2N IP intercom Instruction sheet

www.2n.cz
2N IP intercom
Configuration Manual
Version: 2.22

The 2N TELEKOMUNIKACE a.s. is a Czech manufacturer and supplier of
telecommunications equipment.
The product family developed by 2N TELEKOMUNIKACE a.s. includes GSM gateways,
private branch exchanges (PBX), and door and lift communicators. 2N
TELEKOMUNIKACE a.s. has been ranked among the Czech top companies for years
and represented a symbol of stability and prosperity on the telecommunications
market for almost two decades. At present, we export our products into over 120
countries worldwide and have exclusive distributors on all continents.
2N is a registered trademark of 2N TELEKOMUNIKACE a.s. Any product and/or other
®
names mentioned herein are registered trademarks and/or trademarks or brands
protected by law.
2N TELEKOMUNIKACE a.s. administers the FAQ database to help you quickly find
information and to answer your questions about 2N products and services. On www.
faq.2n.cz you can find information regarding products adjustment and instructions for
optimum use and procedures „What to do if...".
2N TELEKOMUNIKACE a.s. hereby declares that the 2N product complies with all
®
basic requirements and other relevant provisions of the 1999/5/EC directive. For the
full wording of the Declaration of Conformity see the CD-ROM (if enclosed) or our
website at www.2n.cz.
This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference, and (2)
this device must accept any interference received, including interference that may
cause undesired operation.

The 2N TELEKOMUNIKACE a.s. is the holder of the ISO 9001:2009 certificate. All
development, production and distribution processes of the company are managed by
this standard and guarantee a high quality, technical level and professional aspect of
all our products.

2N TELEKOMUNIKACE a.s., www.2n.cz 4/198
Content:
1. Product Overview
2. Express Wizard for Basic Settings
3. Model Differences and Function Licensing
3.1 Model Differences
3.2 Function Licensing
4. Signalling of Operational Statuses
5. Intercom Configuration
5.1 Status
5.2 Directory
5.3 Hardware
5.4 Services
5.5 System
5.6 Used Ports
6. Supplementary Information
6.1 Troubleshooting
6.2 Directives, Laws and Regulations
6.3 General Instructions and Cautions

2N TELEKOMUNIKACE a.s., www.2n.cz 5/198
1. Product Overview
The can smartly replace traditional doorbell push-button 2N IP intercoms
speakerphone panels and all wiring, bells and home intercom installations in buildings
with structured cabling. The intercoms provide more advanced and wider services
than standard home phones. The installation is very easy, all you need is connect the
intercom to the other LAN elements using a UTP cable and set necessary parameters.
Thanks to the integrated SIP protocol, the intercom can make use of all VoIP services:
call forwarding at absence (to another office, VoiceMail or a cellular phone) or call
transfer (from the secretary’s office to the required person, e.g.).
The intercoms are equipped with a programmable number of quick dial buttons for
speed calling to the users whose numbers are included in the intercom Users list. Each
of the quick dial buttons can be assigned up to three phone numbers, which can be
dialled in parallel or sequentially. Thanks to an integrated time sheet it is possible to
configure each of the buttons in such a way that the called party is always accessible
and/or calls to selected phone numbers can be barred off the working hours.
Some models are equipped with a numeric keypad, which can be used 2N IP intercom
as a code lock or a standard push-button phone.
The help LAN users scan the area in front of the camera via video 2N IP intercoms
streaming. Thanks to the full ONVIF support, the intercoms can become part of the
Video Surveillance System in your facility .
The can be equipped with an RFID card reader for authorised access 2N IP intercoms
control and thus become a key part of your surveillance or attendance control
systems.
The is equipped with a relay switch (and, optionally, other relays and 2N IP intercom
outputs), which controls the electric lock or other equipment connected to the
intercom. Its activation time and method can be programmed flexibly: it can be
activated by a code, automatically by a call, by pressing a button, and so on.
The following symbols and pictograms are used in the manual:

2N TELEKOMUNIKACE a.s., www.2n.cz 6/198
Safety
Always abide by this information to prevent persons from injury.
Warning
Always abide by this information to prevent damage to the device.
Caution
Important information for system functionality.
Tip
Useful information for quick and efficient functionality.
Note
Routines or advice for efficient use of the device.

2N TELEKOMUNIKACE a.s., www.2n.cz 7/198
2. Express Wizard for Basic
Settings
LAN Connection Setting
You have to know the intercom configuration interface address to connect to the LAN
successfully. Automatic IP address retrieval from the DHCP server is set by default in
the . Thus, if connected to a network in which a DHCP server 2N IP intercoms
configured to assign IP addresses to all new devices is available, the intercom will
obtain an IP address from the DHCP server. The intercom IP address can be found in
the DHCP server status (according to the MAC address given on the production
plate), or will be communicated to you by the intercom voice function; refer to the
Installation Manual of your intercom model.
If there is no DHCP server in your LAN, use the intercom buttons to set the static IP
address mode, refer to the Installation Manual of your intercom model. Your intercom
address will then be Use it for the first login and then change it if 192.168.1.100.
necessary.
Now enter the intercom IP address into your favourite browser. We recommend you
to use the latest Chrome, Firefox or Internet Explorer 9+ versions as is 2N IP intercom
not fully compatible with earlier browser versions.
Use the name and password (i.e. default reset password) for your first login admin 2n
to the configuration interface.
We recommend you to change the default password upon your first login.
The intercom requires a password change upon the first login. Strong passwords are
only accepted: eight characters at least including one capital letter, one small letter
and one digit.

2N TELEKOMUNIKACE a.s., www.2n.cz 8/198
Remember the new password well or put it down just in case. Because if you forget
the password, you will have to reset the intercom to default values (refer to the
Installation Manual of your intercom model) and lose all your current configuration
changes.
Tip
FAQ: IP address - How to get IP address of 2N IP intercom

2N TELEKOMUNIKACE a.s., www.2n.cz 9/198
Firmware Update
We also recommend you to update your intercom firmware upon the first login to the
intercom. Refer to for the latest firmware version. Press the www.2n.cz Update
button in the menu to upload firmware. The intercom Firmware System Maintenance /
will get restarted upon upload and only then the updating process will be complete.
The process takes about 30 seconds.

2N TELEKOMUNIKACE a.s., www.2n.cz 10/198
SIP Server Connection Setting
Set the following parameters in the menu to allow your Services Phone SIP / /
intercom make calls and be accessible within your VoIP infrastructure.
Display name – set the name to be displayed as CLIP on the called party's
phone, in the login window and on the web interface start page.
Phone number (ID) – set the intercom phone number (or another unique ID
composed of characters and digits) to identify the intercom uniquely in calls and
registration.
Domain – set the domain name of the service with which the intercom is
registered. Typically, it is equivalent to the SIP Proxy or Registrar address. If you
do not use a SIP Proxy in your intercom installation, enter the intercom IP
address.
If you use a SIP server (Proxy, Registrar), set the addresses for the following network
elements:
Proxy address – set the SIP Proxy IP address or domain name.

2N TELEKOMUNIKACE a.s., www.2n.cz 11/198
Proxy address – set the SIP Proxy IP address or domain name.
Registrar address – set the SIP Registrar IP address or domain name. The SIP
Proxy and SIP Registrar addresses are usually identical.
Registration enabled – enable intercom registration with the set SIP Registrar.
If your SIP server requires authentication of terminal equipment, enter the following
parameters:
Password – enter the password for intercom authentication.

2N TELEKOMUNIKACE a.s., www.2n.cz 12/198
Quick Dial Button Settings
All the models are equipped with quick dial buttons. If you press a 2N IP intercom
quick dial button, a call will be set up to the phone number assigned to the respective
Users list position.
Select position 1, which corresponds to quick dial button 1, in the Directory Users/
menu.
Enable the position in the field and enter the called station phone Position Enabled
number into the parameter in the section.Phone Number User Phone Numbers
You can also use the with one or more IP phones without a SIP server. 2N IP intercom
Use the for outgoing calls and enter the called phone SIP address (sip:Direct SIP Call
phone_number@phone_ip_address) instead of the phone number.

2N TELEKOMUNIKACE a.s., www.2n.cz 13/198
Electric Lock Switching Settings
An electric lock can be attached to the and controlled by a code from 2N IP intercoms
the intercom numeric keypad, or a code from the IP phone keypad during a call.
Connect the electric lock as instructed in the Installation Manual of your intercom
model.
Enable the switch in the parameter in the Switch Enabled Hardware Switches / /
tab, set the to the intercom output to which the electric Switch 1 Controlled Output
door lock is connected. Now set one or more activation codes for the electric door
lock switching.

2N TELEKOMUNIKACE a.s., www.2n.cz 14/198
3. Model Differences and
Function Licensing
Here is what you can find in this section:
3.1 Model Differences
3.2 Function Licensing
– factory value
– licensed function to be purchased additionally
– unavailable

2N TELEKOMUNIKACE a.s., www.2n.cz 15/198
3.1 Model Differences
This manual is valid for all members of the family and so some features 2N IP intercom
described herein are only available in selected models or need to be 2N IP intercom
activated with a valid licence key. This section provides a short list of differences
between the models and licences which affect the configuration options. If a function
is not available in all the models, there is a note in the respective subsection and
reference to this section.
The table below includes an overview of properties and functions of all the 2N IP
models.intercom
Property
/Model
2N IP INTERCOMS
IP
Base
IP
Verso
IP
Solo
IP Vario IP
Force
IP
Safety
IP Uni IP
Audio
Kit
IP
Video
Kit
Part No. 9156... 9155… 91553...
C
9137…. 9151… 9152… 9153… 9154… 9154…C
Integrated
camera
yes optional yes optional no
Camera
resolution
1280 x 960 640 x 480 
External
analogue
camera
support
no yes
External IP
camera
support
yes no yes
Internal
RFID card
reader
optional no optional no

2N TELEKOMUNIKACE a.s., www.2n.cz 16/198
Property
/Model
2N IP INTERCOMS
Display no optional no optional no

2N TELEKOMUNIKACE a.s., www.2n.cz 17/198
Property/Model 2N IP INTERCOMS
Base Verso Solo Vario Force Safety Uni Audio
Kit
Video
Kit
Basic unit button
count
1 or 2 1 1 1, 3
or 6
1, 2 or
4
1 1 or
2
up to 16
external
programmable
buttons
Button extenders no up to
145
no up to
48
no
Numeric keypad no optional no optional no
Digital input yes optional no 2
Wideband audio
codecs (L16, G.722)
yes no yes
Amplifier power
output
2 W 150
mW
1 W 10 W
Adjustable
microphone gain
no yes
Extended amplifier
power output (10 W)
no yes no no
Tamper switch yes optional yes no optional yes no
Users position count 1999 2 16
User deputy yes no yes
Controlled switch
count
2 4 1 4
Switch universal code
count
2 10 2 10
User profile count 20

2N TELEKOMUNIKACE a.s., www.2n.cz 18/198
Property/Model 2N IP INTERCOMS
JPEG HTTP video yes no yes
2N® supportIP Eye
yes no yes
Telephone mode no yes no yes no yes

2N TELEKOMUNIKACE a.s., www.2n.cz 19/198
3.2 Function Licensing
Why are some features licensed?
Because we did not want every single customer who purchases our intercom, to pay
for all the advanced features we offer. We believe that most applications can do with
basic level, so the users do not need to pay for features they do not use.
Which features are licensed and what licence types are there?
Some intercom functions are unavailable until a valid licence key is entered 2N IP
(refer to the Licence subsection). The following types of licences are available:
Enhanced Audio (Part No. 9137905)
Enhanced Video (Part No. 9137906)
Enhanced Integration (Part No. 9137907)
Enhanced Security (Part No. 9137908)
Gold (Part No. 9137909)
G.729 (Part No. 9137902)
InformaCast (Part No. 9137910)
NFC (Part No. 9137915)
The G.729 licence allows the audio codec G.729 to be used.
The InformaCast licence allows the SingleWire InformaCast protocol to be used.
2N IP Verso, Solo, Vario, Force, Safety
®and do support this licensing Video Kit
scheme in full. User only needs to observe which licences really make sense for him –
for example, Enhanced Video licence for intercom without camera does not help
much. with display already comes with preloaded Gold licence, so the 2N IP Vario
®
only possible upgrades are G.729 and InformaCast. does support all 2N IP Audio Kit
®
licences except for G.729.
The NFC licence enables authentication via NFC-equipped mobile phones for selected
13 MHz RFID card reader models.
No licensed features are available for the or model.2N IP Uni
® 2N IP Base ®
The table below includes the functions that need to be activated by the licence keys
corresponding to the above mentioned licences. The licences can be combined
arbitrarily.

2N TELEKOMUNIKACE a.s., www.2n.cz 20/198
Property
/Licence
Enhanced
Audio
Enhanced
Video
Enhanced
Integration
Enhanced
Security
NFC G.
729
InformaCast Gold
(Profi)
User sounds •       •
Automatic
audio test
•       •
Noise
detection
•       •
Audio/video
streaming
(RTSP
Server)
 •      •
External IP
camera
support
 •      •
ONVIF
support
 •      •
PTZ
function
support
 •      •
Motion
detection
support
 •      •
Extended
switch
setting
options


•




•
