Zonair3D d2itsu PAR 100 User guide

SERVICE MANUAL
USER MANUAL
UM
SM
En
START-UP GUIDE
Serie
PAR RANGE AIR PURIFIERS
Edition
10/20
Model
PAR 100-300

GENERAL DESCRIPTION
The unit is supplied fully wired and programmed from factory to perform a check at a variable flow.
The module consists of the following sections: G4 prefilter, GRSystemTM gas filter, fan and H14 absolute filter.
The figure below shows the main components of the module.
Airow
Airow
Airow
Airow
PREFILTER AND
GRSYSTEM SECTION
FAN
SECTION
ABSOLUTE FILTER
SECTION
1- Pressure switch connection cable
(black with 2 terminal blocks joined together)
2- Daitsu by Zonair3DTM air quality probe connection cable
(probe not included), with 4 marked terminals, 5 and 6
attached to strip, 17 and 18 (attached
to strip)
3- 230 V network cable (2 phases + earth)
4- Main ON/OFF switch
5- PCB registration cover (4 M5 bolts)
6- H14 positive pressure tap
7- Differential pressure switch
8- Connection to the H14 positive pressure switch
9- M5 threads for fixing the anchor brackets
10- H14 negative pressure tap
11- Connection to the H14 negative pressure switch
12- Red LED to indicate HEPA14 filter change
Maintenance
Maintenance
Airow
Airow
PRODUCT
RANGE
FLOW
(m3/h)
UNIT DIMENSIONS
H x W x L (mm)
CONSUMPTION
(KW)
VOLTAGE AND
FREQUENCY
WEIGHT
(kg)
Pressure available
(Pa)
PAR 100 160-120 207.2 x 577.2 x 985 0.028 (1 unit) 230 V - 50/60 Hz 45.5 100
PAR 300 300-220 207.2 x 577.2 x 985 0.056 (2 units) 230 V - 50/60 Hz 46 100
Thank you for choosing Daitsu by Zonair3DTM products.
Please take a few minutes to read this manual carefully before
using your PURE AIR RESIDENTIAL.

RECEIVING THE UNIT
When you receive the unit, unpack it checking that the packaging is intact. Inspect it and make sure nothing is missing.
In addition to the unit, you will also find:
- One bag containing the anchor brackets or fixing brackets supplied unassembled, for installation in situ
on the machine’s chassis. This includes 8 M5 cross-head bolts to fix the unit to the desired surface.
- Another bag with the differential pressure switch, the transparent pressure tube and the 2 thread/sheet bolts for fixing it.
- An individual absolute filter test certificate.
RECEIVING THE UNIT
The unit is a Plug&Play device, meaning that you do not need to configure anything.
We recommend that you open the access panel to check that nothing has moved during transport, making sure
that the prefilter, the GRSystem and the absolute filter are correctly positioned and fixed in place.
The access panel is opened by removing the 8 M6 Allen bolts (4 on each side), with it being important
to retighten them correctly to ensure the seal of the unit.
The unit starts up automatically when powered up.*
Before starting it up, all of the unit's access panels must be closed.
Keep the start-up switch in the stop position and connect the unit.
Connect the main external power switch to the unit, keeping its start-up switch in the stop position. Once this has been done, check that
the voltage on the unit’s electrical input terminals matches the voltage indicated on the nameplate
(the minimum permitted voltage will be 10% less than the nominal voltage indicated on the nameplate).
Check that the earth connection is connected correctly.
Once all these checks have been done, remove the unit’s stop position (switch it ON).
The fan will not start if the duct network is not completely closed, as the connection of the fan without load can cause overcurrents that
could damage the motor.
(*) See the different types of connection in the User Manual.
EMERGENCY OPERATIONS
If you notice any problem on the unit, switch it off using the emergency stop device.
These emergency operations will generally be due to a problem with the electrical circuit, in which case there will be problems with
the motors. You will therefore need to disconnect the power in order to locate the fault, which may be inside the unit (short circuits, etc.)
or external to the unit (power supply issues, voltage variations, etc.).
In the event of a fire, it must be extinguished using suitable extinguishers. These extinguishers must be
CONTACT DETAILS: EUROFRED 932 998 331 - www.recambios.eurofred.es (online chat)
PAR_START-UP GUIDE_200812
