2N IP Uni User manual



Installation manual 2N® IP
Uni

v.2.16
www.2n.com





Installation manual 2N® IP Uni
2 / 58
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
Content:
1. Product Overview
1.1 Components and Associated Products
1.2 Terms and Symbols
2. Description and Installation
2.1 Before You Start
2.2 Mechanical Installation
2.3 Electric Installation
2.3.1 Overvoltage Protection
2.4 Button Tags
2.5 Extending Module Connection
3. Function and Use
3.1 Configuration
3.2 Control
3.3 Maintenance
3.4 Downloads
4. Technical Parameters
4.1 General drawings
5. Supplementary Information
5.1 Troubleshooting
5.2 Directives, Laws and Regulations
5.3 General Instructions and Cautions

Installation manual 2N® IP Uni
3 / 58
•
•
•
•
•
•
•
•
•
•
•
•
1. Product Overview
Here is what you can find in this section:
1.1 Components and Associated Products
1.2 Terms and Symbols
Basic Features
2N®IP Uniis a highly resistant and reliable IP door access intercom provided with a lot of useful
above-standard functions. Supporting the SIP standard and being compatible with the leading
IP PBX and telephone suppliers,2N®IP Unican make use of all VoIP services.2N®IP Unican
work as a standard or emergency door access intercom for buildings, entrances to premises or
garages, manufacturing halls, highways and so on.
2N®IP Uniis equipped with a loudspeaker (1 W). Thanks to an integrated acoustic echo
cancelling (AEC) system, the product provides mutual audibility even of persons talking at the
same time under normal conditions.
2N®IP Unican be provided with 1 or 2 pre-programmed buttons. You can set up to three
telephone numbers and time profiles for each of the buttons to increase the accessibility of the
called party.
2N®IP Uniis equipped with an electric lock switch. You can control the switch during a call,
using any telephone set.
2N®IP Uniis very easy to install. All you have to do is connect the system into your LAN via a
network cable and feed it from a 12 V power supply or your PoE supporting LAN.
Configure2N®IP Uniusing your PC via any web browser. Use the2N®Access Commanderto
manage extensive2N®IP Unisystems easily and quickly.
Advantages of Use
Variable mounting options (brick/plasterboard flush mounting, wall mounting)
Sensitive microphone and powerful loudspeaker
Bidirectional communication – acoustic echo cancelling
Optional dial buttons including name tags and backlight
Integrated electronic lock switches with wide setting options
LAN (PoE) or external 12 V power supply
Configuration via web interface or dedicated PC application
SIP 2.0 support
HTTP server for configuration
SNTP client for time synchronisation with server

Installation manual 2N® IP Uni
4 / 58
•
•
•
•
•
•
1.1 Components and Associated Products
Basic Units
2N Part No.9153101
Axis Part No. 01361-001
1 button
control of one electric lock
protective switch
2N Part No.9153102
Axis Part No. 01362-001
2 buttons
control of one electric lock
protective switch

Installation manual 2N® IP Uni
5 / 58
•
•
•
2N Part. No. 9153101P
Axis Part No. 01363-001
1 button, pictograms
control of one electric lock
protective switch
All2N®IP Uniunits can be flush mounted without requiring any additional accessories. Use the
appropriate mounting box (see below) for wall (surface) mounting.2N®IP Uni is designed for
outdoor applications and requires no additional roof.

Installation manual 2N® IP Uni
6 / 58
•
•
•
•
Mounting Accessories
2N Part No.9153003
Axis Part No. 01364-001
Wall mounting box
(Al casting)
Brick flush mounting box
(included in the delivery)

Installation manual 2N® IP Uni
7 / 58
•
•
•
•
2N Internal Units and Accessories
Part Numbers:
2N Part No.91378375
Axis Part No. 01668-001
2N Part No.91378376
Axis Part No. 01670-001
2N®Indoor Touch 2.0 - black
WiFi version (second part no.)
The elegant internal touch panel, 2N®Indoor Touch
2.0, is suitable for all 2N IP intercoms. On the panel’s
display not only can you find out who is at the door,
but also start a conversation with the visitor, open the
lock or turn on the light in the entrance hall.
2N Part No. 91378382
Axis Part No. 01425-001

2N®Indoor Touch desk stand black

Installation manual 2N® IP Uni
8 / 58
•
•
•
Part Numbers:
2N Part No.91378375WH
Axis Part No. 01669-001
2N Part No.91378376WH
Axis Part No. 01671-001
2N®Indoor Touch 2.0 - white
WiFi version (second part no.)
The elegant internal touch panel, 2N® Indoor Touch
2.0, is suitable for all 2N IP intercoms. On the panel’s
display not only can you find out who is at the door,
but also start a conversation with the visitor, open the
lock or turn on the light in the entrance hall.

Installation manual 2N® IP Uni
9 / 58
•
•
•
•
2N Part No. 91378382W
Axis Part No. 01426-001
2N®Indoor Touch desk stand white
2N Part No.
1120101W
Axis Part No.
02518-001
2N®IP Handset
answering unit
white color

Installation manual 2N® IP Uni
10 / 58
•
•
•
•
•
•
•
•
•
•
•
•
•
•
2N Part No.
1120101B
Axis Part No.
02519-001

2N®IP Handset
answering unit
black color
IP Phones
2N Part No. 91378360
Axis Part No. 01586-001
Yealink SIP T58A IP video phone
simple operation
HD quality video calls
A display-equipped extender EXP50 (Part No.91378363) can
be added to the phone delivery to make up to 60 speed
dialings.
2N Part No. 1120111EU
Axis Part No.02544-001
Grandstream GXV3350 IP video phone
Android 7.0 OS
5” touch display control
HD quality video calls
WiFi and Bluetooth support
HDMI output and pan tilt zoom camera
Easy integration with intercoms or PBXs via SIP

Installation manual 2N® IP Uni
11 / 58
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
2N Part
No.91378362EU
Grandstream GXV3370 IP video phone
Android 7.0 OS
7” touch display control
HD quality video calls
WiFi and Bluetooth support
Easy integration with IP intercoms, PBXs and security cameras.
Electric Locks
Part No. 11202101 Mini electronic doorstrike series 5
electric opener designed for door frame installation
intended for such narrow profiles as aluminum,
wood or PVC in particular
short sheet metal front cover version (130 mm)
16 mm width
Part No. 11202101-L Mini electronic doorstrike series 5 – long
electric opener designed for door frame installation
intended for such narrow profiles as aluminum,
wood or PVC in particular
long sheet metal front cover version (250 mm)
16 mm width

Installation manual 2N® IP Uni
12 / 58
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
Part No. 11202102 Mini electronic doorstrike series 5 – with
momentum pin
electric opener designed for door frame installation
intended for such narrow profiles as aluminum,
wood or PVC in particular
short sheet metal front cover version (130 mm)
16 mm width
Part No. 11202102-L Mini electronic doorstrike series 5 – with
momentum pin, long
electric opener designed for door frame installation
intended for such narrow profiles as aluminum,
wood or PVC in particular
long sheet metal front cover version (250 mm)
16 mm width
Part No. 11202103 Mini electronic doorstrike series 5 – with
mechanical blocking
electric opener designed for door frame installation
intended for such narrow profiles as aluminum,
wood or PVC in particular
short sheet metal front cover version (130 mm)
16 mm width

Installation manual 2N® IP Uni
13 / 58
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
Part No. 11202103-L Mini electronic doorstrike series 5 – with
mechanical blocking, long
electric opener designed for door frame installation
intended for such narrow profiles as aluminum,
wood or PVC in particular
long sheet metal front cover version (250 mm)
16 mm width
Part No. 11202104 Mini electronic doorstrike series 5 – door signaling
electric opener designed for door frame installation
intended for such narrow profiles as aluminum,
wood or PVC in particular
including a door state monitoring micro switch:
open/closed
short sheet metal front cover version (130 mm)
16 mm width
Part No. 11202104-L Mini electronic doorstrike series 5 – door
signaling, long
electric opener designed for door frame installation
intended for such narrow profiles as aluminum,
wood or PVC in particular
including a door state monitoring micro switch:
open/closed
long sheet metal front cover version (250 mm)
16 mm width

Installation manual 2N® IP Uni
14 / 58
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
Part No. 11202105 Mini electronic doorstrike series 5 – fail-safe
electric opener designed for door frame installation
intended for such narrow profiles as aluminum,
wood or PVC in particular
under voltage: opener secured, blocked
at voltage interruption: opener unblocked, door can
be opened
short sheet metal front cover version (130 mm)
16 mm width
Part No. 11202105-L Mini electronic doorstrike series 5 – fail-safe, long
electric opener designed for door frame installation
intended for such narrow profiles as aluminum,
wood or PVC in particular
under voltage: opener secured, blocked
at voltage interruption: opener unblocked, door can
be opened
long sheet metal front cover version (250 mm)
16 mm width
Part No. 11202106 Mini electronic doorstrike series 5 – fail-safe and
door signaling
electric opener designed for door frame installation
intended for such narrow profiles as aluminum,
wood or PVC in particular
under voltage: opener secured, blocked
at voltage interruption: opener unblocked, door can
be opened
short sheet metal front cover version (130 mm)
16 mm width

Installation manual 2N® IP Uni
15 / 58
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
Part No. 11202106-L Mini electronic doorstrike series 5 – fail-safe and
door signaling, long
electric opener designed for door frame installation
intended for such narrow profiles as aluminum,
wood or PVC in particular
under voltage: opener secured, blocked
at voltage interruption: opener unblocked, door can
be opened
long sheet metal front cover version (250 mm)
16 mm width
Part No. 11202201 Electromechanical lock SAM 7255
72/55 self-locking lock with panic function
A key is necessary for door opening from the outside
(or an electric pulse from a connected 2N IP
intercom / reader).
convenient solution for emergency exits
Part No. 11202201-M Electromechanical lock SAM 7255 with monitoring
72/55 self-locking lock with panic function
A key is necessary for door opening from the outside
(or an electric pulse from a connected 2N IP
intercom / reader).
convenient solution for emergency exits

Installation manual 2N® IP Uni
16 / 58
•
•
•
•
•
•
•
•
•
•
•
Part No. 11202202 Electromechanical lock SAM 9235
92/35 self-locking lock with panic function
A key is necessary for door opening from the outside
(or an electric pulse from a connected 2N IP
intercom / reader).
convenient solution for emergency exits
Part No. 11202202-M Electromechanical lock SAM 9235 with
monitoring
92/35 self-locking lock with panic function
A key is necessary for door opening from the outside
(or an electric pulse from a connected 2N IP
intercom / reader).
convenient solution for emergency exits
Part No. 11202301 Cable protector FX290
Provides secure passage and protection of the
supply cable between the door frame and the door
leaf.
290 mm length

Installation manual 2N® IP Uni
17 / 58
•
•
•
•
•
•
•
•
•
Part No. 11202302 Cable protector FX510
Provides secure passage and protection of the
supply cable between the door frame and the door
leaf.
510 mm length
Part No. 11202303 Cable protector FX300G
Provides secure passage and protection of the
supply cable between the door frame and the door
leaf.
440 mm length
Part No. 11202304 Cable protector FX500G
Provides secure passage and protection of the
supply cable between the door frame and the door
leaf.
640 mm length

Installation manual 2N® IP Uni
18 / 58
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
Part No. 11202107 Maglock MEX100
used as a door holding supplement, not replacing
the lock
consists of two parts: supplied part and counterpart
under voltage: door cannot be opened
at voltage interruption: magnets get disconnected,
door opens
Part No. 11202501 Magnetic handle P300RP
fully replaces a mortise lock and handle
under voltage: door cannot be opened
at voltage interruption: magnets get disconnected,
door opens
suitable for wooden, metal and glass doors
Part No. 11202401 ED100
low energy simple door operator
contactless operation
can be interconnected with a motion sensor and
electronic access control system
applicable for right / left doors
in / out opening versions

Installation manual 2N® IP Uni
19 / 58
•
•
•
•
Power Supply
Part Numbers:
2N Part No. 91378100E
2N Part No. 91378100US
Axis Part No.01403-001

PoE injetor – with EU cable
PoE injector – with US cable
For power supply of intercom viaethernetcable
when PoE switch is not available.
Part No.91341481E
Stabilised 12 V / 2 A power supply needs to be used
when no PoE is available.
•
Tip
FAQ: Electric locks – Difference between locks in 2N IP intercoms accesories


Installation manual 2N® IP Uni
20 / 58
•
•
•
•
•
•
•
•
Part No.932928
12 V transformer
For 230 V mains voltage.
For external power supply of the lock with 12 V AC
voltage.
Additional Modules
2N Part No.9159010
Axis Part No. 01386-001
2N®Security Relay
A handy add-on that significantly enhances door entry
security as it prevents tampering with the intercom
and forced opening of the lock. To be installed
between intercom and lock, powered by the intercom.
Part No. 9159013
Exit button
(suitable for Security relay)
A button for connection to a logic input for opening a
door inside a building.
