enter button once to enter scenario for
AED Plus Trainer2.
CPR PROMPTS
3a
Remote Controller: Action:
The Remote Controller controls all prompts when
the Trainer2 is beeping (during the CPR interval).
NOTE
SCENARIO CONTROLS
3
Remote Controller: Action:
VF (Ventricular Fibrillation-shock advised) is the
default simulated heart rhythm in Manual Scenario.
Analysis - VF
For the next analysis to result in NO Shock advised,
push the NO Shock button.
NOTE
Once the No Shock button has been pushed, the next
simulated heart analysis will advise NO Shock. This setting cannot be
reversed for the next analysis.
In all scenarios the Pads buttton must be pressed
once to proceed with analysis. If pressed again, it
will begin to prompt for attaching pads.
PAUSE/STOP SCENARIO
3b
Press the PUSH HARDER button during the CPR
interval to force the unit to say “Push Harder”.
Press the GOOD COMPRESSIONS button during the
CPR interval to force the unit to say “Good
Compressions”.
Remote Controller: Action:
In all scenarios (manual and automatic), the rescue
can be paused by pushing the Pause/Resume
button once. Push it a second time to resume the
scenario.
Trainer2 unit: Action:
The PUSH HARDER and GOOD COMPRESSIONS
buttons are only valid during the CPR interval.
The red light on the Trainer2’s status window emits
one long flash if the prompt is currently valid.
If the PUSH HARDER or GOOD COMPRESSIONS
buttons are pushed when the Trainer2 is not
beeping, the unit’s red light emits three quick
flashes, indicating that the prompt is currently
invalid.
In all scenarios (manual and automatic), the rescue
can be ended by pushing the End button once.
NOTE
4
On
Off
On
Off
On
Off
On
Off
