Section 1 Introduction
1.1 This manual
The point list manual describes the outlook and properties of the data points
specific to the IED. The manual should be used in conjunction with the
corresponding communication protocol manual.
1.2 Intended audience
This manual addresses the communication system engineer or system integrator
responsible for pre-engineering and engineering for communication setup in a
substation from an IED perspective.
The system engineer or system integrator must have a basic knowledge of
communication in protection and control systems and thorough knowledge of the
specific communication protocol.
1MRS756712 C Section 1
Introduction
REF615 3
Point List Manual

1.3 Product documentation
1.3.1 Product documentation set
Planning & purchase
Engineering
Installing
Commissioning
Operation
Maintenance
Decommissioning deinstalling & disposal
Application manual
Operation manual
Installation manual
Service manual
Engineering manual
Commissioning manual
Communication protocol
manual
Technical manual
Planning & purchase
Engineering
Installing
Commissioning
Operation
Maintenance
Decommissioning deinstalling & disposal
Planning & purchase
Engineering
Installing
Commissioning
Operation
Maintenance
Decommissioning deinstalling & disposal
Application manualApplication manual
Operation manualOperation manual
Installation manualInstallation manual
Service manualService manual
Engineering manualEngineering manual
Commissioning manualCommissioning manual
Communication protocol
manual
Communication protocol
manual
Technical manualTechnical manual
en07000220.vsd
IEC07000220 V1 EN
Figure 1: The intended use of manuals in different lifecycles
The engineering manual contains instructions on how to engineer the IEDs using
the different tools in PCM600. The manual provides instructions on how to set up a
PCM600 project and insert IEDs to the project structure. The manual also
recommends a sequence for engineering of protection and control functions, LHMI
functions as well as communication engineering for IEC 61850 and other
supported protocols.
The installation manual contains instructions on how to install the IED. The
manual provides procedures for mechanical and electrical installation. The chapters
are organized in chronological order in which the IED should be installed.
The commissioning manual contains instructions on how to commission the IED.
The manual can also be used by system engineers and maintenance personnel for
assistance during the testing phase. The manual provides procedures for checking
of external circuitry and energizing the IED, parameter setting and configuration as
Section 1 1MRS756712 C
Introduction
4REF615
Point List Manual

well as verifying settings by secondary injection. The manual describes the process
of testing an IED in a substation which is not in service. The chapters are organized
in chronological order in which the IED should be commissioned.
The operation manual contains instructions on how to operate the IED once it has
been commissioned. The manual provides instructions for monitoring, controlling
and setting the IED. The manual also describes how to identify disturbances and
how to view calculated and measured power grid data to determine the cause of a
fault.
The service manual contains instructions on how to service and maintain the IED.
The manual also provides procedures for de-energizing, de-commissioning and
disposal of the IED.
The application manual contains application descriptions and setting guidelines
sorted per function. The manual can be used to find out when and for what purpose
a typical protection function can be used. The manual can also be used when
calculating settings.
The technical manual contains application and functionality descriptions and lists
function blocks, logic diagrams, input and output signals, setting parameters and
technical data sorted per function. The manual can be used as a technical reference
during the engineering phase, installation and commissioning phase, and during
normal service.
The communication protocol manual describes a communication protocol
supported by the IED. The manual concentrates on vendor-specific implementations.
The point list manual describes the outlook and properties of the data points
specific to the IED. The manual should be used in conjunction with the
corresponding communication protocol manual.
Some of the manuals are not available yet.
1.3.2 Document revision history
Document revision/date Product version History
A/2009-03-04 2.0 First release
B/2009-07-03 2.0 Content updated
C/2010-06-11 3.0 Content updated to correspond to the
product version
Download the latest documents from the ABB web site http://
www.abb.com/substationautomation.
1MRS756712 C Section 1
Introduction
REF615 5
Point List Manual

1.3.3 Related documentation
Name of the document Document ID
IEC 60870-5-103 Communication Protocol Manual 1MRS756710
1.4 Symbols and conventions
1.4.1 Safety indication symbols
The caution icon indicates important information or warning related
to the concept discussed in the text. It might indicate the presence
of a hazard which could result in corruption of software or damage
to equipment or property.
The information icon alerts the reader to important facts and
conditions.
The tip icon indicates advice on, for example, how to design your
project or how to use a certain function.
Although warning hazards are related to personal injury, it should be understood
that operation of damaged equipment could, under certain operational conditions,
result in degraded process performance leading to personal injury or death.
Therefore, comply fully with all warning and caution notices.
1.4.2 Manual conventions
Conventions used in IED manuals. A particular convention may not be used in this
manual.
• Abbreviations and acronyms in this manual are spelled out in the glossary. The
glossary also contains definitions of important terms.
• Push button navigation in the LHMI menu structure is presented by using the
push button icons, for example:
To navigate between the options, use and .
• HMI menu paths are presented in bold, for example:
Select Main menu/Settings.
• LHMI messages are shown in Courier font, for example:
To save the changes in non-volatile memory, select Yes and press .
• Parameter names are shown in italics, for example:
The function can be enabled and disabled with the Operation setting.
• Parameter values are indicated with quotation marks, for example:
Section 1 1MRS756712 C
Introduction
6REF615
Point List Manual

The corresponding parameter values are "On" and "Off".
• IED input/output messages and monitored data names are shown in Courier
font, for example:
When the function starts, the START output is set to TRUE.
1.4.3 Functions, codes and symbols
Table 1: REF615 Functions, codes and symbols
Function IEC 61850 IEC 60617 IEC-ANSI
Protection
Three-phase non-directional
overcurrent protection, low stage,
instance 1
PHLPTOC1 3I> (1) 51P-1 (1)
Three-phase non-directional
overcurrent protection, high stage,
instance 1
PHHPTOC1 3I>> (1) 51P-2 (1)
Three-phase non-directional
overcurrent protection, high stage,
instance 2
PHHPTOC2 3I>> (2) 51P-2 (2)
Three-phase non-directional
overcurrent protection, instantaneous
stage, instance 1
PHIPTOC1 3I>>> (1) 50P/51P (1)
Three-phase directional overcurrent
protection, low stage, instance 1 DPHLPDOC1 3I> -> (1) 67-1 (1)
Three-phase directional overcurrent
protection, low stage, instance 2 DPHLPDOC2 3I> -> (2) 67-1 (2)
Three-phase directional overcurrent
protection, high stage DPHHPDOC1 3I>> -> 67-2
Non-directional earth-fault protection,
low stage, instance 1 EFLPTOC1 Io> (1) 51N-1 (1)
Non-directional earth-fault protection,
low stage, instance 2 EFLPTOC2 Io> (2) 51N-1 (2)
Non-directional earth-fault protection,
high stage, instance 1 EFHPTOC1 Io>> (1) 51N-2 (1)
Non-directional earth-fault protection,
instantaneous stage EFIPTOC1 Io>>> 50N/51N
Directional earth-fault protection, low
stage, instance 1 DEFLPDEF1 Io> -> (1) 67N-1 (1)
Directional earth-fault protection, low
stage, instance 2 DEFLPDEF2 Io> -> (2) 67N-1 (2)
Directional earth-fault protection, high
stage DEFHPDEF1 Io>> -> 67N-2
Admittance based earth-fault
protection, instance 1 EFPADM1 Yo> -> (1) 21YN (1)
Admittance based earth-fault
protection, instance 2 EFPADM2 Yo> -> (2) 21YN (2)
Admittance based earth-fault
protection, instance 3 EFPADM3 Yo> -> (3) 21YN (3)
Table continues on next page
1MRS756712 C Section 1
Introduction
REF615 7
Point List Manual

Function IEC 61850 IEC 60617 IEC-ANSI
Transient / intermittent earth-fault
protection INTRPTEF1 Io> -> IEF 67NIEF
Non-directional (cross-country) earth
fault protection, using calculated Io EFHPTOC1 Io>> (1) 51N-2 (1)
Negative-sequence overcurrent
protection, instance 1 NSPTOC1 I2> (1) 46 (1)
Negative-sequence overcurrent
protection, instance 2 NSPTOC2 I2> (2) 46 (2)
Phase discontinuity protection PDNSPTOC1 I2/I1> 46PD
Residual overvoltage protection,
instance 1 ROVPTOV1 Uo> (1) 59G (1)
Residual overvoltage protection,
instance 2 ROVPTOV2 Uo> (2) 59G (2)
Residual overvoltage protection,
instance 3 ROVPTOV3 Uo> (3) 59G (3)
Three-phase undervoltage protection,
instance 1 PHPTUV1 3U< (1) 27 (1)
Three-phase undervoltage protection,
instance 2 PHPTUV2 3U< (2) 27 (2)
Three-phase undervoltage protection,
instance 3 PHPTUV3 3U< (3) 27 (3)
Three-phase overvoltage protection,
instance 1 PHPTOV1 3U> (1) 59 (1)
Three-phase overvoltage protection,
instance 2 PHPTOV2 3U> (2) 59 (2)
Three-phase overvoltage protection,
instance 3 PHPTOV3 3U> (3) 59 (3)
Positive-sequence undervoltage
protection, instance 1 PSPTUV1 U1< (1) 47U+ (1)
Negative-sequence overvoltage
protection, instance 1 NSPTOV1 U2> (1) 47O- (1)
Frequency protection, instance 1 FRPFRQ1 f>/f<,df/dt (1) 81 (1)
Frequency protection, instance 2 FRPFRQ2 f>/f<,df/dt (2) 81 (2)
Frequency protection, instance 3 FRPFRQ3 f>/f<,df/dt (3) 81 (3)
Three-phase thermal protection for
feeders, cables and distribution
transformers
T1PTTR1 3Ith>F 49F
Circuit breaker failure protection CCBRBRF1 3I>/Io>BF 51BF/51NBF
Three-phase inrush detector INRPHAR1 3I2f> 68
Master trip, instance 1 TRPPTRC1 Master Trip (1) 94/86 (1)
Master trip, instance 2 TRPPTRC2 Master Trip (2) 94/86 (2)
Arc protection, instance 1 ARCSARC1 ARC (1) 50L/50NL (1)
Arc protection, instance 2 ARCSARC2 ARC (2) 50L/50NL (2)
Arc protection, instance 3 ARCSARC3 ARC (3) 50L/50NL (3)
Control
Circuit-breaker control CBXCBR1 I <-> O CB I <-> O CB
Table continues on next page
Section 1 1MRS756712 C
Introduction
8REF615
Point List Manual

Function IEC 61850 IEC 60617 IEC-ANSI
Disconnector position indication,
instance 1 DCSXSWI1 I <-> O DC (1) I <-> O DC (1)
Disconnector position indication,
instance 2 DCSXSWI2 I <-> O DC (2) I <-> O DC (2)
Disconnector position indication,
instance 3 DCSXSWI3 I <-> O DC (3) I <-> O DC (3)
Earthing switch indication ESSXSWI1 I <-> O ES I <-> O ES
Auto-reclosing DARREC1 O -> I 79
Synchronism and energizing check SECRSYN1 SYNC 25
Condition monitoring
Circuit-breaker condition monitoring SSCBR1 CBCM CBCM
Trip circuit supervision, instance 1 TCSSCBR1 TCS (1) TCM (1)
Trip circuit supervision, instance 2 TCSSCBR2 TCS (2) TCM (2)
Current circuit supervision CCRDIF1 MCS 3I MCS 3I
Fuse failure supervision SEQRFUF1 FUSEF 60
Measurement
Disturbance recorder RDRE1 - -
Three-phase current measurement,
instance 1 CMMXU1 3I 3I
Sequence current measurement CSMSQI1 I1, I2, I0 I1, I2, I0
Residual current measurement,
instance 1 RESCMMXU1 Io In
Three-phase voltage measurement VMMXU1 3U 3U
Residual voltage measurement RESVMMXU1 Uo Vn
Sequence voltage measurement VSMSQI1 U1, U2, U0 U1, U2, U0
Three-phase power and energy
measurement, including power factor PEMMXU1 P, E P, E
Frequency measurement FMMXU1 f f
1MRS756712 C Section 1
Introduction
REF615 9
Point List Manual

10

Section 2 IEC 60870-5-103 data mappings
2.1 Overview
These tables show the default point definitions. The user is able to freely remap all
these data. In that case PCM600 can provide an updated point list export of the new
outlook.
Indications and controls table columns
IEC 61850 name Internal signal that is mapped to the IEC 60870-5-103 point.
Expressed in the form 'Logical Device.Logical Node.Data
Object.Data Attribute'.
AFL-Common SA name AFL name of the corresponding data signal.
Description Signal description.
DPI value Value description. DPI value 10 means ON and value 01
means OFF.
FUN Default Function Type definition for the point. Observe that
Function Type 0 means that FUN in practice contains the
given Device Function Type. The user-definable Function
Type definition is set to the same FUN value as default.
INF Default Information Number definition for the point. The user-
definable Information Number definition is set to the same
INF value as default.
InUse 1 means that the point is taken in use as default, and 0 that
the point is not in use as default.
ASDU ASDU point type. 1 and 2 are indications in monitoring
direction. 20 means that the point is controllable.
GI Default setting for General Interrogation. 1 means ON, 0
means OFF.
Coding IEC 60870-5-103 DPI value coding. 1 means that the point
shows OFF (01) and ON (10) values only. 2 means that the
point shows values Intermediate (00), OFF (01), ON (10)
and Error (11).
Class 2 data table columns
Index Value position within the Class2 frame.
IEC 61850 name Internal signal that is mapped to the IEC 60870-5-103 point.
Description Signal description.
Default scale Value that corresponds to the maximum IEC 60870-5-103
measurand value 1.
Table continues on next page
1MRS756712 C Section 2
IEC 60870-5-103 data mappings
REF615 11
Point List Manual

Frame No6 Shows if the value is present in Class2 frame 6.
Frame No7 Shows if the value is present in Class2 frame 7.
Comment Additional information.
Section 2 1MRS756712 C
IEC 60870-5-103 data mappings
12 REF615
Point List Manual

2.2 Point list for REF615 Ver. 3.0 FE01-08
1MRS756712 C Section 2
IEC 60870-5-103 data mappings
REF615 13
Point List Manual

Table 2: Indications and controls
IEC 61850 name AFL-Common SA name Description DPI value FUN INF In Use ASDU GI Coding
Device function type - standard, all variants
LD0.DARREC1.AROn.stVal - Autorecloser state 10=AR On, 01=AR Off 0 16 1 1 1 1 LD0.LLN0.LEDRs1.ctlVal - LED reset 10=Reset indications and alarm LEDs 0 19 1 20 0 1 LD0.LLN0.Beh.stVal (Test mode) - Test mode 10=Test mode ON, 01=Test mode
OFF
0 21 1 1 1 1
LD0.I3CGGIO1.ActSG.ctlVal - Parameter setting group 1 10=Setting group 1 in use 0 23 1 1,20 1 1 LD0.I3CGGIO1.ActSG.ctlVal - Parameter setting group 2 10=Setting group 2 in use 0 24 1 1,20 1 1 LD0.I3CGGIO1.ActSG.ctlVal - Parameter setting group 3 10=Setting group 3 in use 0 25 1 1,20 1 1 LD0.I3CGGIO1.ActSG.ctlVal - Parameter setting group 4 10=Setting group 4 in use 0 26 1 1,20 1 1 LD0.I3CGGIO1.ActSG.ctlVal - Parameter setting group 5 10=Setting group 5 in use 0 27 1 1,20 1 1 LD0.I3CGGIO1.ActSG.ctlVal - Parameter setting group 6 10=Setting group 6 in use 0 28 1 1,20 1 1 LD0.TCSSCBR1.CirAlm.stVal TCSSCBR1.ALARM Trip circuit 1 alarm 10=TCS1 alarm 0 36 1 1 1 1 LD0.LEDPTRC1.Op.general - Global operate 10=Operate (LEDPTRC) 0 68 1 2 0 1 LD0.LEDPTRC1.Str.general - Global start 10=Start (LEDPTRC) 0 84 1 2 1 1 LD0.DARREC1.SucRec.stVal DARREC1.SUC_RECL Successful reclose status 10=Successful reclose 0 128 1 1 0 1 LD0.DARREC1.InInhRec.stVal - Inhibit reclose (status) 10=Reclose inhibit 0 130 1 1 1 1
Device function type - private, all variants
LD0.TRPPTRC1.Op.general - TRPTRC1 input signal 10=Input signal ON 10 1 1 2 0 1 LD0.TRPPTRC1.Tr.general - TRPTRC1 trip output signal 10=Trip output signal ON 10 2 1 2 0 1 LD0.TRPPTRC2.Op.general - TRPTRC2 input signal 10=Input signal ON 10 3 1 2 0 1 LD0.TRPPTRC2.Tr.general - TRPTRC2 trip output signal 10=Trip output signal ON 10 4 1 2 0 1 CTRL.LLN0.Loc.stVal - Local/Remote state 10=Local, 01=Remote 10 10 1 1 1 1 CTRL.LLN0.LocRem.Station - Station state 10=Station ON, 01=OFF 10 11 1 1 1 1 LD0.LLN0.RecRs.ctlVal - Reset all data 10=Reset all data 10 19 1 20 0 1 LD0.LLN0.LEDRs2.ctlVal - Reset alarm LEDs 10=Reset alarm LEDs only 10 21 1 20 0 1 LD0.TCSSCBR2.CirAlm.stVal TCSSCBR2.ALARM Trip circuit 2 alarm 10=TCS2 alarm 10 36 1 1 1 1 DR.RDRE1.RcdTrg.ctlVal - Trig DR recording 10=External DR trig 10 41 1 20 0 1 DR.RDRE1.MemClr.ctlVal - Clear DR memory 10=Clear memory 10 42 1 20 0 1 LD0.CMSTA1.RecRs.ctlVal - Reset CMMXU1 max.demands 10=Reset max values 10 45 1 20 0 1
Multipurpose inputs (all variants)
LD0.MVGAPC1.Q1.stVal - MVGAPC1 input 1 signal 10=Input ON, 01=OFF 11 1 0 1 1 1 LD0.MVGAPC1.Q2.stVal - MVGAPC1 input 2 signal 10=Input ON, 01=OFF 11 2 0 1 1 1 LD0.MVGAPC1.Q3.stVal - MVGAPC1 input 3 signal 10=Input ON, 01=OFF 11 3 0 1 1 1 LD0.MVGAPC1.Q4.stVal - MVGAPC1 input 4 signal 10=Input ON, 01=OFF 11 4 0 1 1 1 LD0.MVGAPC1.Q5.stVal - MVGAPC1 input 5 signal 10=Input ON, 01=OFF 11 5 0 1 1 1 LD0.MVGAPC1.Q6.stVal - MVGAPC1 input 6 signal 10=Input ON, 01=OFF 11 6 0 1 1 1 LD0.MVGAPC1.Q7.stVal - MVGAPC1 input 7 signal 10=Input ON, 01=OFF 11 7 0 1 1 1 LD0.MVGAPC1.Q8.stVal - MVGAPC1 input 8 signal 10=Input ON, 01=OFF 11 8 0 1 1 1
Table continues on next page
Section 2 1MRS756712 C
IEC 60870-5-103 data mappings
14 REF615
Point List Manual
